2. Getting Started with Dockerfiles

Overview

In this chapter, you will study the form and function of a Dockerfile and its directives, including FROM, LABEL, and CMD, with which you will dockerize an application. The chapter will provide you with knowledge of the layered filesystem of Docker images and the use of caching during the Docker build process. By the end of this chapter, you will be able to write a Dockerfile using the common directives and build custom Docker images with the Dockerfile.



Introduction

In the previous chapter, we learned how to run our first Docker container by pulling a pre-built Docker image from the Docker Hub. While it is useful to get pre-built Docker images from Docker Hub, we must know how to create custom Docker images. This is important for running our applications on Docker by installing new packages and customizing the settings of the pre-built Docker images. In this chapter, we are going to learn how to create our custom Docker image and run a Docker container based on it.

This will be done using a text file called a Dockerfile. This file consists of commands that can be executed by Docker to create a Docker image. Docker images are created from a Dockerfile using the docker build (or docker image build) command.

Note

Beginning with Docker 1.13, the Docker CLI syntax has been restructured to the form of Docker COMMAND SUBCOMMAND. For example, the docker build command was replaced by the docker image build command. This restructuring was carried out to clean up the Docker CLI syntax and gain a more consistent grouping of commands. Currently, both syntaxes are supported, but the old syntax is expected to be deprecated in the future.

A Docker image consists of multiple layers, each layer representing the commands provided in the Dockerfile. These read-only layers are stacked on top of one another to create the final Docker image. Docker images can be stored in a Docker registry, such as Docker Hub, which is a place where you can store and distribute Docker images.

A Docker container is a running instance of the Docker image. One or more Docker containers can be created from a single Docker image using the docker run (or docker container run) command. Once a Docker container is created from the Docker image, a new writeable layer will be added on top of the read-only layers from the Docker image. Docker containers can then be listed with the docker ps (or docker container list) command:

Figure 2.1: Image layers and a container layer

Figure 2.1: Image layers and a container layer

As illustrated in the preceding diagram, there can be one or more read-only layers that make up the Docker image. These read-only layers are generated for each command in the Dockerfile during the Docker image build process. Once a Docker container is created from the image, a new read-write layer (known as the Container layer) will be added on top of the image layers and will host all the changes made on the running container.

In this chapter, we will write our first Dockerfile, build the Docker image from the Dockerfile, and run a Docker container from our custom Docker image. Before we can perform any of these tasks, however, we must first define a Dockerfile.



What Is a Dockerfile?

A Dockerfile is a text file that contains instructions on how to create a Docker image. These commands are known as directives. A Dockerfile is a mechanism that we use to create a custom Docker image as per our requirements.

The format of a Dockerfile is as follows:

# This is a comment
DIRECTIVE argument

A Dockerfile can contain multiple lines of comments and directives. These lines will be executed in order by the Docker Engine while building the Docker image. Like programming languages, a Dockerfile can also contain comments.

All statements starting with the # symbol will be treated as a comment. Currently, Dockerfiles only support single-line comments. If you wish you write a multi-line comment, you need to add the # symbol at the beginning of each line.

However, unlike most programming languages, instructions within the Dockerfile are not case-sensitive. Even though the DIRECTIVE is case-insensitive, it is a best practice to write all directives in uppercase to distinguish them from arguments.

In the next section, we will discuss the common directives that we can use in Dockerfiles to create a custom Docker image.

Note

If you are using ubuntu versions later than 18.04, there will be a prompt to enter time zone. Please suppress the prompt with ARG DEBIAN_FRONTEND=non_interactive



Common Directives in Dockerfiles

As discussed in the previous section, a directive is a command that is used to create a Docker image. In this section, we will be discussing the following five Dockerfile directives:

  1. The FROM directive
  2. The LABEL directive
  3. The RUN directive
  4. The CMD directive
  5. The ENTRYPOINT directive

The FROM Directive

A Dockerfile usually starts with the FROM directive. This is used to specify the parent image of our custom Docker image. The parent image is the starting point of our custom Docker image. All the customization that we do will be applied on top of the parent image. The parent image can be an image from Docker Hub, such as Ubuntu, CentOS, Nginx, and MySQL. The FROM directive takes a valid image name and a tag as arguments. If the tag is not specified, the latest tag will be used.

A FROM directive has the following format:

FROM <image>:<tag>

In the following FROM directive, we are using the ubuntu parent image with the 20.04 tag:

FROM ubuntu:20.04

Additionally, we can use the base image if we need to build a Docker image from scratch. The base image, known as the scratch image, is an empty image mostly used to build other parent images.

In the following FROM directive, we are using the scratch image to build our custom Docker image from scratch:

FROM scratch

Now, let's understand what a LABEL directive is in the next section.

The LABEL Directive

A LABEL is a key-value pair that can be used to add metadata to a Docker image. These labels can be used to organize the Docker images properly. An example would be to add the name of the author of the Dockerfile or the version of the Dockerfile.

A LABEL directive has the following format:

LABEL <key>=<value>

A Dockerfile can have multiple labels, adhering to the preceding key-value format:

LABEL [email protected]
LABEL version=1.0
LABEL environment=dev

Or these labels can be included on a single line separated by spaces:

LABEL [email protected] version=1.0 environment=dev

Labels on an existing Docker image can be viewed with the docker image inspect command.

The output should be like the following on running the docker image inspect <image>:<tag> command:

...
...
"Labels": {
    "environment": "dev",
    "maintainer": "[email protected]",
    "version": "1.0"
}
...
...

As shown here, the docker image inspect command will output the key-value pairs configured in the Dockerfile using the LABEL directive.

In the next section, we will learn how to execute commands during the image build time using the RUN directive.

The RUN Directive

The RUN directive is used to execute commands during the image build time. This will create a new layer on top of the existing layer, execute the specified command, and commit the results to the newly created layer. The RUN directive can be used to install the required packages, update the packages, create users and groups, and so on.

The RUN directive takes the following format:

RUN <command>

<command> specifies the shell command you want to execute as part of the image build process. A Dockerfile can have multiple RUN directives adhering to the preceding format.

In the following example, we are running two commands on top of the parent image. The apt-get update is used to update the package repositories, and apt-get install nginx -y is used to install the Nginx package:

RUN apt-get update
RUN apt-get install nginx -y

Alternatively, you can add multiple shell commands to a single RUN directive by separating them with the && symbol. In the following example, we have used the same two commands, but this time in a single RUN directive, separated by an && symbol:

RUN apt-get update && apt-get install nginx -y

Now, let's move on to the next section where we will learn about the CMD directive.

The CMD Directive

A Docker container is normally expected to run one process. A CMD directive is used to provide this default initialization command that will be executed when a container is created from the Docker image. A Dockerfile can execute only one CMD directive. If there is more than one CMD directive in the Dockerfile, Docker will execute only the last one.

The CMD directive has the following format:

CMD ["executable","param1","param2","param3", ...]

For example, use the following command to echo "Hello World" as the output of a Docker container:

CMD ["echo","Hello World"]

The preceding CMD directive will produce the following output when we run the Docker container with the docker container run <image> command (replace <image> with the name of the Docker image):

$ docker container run <image>
Hello World

However, if we send any command-line arguments with docker container run <image>, these arguments will take precedence over the CMD command that we defined. For example, if we execute the following command (replace <image> with the name of the Docker image), the default "Hello World" output defined with the CMD directive will be ignored. Instead, the container will output "Hello Docker !!!":

$ docker container run <image> echo "Hello Docker !!!"

As we discussed, both the RUN and CMD directives can be used to execute a shell command. The main difference between these two directives is that the command provided with the RUN directive will be executed during the image build process, while the command provided with the CMD directive will be executed once a container is launched from the built image.

Another notable difference between the RUN and CMD directives is that there can be multiple RUN directives in a Dockerfile, but there can be only one CMD directive (if there are multiple CMD directives, all others except the last one will be ignored).

As an example, we can use the RUN directive to install a software package during the Docker image build process and the CMD directive to start the software package once a container is launched from the built image.

In the next section, we will learn about the ENTRYPOINT directive, which provides the same functionality as the CMD directive, except for overriding.

The ENTRYPOINT Directive

Similar to the CMD directive, the ENTRYPOINT directive is also used to provide this default initialization command that will be executed when a container is created from the Docker image. The difference between the CMD directive and the ENTRYPOINT directive is that, unlike the CMD directive, we cannot override the ENTRYPOINT command using the command-line parameters sent with the docker container run command.

Note

The --entrypoint flag can be sent with the docker container run command to override the default ENTRYPOINT of the image.

The ENTRYPOINT directive has the following format:

ENTRYPOINT ["executable","param1","param2","param3", ...]

Similar to the CMD directive, the ENTRYPOINT directive also allows us to provide the default executable and the parameters. We can use the CMD directive with the ENTRYPOINT directive to provide additional arguments to the executable.

In the following example, we have used "echo" as the default command and "Hello" as the default parameter using the ENTRYPOINT directive. We have also provided "World" as the additional parameter using the CMD directive:

ENTRYPOINT ["echo","Hello"]
CMD ["World"]

The output of the echo command will differ based on how we execute the docker container run command.

If we launch the Docker image without any command-line parameters, it will output the message as Hello World:

$ docker container run <image>
Hello World

But if we launch the Docker image with additional command-line parameters (for example, Docker), the output message will be Hello Docker:

$ docker container run <image> "Docker"
Hello Docker

Before discussing the Dockerfile directives any further, let's start by creating our first Dockerfile in the next exercise.

Exercise 2.01: Creating Our First Dockerfile

In this exercise, you will create a Docker image that can print the arguments you pass to the Docker image, preceded by the text You are reading. For example, if you pass hello world, it will output You are reading hello world as the output. If no argument is provided, The Docker Workshop will be used as the standard value:

  1. Create a new directory named custom-docker-image using the mkdir command. This directory will be the context for your Docker image. Context is the directory that contains all the files needed to successfully build an image:
    $ mkdir custom-docker-image
  2. Navigate to the newly created custom-docker-image directory using the cd command as we will be creating all the files required during the build process (including the Dockerfile) within this directory:
    $ cd custom-docker-image
  3. Within the custom-docker-image directory, create a file named Dockerfile using the touch command:
    $ touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    $ vim Dockerfile
  5. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # This is my first Docker image
    FROM ubuntu
    LABEL [email protected]
    RUN apt-get update
    CMD ["The Docker Workshop"]
    ENTRYPOINT ["echo", "You are reading"]

    The Docker image will be based on the Ubuntu parent image. You then use the LABEL directive to provide the email address of the author of the Dockerfile. The next line executes the apt-get update command to update the package list of Debian to the latest available version. Finally, you will use the ENTRYPOINT and CMD directives to define the default executable and parameters of the container.

    We have provided echo as the default executable and You are reading as the default parameter that cannot be overridden with command-line parameters. Also, we have provided The Docker Workshop as an additional parameter that can be overridden with command-line parameters with a docker container run command.

In this exercise, we created our first Dockerfile using the common directives that we learned in the previous sections. The next step of the process is to build the Docker image from the Dockerfile. You can only run a Docker container after building the Docker image from the Dockerfile. In the next section, we are going to look at how to build a Docker image from the Dockerfile.



Building Docker Images

In the last section, we learned how to create a Dockerfile. The next step of the process is to build a Docker image using the Dockerfile.

A Docker image is the template used to build Docker containers. This is analogous to how a house plan can be used to create multiple houses from the same design. If you are familiar with object-oriented programming concepts, a Docker image and a Docker container have the same relationship as a class and an object. A class in object-oriented programming can be used to create multiple objects.

A Docker image is a binary file consisting of multiple layers based on the instructions provided in the Dockerfile. These layers are stacked on top of one another, and each layer is dependent on the previous layer. Each of the layers is a result of the changes from the layer below it. All the layers of the Docker image are read-only. Once we create a Docker container from a Docker image, a new writable layer will be created on top of other read-only layers, which will contain all the modifications made to the container filesystem:

Figure 2.2: Docker image layers

Figure 2.2: Docker image layers

As illustrated in the preceding image, the docker image build command will create a Docker image from the Dockerfile. The layers of the Docker image will be mapped to the directives provided in the Dockerfile.

This image build process is initiated by the Docker CLI and executed by the Docker daemon. To generate a Docker image, the Docker daemon needs access to the Dockerfile, source code (for example, index.html), and other files (for example, properties files) that are referenced in the Dockerfile. These files are typically stored in a directory that is known as the build context. This context will be specified while executing the docker image build command. The entire context will be sent to the Docker daemon during the image build process.

The docker image build command takes the following format:

$ docker image build <context>

We can execute the docker image build command from the folder that contains the Dockerfile and the other files, as shown in the following example. Note that the dot (.) at the end of the command is used to denote the current directory:

$ docker image build.

Let's see the Docker image build process for the following sample Dockerfile:

FROM ubuntu:latest
LABEL [email protected]
CMD ["echo","Hello World"]

This Dockerfile uses the latest ubuntu images as the parent image. Then, the LABEL directive is used to specify [email protected] as the maintainer. Finally, the CMD directive is used to echo "Hello World" as the output of the image.

Once we execute the docker image build command for the preceding Dockerfile, we can see an output similar to the following on the console during the build process:

Sending build context to Docker daemon 2.048kB
Step 1/3 : FROM ubuntu:latest
latest: Pulling from library/ubuntu
2746a4a261c9: Pull complete
4c1d20cdee96: Pull complete
0d3160e1d0de: Pull complete
c8e37668deea: Pull complete
Digest: sha256:250cc6f3f3ffc5cdaa9d8f4946ac79821aafb4d3afc93928
        f0de9336eba21aa4
Status: Downloaded newer image for ubuntu:latest
 ---> 549b9b86cb8d
Step 2/3 : LABEL [email protected]
 ---> Running in a4a11e5e7c27
Removing intermediate container a4a11e5e7c27
 ---> e3add5272e35
Step 3/3 : CMD ["echo","Hello World"]
 ---> Running in aad8a56fcdc5
Removing intermediate container aad8a56fcdc5
 ---> dc3d4fd77861
Successfully built dc3d4fd77861

The first line of the output is Sending build context to Docker daemon, which indicates that the building starts by sending the build context to the Docker daemon. All the files available in the context will be sent recursively to the Docker daemon (unless specifically asked to ignore certain files).

Next, there are steps mentioned as Step 1/3 and Step 2/3, which correspond to the instructions in the Dockerfile. As the first step, the Docker daemon will download the parent image. In the preceding output shown, Pulling from library/ubuntu indicates this. For each line of the Dockerfile, a new intermediate container will be created to execute the directive, and once this step is completed, this intermediate container will be removed. The lines Running in a4a11e5e7c27 and Removing intermediate container a4a11e5e7c27 are used to indicate this. Finally, the Successfully built dc3d4fd77861 line is printed when the build is completed without any errors. This line prints the ID of the newly built Docker image.

Now, we can list the available Docker images using the docker image list command:

$ docker image list

This list contains the locally built Docker images and Docker images pulled from remote Docker repositories:

REPOSITORY   TAG       IMAGE ID        CREATED          SIZE
<none>       <none>    dc3d4fd77861    3 minutes ago    64.2MB
ubuntu       latest    549b9b86cb8d    5 days ago       64.2MB

As shown in the preceding output, we can see two Docker images. The first Docker image with the IMAGE ID of dc3d4fd77861 is the locally built Docker image during the build process. We can see that this IMAGE ID is identical to the ID in the last line of the docker image build command. The next image is the ubuntu image that we used as the parent image of our custom image.

Now, let's build the Docker image again using the docker image build command:

$ docker image build
Sending build context to Docker daemon  2.048kB
Step 1/3 : FROM ubuntu:latest
 ---> 549b9b86cb8d
Step 2/3 : LABEL [email protected]
 ---> Using cache
 ---> e3add5272e35
Step 3/3 : CMD ["echo","Hello World"]
 ---> Using cache
 ---> dc3d4fd77861
Successfully built dc3d4fd77861

This time, the image build process was instantaneous. The reason for this is the cache. Since we did not change any content of the Dockerfile, the Docker daemon took advantage of the cache and reused the existing layers from the local image cache to accelerate the build process. We can see that the cache was used this time with the Using cache lines available in the preceding output.

The Docker daemon will perform a validation step before starting the build process to make sure that the Dockerfile provided is syntactically correct. In the case of an invalid syntax, the build process will fail with an error message from the Docker daemon:

$ docker image build
Sending build context to Docker daemon  2.048kB
Error response from daemon: Dockerfile parse error line 5:
unknown instruction: INVALID

Now, let's revisit the locally available Docker images with the docker image list command:

$ docker image list

The command should return the following output:

REPOSITORY    TAG       IMAGE ID         CREATED          SIZE
<none>        <none>    dc3d4fd77861     3 minutes ago    64.2MB
ubuntu        latest    549b9b86cb8d     5 days ago       64.2MB

Note that there was no name for our custom Docker image. This was because we did not specify any repository or tag during the build process. We can tag an existing image with the docker image tag command.

Let's tag our image with IMAGE ID dc3d4fd77861 as my-tagged-image:v1.0:

$ docker image tag dc3d4fd77861 my-tagged-image:v1.0

Now, if we list our images again, we can see the Docker image name and the tag under the REPOSITORY and TAG columns:

REPOSITORY        TAG       IMAGE ID        CREATED         SIZE
my-tagged-image   v1.0      dc3d4fd77861    20 minutes ago  64.2MB
ubuntu            latest    549b9b86cb8d    5 days ago      64.2MB

We can also tag an image during the build process by specifying the -t flag:

$ docker image build -t my-tagged-image:v2.0 .

The preceding command will print the following output:

Sending build context to Docker daemon  2.048kB
Step 1/3 : FROM ubuntu:latest
 ---> 549b9b86cb8d
Step 2/3 : LABEL [email protected]
 ---> Using cache
 ---> e3add5272e35
Step 3/3 : CMD ["echo","Hello World"]
 ---> Using cache
 ---> dc3d4fd77861
Successfully built dc3d4fd77861
Successfully tagged my-tagged-image:v2.0

This time, in addition to the Successfully built dc3d4fd77861 line, we can see a Successfully tagged my-tagged-image:v2.0 line, which indicates the tagging on our Docker image.

In this section, we learned how to build a Docker image from a Dockerfile. We discussed the difference between a Dockerfile and a Docker image. Then, we discussed how a Docker image is made up of multiple layers. We also experienced how caching can accelerate the build process. Finally, we tagged the Docker images.

In the next exercise, we are going to build a Docker image from the Dockerfile that we created in Exercise 2.01: Creating Our First Dockerfile.

Exercise 2.02: Creating Our First Docker Image

In this exercise, you will build the Docker image from the Dockerfile that you created in Exercise 2.01: Creating Our First Dockerfile and run a Docker container from the newly built image. First, you will run the Docker image without passing any arguments, expecting You are reading The Docker Workshop as the output. Next, you will run the Docker image with Docker Beginner's Guide as the argument and expect You are reading Docker Beginner's Guide as the output:

  1. First, make sure you are in the custom-docker-image directory created in Exercise 2.01: Creating Our First Dockerfile. Confirm that the directory contains the following Dockerfile created in Exercise 2.01: Creating Our First Dockerfile:
    # This is my first Docker image
    FROM ubuntu
    LABEL [email protected]
    RUN apt-get update
    CMD ["The Docker Workshop"]
    ENTRYPOINT ["echo", "You are reading"]
  2. Build the Docker image with the docker image build command. This command has the optional -t flag to specify the tag of the image. Tag your image as welcome:1.0:
    $ docker image build -t welcome:1.0 .

    Note

    Do not forget the dot (.) at the end of the preceding command, which is used to denote the current directory as the build context.

    It can be seen from the following output that all five steps mentioned in the Dockerfile are executed during the build process. The last two lines of the output suggest that the image is successfully built and tagged:

    Figure 2.3: Building the welcome:1.0 Docker image

    Figure 2.3: Building the welcome:1.0 Docker image

  3. Build this image again without changing the Dockerfile content:
    $ docker image build -t welcome:2.0 .

    Note that this build process completed much quicker than the previous process due to the cache being used:

    Figure 2.4: Building the welcome:1.0 Docker image using the cache

    Figure 2.4: Building the welcome:1.0 Docker image using the cache

  4. Use the docker image list command to list all the Docker images available on your computer:
    $ docker image list

    These images are available on your computer, either when you pull them from a Docker registry, or when you build on your computer:

    REPOSITORY   TAG      IMAGE ID        CREATED          SIZE
    welcome      1.0      98f571a42e5c    23 minutes ago   91.9MB
    welcome      2.0      98f571a42e5c    23 minutes ago   91.9MB
    ubuntu       latest   549b9b86cb8d    2 weeks ago      64.2MB

    As you can see from the preceding output, there are three Docker images available. The ubuntu image is pulled from the Docker Hub, and version (tag) 1.0 and 2.0 of the welcome images are built on your computer.

  5. Execute the docker container run command to start a new container from the Docker image that you built in step 1 (welcome:1.0):
    $ docker container run welcome:1.0

    The output should be as follows:

    You are reading The Docker Workshop

    You receive the expected output of You are reading The Docker Workshop. You are reading is due to the parameter provided with the ENTRYPOINT directive, and The Docker Workshop comes from the parameter provided with the CMD directive.

  6. Finally, execute the docker container run command again, this time with command-line arguments:
    $ docker container run welcome:1.0 "Docker Beginner's Guide"

    You will get the output You are reading Docker Beginner's Guide because of the command-line argument, Docker Beginner's Guide, and the You are reading argument provided in the ENTRYPOINT directive:

    You are reading Docker Beginner's Guide

In this exercise, we learned how to build a custom Docker image using the Dockerfile and run a Docker container from the image. In the next section, we are going to learn other Docker directives that we can use in the Dockerfile.



Other Dockerfile Directives

In the section Common Directives in Dockerfile, we discussed the common directives available for a Dockerfile. In that section, we discussed FROM, LABEL, RUN, CMD, and ENTRYPOINT directives and how to use them to create a simple Dockerfile.

In this section, we will be discussing more advanced Dockerfile directives. These directives can be used to create more advanced Docker images. For example, we can use the VOLUME directive to bind the filesystem of the host machine to a Docker container. This will allow us to persist the data generated and used by the Docker container. Another example is the HEALTHCHECK directive, which allows us to define health checks to evaluate the health status of Docker containers. We will look into the following directives in this section:

  1. The ENV directive
  2. The ARG directive
  3. The WORKDIR directive
  4. The COPY directive
  5. The ADD directive
  6. The USER directive
  7. The VOLUME directive
  8. The EXPOSE directive
  9. The HEALTHCHECK directive
  10. The ONBUILD directive

The ENV Directive

The ENV directive in Dockerfile is used to set environment variables. Environment variables are used by applications and processes to get information about the environment in which a process runs. One example would be the PATH environment variable, which lists the directories to search for executable files.

Environment variables are defined as key-value pairs as per the following format:

ENV <key> <value>

The PATH environment variable is set with the following value:

$PATH:/usr/local/myapp/bin/

Hence, it can be set using the ENV directive as follows:

ENV PATH $PATH:/usr/local/myapp/bin/

We can set multiple environment variables in the same line separated by spaces. However, in this form, the key and value should be separated by the equal to (=) symbol:

ENV <key>=<value> <key>=<value> ...

In the following example, there are two environment variables configured. The PATH environment variable is configured with the value of $PATH:/usr/local/myapp/bin/, and the VERSION environment variable is configured with the value of 1.0.0:

ENV PATH=$PATH:/usr/local/myapp/bin/ VERSION=1.0.0

Once an environment variable is set with the ENV directive in the Dockerfile, this variable is available in all subsequent Docker image layers. This variable is even available in the Docker containers launched from this Docker image.

In the next section, we will look into the ARG directive.

The ARG Directive

The ARG directive is used to define variables that the user can pass at build time. ARG is the only directive that can precede the FROM directive in the Dockerfile.

Users can pass values using --build-arg <varname>=<value>, as shown here, while building the Docker image:

$ docker image build -t <image>:<tag> --build-arg <varname>=<value> .

The ARG directive has the following format:

ARG <varname>

There can be multiple ARG directives in a Dockerfile, as follows:

ARG USER
ARG VERSION

The ARG directive can also have an optional default value defined. This default value will be used if no value is passed at build time:

ARG USER=TestUser
ARG VERSION=1.0.0

Unlike the ENV variables, ARG variables are not accessible from the running container. They are only available during the build process.

In the next exercise, we will use the knowledge gained so far to use ENV and ARG directives in a Dockerfile.

Exercise 2.03: Using ENV and ARG Directives in a Dockerfile

Your manager has asked you to create a Dockerfile that will use ubuntu as the parent image, but you should be able to change the ubuntu version at build time. You will also need to specify the publisher's name and application directory as the environment variables of the Docker image. You will use the ENV and ARG directives in the Dockerfile to perform this exercise:

  1. Create a new directory named env-arg-exercise using the mkdir command:
    mkdir env-arg-exercise
  2. Navigate to the newly created env-arg-exercise directory using the cd command:
    cd env-arg-exercise
  3. Within the env-arg-exercise directory, create a file named Dockerfile:
    touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  5. Add the following content to the Dockerfile. Then, save and exit from the Dockerfile:
    # ENV and ARG example
    ARG TAG=latest
    FROM ubuntu:$TAG
    LABEL [email protected]
    ENV PUBLISHER=packt APP_DIR=/usr/local/app/bin
    CMD ["env"]

    This Dockerfile first defined an argument named TAG with the default value of the latest. The next line is the FROM directive, which will use the ubuntu parent image with the TAG variable value sent with the build command (or the default value if no value is sent with the build command). Then, the LABEL directive sets the value for the maintainer. Next is the ENV directive, which defines the environment variable of PUBLISHER with the value packt, and APP_DIR with the value of /usr/local/app/bin. Finally, use the CMD directive to execute the env command, which will print all the environment variables.

  6. Now, build the Docker image:
    $ docker image build -t env-arg --build-arg TAG=19.04 .

    Note the env-arg --build-arg TAG=19.04 flag used to send the TAG argument to the build process. The output should be as follows:

    Figure 2.5: Building the env-arg Docker image

    Figure 2.5: Building the env-arg Docker image

    Note that the 19.04 tag of the ubuntu image was used as the parent image. This is because you sent the --build-arg flag with the value of TAG=19.04 during the build process.

  7. Now, execute the docker container run command to start a new container from the Docker image that you built in the last step:
    $ docker container run env-arg

    As we can see from the output, the PUBLISHER environment variable is available with the value of packt, and the APP_DIR environment variable is available with the value of /usr/local/app/bin:

    Figure 2.6: Running the env-arg Docker container

Figure 2.6: Running the env-arg Docker container

In this exercise, we defined environment variables for a Docker image using the ENV directive. We also experienced how to use ARG directives to pass values during the Docker image build time. In the next section, we will be covering the WORKDIR directive, which can be used to define the current working directory of the Docker container.

The WORKDIR Directive

The WORKDIR directive is used to specify the current working directory of the Docker container. Any subsequent ADD, CMD, COPY, ENTRYPOINT, and RUN directives will be executed in this directory. The WORKDIR directive has the following format:

WORKDIR /path/to/workdir

If the specified directory does not exist, Docker will create this directory and make it the current working directory, which means this directive executes both mkdir and cd commands implicitly.

There can be multiple WORKDIR directives in the Dockerfile. If a relative path is provided in a subsequent WORKDIR directive, that will be relative to the working directory set by the previous WORKDIR directive:

WORKDIR /one
WORKDIR two
WORKDIR three
RUN pwd

In the preceding example, we are using the pwd command at the end of the Dockerfile to print the current working directory. The output of the pwd command will be /one/two/three.

In the next section, we will discuss the COPY directive that is used to copy files from the local filesystem to the Docker image filesystem.

The COPY Directive

During the Docker image build process, we may need to copy files from our local filesystem to the Docker image filesystem. These files can be source code files (for example, JavaScript files), configuration files (for example, properties files), or artifacts (for example, JAR files). The COPY directive can be used to copy files and folders from the local filesystem to the Docker image during the build process. This directive takes two arguments. The first one is the source path from the local filesystem, and the second one is the destination path on the image filesystem:

COPY <source> <destination>

In the following example, we are using the COPY directive to copy the index.html file from the local filesystem to the /var/www/html/ directory of the Docker image:

COPY index.html /var/www/html/index.html

Wildcards can also be specified to copy all files that match the given pattern. The following example will copy all files with the .html extension from the current directory to the /var/www/html/ directory of the Docker image:

COPY *.html /var/www/html/

In addition to copying files, the --chown flag can be used with the COPY directive to specify the user and group ownership of the files:

COPY --chown=myuser:mygroup *.html /var/www/html/

In the preceding example, in addition to copying all the HTML files from the current directory to the /var/www/html/ directory, the --chown flag is used to set file ownership, with the user as myuser and group as mygroup:

Note

The --chown flag is only supported from Docker version 17.09 and above. For Docker versions below 17.09, you need to run the chown command after the COPY command to change file ownership.

In the next section, we will look at the ADD directive.

The ADD Directive

The ADD directive is also similar to the COPY directive, and has the following format:

ADD <source> <destination>

However, in addition to the functionality provided by the COPY directive, the ADD directive also allows us to use a URL as the <source> parameter:

ADD http://sample.com/test.txt /tmp/test.txt

In the preceding example, the ADD directive will download the test.txt file from http://sample.com and copy the file to the /tmp directory of the Docker image filesystem.

Another feature of the ADD directive is automatically extracting the compressed files. If we add a compressed file (gzip, bzip2, tar, and so on) to the <source> parameter, the ADD directive will extract the archive and copy the content to the image filesystem.

Imagine we have a compressed file named html.tar.gz that contains index.html and contact.html files. The following command will extract the html.tar.gz file and copy the index.html and contact.html files to the /var/www/html directory:

ADD html.tar.gz /var/www/html

Since the COPY and ADD directives provide almost the same functionality, it is recommended to always use the COPY directive unless you need the additional functionality (add from a URL or extract a compressed file) provided by the ADD directive. This is because the ADD directive provides additional functionality that can behave unpredictably if used incorrectly (for example, copying files when you want to extract, or extracting files when you want to copy).

In the next exercise, we are going to use the WORKDIR, COPY, and ADD directives to copy files into the Docker image.

Exercise 2.04: Using the WORKDIR, COPY, and ADD Directives in the Dockerfile

In this exercise, you will deploy your custom HTML file to the Apache web server. You will use Ubuntu as the base image and install Apache on top of it. Then, you will copy your custom index.html file to the Docker image and download the Docker logo (from the https://www.docker.com website) to be used with the custom index.html file:

  1. Create a new directory named workdir-copy-add-exercise using the mkdir command:
    mkdir workdir-copy-add-exercise
  2. Navigate to the newly created workdir-copy-add-exercise directory:
    cd workdir-copy-add-exercise
  3. Within the workdir-copy-add-exercise directory, create a file named index.html. This file will be copied to the Docker image during build time:
    touch index.html
  4. Now, open index.html using your favorite text editor:
    vim index.html
  5. Add the following content to the index.html file, save it, and exit from index.html:
    <html>
      <body>
        <h1>Welcome to The Docker Workshop</h1>
        <img src="logo.png" height="350" width="500"/>
      </body>
    </html>

    This HTML file will output Welcome to The Docker Workshop as the header of the page and logo.png (which we will download during the Docker image build process) as an image. You have defined the size of the logo.png image as a height of 350 and a width of 500.

  6. Within the workdir-copy-add-exercise directory, create a file named Dockerfile:
    touch Dockerfile
  7. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  8. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # WORKDIR, COPY and ADD example
    FROM ubuntu:latest
    RUN apt-get update && apt-get install apache2 -y
    WORKDIR /var/www/html/
    COPY index.html .
    ADD https://www.docker.com/sites/default/files/d8/2019-07/  Moby-logo.png ./logo.png
    CMD ["ls"]

    This Dockerfile first defines the ubuntu image as the parent image. The next line is the RUN directive, which will execute apt-get update to update the package list, and apt-get install apache2 -y to install the Apache HTTP server. Then, you will set /var/www/html/ as the working directory. Next, copy the index.html file that we created in step 3 to the Docker image. Then, use the ADD directive to download the Docker logo from https://www.docker.com/sites/default/files/d8/2019-07/Moby-logo.png to the Docker image. The final step is to use the ls command to print the content of the /var/www/html/ directory.

  9. Now, build the Docker image with the tag of workdir-copy-add:
    $ docker image build -t workdir-copy-add .

    You will observe that the image is successfully built and tagged as latest since we did not explicitly tag our image:

    Figure 2.7: Building the Docker image using WORKDIR, COPY, and ADD directives

    Figure 2.7: Building the Docker image using WORKDIR, COPY, and ADD directives

  10. Execute the docker container run command to start a new container from the Docker image that you built in the previous step:
    $ docker container run workdir-copy-add

    As we can see from the output, both the index.html and logo.png files are available in the /var/www/html/ directory:

    index.html

In this exercise, we observed how the WORKDIR, ADD, and COPY directives work with Docker. In the next section, we are going to discuss the USER directive.

The USER Directive

Docker will use the root user as the default user of a Docker container. We can use the USER directive to change this default behavior and specify a non-root user as the default user of a Docker container. This is a great way to improve security by running the Docker container as a non-privileged user. The username specified with the USER directive will be used to run all subsequent RUN, CMD, and ENTRYPOINT directives in the Dockerfile.

The USER directive takes the following format:

USER <user>

In addition to the username, we can also specify the optional group name to run the Docker container:

USER <user>:<group>

We need to make sure that the <user> and <group> values are valid user and group names. Otherwise, the Docker daemon will throw an error while trying to run the container:

docker: Error response from daemon: unable to find user my_user:
        no matching entries in passwd file.

Now, let's try our hands at using the USER directive in the next exercise.

Exercise 2.05: Using USER Directive in the Dockerfile

Your manager has asked you to create a Docker image to run the Apache web server. He has specifically requested that you use a non-root user while running the Docker container due to security reasons. In this exercise, you will use the USER directive in the Dockerfile to set the default user. You will be installing the Apache web server and changing the user to www-data. Finally, you will execute the whoami command to verify the current user by printing the username:

Note

The www-data user is the default user for the Apache web server on Ubuntu.

  1. Create a new directory named user-exercise for this exercise:
    mkdir user-exercise
  2. Navigate to the newly created user-exercise directory:
    cd user-exercise
  3. Within the user-exercise directory, create a file named Dockerfile:
    touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  5. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # USER example
    FROM ubuntu
    RUN apt-get update && apt-get install apache2 -y
    USER www-data
    CMD ["whoami"]

    This Dockerfile first defines the Ubuntu image as the parent image. The next line is the RUN directive, which will execute apt-get update to update the package list, and apt-get install apache2 -y to install the Apache HTTP server. Next, you use the USER directive to change the current user to the www-data user. Finally, you have the CMD directive, which executes the whoami command, which will print the username of the current user.

  6. Build the Docker image:
    $ docker image build -t user .

    The output should be as follows:

    Figure 2.8: Building the user Docker image

    Figure 2.8: Building the user Docker image

  7. Now, execute the docker container run command to start a new container from the Docker image that we built in the previous step:
    $ docker container run user

    As you can see from the following output, www-data is the current user associated with the Docker container:

    www-data

In this exercise, we implemented the USER directive in the Dockerfile to set the www-data user as the default user of the Docker image.

In the next section, we will discuss the VOLUME directive.

The VOLUME Directive

In Docker, the data (for example, files, executables) generated and used by Docker containers will be stored within the container filesystem. When we delete the container, all the data will be lost. To overcome this issue, Docker came up with the concept of volumes. Volumes are used to persist the data and share the data between containers. We can use the VOLUME directive within the Dockerfile to create Docker volumes. Once a VOLUME is created in the Docker container, a mapping directory will be created in the underlying host machine. All file changes to the volume mount of the Docker container will be copied to the mapped directory of the host machine.

The VOLUME directive generally takes a JSON array as the parameter:

VOLUME ["/path/to/volume"]

Or, we can specify a plain string with multiple paths:

VOLUME /path/to/volume1 /path/to/volume2

We can use the docker container inspect <container> command to view the volumes available in a container. The output JSON of the docker container inspect command will print the volume information similar to the following:

"Mounts": [
    {
        "Type": "volume",
        "Name": "77db32d66407a554bd0dbdf3950671b658b6233c509ea
ed9f5c2a589fea268fe",
        "Source": "/var/lib/docker/volumes/77db32d66407a554bd0
dbdf3950671b658b6233c509eaed9f5c2a589fea268fe/_data",
        "Destination": "/path/to/volume",
        "Driver": "local",
        "Mode": "",
        "RW": true,
        "Propagation": ""
    }
],

As per the preceding output, there is a unique name given to the volume by Docker. Also, the source and destination paths of the volume are mentioned in the output.

Additionally, we can execute the docker volume inspect <volume> command to display detailed information pertaining to a volume:

[
    {
        "CreatedAt": "2019-12-28T12:52:52+05:30",
        "Driver": "local",
        "Labels": null,
        "Mountpoint": "/var/lib/docker/volumes/77db32d66407a554
bd0dbdf3950671b658b6233c509eaed9f5c2a589fea268fe/_data",
        "Name": "77db32d66407a554bd0dbdf3950671b658b6233c509eae
d9f5c2a589fea268fe",
        "Options": null,
        "Scope": "local"
    }
]

This is also similar to the previous output, with the same unique name and the mount path of the volume.

In the next exercise, we will learn how to use the VOLUME directive in a Dockerfile.

Exercise 2.06: Using VOLUME Directive in the Dockerfile

In this exercise, you will be setting a Docker container to run the Apache web server. However, you do not want to lose the Apache log files in case of a Docker container failure. As a solution, you have decided to persist in the log files by mounting the Apache log path to the underlying Docker host:

  1. Create a new directory named volume-exercise:
    mkdir volume-exercise
  2. Navigate to the newly created volume-exercise directory:
    cd volume-exercise
  3. Within the volume-exercise directory, create a file named Dockerfile:
    touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  5. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # VOLUME example
    FROM ubuntu
    RUN apt-get update && apt-get install apache2 -y
    VOLUME ["/var/log/apache2"]

    This Dockerfile started by defining the Ubuntu image as the parent image. Next, you will execute the apt-get update command to update the package list, and the apt-get install apache2 -y command to install the Apache web server. Finally, use the VOLUME directive to set up a mount point to the /var/log/apache2 directory.

  6. Now, build the Docker image:
    $ docker image build -t volume .

    The output should be as follows:

    Figure 2.9: Building the volume Docker image

    Figure 2.9: Building the volume Docker image

  7. Execute the docker container run command to start a new container from the Docker image that you built in the previous step. Note that you are using the --interactive and --tty flags to open an interactive bash session so that you can execute commands from the bash shell of the Docker container. You have also used the --name flag to define the container name as volume-container:
    $ docker container run --interactive --tty --name volume-container volume /bin/bash

    Your bash shell will be opened as follows:

    [email protected]: /#
  8. From the Docker container command line, change directory to the /var/log/apache2/ directory:
    # cd /var/log/apache2/

    This will produce the following output:

    [email protected]: /var/log/apache2#
  9. Now, list the available files in the directory:
    # ls -l

    The output should be as follows:

    Figure 2.10: Listing files of the /var/log/apache2 directory

    Figure 2.10: Listing files of the /var/log/apache2 directory

    These are the log files created by Apache while running the process. The same files should be available once you check the host mount of this volume.

  10. Now, exit the container to check the host filesystem:
    # exit
  11. Inspect volume-container to view the mount information:
    $ docker container inspect volume-container

    Under the "Mounts" key, you can see the information relating to the mount:

    Figure 2.11: Inspecting the Docker container

    Figure 2.11: Inspecting the Docker container

  12. Inspect the volume with the docker volume inspect <volume_name> command. <volume_name> can be identified by the Name field of the preceding output:
    $ docker volume inspect 354d188e0761d82e1e7d9f3d5c6ee644782b7150f51cead8f140556e5d334bd5

    You should get the output similar to the following:

    Figure 2.12: Inspecting the Docker volume

    Figure 2.12: Inspecting the Docker volume

    We can see that the container is mounted to the host path of "/var/lib/docker/volumes/354d188e0761d82e1e7d9f3d5c6ee644782b 7150f51cead8f140556e5d334bd5/_data", which is defined as the Mountpoint field in the preceding output.

  13. List the files available in the host file path. The host file path can be identified with the "Mountpoint" field of the preceding output:
    $ sudo ls -l /var/lib/docker/volumes/354d188e0761d82e1e7d9f3d5c6ee644782b7150f51cead8f14 0556e5d334bd5/_data

    In the following output, you can see that the log files in the /var/log/apache2 directory of the container are mounted to the host:

    Figure 2.13: Listing files in the mount point directory

Figure 2.13: Listing files in the mount point directory

In this exercise, we observed how to mount the log path of the Apache web server to the host filesystem using the VOLUME directive. In the next section, we will learn about the EXPOSE directive.

The EXPOSE Directive

The EXPOSE directive is used to inform Docker that the container is listening on the specified ports at runtime. We can use the EXPOSE directive to expose ports through either TCP or UDP protocols. The EXPOSE directive has the following format:

EXPOSE <port>

However, the ports exposed with the EXPOSE directive will only be accessible from within the other Docker containers. To expose these ports outside the Docker container, we can publish the ports with the -p flag with the docker container run command:

docker container run -p <host_port>:<container_port> <image>

As an example, imagine that we have two containers. One is a NodeJS web app container that should be accessed from outside via port 80. The second one is the MySQL container, which should be accessed from the node app container via port 3306. In this scenario, we have to expose port 80 of the NodeJS app with the EXPOSE directive and use the -p flag with the docker container run command to expose it externally. However, for the MySQL container, we can only use the EXPOSE directive without the -p flag when running the container, as 3306 should only be accessible from the node app container.

So, in summary, the following statements define this directive:

  • If we specify both the EXPOSE directive and -p flag, exposed ports will be accessible from other containers as well as externally.
  • If we specify EXPOSE without the -p flag, exposed ports will only be accessible from other containers, but not externally.

You will learn about the HEALTHCHECK directive in the next section.

The HEALTHCHECK Directive

Health checks are used in Docker to check whether the containers are running healthily. For example, we can use health checks to make sure the application is running within the Docker container. Unless there is a health check specified, there is no way for Docker to say whether a container is healthy. This is very important if you are running Docker containers in production environments. The HEALTHCHECK directive has the following format:

HEALTHCHECK [OPTIONS] CMD command

There can be only one HEALTHCHECK directive in a Dockerfile. If there is more than one HEALTHCHECK directive, only the last one will take effect.

As an example, we can use the following directive to ensure that the container can receive traffic on the http://localhost/ endpoint:

HEALTHCHECK CMD curl -f http://localhost/ || exit 1

The exit code at the end of the preceding command is used to specify the health status of the container. 0 and 1 are valid values for this field. 0 is used to denote a healthy container, and 1 is used to denote an unhealthy container.

In addition to the command, we can specify a few other parameters with the HEALTHCHECK directive, as follows:

  • --interval: This specifies the period between each health check (the default is 30s).
  • --timeout: If no success response is received within this period, the health check is considered failed (the default is 30s).
  • --start-period: The duration to wait before running the first health check. This is used to give a startup time for the container (the default is 0s).
  • --retries: The container will be considered unhealthy if the health check failed consecutively for the given number of retries (the default is 3).

In the following example, we have overridden the default values by providing our custom values with the HEALTHCHECK directive:

HEALTHCHECK --interval=1m --timeout=2s --start-period=2m --retries=3 \    CMD curl -f http://localhost/ || exit 1

We can check the health status of a container with the docker container list command. This will list the health status under the STATUS column:

CONTAINER ID  IMAGE     COMMAND                  CREATED
  STATUS                        PORTS                NAMES
d4e627acf6ec  sample    "apache2ctl -D FOREG…"   About a minute ago
  Up About a minute (healthy)   0.0.0.0:80->80/tcp   upbeat_banach

As soon as we start the container, the health status will be health: starting. Following the successful execution of the HEALTHCHECK command, the status will change to healthy.

In the next exercise, we are going to use the EXPOSE and HEALTHCHECK directives to create a Docker container with the Apache web server and define health checks for it.

Exercise 2.07: Using EXPOSE and HEALTHCHECK Directives in the Dockerfile

Your manager has asked you to dockerize the Apache web server to access the Apache home page from the web browser. Additionally, he has asked you to configure health checks to determine the health status of the Apache web server. In this exercise, you will use the EXPOSE and HEALTHCHECK directives to achieve this goal:

  1. Create a new directory named expose-healthcheck:
    mkdir expose-healthcheck
  2. Navigate to the newly created expose-healthcheck directory:
    cd expose-healthcheck
  3. Within the expose-healthcheck directory, create a file named Dockerfile:
    touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  5. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # EXPOSE & HEALTHCHECK example
    FROM ubuntu
    RUN apt-get update && apt-get install apache2 curl -y
    HEALTHCHECK CMD curl -f http://localhost/ || exit 1
    EXPOSE 80
    ENTRYPOINT ["apache2ctl", "-D", "FOREGROUND"]

    This Dockerfile first defines the ubuntu image as the parent image. Next, we execute the apt-get update command to update the package list, and the apt-get install apache2 curl -y command to install the Apache web server and curl tool. Curl is required to execute the HEALTHCHECK command. Next, we define the HEALTHCHECK directive with curl to the http://localhost/ endpoint. Then, we exposed port 80 of the Apache web server so that we can access the home page from our web browser. Finally, we start the Apache web server with the ENTRYPOINT directive.

  6. Now, build the Docker image:
    $ docker image build -t expose-healthcheck.

    You should get the following output:

    Figure 2.14: Building the expose-healthcheck Docker image

    Figure 2.14: Building the expose-healthcheck Docker image

  7. Execute the docker container run command to start a new container from the Docker image that you built in the previous step. Note that you are using the -p flag to redirect port 80 of the host to port 80 of the container. Additionally, you have used the --name flag to specify the container name as expose-healthcheck-container, and the -d flag to run the container in detached mode (this runs the container in the background):
    $ docker container run -p 80:80 --name expose-healthcheck-container -d expose-healthcheck
  8. List the running containers with the docker container list command:
    $ docker container list

    In the following output, you can see that the STATUS of the expose-healthcheck-container is healthy:

    Figure 2.15: List of running containers

    Figure 2.15: List of running containers

  9. Now, you should be able to view the Apache home page. Go to the http://127.0.0.1 endpoint from your favorite web browser:
    Figure 2.16: Apache home page

    Figure 2.16: Apache home page

  10. Now, clean up the container. First, stop the Docker container by using the docker container stop command:
    $ docker container stop expose-healthcheck-container
  11. Finally, remove the Docker container with the docker container rm command:
    $ docker container rm expose-healthcheck-container

In this exercise, you utilized the EXPOSE directive to expose an Apache web server as a Docker container and used the HEALTHCHECK directive to define a health check to verify the healthy status of the Docker container.

In the next section, we will learn about the ONBUILD directive.

The ONBUILD Directive

The ONBUILD directive is used in the Dockerfile to create a reusable Docker image that will be used as the base for another Docker image. As an example, we can create a Docker image that contains all the prerequisites, such as dependencies and configurations, in order to run an application. Then, we can use this 'prerequisite' image as the parent image to run the application.

While creating the prerequisite image, we can use the ONBUILD directive, which will include the instructions that should only be executed when this image is used as the parent image in another Dockerfile. ONBUILD instructions will not be executed while building the Dockerfile that contains the ONBUILD directive, but only when building the child image.

The ONBUILD directive takes the following format:

ONBUILD <instruction>

As an example, consider that we have the following ONBUILD instruction in the Dockerfile of our custom base image:

ONBUILD ENTRYPOINT ["echo","Running ONBUILD directive"]

The "Running ONBUILD directive" value will not be printed if we create a Docker container from our custom base image. However, the "Running ONBUILD directive" value will be printed if we use our custom base image as the base for our new child Docker image.

We can use the docker image inspect command for the parent image to list the OnBuild triggers listed for the image:

$ docker image inspect <parent-image>

The command will return output similar to the following:

...
"OnBuild": [
    "CMD [\"echo\",\"Running ONBUILD directive\"]"
]
...

In the next exercise, we will be using the ONBUILD directive to define a Docker image to deploy the HTML files.

Exercise 2.08: Using ONBUILD Directive in the Dockerfile

You have been asked by your manager to create a Docker image that is capable of running any HTML files provided by the software development team. In this exercise, you will build a parent image with the Apache web server and use the ONBUILD directive to copy the HTML files. The software development team can use this Docker image as the parent image to deploy and test any HTML files created by them:

  1. Create a new directory named onbuild-parent:
    mkdir onbuild-parent
  2. Navigate to the newly created onbuild-parent directory:
    cd onbuild-parent
  3. Within the onbuild-parent directory, create a file named Dockerfile:
    touch Dockerfile
  4. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  5. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # ONBUILD example
    FROM ubuntu
    RUN apt-get update && apt-get install apache2 -y
    ONBUILD COPY *.html /var/www/html
    EXPOSE 80
    ENTRYPOINT ["apache2ctl", "-D", "FOREGROUND"]

    This Dockerfile first defines the ubuntu image as the parent image. It then executes the apt-get update command to update the package list, and the apt-get install apache2 -y command to install the Apache web server. The ONBUILD directive is used to provide a trigger to copy all HTML files to the /var/www/html directory. The EXPOSE directive is used to expose port 80 of the container and ENTRYPOINT to start the Apache web server using the apache2ctl command.

  6. Now, build the Docker image:
    $ docker image build -t onbuild-parent .

    The output should be as follows:

    Figure 2.17: Building the onbuild-parent Docker image

    Figure 2.17: Building the onbuild-parent Docker image

  7. Execute the docker container run command to start a new container from the Docker image built in the previous step:
    $ docker container run -p 80:80 --name onbuild-parent-container -d onbuild-parent

    In the preceding command, you have started the Docker container in detached mode while exposing port 80 of the container.

  8. Now, you should be able to view the Apache home page. Go to the http://127.0.0.1 endpoint from your favorite web browser. Note that the default Apache home page is visible:
    Figure 2.18: Apache home page

    Figure 2.18: Apache home page

  9. Now, clean up the container. Stop the Docker container by using the docker container stop command:
    $ docker container stop onbuild-parent-container
  10. Remove the Docker container with the docker container rm command:
    $ docker container rm onbuild-parent-container
  11. Now, create another Docker image using onbuild-parent-container as the parent image to deploy a custom HTML home page. First, change the directory back to the previous directory:
    cd ..
  12. Create a new directory named onbuild-child for this exercise:
    mkdir onbuild-child
  13. Navigate to the newly created onbuild-child directory:
    cd onbuild-child
  14. Within the onbuild-child directory, create a file named index.html. This file will be copied to the Docker image by the ONBUILD command during build time:
    touch index.html
  15. Now, open the index.html file using your favorite text editor:
    vim index.html
  16. Add the following content to the index.html file, save it, and exit from the index.html file:
    <html>
      <body>
        <h1>Learning Docker ONBUILD directive</h1>
      </body>
    </html>

    This is a simple HTML file that will output the Learning Docker ONBUILD directive as the header of the page.

  17. Within the onbuild-child directory, create a file named Dockerfile:
    touch Dockerfile
  18. Now, open the Dockerfile using your favorite text editor:
    vim Dockerfile
  19. Add the following content to the Dockerfile, save it, and exit from the Dockerfile:
    # ONBUILD example
    FROM onbuild-parent

    This Dockerfile has only one directive. This will use the FROM directive to utilize the onbuild-parent Docker image that you created previously as the parent image.

  20. Now, build the Docker image:
    $ docker image build -t onbuild-child .
    Figure 2.19: Building the onbuild-child Docker image

    Figure 2.19: Building the onbuild-child Docker image

  21. Execute the docker container run command to start a new container from the Docker image that you built in the previous step:
    $ docker container run -p 80:80 --name onbuild-child-container -d onbuild-child

    In this command, you have started the Docker container from the onbuild-child Docker image while exposing port 80 of the container.

  22. You should be able to view the Apache home page. Go to the http://127.0.0.1 endpoint from your favorite web browser:
    Figure 2.20: Customized home page of the Apache web server

    Figure 2.20: Customized home page of the Apache web server

  23. Now, clean up the container. First, stop the Docker container by using the docker container stop command:
    $ docker container stop onbuild-child-container
  24. Finally, remove the Docker container with the docker container rm command:
    $ docker container rm onbuild-child-container

In this exercise, we observed how we can use the ONBUILD directive to create a reusable Docker image that is capable of running any HTML file provided to it. We created the reusable Docker image named onbuild-parent with the Apache web server, with port 80 exposed. This Dockerfile contains the ONBUILD directive to copy the HTML files in the context of the Docker image. Then, we created the second Docker image named onbuild-child, using onbuild-parent as the base image, that provided a simple HTML file to be deployed to the Apache web server.

Now, let's test our knowledge that we have acquired in this chapter by dockerizing the given PHP application using the Apache web server in the following activity.

Activity 2.01: Running a PHP Application on a Docker Container

Imagine that you want to deploy a PHP welcome page that will greet visitors based on the date and time using the following logic. Your task is to dockerize the PHP application given here, using the Apache web server installed on an Ubuntu base image:

<?php
$hourOfDay = date('H');
if($hourOfDay < 12) {
    $message = "Good Morning";
} elseif($hourOfDay > 11 && $hourOfDay < 18) {
    $message = "Good Afternoon";
} elseif($hourOfDay > 17){
    $message = "Good Evening";
}
echo $message;
?>

This is a simple PHP file that will greet the user based on the following logic:

Figure 2.21: Logic of PHP application

Figure 2.21: Logic of PHP application

Execute the following steps to complete this activity:

  1. Create a folder to store the activity files.
  2. Create a welcome.php file with the code provided previously.
  3. Create a Dockerfile and set up the application with PHP and Apache2 on an Ubuntu base image.
  4. Build and run the Docker image.
  5. Once completed, stop and remove the Docker container.

    Note

    The solution for this activity can be found via this link.



Summary

In this chapter, we discussed how we can use a Dockerfile to create our own custom Docker images. First, we discussed what is a Dockerfile and the syntax of a Dockerfile. We then discussed some common Docker directives, including the FROM, LABEL, RUN, CMD, and ENTRYPOINT directives. Then, we created our first Dockerfile with the common directives that we learned.

In the next section, we focused on building Docker images. We discussed multiple areas in depth regarding Docker images, including the layered filesystem of Docker images, the context in Docker builds, and the use of the cache during the Docker build process. Then, we discussed more advanced Dockerfile directives, including the ENV, ARG, WORKDIR, COPY, ADD, USER, VOLUME, EXPOSE, HEALTHCHECK, and ONBUILD directives.

In the next chapter, we will discuss what a Docker registry is, look at private and public Docker registries, and learn how we can publish Docker images to Docker registries.

About the Authors

  • Vincent Sesto

    Vincent Sesto, when changing skill sets and moving from business into the information technology field 10 years ago, saw the potential of doing things via technology and has continued to follow his passion to find better ways of doing so. Vince has worked with Splunk for the past 4 years, developing apps and reporting applications around Splunk, and now works hard to advocate its success. He has worked as a system engineer in big data companies and development departments, where he has regularly supported, built, and developed with Splunk. His LinkedIn profile is at https://au.linkedin.com/in/vincesesto.

    Browse publications by this author
  • Onur Yılmaz

    Onur Ylmaz is a senior software engineer in a multinational enterprise software company. He is a certified Kubernetes administrator (CKA) and works on Kubernetes and cloud management systems. He is a keen supporter of cutting-edge technologies including Docker, Kubernetes, and cloud-native applications. He has one master's and two bachelor's degrees in the engineering field.

    Browse publications by this author
  • Sathsara Sarathchandra

    Sathsara Sarathchandra is a DevOps engineer, experienced in building and managing Kubernetes based production deployments both in cloud and on-premise. He has over 8 years of experience working in several companies ranging from small start-ups to enterprises. He is a Certified Kubernetes Administrator (CKA) and a certified Kubernetes application developer (CKAD). He holds a master's degree in business administration and a bachelor's degree in computer science.

    Browse publications by this author
  • Aric Renzo

    Aric Renzo is a DevOps engineer based in Charlotte, North Carolina, and is a fan of all things geeky and open source. He has experience working on many open source and free software project deployments for clients based on OpenStack, Ansible, Docker, Chef, SaltStack, and Kubernetes. Aric is a member of the Ansible community and teaches courses on basic and advanced Ansible concepts. His past projects include work on data center deployments, network infrastructure automation, MongoDB NoSQL database architecture, and designing highly available OpenStack environments. Aric is a fan of anything to do with DevOps, automation, and making his workflow more efficient. Aric is a lifelong geek and a graduate of Penn State University in the information sciences and technology program. He is married to Ashley Renzo, an incredibly beautiful and talented science teacher in Gaston County, North Carolina.

    Browse publications by this author
  • Engy Fouda

    Engy Fouda is an author, freelance engineer, and journalist. Currently, she teaches SAS, Docker Fundamentals, Docker for Enterprise Developers, Docker for Enterprise Operations, and Kubernetes at several venues as a freelance instructor. She works as a freelance journalist and publishes her work at various media outlets. She holds two master’s degrees, one in journalism from Harvard University, Extension School, and another in computer engineering from Cairo University, Egypt. Moreover, she earned the Data Science Professional Graduate Certificate from Harvard University, Extension School. She has taught academically as a teacher assistant at the German University in Cairo and the American University in Cairo. She volunteers as the team lead for Momken Group (Engineering for the Blind), Egypt Scholars Inc. Also, she volunteers as a member-at-large and the newsletter editor of the IEEE Mid-Hudson Section.

    Browse publications by this author

Latest Reviews

(1 reviews total)
livre bien et tres lisible

Recommended For You

The Docker Workshop
Unlock this book and the full library for FREE
Start free trial
