Handling exceptions in Struts 2 Struts 2 provides a declarative exception handling mechanism that can be configured globally (for an entire package), or for a specific action. This capability can reduce the amount of exception handling code necessary inside actions under some circumstances, most notably when underlying systems, such as our services, throw runtime exceptions (exceptions that we don't need to wrap in a try/catch or declare that a method throws). To sum it up, we can map exception classes to Struts 2 results. The exception handling mechanism depends on the exception interceptor. If we modify our interceptor stack, we must keep that in mind. In general, removing the exception interceptor isn't preferred. Global exception mappings Setting up a global exception handler result is as easy as adding a global exception mapping element to a Struts 2 configuration file package definition and configuring its result. For example, to catch generic runtime exceptions, we could add the following: <global-exception-mappings><exception-mapping result="runtime"exception="java.lang.RuntimeException"/></global-exception-mappings> This means that if a java.lang.RuntimeException (or a subclass) is thrown, the framework will take us to the runtime result. The runtime result may be declared in an element, an action configuration, or both. The most specific result will be used. This implies that an action's result configuration might take precedence over a global exception mapping. For example, consider the global exception mapping shown in the previous code snippet. If we configure an action as follows, and a RuntimeException is thrown, we'll see the locally defined runtime result, even if there is a global runtime result. <action name="except1"class="com.packt.s2wad.ch09.examples.exceptions.Except1"><result name="runtime">/WEB-INF/jsps/ch9/exceptions/except1-runtime.jsp</result>... This can occasionally lead to confusion if a result name happens to collide with a result used for an exception. However, this can happen with global results anyway (a case where a naming convention for global results can be handy). Action-specific exception mappings In addition to overriding the result used for an exception mapping, we can also override a global exception mapping on a per-action basis. For example, if an action needs to use a result named runtime2 as the destination of a RuntimeException, we can configure an exception mapping specific to that action. <action name="except2"class="com.packt.s2wad.ch09.examples.exceptions.Except1"><exception-mapping result="runtime2"exception="java.lang.RuntimeException"/>... As with our earlier examples, the runtime2 result may be configured either as a global result or as an action-specific result. Accessing the exception We have many options regarding how to handle exceptions. We can show the user a generic "Something horrible has happened!" page, we can take the user back and allow them to retry the operation or refill the input form, and so on. The appropriate course of action depends on the application and, most likely, on the type of exception. We can display exception-specific information as well. The exception interceptor pushes an exception encapsulation object onto the stack with the exception and exceptionStack properties. While the stack trace is probably not appropriate for user-level error pages, the exception can be used to help create a useful error message, provide I18N property keys for messages (or values used in messages), suggest possible remedies, and so on. The simplest example of accessing the exception property from our JSP is to simply display the exception message. For example, if we threw a RuntimeException, we might create it as follows: throw newRuntimeException("Runtime thrown from ThrowingAction"); Our exception result page, then, could access the message using the usual property tag (or JSTL, if we're taking advantage of Struts 2's custom request processor): <s:property value="exception.message"/> The underlying action is still available on the stack—it's the next object on the value stack. It can be accessed from the JSP as usual, as long as we're not trying to access properties named exception or exceptionStack, which would be masked by the exception holder. (We can still access an action property named exception using OGNL's immediate stack index notation—[1].exception.) Architecting exceptions and exception handling We have pretty good control over what is displayed for our application exceptions. It is customizable based on exception type, and may be overridden on a per-action basis. However, to make use of this flexibility, we require a well-thought-out exception policy in our application. There are some general principles we can follow to help make this easier. Checked versus unchecked exceptions Before we start, let's recall that Java offers two main types of exceptions—checked and unchecked. Checked exceptions are exceptions we declare with a throws keyword or wrapped in a try/catch block. Unchecked exceptions are runtime exceptions or a subclass. It isn't always clear what type we should use when writing our code or creating our exceptions. It's been the subject of much debate over the years, but some guidelines have become apparent. One clear thing about checked exceptions is that they aren't always worth the aggravation they cause, but may be useful when the programmer has a reasonable chance of recovering from the exception. One issue with checked exceptions is that unless they're caught and wrapped in a more abstract exception (coming up next), we're actually circumventing some of the benefits of encapsulation. One of the benefits being circumvented is that when exceptions are declared as being thrown all the way up a call hierarchy, all of the classes involved are forced to know something about the class throwing the exception. It's relatively rare that this exposure is justifiable. Application-specific exceptions One of the more useful exception techniques is to create application-specific exception classes. A compelling feature of providing our own exception classes is that we can include useful diagnostic information in the exception class itself. These classes are like any other Java class. They can contain methods, properties, and constructors. For example, let's assume a service that throws an exception when the user calling the service doesn't have access rights to the service. One way to create and throw this exception would be as follows: throw new RuntimeException("User " + user.getId()+ " does not have access to the 'update' service."); However, there are some issues with this approach. It's awkward from the Struts 2's standpoint. Because it's a RuntimeException, we have only one option for handling the exception—mapping a RuntimeException to a result. Yes, we could map the exception type per-action, but that gets unwieldy. It also doesn't help if we need to map two different types of RuntimeExceptions to two different results. Another potential issue would arise if we had a process that examined exceptions and did something useful with them. For example, we might send an email with user details based on the above exception. This would amount to parsing the exception message, pulling out the user ID, and using it to get user details for inclusion in the email. This is where we'd need to create an exception class of our own, subclassed from RuntimeException. The class would have encapsulated exception related information, and a mechanism to differentiate between the different types of exceptions. A third benefit comes when we wrap lower-level exceptions—for example, a Spring-related exception. Rather than create a Spring dependency up the entire call chain, we'd wrap it in our own exception, abstracting the lower-level exception. This allows us to change the underlying implementation and aggregate differing exception types under one (or more) application-specific exception. One way of creating the above scenario would be to create an exception class that takes a User object and a message as its constructor arguments: package com.packt.s2wad.ch09.exceptions;public class UserAccessException extends RuntimeException {private User user;private String msg;public UserAccessException(User user, String msg) {this.user = user;this.msg = msg;}public String getMessage() {return "User " + user.getId() + " " + msg;}} We can now create an exception mapping for a UserAccessException (as well as a generic RuntimeException if we need it). In addition, the exception carries along with it the information needed to create useful messages: throw new UserAccessException(user,"does not have access to the 'update' service."); "Self-documenting" of code could be made even safer, in the sense of ensuring that it's only used in the ways in which it is intended. We could add an enum to the class to encapsulate the reasons the exception can be thrown, including the text for each reason. We'll add the following inside  our UserAccessException: public enum Reason {NO_ROLE("does not have role"),NO_ACCESS("does not have access");private String message;private Reason(String message) {this.message = message;}public String getMessage() { return message; }}; We'll also modify the constructor and getMessage() method to use the new Reason enumeration. public UserAccessException(User user, Reason reason) {this.user = user;this.reason = reason;}public String getMessage() {return String.format("User %d %s.",user.getId(), reason.getMessage());} Now, when we throw the exception, we explicitly know that we're using the exception class correctly (at least type-wise). The string message for each of the exception reasons is encapsulated within the exception class itself. throw new UserAccessException(user,UserAccessException.Reason.NO_ACCESS); With Java 5's static imports, it might make even more sense to create static helper methods in the exception class, leading to the concise, but understandable code: throw userHasNoAccess(user);

The central activity you'll be doing with your blog is adding posts. A post is like an article in a magazine; it's got a title, content, and an author (you). If a blog is like an online diary, then every post is an entry in that diary. A blog post also has a lot of other information attached to it, such as a date and categories. In this article, you will learn how to create a new post and what kind of information you can attach to it. Adding a simple post Let's review the process of adding a simple post to your blog. Whenever you want to do maintenance on your WordPress website, you have to start by logging in to the WP Admin (WordPress Administration panel) for your site. To get to the admin panel, just point your web browser to http://yoursite.com/wp-admin. Remember that if you have installed WordPress in a subfolder (for example, blog), then your URL has to include the subfolder (that is, http://yoursite.com/blog/wp-admin). When you first log into the WP Admin, you'll be at the Dashboard. The Dashboard has a lot of information on it. The very top bar, which I'll refer to as the top menu, is mostly dark grey and on the left, of course, is the main menu. The top menu and the main menu exist on every page within the WP Admin. The main section on the right contains information for the current page you're on. In this case, we're on the Dashboard. It contains boxes that have a variety of information about your blog, and about WordPress in general. The quickest way to get to the Add New Post page at any time is to click on the New Post link at the top of the page in the top bar (top menu). This is the Add New Post page: To quickly add a new post to your site, all you have to do is: Type in a title into the text field under Add New Post (for example, Making Lasagne). Type the text of your post in the content box. Note that the default view is Visual, but you actually have a choice of the HTML view as well. Click on the Publish button, which is at the far right. Note that you can choose to save a draft or view a preview of your post. In the following image, the title field, the content box, and the Publish button of the Add New Post page are highlighted: Once you click on the Publish button, you have to wait while WordPress performs its magic. You'll see yourself still on the Edit Post page, but now the following message has appeared telling you that your post was published and giving you a link to View post: If you go to the front page of your site, you'll see that your new post has been added at the top (newest posts are always at the top): Common post options Now that we've reviewed the basics of adding a post, let's investigate some of the other options on the Add New Post page. In this section we'll look at the most commonly used options, and in the next section we'll look at the more advanced options. Categories and tags Categories and tags are two similar types of information that you can add to a blog post. We use them to organize the information in your blog by topic and content (rather than just by, say, date), and to help visitors find what they are looking for on your blog. Categories are primarily used for structural organizing. They can be hierarchical. A relatively busy blog will probably have at least 10 categories, but probably not more than 15 or 20. Each post in this blog will likely have one to four categories assigned to it. For example, a blog about food might have these categories: Cooking Adventures, In The Media, Ingredients, Opinion, Recipes Found, Recipes Invented, and Restaurants. Tags are primarily used as shorthand for describing the topics covered in a particular blog post. A relatively busy blog will have anywhere from 15 to 30 tags in use. Each post in this blog will likely have three to ten tags assigned to it. For example, a post on the food blog about a recipe for butternut squash soup may have these tags: soup, vegetarian, autumn, hot, easy. Let's add a new post to the blog. This time, we'll give it not only a title and content, but also tags and categories. When adding tags, just type your list of tags into the Tags box on the right, separated by commas: Then click on the Add button. The tags you just typed in will appear below the text field with little xs next to them. You can click on an x to delete a tag. Once you've used some tags in your blog, you'll be able to click on the Choose from the most popular tags link in this box so that you can easily re-use tags. Categories work a bit differently than tags. Once you get your blog going, you'll usually just check the boxes next to existing categories in the Categories box. In this case, as we don't have any existing categories, we'll have to add one or two. In the Categories box on the right, click on the + Add New Category link. Type your category into the text field and click on the Add button. Your new category will show up in the list, already checked. Look at the following screenshot: If in the future you want to add a category that needs a parent category, select Parent category from the pull-down menu before clicking on the Add button. If you want to manage more details about your categories, move them around, rename them, assign parent categories, and assign descriptive text. You can do this on the Categories page, which we'll see in detail later in this article. Now fill in your title and content here: Click on the Publish button and you're done. When you look at the front page of your site, you'll see your new post on the top, your new category in the sidebar, and the tags and category (that you chose for your post) listed under the post itself: Adding an image to a post You may often want to have an image show up in your post. WordPress makes this very easy. Let's add an image to the post we just created. You can click on Edit underneath your post on the front page of your site to get there quickly. Alternatively, go back to the WP Admin, open Posts in the main menu, and then click on Edit underneath your new post. To add an image to a post, first you'll need to have that image on your computer. Before you get ready to upload an image, make sure that your image is optimized for the Web. Huge files will be uploaded slowly and slow down the process of viewing your site. You can re-size and optimize images using software such as GIMP or Photoshop. For the example in this article, I have used a photo of butternut squash soup that I have taken from the website where I got the recipe, and I know it's on the desktop of my computer. Once you have a picture on your computer and know where it is, follow these steps to add the photo to your blog post: Click on the little photo icon, which is next to the word Upload/Insert and below the box for the title: In the box that appears, click on the Select Files button and browse to your image. Then click on Open and watch the uploader bar. When it's done, you'll have a number of fields you can fill in: The only fields that are important right now are Title, Alignment, and Size. Title is a description for the image, Alignment will tell the image whether to have text wrap around it, and Size is the size of the image. As you can see, I've chosen the Right alignment and the Thumbnail size. Now click on Insert into Post. This box will disappear, and your image will show up in the post on the edit page itself: Now click on the Update Post button and go look at the front page of your site again. There's your image! You may be wondering about those image sizes. What if you want bigger or smaller thumbnails? You can set the pixel dimensions of your uploaded images and other preferences by opening Settings in the main menu and then clicking on Media. This takes you to the Media Settings page: Here you can specify the size of the uploaded images for: Thumbnail Medium Large If you change the dimensions on this page and click on the Save Changes button, only images you upload in the future will be affected. Images you've already uploaded to the site will have had their thumbnail, medium, and large versions created already using the old dimensions. Using the Visual editor versus the HTML editor WordPress comes with a Visual editor, otherwise known as a WYSIWYG editor (pronounced wissy-wig, which stands for What You See Is What You Get). This is the default editor for typing and editing your posts. If you're comfortable with HTML, you may prefer to write and edit your posts using the HTML editor—particularly useful if you want to add special content or styling. To switch from the rich text editor to the HTML editor, click on the HTML tab next to the Visual tab at the top of the content box: You'll see your post in all its raw HTML glory and you'll get a new set of buttons that lets you quickly bold and italicize text as well as add link code, image code, and so on. You can make changes and swap back and forth between the tabs to see the result. If you want the HTML tab to be your default editor, you can change this on your Profile page. Navigate to Users | Your Profile, and select the Disable the visual editor when writing checkbox. Drafts, timestamps, and managing posts There are three additional, simple but common, items I'd like to cover in this section: drafts, timestamps, and managing posts. Drafts WordPress gives you the option to save a draft of your post so that you don't have to publish it right away but can still save your work. If you've started writing a post and want to save a draft, just click on the Save Draft button at the right (in the Publish box), instead of the Publish button. Even if you don't click on the Save Draft button, WordPress will attempt to save a draft of your post for you about once a minute. You'll see this in the area just below the content box. The text will say Saving Draft... and then the time of the last draft saved: At this point, after a manual save or an auto-save, you can leave the Edit Post page and do other things. You'll be able to access all of your draft posts from the Dashboard or from the Edit Posts page. Timestamps WordPress will also let you alter the timestamp of your post. This is useful if you are writing a post today that you wish you'd published yesterday, or if you're writing a post in advance and don't want it to show up until the right day. The default timestamp will always be set to the moment you publish your post. To change it, just find the Publish box and click on the Edit link (next to the calendar icon and Publish immediately), and fields will show up with the current date and time for you to change: Change the details, click on the OK button, and then Publish your post (or save a draft). Managing posts If you want to see a list of your posts so that you can easily skim and manage them, you just need to go to the Edit Posts page in the WP Admin by navigating to Posts in the main menu. You'll see a detailed list of your posts, as seen in the next screenshot: There are so many things you can do on this page! You can: Choose a post to edit—click on a post title and you'll go back to the main Edit Post page Quick-edit a post—click on the Quick Edit link for any post and new options will appear right in the list, which will let you edit the title, timestamp, categories, tags, and more Delete one or more posts—click on the checkboxes next to the posts you want to delete, choose Delete from the Bulk Actions drop-down menu at the bottom, and click on the Apply button Bulk edit posts—choose Edit from the Bulk Actions menu at the bottom, click on the Apply button, and you'll be able to assign categories and tags to multiple posts, as well as edit other information about them You can experiment with the other links and options on this page. Just click on the pull-down menus and links, and see what happens.

Recipe 87: Creating an issue Page Bookmark IngredientsWeb Browser The issue queue is the central place of progress for Drupal modules. It serves as a place to find answers, patches, new ideas, and work on common concerns. Issues are referenced by number. On occasion, a web page will contain an issue queue number in text form rather than a full link to the issue. This recipe, once set up, simply saves the trouble of having to type drupal.org/node/ into the browser address bar. Just select the number and the bookmark will take you there. In Firefox add a new Bookmark onto the toolbar. Select Bookmarks | Organize Bookmarks | Bookmarks Toolbar | Organize | New Bookmark Set the Name to Drupal Issue and set the Location to the following: javascript:inum=escape(getSelection());location.href='http://www.drupal.org/node/'+inum. Visit a web page that contains an issue number and select the issue number text. For instance, try http://cvs.drupal.org/viewvc.py/drupal/contributions/modules/views/modules/views_taxonomy.inc. (Be sure to exclude the surrounding space and pound sign when selecting the number.) Click the Drupal Issue button in the bookmark toolbar. Recipe notes This bookmark approach may be replicated to visit a URL containing any selectable text. For instance, below is a variation to display all of your delicious bookmarks tagged with the selected text. (Delicious.com—also found at http://del.icio.us, is a wonderful online bookmark service.) Replace <ACCOUNTNAME> with your delicious.com account. Name: DeliciousLocation: javascript_tag=escape(getSelection());location.href='http://delicious.com/<ACCOUNTNAME>/'+tag Recipe 88: Searching the Views issue queue IngredientsWeb Browser In this recipe we look closely at how to search the Views issue queue. The lessons apply to all other Drupal projects as well. It is always a good idea to search the issue queue for related content before posting. Log on to drupal.org (if you are not already a member of the Drupal site, become a member). Basic Search Visit http://drupal.org/project/issues/views. At this main issue queue page you may search for text or filter by Status, Priority, Category, Version, or Component. These options are discussed in further detail below. You may also sort the table of issues by clicking on the table header. By default, the table is sorted by date. Advanced Search Go to the Views issue queue Advanced Search page. Visit the URL directly, at http://drupal.org/project/issues/search/views. From the project page (drupal.org/project/views), find the Issues block on the left, and click on the Advanced Search link. From the issue queue (drupal.org/project/issues/views), the Advanced Search Link appears under the title. There are a variety of routes to get there: Get to know the search options. Although there are ten form elements to choose, most users will routinely use just a few, leaving the other options blank. Search For (Routinely used): Enter search text. Use quotation marks to create a phrase. Assigned: This field is generally used by issue maintainers. Submitted by: This is most often used to find your own issues, though it could be used to see what other Drupal users are posting as well. Participant: This is also used to find your own posts. Note that Submitted by finds only the initial post by a user in the issue queue. Participant additionally includes responses to initial posts. Status: Leave blank to get all statuses. You may also select multiple options. For instance, you could select all issues designated as needs work, needs review, and reviewed & tested by the community. Scroll down the list and note Status filters such as closed issues, duplicates, issues that the maintainer won't fix, and features noted as by design. These are the statuses that are excluded if you select -Open Issues-. Priority: Leave blank to get all priorities. Category: Leave blank to get all categories. Version (Routinely used): A relative new option, 5.x issues saves you the trouble of having to Shift+click on each Drupal 5 release name. Component: The views module issue queue offers more component options than most modules. As a result, users may not always be familiar with properly assigning a component when they create an issue. A search of exposed filters components, for instance, may not find as many results as a text search of "exposed filters." Component can occasionally be a helpful selection, but is most often left blank. Issue Tags: These may be a challenge to search since few people add tag issues. This may become a more popular option in the future. Recipe notes Search ideas: Find all your posts by filling in your drupal.org user name under participant. Find patches by selecting all of the four patch statuses. Find all documentation issues connected to Views for Drupal 5.x. Go to another issue queue http://drupal.org/project/issues/search/<MODULENAME> and search for the word Views. From the module issue pages http://drupal.org/project/issues/<MODULENAME> you may also review module Statistics, and Subscribe to issues. Subscribe to your Own Issues (the default), None, or All Issues. I don't recommend the latter for the Views module as you will be setting yourself up for a deluge of email. Search across all projects at http://drupal.org/search/issues. Recipe 89: Posting an issue Posting a New issue If you are new to posting Drupal issues, consider just reading the issue queue for at least several days before posting. This will help you to get a sense of the culture of issue queue interaction. If you don't already have an account on drupal.org get one. Look for the User login block on the home page, and click on Create new account. Complete the steps to login. Search the issue queue before you post! (Recipe 88). If your topic already has an associated active issue, reply rather than posting a new issue.Also, before posting to the issue queue in a panic read the Drupal Troubleshooting FAQ http://drupal.org/Troubleshooting-FAQ. For instance, standard fare is to increase memory in the face of the White Screen of Death (WSOD) or to disable buggy modules by setting the status = 0 in the system table. Be sure to know which version of the module you're using. Is it the dev (development) version? Is it the latest recommended release? The version number can generally be found at http://YOURSITE.com/admin/build/modules. To start a new issue, go to http://drupal.org/project/issues/<MODULENAME> and click on Create a new issue. This directs the browser to: http://drupal.org/node/add/project-issue/<MODULENAME>. For the Views module, the link at http://drupal.org/node/add/project-issue/views offers guidance (in bold!) for posting. Read it! Much of it applies to Views 2 but it contains useful information for Views 1 users as well. Required fields for a new issue include Version, Component, Category, Title, and Description. Be thoughtful with these details. For instance, do not title your issue HELP??!! A much more useful description would be something like Missing taxonomy terms in filters. Priority should generally be left as normal. Critical is reserved for occasions then the module simply does not work. Responding to an existing issue You may also respond to an existing issue by selecting the Add New Comment link or one of the Reply links on an individual issue page. Another option is just to scroll down to the bottom of the issue page, and begin entering a response. Unlike some forum tools, in which replies are indented, all new comments are given a new comment number, and added to the bottom of the comments. When responding to an issue you may take a variety of actions: Change the Issue Title. In general, don't change this unless you have a very good reason (for instance, if the original title is misleading, or spelled wrong). Some people are used to forums where a response can have a different name as the original post. In the issue queue, changing the name when responding to an issue actually changes the name of the issue. This is generally best left untouched. Change the Project. A question that someone asks in the Views issue queue may be more appropriately managed in the issue queue for a different module. This is a rare change generally left to the maintainer of one of the two modules who will know in which issue queue a discussion belongs. Change the Version number, Component, Category, or Priority. These changes are rare (correcting the version number is probably the most common). When changes are made, they are noted in the post as shown below: Change Assign. Do not assign someone other than yourself to an issue. Assign yourself if you are sure that you will soon fix the issue. It is quite common to leave this as Unassigned. Change the Status. For instance: Mark an issue as a duplicate (always provide a pointer to the issue it duplicates). Note that a patch is reviewed and tested by the community. Post a question, patch, answer, or idea related to the issue in the Comment section. Open the Input format fieldset below the comment field to see what markup is available. Note the <code> tag, for instance (and remember to close it with a </code> tag). Attach a file. Recipe notes Remember that respondents and maintainers are volunteers. They are generally very busy people who want to help, but they do not have time to do free consulting. See the following pages for spirited discussions about issue queue etiquette: http://acko.net/blog/whats-wrong-with-drupal http://paul.leafish.co.uk/articles/drupal/on_subscribing_to_module_portingupdating_issues One discussion theme is the merit of simply sending the word subscribe to the issue queue. People sometimes do this so that they can track an issue—receiving an email alert each time something new is posted. On drupal.org it is possible to subscribe to a node only if you leave a comment, but most people prefer comments with substance. You may create functionality similar to the Drupal issue queue on your own site by installing the project, project_issue, and comment_upload modules.

Building a kiosk locator feature for your site Your company has just deployed 500 multi-purpose payment kiosks around the country, cash cows for the milking. Another 500 more are on the way, promising to bring in the big bucks for all the hardworking employees in the company. Naturally your boss wants as many people as possible to know about them and use them. The problem is that while the marketing machine churns away on the marvels and benefits of the kiosks, the customers need to know where they are located to use them. He commands you: "Find a way to show our users where the nearest kiosks to him are, and directions to reach them!" What you have is a database of all the 500 locations where the kiosks are located, by their full address. What can you do? Requirements overview Quickly gathering your wits, you penned down the following quick requirements: Each customer who comes to your site needs to be able to find the closest kiosk to his or her current location. He or she might also want to know the closest kiosk to any location. You want to let the users determine the radius of the search. Finding the locations of the closest kiosks, you need to show him how to reach them. You have 500 kiosks now, (and you need to show where they are) but another 500 will be coming, in 10s and 20s, so the location of the kiosks need to be specified during the entry of the kiosks. You want to put all of these on some kind of map. Sounds difficult? Only if you didn't know about web mashups! Design The design for this first project is rather simple. We will build a simple database application using Rails and create a main Kiosk class in which to store the kiosk information including its address, longitude, and latitude information. After populating the database with the kiosk information and address, we will use a geolocation service to discover its longitude and latitude. We store the information in the same table. Next, we will take the kiosk information and mash it up with Google Maps and display the kiosks as pushpins on the online map and place its information inside an info box attached to each pushpin. Mashup APIs on the menu In this article we will be using the following services to create a 'find closest' mashup plugin: Google Maps APIs including geocoding services Yahoo geocoding services (part of Yahoo Maps APIs) Geocoder.us geocoding services Geocoder.ca geocoding services Hostip.info Google Maps Google Maps is a free web-based mapping service provided by Google. It provides a map that can be navigated by dragging the mouse across it and zoomed in and out using the mouse wheel or a zoom bar. It has three forms of views—map, satellite and a hybrid of map and satellite. Google Maps is coded almost entirely in JavaScript and XML and Google provides a free JavaScript API library that allows developers to integrate Google Maps into their own applications. Google Maps APIs also provide geocoding capabilities, that is, they able to convert addresses to longitude and latitude coordinates. We will be using two parts of Google Maps: Firstly to geocode addresses as part of GeoKit's APIs Secondly to display the found kiosk on a customized Google Maps map Yahoo Maps Yahoo Maps is a free mapping service provided by Yahoo. Much like Google Maps it also provides a map that is navigable in a similar way and also provides an extensive set of APIs. Yahoo's mapping APIs range from simply including the map directly from the Yahoo Maps website, to Flash APIs and JavaScript APIs. Yahoo Maps also provides geocoding services. We will be using Yahoo Maps geocoding services as part of GeoKit's API to geocode addresses. Geocoder.us Geocoder.us is a website that provides free geocoding of addresses and intersections in the United States. It relies on Geo::Coder::US, a Perl module available for download from the CPAN and derives its data from the TIGER/Line data set, public-domain data from the US Census Bureau. Its reliability is higher in urban areas but lower in the other parts of the country. We will be using Geocoder.us as part of GeoKit's API to geocode addresses. Geocoder.ca Geocoder.ca is a website that provides free geocoding of addresses in the United States and Canada. Like Geocoder.us. it uses data from TIGER/Line but in addition, draws data from GeoBase, the Canadian government-related initiative that provides geospatial information on Canadian territories. We will be using Geocoder.ca as part of GeoKit's API to geocode addresses. Hostip.info Hostip.info is a website that provides free geocoding of IP addresses. Hostip.info offers an HTTP-based API as well as its entire database for integration at no cost. We will be using Hostip.info as part of GeoKit's API to geocode IP addresses. GeoKit GeoKit is a Rails plugin that enables you to build location-based applications. For this article we will be using GeoKit for its geocoding capabilities in two ways: To determine the longitude and latitude coordinates of the kiosk from its given address To determine the longitude and latitude coordinates of the user from his or her IP address GeoKit is a plugin to your Rails application so installing it means more or less copying the source files from the GeoKit Subversion repository and running through an installation script that adds certain default parameters in your environment.rb file. To install the GeoKit, go to your Rails application folder and execute this at the command line: $./script/plugin install svn://rubyforge.org/var/svn/geokit/trunk This will copy the necessary files to your RAILS_ROOT/vendor/plugins folder and run the install.rb script. Configuring GeoKit After installing GeoKit you will need to configure it properly to allow it to work. GeoKit allows you to use a few sets of geocoding APIs, including Yahoo, Google, Geocoder.us, and Geocoder.ca. These geocoding providers can be used directly or through a cascading failover sequence. Using Yahoo or Google requires you to register for an API key but they are free. Geocoder.us is also free under certain terms and conditions but both Geocoder.us and Geocoder.ca have commercial accounts. In this article I will briefly go through how to get an application ID from Yahoo and a Google Maps API key from Google. Getting an application ID from Yahoo Yahoo's application ID is needed for any Yahoo web service API calls. You can use the same application ID for all services in the same application or multiple applications or one application ID per service. To get the Yahoo application ID, go to https://developer.yahoo.com/wsregapp/index.php and provide the necessary information. Note that for this application you don't need user authentication. Once you click on submit, you will be provided an application ID. Getting a Google Maps API key from Google To use Google Maps you will need to have a Google Maps API key. Go to http://www.google.com/apis/maps/signup.html. After reading the terms and conditions you will be asked to give a website URL that will use the Google Maps API. For geocoding purposes, this is not important (anything will do) but to display Google Maps on a website, this is important because Google Maps will not display if the URL doesn't match. However all is not lost if you have provided the wrong URL at first; you can create any number of API keys from Google. Configuring evironment.rb Now that you have a Yahoo application ID and a Google Maps API key, go to environment.rb under the RAILS_ROOT/config folder. Installing GeoKit should have added the following to your environment.rb file: # Include your application configuration below # These defaults are used in GeoKit::Mappable.distance_to and in acts_as_mappable GeoKit::default_units = :miles GeoKit::default_formula = :sphere # This is the timeout value in seconds to be used for calls to the geocoder web # services. For no timeout at all, comment out the setting. The timeout unit is in seconds. # GeoKit::Geocoders::timeout = 3 # These settings are used if web service calls must be routed through a proxy. # These setting can be nil if not needed, otherwise, addr and port must be filled in at a minimum. If the proxy requires authentication, the username and password can be provided as well. GeoKit::Geocoders::proxy_addr = nil GeoKit::Geocoders::proxy_port = nil GeoKit::Geocoders::proxy_user = nil GeoKit::Geocoders::proxy_pass = nil # This is your yahoo application key for the Yahoo Geocoder # See http://developer.yahoo.com/faq/index.html#appid and http://developer.yahoo.com/maps/rest/V1/geocode.html GeoKit::Geocoders::yahoo = <YOUR YAHOO APP ID> # This is your Google Maps geocoder key. # See http://www.google.com/apis/maps/signup.html and http://www.google.com/apis/maps/documentation/#Geocoding_Examples GeoKit::Geocoders::google = <YOUR GOOGLE MAPS KEY> # This is your username and password for geocoder.us # To use the free service, the value can be set to nil or false. For usage tied to an account, the value should be set to username:password. # See http://geocoder.us and http://geocoder.us/user/signup GeoKit::Geocoders::geocoder_us = false # This is your authorization key for geocoder.ca. # To use the free service, the value can be set to nil or false. For usage tied to an account, set the value to the key obtained from Geocoder.ca # See http://geocoder.ca and http://geocoder.ca/?register=1 GeoKit::Geocoders::geocoder_ca = false # This is the order in which the geocoders are called in a failover scenario # If you only want to use a single geocoder, put a single symbol in the array. # Valid symbols are :google, :yahoo, :us, and :ca # Be aware that there are Terms of Use restrictions on how you can use the various geocoders. Make sure you read up on relevant Terms of Use for each geocoder you are going to use. GeoKit::Geocoders::provider_order = [:google,:yahoo] Go to the lines where you are asked to put in the Yahoo and Google keys and change the values accordingly. Make sure the keys are within apostrophes. Then go to the provider order and put in the order you want (the first will be tried; if that fails it will go to the next until all are exhausted): GeoKit::Geocoders::provider_order = [:google,:yahoo] This completes the configuration of GeoKit. YM4R/GM YM4R/GM is another Rails plugin, one that facilitates the use of Google Maps APIs. We will be using YM4R/GM to display the kiosk locations on a customized Google Map. This API essentially wraps around the Google Maps APIs but also provides additional features to make it easier to use from Ruby. To install it, go to your Rails application folder and execute this at the command line: $./script/plugin install svn://rubyforge.org/var/svn/ym4r/Plugins/GM/trunk/ym4r_gm During the installation, the JavaScript files found in the RAILS_ROOT/vendors/plugin/javascript folder will be copied to the RAILS_ROOT/public/javascripts folder. A gmaps_api_key.yml file is also created in the RAILS_ROOT/config folder. This file is a YAML representation of a hash, like the database.yml file in which you can set up a test, development, and production environment. This is where you will put in your Google Maps API key (in addition to the environment.rb you have changed earlier). For your local testing you will not need to change the values but once you deploy this in production on an Internet site you will need to put in a real value according to your domain.

Activating the Administration Interface The administration interface comes as a Django application. To activate it, we will follow a simple procedure that is similar to how we enabled the user authentication system. The admininistration application is located in the django.contrib.admin package. So the first step is adding the path of this package to the INSTALLED_APPS variable. Open settings.py, locate INSTALLED_APPS and edit it as follows: INSTALLED_APPS = ( 'django.contrib.auth', 'django.contrib.contenttypes', 'django.contrib.sessions', 'django.contrib.sites', 'django.contrib.admin', 'django.contrib.comments', 'django_bookmarks.bookmarks',) Next, run the following command to create the necessary tables for the administration application: $ python manage.py syncdb Now we need to make the administration interface accessible from within our site by adding URL entries for it. The administration application defines many views, so manually adding a separate entry for each view can become a tedious task. Therefore, Django provides a shortcut for this. The administration interface defines all of its URL entries in a module located at django.contrib.admin.urls, and we can include these entries in our project under a particular path by using a function called include(). Open urls.py and add the following URL entry to it: urlpatterns = ( # Admin interface (r'^admin/', include('django.contrib.admin.urls')),) This looks different from how we usually define URL entries. We are basically telling Django to retrieve all of the URL entries in the django.contrib.admin.urls module, and to include them in our application under the path ^admin/. This will make the views of the administration interface accessible from within our project. One last thing remains before we see the administration page in action. We need to tell Django what models can be managed in the administration interface. This is done by defining a class called Admin inside each model. Open bookmarks/models.py and add the highlighted section to the Link model: class Link(models.Model): url = models.URLField(unique=True) def __str__(self): return self.url class Admin: pass The Admin class defined inside the model effectively tells Django to enable the Link model in the administration interface. The keyword pass means that the class is empty. Later, we will use this class to customize the administration page, so it won't remain empty. Do the same to the Bookmark, Tag and SharedBookmark models; append an empty class called Admin to each of them. The User model is provided by Django and therefore we don't have control over it. Fortunately however, it already contains an Admin class so it's available in the administration interface by default. Next, launch the development server and direct your browser to http://127.0.0.1:8000/admin/. You will be greeted by a login page. Remember we need to create a superuser account after writing the database model. This is the account that you have to use in order to log in: Next, you will see a list of the models that are available to the administration interface. As discussed earlier, only models with a class named Admin inside them will appear on this page: If you click on a model name, you will get a list of the objects that are stored in the database under this model. You can use this page to view or edit a particular object, or to add a new one. The figure below shows the listing page for the Link model. The edit form is generated according to the fields that exist in the model. The Link form, for example, contains a single text field called Url. You can use this form to view and change the URL of a Link object. In addition, the form performs proper validation of fields before saving the object. So if you try to save a Link object with an invalid URL, you will receive an error message asking you to correct the field. The figure below shows a validation error when trying to save an invalid link: Fields are mapped to form widgets according to their type. Date fields are edited using a calendar widget for example, whereas foreign key fields are edited using a list widget, and so on. The figure below shows a calendar widget from the user edit page. Django uses it for date and time fields: As you may have noticed, the administration interface represents models by using the string returned by the __str__ method. It was indeed a good idea to replace the generic strings returned by the default __str__ method with more helpful ones. This greatly helps when working with the administration page, as well as with debugging. Experiment with the administration pages; try to create, edit and delete objects. Notice how changes made in the administration interface are immediately reflected on the live site. Also, the administration interface keeps track of the actions that you make, and lets you review the history of changes for each object. This section has covered most of what you need to know in order to use the administration interface provided by Django. This feature is actually one of the main advantages of using Django; you get a fully featured administration interface from writing only a few lines of code! Next, we will see how to tweak and customize the administration pages. And as a bonus, we will learn more about the permissions system offered by Django.

Structured Content Types Support for structured content is a key feature of OpenCms. Structured content types allow different templates to be used to re-skin a site, or to share content with other sites that have a different look. Structured content types are defined by creating XSD schemas and placing them into modules. Once a new content type has been defined, the Workplace Explorer provides a user interface to create new instances of the content and allows it to be edited. There are some sample content types and templates that come with the Template One group of modules. These content types are very flexible and allow a site to be built using them right away. However, they may not fit our site requirements. In general, site requirements and features will determine the design of the structured content types and templates that need to be developed. BlogEntry Content Type For designing a blog website it is required that the content type contains blog entries. The schema file for the BlogEntry content type looks like the following : <!-- ======================================================== Content definition schema for the BlogEntry type ========================================================== --> <!-- 1. Root Element --> <xsd:schema elementFormDefault="qualified"> <!-- 2. Define the location of the schema location --> <xsd:include schemaLocation="opencms://opencms-xmlcontent.xsd"/> <!-- 3. Root element name and type of our XML type --> <xsd:element name="BlogEntrys" type="OpenCmsBlogEntrys"/> <!-- 4. Definition of the type described above --> <xsd:complexType name="OpenCmsBlogEntrys"> <xsd:sequence> <xsd:element name="BlogEntry" type="OpenCmsBlogEntry" minOccurs="0" maxOccurs="unbounded"/> </xsd:sequence> </xsd:complexType> <!-- 5. Data field definitions --> <xsd:complexType name="OpenCmsBlogEntry"> <xsd:sequence> <xsd:element name="Title" type="OpenCmsString" minOccurs="1" maxOccurs="1" /> <xsd:element name="Date" type="OpenCmsDateTime" minOccurs="1" maxOccurs="1" /> <xsd:element name="Image" type="OpenCmsVfsFile" minOccurs="0" maxOccurs="1" /> <xsd:element name="Alignment" type="OpenCmsString" minOccurs="1" maxOccurs="1" /> <xsd:element name="BlogText" type="OpenCmsHtml" minOccurs="1" maxOccurs="1" /> <xsd:element name="Category" type="OpenCmsString" minOccurs="0" maxOccurs="10" /> </xsd:sequence> <!-- 6. locale attribute is required --> <xsd:attribute name="language" type="OpenCmsLocale" use="required"/> </xsd:complexType> <!—optional code section --> <xsd:annotation> <xsd:appinfo> <!-- Mappings allow data fields to be mapped to content properties --> <mappings> <mapping element="Title" mapto="property:Title" /> <mapping element="Date" mapto="attribute:datereleased" /> </mappings><!-- Validation rules for fields --> <validationrules> <rule element="BlogText" regex="!.*[Bl]og.*" type= "warning" message="${key.editor.warning.BlogEntry. dontallowblog|${validation.path}}"/> </validationrules> <!-- Default values for fields --> <defaults> <default element="Date" value="${currenttime}"/> <default element="Alignment" value="left"/> </defaults> <!-- user interface widgets for data fields --> <layouts> <layout element="Image" widget="ImageGalleryWidget"/> <layout element="Alignment" widget="SelectorWidget" configuration="left|right|center" /> <layout element="Category" widget="SelectorWidget" configuration="silly|prudent|hopeful|fearful| worrisome|awesome" /> <layout element="BlogText" widget="HtmlWidget"/> </layouts> <!-- UI Localization --> <resourcebundle name="com.deepthoughts.templates.workplace"/> <!-- Relationship checking --> <relations> <relation element="Image" type="strong" invalidate="node" /> </relations> <!-- Previewing URI --> <preview uri="${previewtempfile}" /> <!-- Model Folder for content models --> <modelfolder uri="/system/modules/com.deepthoughts.templates /defaults/" /> </xsd:appinfo> </xsd:annotation> </xsd:schema> The BlogEntry content type file is named as blogentry.xsd and it placed in the folder named schemas in modules. Designing a Custom Widget Referring to the highlighted code in BlogEntry content type schema file we can see that the category field is populated from a drop-down list provided by SelectorWidget. The SelectorWidget obtains its values from the static configuration string defined within the blog schema file. This design is problematic as we would like category values to be easily changed or added. Ideally, the list of category values should be able to be updated by site content editors. Fortunately, we can create our own custom widget to handle this requirement. An OpenCms widget is a Java class that implements the I_CmsWidget interface, located in the org.opencms.widgets package. The interface contains a number of methods that must be implemented. First there are some methods dealing with instantiation and configuration of the widget: newInstance: This returns a new instance of the widget. setConfiguration: This method is called after the widget has been initialized to configure it. The configuration information is passed as a string value coming from the declaration of the widget within the schema file of the content type using it. getConfiguration: This is called to retrieve the configuration information for the widget. Next, there are some methods used to handle the rendering. These methods are called by widget enabled dialogs that might be used in a structured content editor or an administration screen. The methods provide any Javascript, CSS, or HTML needed by the widget dialogs: getDialogIncludes: This method is called to retrieve any Javascript or CSS includes that may be used by the widget. getDialogInitCall: This method may return Javascript code that performs initialization or makes calls to other Javascript initialization methods needed by the widget. getDialogInitMethod: This method may return Javascript code containing any functions needed by the widget. getDialogHtmlEnd: This method is called at the end of the dialog and may be used to return an HTML or Javascript needed by the widget. getDialogWidget: This method returns the actual HTML and Javascript used to render the widget along with its values. getHelpBubble: This method returns the HTML for displaying the help icon relating to this widget. getHelpText: This method returns the HTML for displaying the help text relating to this widget. Lastly, there are some methods used to get and set the widget value: getWidgetStringValue: This method returns the value selected from the widget. setEditorValue: This method sets the value into the widget. All these methods have base implementations in the A_CmsWidget class. In most cases, the base methods do not need to be overridden. As such, we will not cover all the methods in detail. If it is necessary to override the methods, the best way to get an idea of how to implement them is to look at the code using them. All widgets are used in dialog boxes which have been enabled for widgets, by implementing the I_CmsWidgetDialog interface. There are two general instances of these dialogs, one is used for editing structured XML content, the other is found in any dialog appearing in the Administration View. The two classes implementing this interface are: org.opencms.workplace.CmsWidgetDialog org.opencms.workplace.editors.CmsXmlContentEditor The CmsWidgetDialog class is itself a base class, which is used by all dialogs found in the Administrative View. Before designing a new widget, it is useful to examine the existing widget code. The default OpenCms widgets can be found in the org.opencms.widgets package. All the widgets in this package subclass the A_CmsWidget class mentioned earlier. Often, a new widget design may be subclassed from an existing widget. Designing the Widget As mentioned earlier, we would like to have a widget that obtains its option data values dynamically rather than from a fixed configuration string value. Rather than create a widget very specific to our needs, we will use a flexible design where the data source location can be specified in the configuration parameter. The design will allow for other data sources to be plugged into the widget. This way, we can use a single widget to obtain dynamic data from a variety of sources. To support this design, we will use the configuration parameter to contain the name of a Java class used as a data source. The design will specify a pluggable data source through a Java interface that a data source must implement. Furthermore, a data source can accept parameters via the widget configuration string. With this design, an example declaration for a widget named CustomSourceSelectWidget would look like this: <layout element="Category" widget="CustomSourceSelectWidget" configuration="source='com.widgets.sources.MySource'| option1='some config param'| option2='another param'" /> This declaration would appear in the schema of a content type, using the widget as covered earlier. The configuration parameter consists of name/value pairs, delimited by the vertical bar character. Each name/value pair is separated by the equal to sign and the value is always enclosed in single quotes. The design requires that at least the source parameter be specified. Additional parameters will depend upon the specific data source being used. The example declaration specifies that the data field named Category will use the CustomSourceSelectWidget widget for its layout. The configuration parameter contains the name of the Java class to be used to obtain the data source. The data source will receive the two parameters named option1 and option2 along with their values. Next, lets move on to the code to see how this all gets implemented.

Rich user interfaces and AJAX Rich user interfaces can be achieved by using a combination of dynamic HTML elements such as HTML and JavaScript. However, the scope of such an interface is limited to client-side behavior and has minimal functional implications due to the lack of server-side interactions. The power of AJAX is in its capability to provide even richer interface by supplementing its dynamic user interface with powerful functionality through seamless server-side invocation power. AJAX allows individual user interface components to communicate with the server and exchange data without the need for refreshing the whole screen. This is achieved using a process called Web Remoting. Web remoting, or the process of communicating between a browser and a server, can be performed in multiple ways. The popular approaches that are supported by today's browsers are IFrames and XMLHttpRequest. Dynamic HTML can be complemented with either of these methods to generate AJAX functionality. Asynchronous JavaScript and XML or AJAX Asynchronous communication between the client and the server forms the backbone of AJAX. Although an asynchronous request-response method can provide significant value in the development of rich functionality by itself, the results are lot more pronounced when used in conjunction with other functional standards such as CSS, DOM, JavaScript, and so on. The predominant popularity of AJAX stems from such usage. Client-server communication can be achieved either by using IFrames, or by using the supported JavaScript function called XMLHttpRequest(). Due to certain limitations of IFrames, XMLHttpRequest has gained a lot more acceptance. While IFrame can also be an effective option for implementing AJAX-based solutions, in this article, we will focus largely on an XMLHttpRequest-based implementation. The primary advantage of using AJAX-based interfaces is that the update of content occurs without page refreshes. A typical AJAX implementation using XMLHttpRequest happens as described in the following steps: An action on the client side, whether this is a mouse click or a timed refresh, triggers a client event An XMLHttpRequest object is created and configured The XMLHttpRequest object makes a call The request is processed by a server-side component The component returns an XML (or an equivalent) document containing the result The XMLHttpRequest object calls the callback() function and processes the result The HTML DOM is updated with any resulting values The following simplified image illustrates the high-level steps involved in an AJAX request flow. The portal client page gets served to the client browser, where the execution of JavaScript functions takes place. The following example illustrates the initialization of the request object and its basic use: if (window.XMLHttpRequest) // Object of the current window { // for non-IE browsers request = new XMLHttpRequest();}else if (window.ActiveXObject){ // For IE request = new ActiveXObject("Microsoft.XMLHTTP");}request.onreadystatechange = function(){ // do something to process response};if (request.readyState == 4){ // everything received, OK. Do something now..} else { // wait for the response to come to ready state} In subsequent sections, we will modify our sample portal application by adding AJAX functionality to one of the portlets. AJAX in JBoss portal AJAX has gained tremendous popularity in the traditional web application development world due to the richness and agility that it brings to user interfaces. Portals, such as JBoss portal, can also gain significantly from AJAX, in terms of implementation of both behavior and functionality. Refreshing the page content tends to be a time-consuming and resource-intensive process. Every request that a user makes to the server, either by clicking on submissions or links, results in the portal calling doView() and a series of methods for each portlet on the page, one at a time, before aggregating the results and sending the response back to the browser. Using AJAX allows for simultaneous submissions of request in their own independent threads of execution, resulting in an asynchronous and parallel execution. The portal page refresh overhead is now only as long as the time consumed by the slowest portlet. The response times observed by the user improve dramatically, while at the same time allowing more functionality on pages. Architecturally, vertical independent stacks of execution facilitate cleaner and more modular designs and implementations. AJAX can be implemented in JBoss portal in the following two ways: Using in-built support for asynchronous portal behavior by using configurations Writing custom behavior in portlets and page content by using AJAX libraries The in-built support for asynchronous behavior comprises of support for both markup and content. The markup support is in layouts and renderers, while the content is supported through configurable drag-drop and partial page refresh behavior. Almost all of the AJAX behavior supported by JBoss portal relates to asynchronous communication between the client and the portal servers. The only exception is the drag-drop behavior, which is largely view functionality. As far as the custom development within a portlet is concerned, the options are innumerable. A portlet can be developed using many advanced frameworks that are available as either commercial or open source products. For example, user interface features such as drag-and-drops, grids, accordion selects, pull-down menus, content refresh, and so on can be implemented by using third-party libraries including Scriptaculous, JQuery, and DOJO, which have gained a strong following among developers, even on traditional applications and non-portal platforms. In the next few sections, we will walk through an example of AJAX-enabled portlets using one of these libraries, developed on the JBoss portal platform. However, before we go into the implementation, let's step back and understand the limitations that the current portlet specification– JSR-286–addresses, facilitating easy development of AJAX portlets. JSR-168 AJAX limitations Before we look at the features and options provided by the new specification, let's look at how traditional JSR-168 portlets functioned. As shown in the following figure, the "Action" request invoked the processAction method on the server, which implemented controller logic to route it to the correct view. The "Render" request then invokes the render method to serve the content page to the browser. However, when the portlet uses AJAX and needs to makes an asynchronous call, it has to use ActionURL. This in turn follows the standard processing when processAction processes the request and the render method creates the user interface. However, now when the user interface is sent back, the portal injects some other markup and recreates the entire portal page. Hence, instead of refreshing a snippet of user interface, we end up refreshing the whole page. The issues with JSR-168 and AJAX can be broadly summarized as follows: ActionURL and RenderURL point to a portal, and not to a portlet. When we point to a portal, the result is a complete portal page, even if the portlet generates only a snippet. As per the specification, the user interface rendered by the portlet is supposed to be aggregated with some other markup and served back to the browser. When more than only the necessary data and markup is sent back, the JavaScript code on the client side that makes the asynchronous call cannot process the request. Asynchronous calls are made through XMLHttpRequest, which is designed to consume and process the complete response from the portlet. With the portal processing the request in between, XMLHttpRequest cannot consume the original response for processing. This defeats the purpose and value of using asynchronous calls to the server, and we end up with traditional full page refreshes. There were obviously a few workarounds to this. The most common practice was to serve the request from outside of the portal container into the web container. The idea is that the AJAX call can still be made to ActionURL, but the render function copies or shares its context with a traditional Java servlet in the web container of the application server. The AJAX call can now make a direct request to the servlet and get an asynchronous response from the servlet with no interference from the portal. There was a need for a better solution, and one that was incorporated as part of the specification. JSR-286, the latest portlet specification, addresses these problems.

Although there are a handful of controls that we can add to this custom audio player, this section will demonstrate the concept by adding the most basic control for multimedia, which is the play and pause buttons. Adding a play and pause button To begin, we will need to first move and resize our title field within our Flash application, so that it can hold more text than "Hello World". We can then make room for some new controls that will be used to control the playback of our audio file. Again, the design of each of these components is subjective, but what is important is the MovieClip instance hierarchy, which will be used within our ActionScript code. Before we begin, we will need to create a new layer in our TIMELINE that will be used to place all AudioPlayer objects. We will call this new layer player: Creating a base button MovieClip Our base button will simply be a rounded rectangle, which we will then add some gradients to, so as to give it depth. We can do this by first creating a rounded rectangle with a vertical linear gradient fill as follows: We can now give it some very cool depth by adding a smaller rounded rectangle within this one, and then orient the same gradient horizontally. An easy way to do this is to copy the original shape and paste it as a new shape. Once we have a new copy of our original rounded rectangle, we can navigate to Modify | Shape | Expand fill, where we will then select Inset, change our Distance to 4px, and then click on OK. After doing this, you will realize how such a simple contrast in gradients can really bring out the shape. After we have our new button shape, we will then need to create a new MovieClip, so that we can reuse this button for both the play and pause buttons. To do this, simply select both the rounded rectangle regions, and then choose Modify | Convert to Symbol in the Flash menu. We are going to call this new movie clip mcButton. Now that we have a base button MovieClip, we can now add the play and pause symbols to complete the play and pause buttons. Adding the PlayButton movie clip The first button that we will create is the play button, which simply consists of a sideways triangle (icon) with the button behind it. To do this, we will first create a new movie clip that will hold the button we just created, and the play icon. We can do this by first clicking on the mcButton movie clip, and then creating a new movie clip from that by selecting Modify | Convert to Symbol. We will call our new movie clip mcPlayButton. What we are really doing here is creating a parent movie clip for our mcButton, which will allow us to add new specific elements. For the play button, we simply want to add a play symbol. To do this, we first want to make sure that we are within the mcPlayButton movie clip by double-clicking on this symbol, so that our breadcrumb at the top of the stage looks as follows: Our next task is to modify our timeline within this movie clip so that we can separate the icon from the button. We can do this by creating two new layers within our timeline, called button (which will hold our button) and icon (which we will create in the next section). We are now ready to start drawing the play icon. Drawing a play icon To draw a Play icon, we will need to first select the PolyStar Tool by clicking and holding on the tool until you can select the PolyStar Tool. This tool will allow us to create a triangle, which we will use for the play icon in our play button. But before we can start drawing, we need to first set up the PolyStar Tool so that it will draw a triangle. We can do this by clicking on the Options button within the Properties tab, which will then bring up a dialog, where we can tell it to draw a polygon with three sides (triangle). After we click on OK, we will then need to change the fill color of this triangle, so that it is visible on our button. We will just change the fill color to Black. We can then move our cursor onto the stage where the button is, and then draw our triangle in the shape of a play button icon. Remember, if you do not like the shape of what you made, you can always tweak it using the transform tool. When we are done, we should have something that resembles a play button! Our next task is to create a pause button. Since we have already created the play button, which is similar to the pause button except for the icon, we can use a handy tool in Flash that will let us duplicate our play button, and then modify our duplication for the pause button icon. Creating a pause button from the play button In order to create our pause button, we will first need to duplicate our play button into a new movie clip, where we can change the icon from play to pause. To do this, we will first direct our attention to the library section of our Flash IDE, which should show us all of the movie clips that we have created so far. We can find the LIBRARY by clicking on the button on the right-hand side of our workspace. To create a duplicate, we will now right-click on the mcPlayButton movie clip, and then select the option Duplicate. This will then bring up a dialog very similar to the dialog when we created new symbols, but this time, we are defining a new movie clip name that will serve as a duplicate for the original one. We will call our new movie clip duplicate mcPauseButton. Now that we have created our duplicate movie clip, the next task is to change the icon within the pause button. We can do this by opening up our mcPauseButton movie clip by double-clicking on that name within the Library. At this point, we can now change the icon of our pause button without running any risk of also modifying the play button (since we created a duplicate). When we are done, we should have a complete pause button. We now have play a nd pause buttons that we will use to link to our AudioPlayer class.

AJAX support for markup Special tags are added to layout JSPs that facilitate the placement of AJAX features on a page. Similarly, renderers are used to interpret the tags and to render AJAX-driven content. The obvious advantage is the in-built support for the auto-creation and control of AJAX components on portal pages. Layout markup Layouts provide a structure for the creation and serving of portal pages. Layouts aggregate all of the content generated by the portlet, based on region and order, merge them with some additional content provided by the portal, and serve a response back to the user. By providing support for AJAX in the layout, helps facilitate the easy development and implementation of dynamic functionality in pages, with minimal effort. Layout markup is implemented using JSP tags. The JBoss JSP tag library, portlet-layout.tld, offers tags that facilitate the implementation of AJAX features in layouts. A JSP layout can be changed to an AJAX-supported page simply by adding references to the tags. Hence, using tags also helps with the easy implementation of features. The following is the layout page from the default portal generic layout ${JBOSS_PORTAL_HOME}serverdefaultdeployjboss-portal.sarportal-core.warlayoutsgenericindex.jsp, and shows AJAX support implemented as tags: <%@ page import="org.jboss.portal.server.PortalConstants" %><%@ taglib uri="/WEB-INF/theme/portal-layout.tld" prefix="p" %><!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN""http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd"><html ><head> <title><%= PortalConstants.VERSION.toString() %></title> <meta http-equiv="Content-Type" content="text/html;"/> <!-- to correct the unsightly Flash of Unstyled Content. --> <script type="text/javascript"></script> <!-- inject the theme, default to the Renaissance theme if nothing is selected for the portal or the page --> <p:theme themeName="renaissance"/> <!-- insert header content that was possibly set by portlets on the page --> <p:headerContent/> <%@include file="/layouts/common/modal_head.jsp"%></head><body id="body"><p:region regionName='AJAXScripts' regionID='AJAXScripts'/><%@include file="/layouts/common/modal_body.jsp"%><div id="portal-container"> <div id="sizer"> <div id="expander"> <div id="logoName"></div> <table border="0" cellpadding="0" cellspacing="0" id="header-container"> <tr> <td align="center" valign="top" id="header"> <!-- Utility controls --> <p:region regionName='dashboardnav' regionID='dashboardnav'/> <!-- navigation tabs and such --> <p:region regionName='navigation' regionID='navigation'/> <div id="spacer"></div> </td> </tr> </table> <div id="content-container"> <!-- insert the content of the 'left' region of the page, and assign the css selector id 'regionA' --> <p:region regionName='left' regionID='regionA'/> <!-- insert the content of the 'center' region of the page, and assign the css selector id 'regionB' --> <p:region regionName='center' regionID='regionB'/> <hr class="cleaner"/> </div> </div> </div></div><div id="footer-container" class="portal-copyright">Powered by <a class="portal-copyright" href="http://www.jboss.com/products/jbossportal">JBoss Portal</a><br/></div><p:region regionName='AJAXFooter' regionID='AJAXFooter'/></body></html> Renderer markup The portal combines the renderers and layouts to generate the final content. Enabling support for AJAX in the renderer just requires adding the statement <ajax-enabled>true</ajax-enabled> to the renderer descriptor. The following example, at {JBOSS_PORTAL_HOME}serverdefaultdeployjbossportal.sarportal-core.warWEB-INFlayoutportal-renderSet.xml, shows the renderer configuration of the emptyRenderer RenderSet for AJAX support: <renderSet name="emptyRenderer"> <set content-type="text/html"> <ajax-enabled>true</ajax-enabled> <region-renderer> org.jboss.portal.theme.impl.render.empty.EmptyRegionRenderer </region-renderer> <window-renderer> org.jboss.portal.theme.impl.render.empty.EmptyWindowRenderer </window-renderer> <portlet-renderer> org.jboss.portal.theme.impl.render.empty.EmptyPortletRenderer </portlet-renderer> <decoration-renderer> org.jboss.portal.theme.impl.render.empty.EmptyDecorationRenderer </decoration-renderer> </set></renderSet> AJAX support for content Whereas the layout and renderer contribute to AJAX behavior at the markup level, JBoss portal's support for object-level configuration can be leveraged to provide AJAX support at the page level. The object property inherits a configured behavior from its parent. Currently, two features are offered for AJAX-driven content: Drag and drop: Facilitates easy movement of portlets to various locations on screen using the mouse. Screen Refresh: Allows sub-components of pages or individual portlets to refresh themselves without refreshing the entire page. Drag-and-Drop As the name suggests, this feature is triggered by a user action, and allows a portlet to detach itself from a specific location on the page and move to a different location on the page. This allows for the customization of the user interface to a form that is most convenient to the user. The dynamic view behavior comes from a combination of DHTML and asynchronous server-side communication. Due to the nature of the behavior, drag-and-drop capability is available and effective only in dashboard pages where there are multiple portlets and the page layout can be personalized. The feature is allowed by default on the dashboard, but can be turned off by setting the value in the configuration file to false. The following is a snippet of the default object configuration file ( jboss-portal.sar/conf/data/default-object.xml ), which illustrates the enabling of the feature. Please note that this can also be configured using the administration console user interface of the JBoss server. <deployment> <if-exists>keep</if-exists> <context> <context-name>dashboard</context-name> <properties> ... <!-- Set the dnd property --> <property> <name>theme.dyna.dnd_enabled</name> <value>true</value> </property> ... </properties> </context></deployment> <name>theme.dyna.dnd_enabled</name> value enables or disables the drag-and-drop behavior. Partial content refresh One of the most expensive processes in a portal is the refresh of portlets when the page is generated. For every user action on a page, the portal calls all of the portlet methods in a serial, but non-specific order, which involves a significant amount of time and server-side processing. Partial content refresh support mitigates these issues to a large extent with an effective use of client-server asynchronous communication. When the state of a single portlet changes, a partial content refresh facilitates the update and refresh of only that portlet, instead of for all of the portlets on the page. This prevents the regeneration of the whole page and the initialization of all of the portlets on the page. The following image illustrates the partial content refresh flow:   The partial refresh capability is compatible with the JSR-168 portlet API, which allows for programmatic update of portlet states during runtime. Partial refreshes can be enabled through portal object configuration or through configuration at the default server level.

Add basic tagging Tagging is a loose, community-based way of categorizing content. It allows a group of people to categorize by consensus. Anyone is able to tag a piece of content. The more a tag is used, the more meaning it takes on and the more widely used it becomes. This categorization by consensus has been dubbed as folksonomy (http://en.wikipedia.org/wiki/Folksonomy) So let's get started by building our tagging support. Tagging domain model When implementing tagging in our system, we need to consider the following: We must be able to have many tags in our system We must be able to associate a single tag with many different files and messages We need to make sure that new domain objects can be easily tagged without having to change the tagging logic We want to know when a domain object was tagged To satisfy these requirements, we need to create the following new domain classes: Tag—to store the name of the tag. There is one instance of this class per unique tag name in the application. Tagger—to store the relationship from domain objects to a tag. This allows us to store the date a tag was added to a domain object. Let's create these domain classes and then write a test to prove that we can tag a message using this tagging structure. The Tag class We are going to separate the tagging classes out from our application domain classes. Create a folder under grails-app/domain called tagging. This is where we will put the domain model to implement tagging. Our Tag class is extremely simple and holds only a name property: package taggingclass Tag { String name static constrains = { name( blank: false ) } } The Tagger class The next class that we are going to create is the Tagger class. In relational terms, this object represents a link table between a Tag and any other domain class. It is important that the relationship between tagged domain classes and the Tagger relationship class is unidirectional. By this, we mean the domain classes are allowed to know that they can be tagged, but tags do not know which domain classes can be tagged, otherwise every tagged domain class would need a special relationship class. Create the Tagger class as a domain class in the tagging package as follows: package taggingclass Tagger { Tag tag static constraints = { tag( nullable: false ) }} The basics of our tagging model are complete! We now need some logic to allow tags to be created. Create a new service class called TagService under grails-app/services/tagging, as shown below: package taggingclass TagService { boolean transactional = true def createTagRelationships(String spaceDelimitedTags) { return spaceDelimitedTags?.split(' ')?.collect { tagName -> createTagRelationship( tagName ) }}def createTagRelationship(String tagName) {def tag = Tag.findByName(tagName)?: new Tag(name: tagName).save()return new Tagger( tag: tag )} This service provides two utility methods to create new relationships by tag name or by a space delimited string of tag names. The important behavior of these two methods is that they do not allow duplicate tags to be created in the application. If a tag name already exists, the tag will be retrieved from the database and used as the tag in the relationship. Notice that the createTagRelationships method is using the collect method to simplify what would normally take a few more lines of code to achieve. The collect method is dynamically added to any object that can be iterated over. For example, collections, arrays, strings and so on. It takes a closure as its argument and executes this closure for each item in the collection. The return value from each execution of the closure is added to a new collection that the collect method builds up and then returns once it has finished iterating the original collection. In createTagRelationship, we are using another neat language feature of Groovy called the "Elvis operator". It is named so, as it looks like Elvis' hair style. This is a shorter version of the normal Java ternary operator. If the operand being checked is true then the checked operand will be returned as the default, otherwise the alternative operand will be used. So in our example:     def tag = Tag.findByName(tagName) ?: new Tag(name: tagName).save() If a tag can be found from the database then it is used, otherwise a new tag is created. Tagging a message The next step is to allow a message to be tagged. Write some integration tests to make sure the relationships are working before using tagging in the application. In the folder test/integration/app, create the file TaggableIntegrationTests.groovy and add the following code: package appimport tagging.Tagclass TaggableIntegrationTest extends GroovyTestCase { User flancelot protected void setUp() { flancelot = User.findByUsername('flancelot') Tag.list().each { it.delete() } Message.list().each { it.delete() } }} The code above sets up the test data needed to create messages and associate tags to messages. Remember that the flancelot user already exists because it was created by the BootStrap class. The first test will determine that we can add tags to a message and then retrieve messages by tag. Add the following test method to your test class: void testCanRetrieveMessagesByTags() { Message message = new Message(user: flancelot, title: 'tagged', detail: "I've been tagged.").save(flush: true) Message secondMessage = new Message(user: flancelot, title: 'other tagged', detail: "I've been tagged.").save(flush: true) message.addTag('urgent') message.addTag('late') secondMessage.addTag('urgent') def taggedMessages = Message.withTag( 'urgent' ) assertEquals(2, taggedMessages.size()) assertEquals(2, Tag.list().size()) def secondMessages = Message.withTag( 'late' ) assertEquals(1, secondMessages.size()) assertEquals(2, Tag.list().size())} The test above does the following: Creates two new messages Adds the urgent tag to both messages Adds the late tag to one message Checks if we can retrieve both messages by using the urgent tag Checks if only one message is returned for the late tag Notice that the highlighted lines of code have not been implemented yet. To allow this test to pass, we need to add the following methods to the Message domain class: addTag—instance method to allow a message to be tagged withTag—class method to retrieve all messages with a particular tag Add the following method to the Message class (don't forget to import tagging.Tagger): def addTag(String tagName) { tags = (tags)?:[] tags << tagService.createTagRelationship( tagName )} This method simply delegates the creation of the tag relationship off to the TagService class, and then stores the relationship in the tags list. Add the following method to the Message class that retrieves all messages with a given tag name: def static withTag(String tagName) { return Message.withCriteria { tags { tag { eq('name', tagName ) } } }} This method must be static on the Message class, as it is used to load message instances for a given tag. We do not want to have to instantiate a message before we can perform the search. Before running the test, you will notice both of these new methods assume that there is a property on the Message class called tags. This has not yet been created. We need to create a one-to-many relationship from Message to Tagger that will allow messages to be tagged. We also need to inject the TagService into new instances of the Message class so the work for creating a new tag relationship can be delegated. Add the relationship to the Message class and inject TagService as shown below: class Message { def tagService static hasMany = [tags:Tagger] ...} Now we can run our tests by entering the following on the command line: grails test-app We should see some output in the command line similar to: Running test app.TaggableTest... testCanRetrieveMessagesByTags...SUCCESS Tagging a file Now that we have implemented tagging for messages, we need to make tagging available for files. Currently the logic for creating and fetching tags is in the Message domain class. We need to extract this logic so the File domain class can reuse it. It's time to look at how GORM supports inheritance. GORM inheritance The GORM supports inheritance of domain classes by default through the underlying Hibernate framework. Hibernate has a number of strategies for handling inheritance and Grails supports the following two: Table-per-hierarchy—this strategy creates one database table per inheritance hierarchy. This is the default strategy in Grails. Table-per-subclass—this strategy creates a database table for each subclass in an inheritance hierarchy and treats the inheritance (is a) relationship as a foreign key (has a) relationship. Taking our domain as an example, we have two classes. They are Message and File. We are going to make them both extend a super class Taggable, which will handle all of our tagging logic and state. Table-per-hierarchy If we were to choose the table-per-hierarchy strategy, we would end up with one table called Taggable that contained the data for both Message and File. The database structure would look something like: The interesting side-effect of this approach is that all of the fields to be persisted must be nullable. If a File is created and persisted, it is obviously not possible for the fields from Message to be populated. Table-per-subclass By using the table-per-subclass strategy, we would keep two separate tables called Message and File, and both would have the tags relationship inherited from Taggable. So the Message table will look like: We can see in the diagram above that the Message and File tables have remained separate and a table representing the superclass Taggable has been created, which the subclass tables have foreign key relationships to. In the table-per-subclass strategy, a table must exist to represent the inheritance (is a) relationship. We are going to follow the table-per-subclass strategy so that we can retain database level data integrity. The default behavior for GORM is to use the table-per-hierarchy strategy. To override this we must use the mapping property: static mapping = { tablePerHierarchy false}

Create web site project and add LinqDataSource control Open Visual Studio 2008 from its shortcut on the desktop. Click File | New | Web Site...(or Shift+Alt+N) to open the New Web Site window. Change the default name of the site to a name of your choice (herein LinqDemo)on your local web server as shown. Make sure you are creating a .NET Framework 3.5 web site as shown here. Drag and drop a LinqDataSource control from Toolbox|Data shown in the next figure on to the Default.aspx This creates an instance of the control LinqDataSource1 as shown. The figure also shows the smart tasks of this control as shown. Create a data context for the LinqDataSource control In order to use this control you also need to create a data context. Right click the localhost web site and choose Add New Item...to open the Add New Item - http://localhost/ LinqDemo window as shown. In the Visual Studio installed templates highlight Linq to SQL Classes. Change the default name from DataClasses.dbml to a name of your choosing. Herein MyDC.dbml. Click Add. This pops-up a Microsoft Visual Studio warning message as shown. The preferred location for this file is in the App_Code folder of your project as suggested here. Click on Yes. This adds a MyDC.dbml file to APP_Code folder as shown. MyDC.dbml consists of two components MyDC.dbml and MyDC.designer.vb to the App_Code folder as shown . Double click the MyDC.dbml node in the APP_Code folder. This opens the ObjectRelational Designer and the designer surface with two panes as shown. Read the instructions in the windows. In the left pane you can drag and drop items from the Server Explorer in Visual Studio to create the appropriate classes and in the right pane you can drag and drop stored procedures. In this article we will be looking at just creating classes from table objects.

Accordion's structure Let's take a moment to familiarize ourselves with what an accordion is made of. Within the outer container is a series of links. These links are the headings within the accordion and each heading will have a corresponding content panel, or drawer as they are sometimes referred to, which opens when the heading is clicked. The following screenshot shows these elements as they may appear in an accordion: It's worth remembering that when using the accordion widget, only one content panel can be open at any one time. Let's implement a basic accordion now. In a blank page in your text editor, create the following page: <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd"><html lang="en"> <head> <meta http-equiv="Content-Type" content="text/html; charset=utf-8"> <title>jQuery UI Accordion Widget Example 1</title> </head> <body> <ul id="myAccordion"> <li> <a href="#">Header 1</a> <div>Wow, look at all this content that can be shown or hidden with a simple click!</div> </li> <li> <a href="#">Header 2</a> <div>Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Aenean sollicitudin. Sed interdum pulvinar justo. Nam iaculis volutpatligula. Integer vitae felis quis diam laoreet ullamcorper. Etiam tincidunt est vitae est. Ut posuere, mauris at sodales rutrum, turpis tellus fermentum metus, ut bibendum velit enim eu lectus. Suspendisse potenti. </div> </li> <li> <a href="#">Header 3</a> <div>Donec at dolor ac metus pharetra aliquam. Suspendisse purus. Fusce tempor ultrices libero. Sed quis nunc. Pellentesque tincidunt viverra felis. Integer elit mauris, egestas ultricies, gravida vitae, feugiat a, tellus.</div> </li> </ul> <script type="text/javascript" src="jqueryui1.6rc2/jquery-1.2.6.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.core.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.accordion.js"></script> <script type="text/javascript"> //function to execute when doc ready $(function() { //turn specified element into an accordion $("#myAccordion").accordion(); }); </script> </body></html> Save the file as accordion1.html in your jqueryui folder and try it out in a browser. We haven't specified any styling at all at this stage, but as you can see from the following screenshot, it still functions exactly as intended: Little code is required for a basic working version of the accordion widget. A simple unordered list element is the mark-up foundation which is transformed by the library into the accordion object. The following three separate external script files are required for an accordion: The jQuery library itself (jquery-1.2.6.js) The UI base file (ui.core.js) The accordion source file (ui.accordion.js) The first two files are mandatory requirements of all components of the UI library. They should be linked to in the order shown here. Each widget also has its own source file, and may depend on other components as well. The order in which these files appear is important. The jQuery library must always appear first, followed by the UI base file. After these files, any other files that the widget depends upon should appear before the widget's own script file. The library components will not function as expected if files are not loaded in the correct order. Finally, we use a custom <script> block to turn our <ul> element into the accordion. We can use the jQuery object shortcut $ to specify an anonymous function which will be executed as soon as the document is ready. This is analogous to using $(document).ready(function(){}) and helps to cut down on the amount of code we have to type. Following this, we use the simple ID selector $("#myAccordion") to specify the element on the page we want to transform. We then use the accordion() constructor method to create the accordion Other elements can be turned into accordions as well. All list element variants are supported including ordered lists and definition lists. You don't even need to base the accordion on a list element at all. You can build a perfectly functional accordion using just nested <div> and <a> elements, although additional configuration will be required In the above example, we used an empty fragment (#) as the value of the href attribute. You should note that any URLs supplied for accordion headers will not be followed when the header is clicked within the accordion when using the default implementation. Styling the accordion With no styling, the accordion will take up 100% of the width of its container. Like with other widgets, we have several options for styling the accordion. We can create our own custom stylesheet to control the appearance of the accordion and its content, we can use the default or flora themes that come with the library, or we can use Theme Roller to create an extensive skin for the whole library. Let's see how using the flora theme for the accordion will cause it to render. In accordion1.html, add the following <link> tag to the <head> of the page: <link rel="stylesheet" type="text/css" href="jqueryui1.6rc2/themes/flora/flora.accordion.css"> Save the new file as accordion2.html, also in the jqueryui folder, and view it again in a browser. It should appear something like this: The accordion theme file assumes that an unordered list is being used as the basis of the widget and specifically targets <li> elements with certain style rules. We can easily create our own custom theme to style the accordion for situations where we want to use a non-list-based accordion widget, or if we simply want different colors or font styles. You can use the excellent Firebug plugin for Firefox, or another DOM viewer, to see the class names that are automatically added to certain elements when the accordion is generated. You can also read through an un-minified version of the source file if you really feel like it. These will be the class names that we'll be targeting with our custom CSS. The following screenshot shows Firebug in action: Change accordion2.html so that it appears as follows (new code is shown in bold): <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd"><html lang="en"> <head> <link rel="stylesheet" type="text/css" href="styles/accordionTheme.css"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8"> <title>jQuery UI Accordion Widget Example 3</title> </head> <body> <div id="myAccordion"> <span class="corner topLeft"></span><span class="corner topRight"></span><span class="corner bottomLeft"></span><span class="corner bottomRight"></span> <div><a href="#">Header 1</a><div>Wow, look at all this content that can be shown or hidden with a simple click!</div></div> <div><a href="#">Header 2</a><div>Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Aenean sollicitudin. Sed interdum pulvinar justo. Nam iaculis volutpatligula. Integer vitae felis quis diam laoreet ullamcorper. Etiam tincidunt est vitae est. Ut posuere, mauris at sodales rutrum, turpis tellus fermentum metus, ut bibendum velit enim eu lectus. Suspendisse potenti.</div></div> <div><a href="#">Header 3</a><div>Donec at dolor ac metus pharetra aliquam. Suspendisse purus. Fusce tempor ultrices libero. Sed quis nunc. Pellentesque tincidunt viverra felis. Integer elit mauris, egestas ultricies, gravida vitae, feugiat a, tellus.</div></div> </div> <script type="text/javascript" src="jqueryui1.6rc2/jquery-1.2.6.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.core.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.accordion.js"></script> <script type="text/javascript"> //function to execute when doc ready $(function() { //turn specified element into an accordion $("#myAccordion").accordion(); }); </script> </body></html> Save this version as accordion3.html in the jqueryui folder. The class name ui-accordion is automatically added to the accordion's container element. Therefore, we can use this as a starting point for most of our CSS selectors. The links that form our drawer headers are given the class ui-accordion-header so we can also target this class name. In a new file, create the following stylesheet: #myAccordion { width:200px; border:2px solid #000000; position:relative; list-style-type:none; padding-left:0;}.ui-accordion-header { text-decoration:none; font-weight:bold; color:#000000; display:block; width:100%; text-align:center;}.ui-accordion div div { font-size:90%;}.ui-accordion a { color:#ffffff; background:url(../img/accordion/header-sprite.gif) repeat-x 0px 0px;}.ui-accordion a.selected { background:url(../img/accordion/header-sprite.gif) repeat-x 0px -22px;}.ui-accordion a:hover { background:url(../img/accordion/header-sprite.gif) repeat-x 0px -44px;}/* container rounded corners */.corner { position:absolute; width:12px; height:13px; background:url(../img/accordion/corner-sprite.gif) no-repeat;}.topLeft { top:-2px; left:-2px; background-position:0px 0px;}.topRight { top:-2px; right:-2px; background-position:0px -13px;}.bottomRight { bottom:-2px; right:-2px; background-position:0px -26px;}.bottomLeft { bottom:-2px; left:-2px; background-position:0px -39px;} Save this file as accordionTheme.css in your styles folder and preview accordion3.html in a browser. We will need a new folder for the images we use in this and subsequent examples. Create a new folder inside the img folder and name it accordion. With just two images, and a few simple style rules, we can drastically change the default appearance of the accordion with our own custom skin as shown in the following screenshot: Configuring accordion The accordion has a range of configurable properties which allow us to easily change the default behaviour of the widget. The following table lists the available properties, their default value, and gives a brief description of their usage:

Creating our first container In VWD (Visual Web Developer), from the Solution Explorer window, find the following location and create a new folder called FirstSkin: ~/Portals/_default/Containers/ Add a new item by right-clicking on this new folder. Add a new HTML file and call it Container.htm. Similarly, add a CSS and an XML file, Container.css and Container.xml respectively. Clear out all the code in the newly created files that VWD initializes it with. DNN tokens for containers These tokens, however, have applied mostly to creating skins, not containers. Containers have their own set of tokens to use here. The following is a listing of them. We'll be working with them throughout the rest of this article. Actions: This is the menu that will appear when you hover over the triangle. It is traditionally placed to the left of the icon and title of the module. Title: As you can imagine, this is the title of the module displayed in the container. This is usually placed at the top. Icon: Most of the modules don't have an icon, but many of the administrative pages in DotNetNuke have icons assigned to them. You can always assign icons to your modules, but none of them are set by default. Visibility: This skin object is traditionally displayed as a plus or a minus sign inside a small square. It acts as a toggle to show or hide/collapse or expand the content of the module. Content Pane: Similar to when we created our skin, this is where the content goes. The difference here is that we have only one content pane. It is required in order to make the container work. LINKACTIONS: This isn't used very often in containers. It is a listing of links that gives you access to the same things contained in the ACTIONS skin object. PRINTMODULE: This is the small printer icon you see in the preceding screenshot. When you click on it, it allows you to print the contents of the module. ACTIONBUTTON: This skin object allows you to display items as links or image links to commonly used items found in the actions menu. The last item on that list, the ActionButton, is different from the others in that we can have several uses of it in different ways. When used as a token, you would place them in your container HTM file as [ACTIONBUTTON:1], [ACTIONBUTTON:2], [ACTIONBUTTON:3], and so on. As you can imagine, we would define what each of these action buttons refer to. We do this in the XML file with an attribute called CommandName. For example, the following is a code snippet of what you could have to add as an action button: <Objects> <Object> <Token>[ACTIONBUTTON:1]</Token> <Settings> <Setting> <Name>CommandName</Name> <Value>AddContent.Action</Value> </Setting> <Setting> <Name>DisplayIcon</Name> <Value>True</Value> </Setting> <Setting> <Name>DisplayLink</Name> <Value>True</Value> </Setting> </Settings> </Object> Looking at the CommandName attribute, we can have several values which will determine which of the action buttons will be inserted into our container. The following is a listing: AddContent.Action: This typically allows you to add content, or in this case of the Text/HTML module, edit the content of the module. SyndicateModule.Action: This is an XML feed button, if it is supported by the module. PrintModule.Action: This is the printer icon allowing the users to print the content of the module. Yes, this is the second way of adding it as we already have the PRINTMODULE token. ModuleSettings.Action: This is a button/link which takes you to the settings of the module. ModuleHelp.Action—This is a help question mark icon/link that we've seen in the preceding screenshots. Adding to the container Now that we know what can be added, let's add them to our new container. We'll start off with the HTM file and then move on to the CSS file. In our HTM file, add the following code. This will utilize all of the container tokens with the exception of the action buttons, which we'll add soon. <div style="background-color:White;"> ACTIONS[ACTIONS] <hr /> TITLE[TITLE] <hr /> ICON[ICON] <hr /> VISIBILITY[VISIBILITY] <hr /> CONTENTPANE[CONTENTPANE] <hr /> LINKACTIONS[LINKACTIONS] <hr /> PRINTMODULE[PRINTMODULE]</div> Go to the skin admin page (Admin | Skins on the menu). Now that we have a container in the folder called FirstSkin, we'll now get a little added benefit: When you select FirstSkin as the skin to deal with, the container will be selected as well, so you can work with them as a unit or as a Skin Package. Go ahead, parse the skin package and apply our FirstSkin container. Go to the Home page. It may not be pretty, but pretty is not what we were looking for. This container, as it sits, gives us a better illustration of how each token is displayed with a convenient label beside each. There are a few things to point out here, besides we'll be taking out our handy labels and putting in some structure. Our module has no icon, so we won't see one here. If you go to the administrative pages, you will see the icon. The LINKACTIONS is a skin object that you'll use if you don't want to use the action menu ([ACTIONS]). Table Structure The structure of our container will be quite similar to how we laid out our skin. Let's start off with a basic table layout. We'll have a table with three rows. The first row will be for the header area which will contain things like the action menu, the title, icon, and so forth. The second row will be for the content. The third row will be for the footer items, like the printer and edit icon/links. Both the header and footer rows will have nested tables inside to have independent positioning within the cells. The markup which defines these three rows has been highlighted: <table border="0" cellpadding="0" cellspacing="0" class="ContainerMainTable"> <tr> <td style="padding:5px;"> <table border="0" cellpadding="0" cellspacing="0" class="ContainerHeader"> <tr> <td style="width:5px;">[ACTIONS]</td> <td style="width:5px;">[ICON]</td> <td align="left">[TITLE]</td> <td style="width:5px;padding-right:5px;" valign="top">[VISIBILITY]</td> <td style="width:5px;">[ACTIONBUTTON:4]</td> </tr> </table> </td> </tr> <tr> <td class="ContainerContent"> [CONTENTPANE] </td> </tr> <tr> <td style="padding:5px;"> <table border="0" cellpadding="0" cellspacing="0" class="ContainerFooter"> <tr> <td>[ACTIONBUTTON:1]</td> <td>[ACTIONBUTTON:2]</td> <td></td> <td>[ACTIONBUTTON:3]</td> <td style="width:10px;">[PRINTMODULE]</td> </tr> </table> </td> </tr></table> Making necessary XML additions The action buttons we used will not work unless we add items to our XML file. For each of our action buttons, we'll add a token element, then a few setting elements for each. There are three specific settings we'll set up for each: CommandName, DisplayIcon, and DisplayLink. See the following code: <Objects> <Object> <Token>[ACTIONBUTTON:1]</Token> <Settings> <Setting> <Name>CommandName</Name> <Value>AddContent.Action</Value> </Setting> <Setting> <Name>DisplayIcon</Name> <Value>True</Value> </Setting> <Setting> <Name>DisplayLink</Name> <Value>True</Value> </Setting> </Settings> </Object> <Object> <Token>[ACTIONBUTTON:2]</Token> <Settings> <Setting> <Name>CommandName</Name> <Value>SyndicateModule.Action</Value> </Setting> <Setting> <Name>DisplayIcon</Name> <Value>True</Value> </Setting> <Setting> <Name>DisplayLink</Name> <Value>False</Value> </Setting> </Settings> </Object> <Object> <Token>[ACTIONBUTTON:3]</Token> <Settings> <Setting> <Name>CommandName</Name> <Value>ModuleSettings.Action</Value> </Setting> <Setting> <Name>DisplayIcon</Name> <Value>True</Value> </Setting> <Setting> <Name>DisplayLink</Name> <Value>False</Value> </Setting> </Settings> </Object> <Object> <Token>[ACTIONBUTTON:4]</Token> <Settings> <Setting> <Name>CommandName</Name> <Value>ModuleHelp.Action</Value> </Setting> <Setting> <Name>DisplayIcon</Name> <Value>True</Value> </Setting> <Setting> <Name>DisplayLink</Name> <Value>False</Value> </Setting> </Settings> </Object></Objects> The CommandName is the attribute that determines which action button is used by the ordinal numeric values. Notice that these four action buttons use different CommandName values as you might expect. The DisplayIcon attribute is a Boolean (true/false or yes/no) value indicating whether or not the icon is displayed; the DisplayLink is similar and used for setting if the text is used as a link. A good example of both is the EditText ([ACTIONBUTTON:1]) in our Text/HTML module on the Home page. Notice that it has both the icon and the text as links to add/edit the content of the module.

Authentication Authentication in JBoss portal builds on the JEE security provided by the JBoss server. The JEE specification defines the roles and constraints under which certain URLs and components are protected. However, this might not always be sufficient for building enterprise applications or portals. Application server providers such as JBoss supplement the authentication and authorization features provided by the JEE specification with additional features such as role-to-group mapping and session logout. Authentication in JBoss portal can be divided into configuration files and portal server configuration. The jboss-portal.sar/portal-server.war file is the portal deployment on the JBoss application server. Assuming that the portal server is like any JEE application deployed on an application server, all user authentication configurations go into the WEB-INF/web.xml and the WEB-INF/jboss-web.xml files. The WEB-INF/web.xml entry defines the authentication mode, with the default being form-based authentication. This file is also used to define the login and error pages, as defined by the JEE specification. The default security domain defined by the JBoss application server is java:/jaas/portal for JBoss portal. The security domain maps the JEE security constructs to the operational domain. This is defined in a proprietary file, WEB-INF/jboss-web.xml. The portal security domain authentication stack is defined in the jboss-portal.sar/conf/login-config.xml file, and is deployed along with the portal. Login-config.xml houses the JAAS modules for authentication. Custom modules can be written and added here to support special scenarios. The server provides a defined set of JAAS login modules that can be used for various scenarios. For example, the IdentityLoginModule is used for authentication based on local portal data, SynchronizingLdapLoginModule for authentication using LDAP, and DBIdentityLoginModule for authentication using a database. Within the jboss-portal.sar/portal-server.war application, all portal requests are routed through a single servlet called org.jboss.portal.server.servlet.PortalServlet. This servlet is defined twice, as follows, in the configuration file WEB-INF/web.xml to ensure that all possible request sources are covered: PortalServletWithPathMapping for path mappings PortalServletWithDefaultServletMapping for the default servlet mapping The servlet is mapped four times with variations to address a combination of secure SSL access and authenticated URLs, as follows: /*: Default access, and with no security constraint, allows access to everybody /sec/*: All requests to a secure protocol are routed through this path, ensuring SSL transport /auth/*: Authenticated access. Requires user to be authenticated before accessing the content under this tree /authsec/*: An authenticated and secure access The following snippet from web.xml shows the entries: <!-- Provide access to unauthenticated users --> <servlet-mapping> <servlet-name>PortalServletWithPathMapping</servlet-name> <url-pattern>/*</url-pattern> </servlet-mapping> <!-- Provide secure access to unauthenticated users --> <servlet-mapping> <servlet-name>PortalServletWithPathMapping</servlet-name> <url-pattern>/sec/*</url-pattern> </servlet-mapping> <!-- Provide access to authenticated users --> <servlet-mapping> <servlet-name>PortalServletWithPathMapping</servlet-name> <url-pattern>/auth/*</url-pattern> </servlet-mapping> <!-- Provide secure access to authenticated users --> <servlet-mapping> <servlet-name>PortalServletWithPathMapping</servlet-name> <url-pattern>/authsec/*</url-pattern> </servlet-mapping> The URL patterns can be changed based on personal preference. Authorization Authorization is the process of determining if an authenticated user has access to a particular resource. Similar to authentication, JBoss portal provides in-built support for authorization, through Java Authorization Contract for Containers(JACC). JACC is a JSR-115 specification for the authorization models of the Java2 and JEE enterprise platforms. In the next few sections, we will look at how JBoss portal facilitates authorization using JACC. However, before we go into the details of access controls and authorization configurations, let's quickly look at how roles are configured in JBoss Portal. User and role management A role is an authorization construct that denotes the group that a user of the portal belongs to. Typically, roles are used to determine the access rights and the extent of these rights for a given resource. We saw in an earlier section how to configured portal assets such as, portals, pages, and portlet instances, to restrict certain actions to specific roles. We used a role called SPECIAL_USER for our examples. However, we never really defined what this role means to JBoss portal. Let's use the JBoss portal server console to register this role with the server. Log in as admin, and then click on the Members tab. This takes us to the User Management and Role Management tabs. The User Management tab is used for creating new users. We will come back to this shortly, but for now, let's switch over to the Role Management tab and click on the Create role link on the bottom right of the page. We can now add our SPECIAL_USER role and provide a display name for it. Once we submit it, the role will be registered with the portal server. As we will see later, every attempt by an authenticated user to access a resource that has security constraints through a specific role will be matched by the portal before granting or denying access to the resource. Users can be added to a role by using the User Management tab. Each user has a role property assigned, and this can be edited to check all of the roles that we want the user to belong to. We can see that for the user User, we now have an option to add the user to the Special User role. The portal permission A permission object carries the relevant permission for a given entity. The org.jboss.portal.security.PortalPermission object is used to describe permission for the portal. Like all the other entity-specific permission classes, it extends the java.security.Permission class, and any permission checked in the portal should extend the PortalPermission as well. Two additional fields of significance are as follows: uri: A string that specifies the URI of the resource that is described by the permission collection: An object of class org.jboss.portal.security.PortalPermissionCollection, which is used when the permission acts as a container for other permissions The authorization provider The authorization provider is a generic interface of the type org.jboss.portal.security.spi.provider.AuthorizationDomain, and provides access to several services. public interface AuthorizationDomain{ String getType(); DomainConfigurator getConfigurator(); PermissionRepository getPermissionRepository(); PermissionFactory getPermissionFactory();} Let us look into these classes a bit more in detail: org.jboss.portal.security.spi.provider.DomainConfigurator provides configuration access to an authorization domain. The authorization schema consists of bindings between URIs, roles, and permissions. org.jboss.portal.security.spi.provider.PermissionRepository provides runtime access to the authorization domain. It is used to retrieve the permissions for a specific role and URI. It is used at runtime by the framework, to take security decisions. org.jboss.portal.security.spi.provider.PermissionFactory is a factory to instantiate permissions for the specific domain. It is used at runtime to create permission objects of the appropriate type by the security framework.

Accordion animation You may have noticed the default slide animation built into the accordion. Apart from this, there are two other built-in animations that we can easily make use of. We can also switch off animations entirely by supplying false as the value of the animated property, although this doesn't look too good! The other values we can supply are bounceslide and easeslide. However, these aren't actually unique animations as such. These are different easing styles which don't change the animation itself but instead, alter the way it runs. You should note at this stage that additional jQuery plugins are required for these easing methods. For example, the bounceslide easing method causes the opening drawer to appear to bounce up and down slightly as it reaches the end of the animation. On the other hand, easeslide makes the animation begin slowly and then builds up to its normal speed. Let's take a moment to look at these different easing methods now. Change accordion11.html so that it appears as follows: <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd"> <html lang="en"> <head> <link rel="stylesheet" type="text/css" href="styles/accordionTheme2.css"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8"> <title>jQuery UI Accordion Widget Example 12</title> </head> <body> <div id="myAccordion"> <span class="corner topLeft"></span><span class="corner topRight"></span><span class="corner bottomLeft"></span> <span class="corner bottomRight"></span> <div><a href="#">Header 1</a><div>Wow, look at all this content that can be shown or hidden with a simple click!</div></div> <div><a href="#">Header 2</a><div>Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Aenean sollicitudin. Sed interdum pulvinar justo. Nam iaculis volutpat ligula. Integer vitae felis quis diam laoreet ullamcorper. Etiam tincidunt est vitae est. Ut posuere, mauris at sodales rutrum, turpis tellus fermentum metus, ut bibendum velit enim eu lectus. Suspendisse potenti.</div> </div> <div><a href="#">Header 3</a><div>Donec at dolor ac metus pharetra aliquam. Suspendisse purus. Fusce tempor ultrices libero. Sed quis nunc. Pellentesque tincidunt viverra felis. Integer elit mauris, egestas ultricies, gravida vitae, feugiat a, tellus. </div> </div> </div> <script type="text/javascript" src="jqueryui1.6rc2/jquery-1.2.6.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.core.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/jquery.easing.1.3.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/jquery.easing.compatibility.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.accordion.js"></script> <script type="text/javascript"> //function to execute when doc ready $(function() { //set custom easing var accOpts = { animated: "bounceslide" } //turn specified element into an accordion $("#myAccordion").accordion(accOpts); }); </script> </body> </html> Save this file as accordion12.html. We've used a couple of new script files in the source code. The jquery.easing.1.3.js file is the latest version of the easing plugin, and the jquery.easing.compatibility.js plugin which enables the latest version of the easing file to work without any further modifications. The easing type names were renamed in version 1.2 of the easing plugin. Both of these files can be found on the jQuery site. The built-in easing effects, based on a series of equations created by Robert Penner in 2006, are very easy to use and create a great effect which can help build individuality into accordion implementations Plugins There are many jQuery plugins available. These are often developed by the open-source community instead of the library's authors and can be used with jQuery and jQuery UI. A good place to find plugins is on the jQuery site itself at http://plugins.jquery.com/. Some of these plugins, such as the easing plugin, work with the library components, while other plugins, such as the compatibility plugin, assist other plugins. Accordion events The accordion defines the custom change event which is fired after a drawer on the accordion opens or closes. To react to this event, we can use the change configuration property to specify a function to be executed every time the event occurs. In a new file in your text editor, add the following code: <!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN" "http://www.w3.org/TR/html4/strict.dtd"> <html lang="en"> <head> <link rel="stylesheet" type="text/css" href="styles/accordionTheme.css"> <meta http-equiv="Content-Type" content="text/html; charset=utf-8"> <title>jQuery UI Accordion Widget Example 13</title> </head> <body> <div id="myAccordion"> <span class="corner topLeft"></span><span class="corner topRight"></span><span class="corner bottomLeft"></span> <span class="corner bottomRight"></span> <div><a href="#">Header 1</a><div id="panel1">Wow, look at all this content that can be shown or hidden with a simple click!</div> </div> <div><a href="#">Header 2</a><div id="panel2">Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Aenean sollicitudin. Sed interdum pulvinar justo. Nam iaculis volutpat ligula. Integer vitae felis quis diam laoreet ullamcorper. Etiam tincidunt est vitae est. Ut posuere, mauris at sodales rutrum, turpis tellus fermentum metus, ut bibendum velit enim eu lectus. Suspendisse potenti.</div></div> <div><a href="#">Header 3</a><div id="panel3">Donec at dolor ac metus pharetra aliquam. Suspendisse purus. Fusce tempor ultrices libero. Sed quis nunc. Pellentesque tincidunt viverra felis. Integer elit mauris, egestas ultricies, gravida vitae, feugiat a, tellus.</div> </div> </div> <script type="text/javascript" src="jqueryui1.6rc2/jquery-1.2.6.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.core.js"></script> <script type="text/javascript" src="jqueryui1.6rc2/ui/ui.accordion.js"></script> <script type="text/javascript"> //function to execute when doc ready $(function() { //define config object var accOpts = { //add change event callback change: function(e, ui) { alert($(ui.newContent).attr("id") + " was opened, " + $(ui.oldContent).attr("id") + " was closed"); } }; $("#myAccordion").accordion(accOpts); }); </script> </body> </html> Save this as accordion13.html. In this example, we use the change configuration property to specify an anonymous callback function which is executed every time the event is triggered. This function will automatically receive two objects as arguments. The first object is the event object which contains information about the event. The second object is an object containing useful information about the accordion widget, such as the content drawer that just opened or closed. In the mark-up for the accordion, we have given each of the content drawer <div> elements an id attribute which can be used in the alert generated by the change callback. We can use the ui.newContent and ui.oldContent properties to obtain the relevant content drawer and display its id in the alert. The accordion widget also defines the accordion change event which is fired after a drawer on the accordion opens or closes. To react to this event, we can use the standard jQuery bind() method to specify a callback function, just like with the tabs widget.
