So it's time to get our hands on this! As previously stated, PRN generation can be a complicated mathematical problem but Unity has a built-in class for us called Random
. Now, let's get exposed to PRNs in our first PCG example.
Let's begin by setting up the project and completing the classic Hello World
program. Start by launching Unity and creating a new project. You can name it Hello World
. You can also set the perspective to 2D since most of what we do in this book will be in 2D.
Once the project is loaded, we will create a new Text GameObject in order to render our Hello World
to the screen. On the top toolbar, select GameObject | UI | Text. This will place a new Canvas object with a Text object child onto the scene. An EventSystem is also placed in the Hierarchy panel but you can ignore this.
Canvas is mostly off screen and you have to zoom out quite a lot to see the full view. Rather than zooming out, let's adjust the Canvas to occupy the Main Camera view space, as follows:
Select Canvas.
Select the Render Mode dropdown in the Canvas component section.
Select Screen Space - Camera.
This will open up a new field called Render Camera.
From the Hierarchy pane, drag and drop the Main Camera object into the Render Camera field.
This will adjust your
Canvas object to fit the Main Camera view. You might still need to zoom out slightly to see the edges of Canvas.
You might have noticed at this point that there is some text on the screen. In the lower left corner of the Canvas, it says New Text in a default grey that is difficult to see. Let's change that.
Select the Text object, which is a child of the Canvas object. First, we will change the position. In the Rect Transform component section:
Select the value in the Pos X field and change it to 0
.
Repeat for the Pos Y field.
The anchors are set to center so the Rect should snap to the center of the Canvas. Next, we'll change the size of the Rect so that we can make the text larger:
Select the Width field and change it to 500
.
Select the Height field and change it to 65
.
This will allow us to have much larger text. Note that if we had just tried to change the font size without changing the Rect size, the text would be clipped or would even vanish completely. Now let's get the text looking nice by going to the Text (Script) component section:
Under Character, select the Font Size field and change it to 55
.
Under Paragraph, select the center alignment button.
Select the Color field and change it to white.
Note
The center alignment button appears as in the Unity Editor.
Now our text is nice and visible. At this point, you can select the text in the Text field and delete it. We are going to have our script write the text for us.
Let's start scripting by creating a new C# script. On the top toolbar, select Assets | Create | C# Script. This will create a new script in your Assets folder under the Project pane. You can name the script HelloWorld.cs
.
Open the script in MonoDevelop or your favorite IDE. We are going to use the following Code Snip 1.1:
Tip
Downloading the example code
You can download the example code files for all Packt books you have purchased from your account at http://www.packtpub.com. If you purchased this book elsewhere, you can visit http://www.packtpub.com/support and register to have the files e-mailed directly to you.
Let's take a look at what's happening in Code Snip 1.1:
Line 2
: Be sure to include UnityEngine.UI
or you won't be able to access the Text
component
Line 7
: This is our public Text
object, which we will define in the Unity editor
Line 10
: At the start of the scene, we will take our text object and assign the string Hello World
to it.
That's all there is to it. Now, we just need to add the script to the scene. It doesn't matter which object you attach the HelloWorld.cs
script to because we will declare the specific Text
object the script acts on. To keep things organized, this way works well:
Drag and drop the HelloWorld.cs
script from the Assets folder to the Text object on the scene.
Drag and drop the Text object from the Hierarchy pane to the Text String field in the Hello World (Script) component of the Text object.
Now, you can press the play button, and you'll see Hello World in a large font:
That completes the Hello World
program. However, that's not all that interesting. In order to give this classic programming example some new flair, let's add some randomness.
Using our Hello World
example, we will add PRNs into the mix and give our program some procedurally generated text. We'll start by editing our current HelloWorld.cs
script. The goal here is to randomly display one of a few variations of the Hello World text.
You can achieve this by creating an array of different strings and having Unity's Random method choose a number from 0 to the length of the array. You will use that PRN as the index of the string array. In this case, our array holds the Hello World string in a few different languages. So instead of telling the Text
object to display Hello World, we will tell it to display the contents of the array at the PRN index.
Note
Unity's Random.Range
has a usage of (inclusive, exclusive). In our code, we use Random.Range (0, 4)
, which means 0 will be in the selected range but the range stops at 3. One reason for this is if we have a C# list, we can write the range as (0, List.Count)
instead of (0, ListCount - 1)
.
You can find more information on Unity's Random at http://docs.unity3d.com/ScriptReference/Random.html.
Open the HelloWorld.cs
script and make the following changes in Code Snip 1.2:
The changes in Code Snip 1.2 are as follows:
Line 7
: Here you will declare a string array that we can call hellos
, which will hold all our Hello World
strings.
Line 12
: This is the PRN generator seed, which we discussed earlier in the chapter. We are picking a random number to seed the generator. The seed comes from your computer's current time in processor ticks (which is somewhere around a millisecond).
Line 13
: Here, we call Random.Range
to choose a PRN from 0 to 3, which will be the index of hellos
that we choose to display.
Line 15
: This line is a modification from our previous example; here, we set the text display to our randomly selected Hello World
string.
Head back into the Unity editor to see the changes. You should see the new Hellos field. If you expand it, then you will see all of the strings contained in the array. The script might also lose connection to the Text object. You can just drag and drop the Text object into the Text String field to reconnect it.
And that's it. You completed your first PCG capable program. Test it out by pressing the play button. You will randomly get one of the four Hello World
strings displayed in the Game screen. There are only four choices so you might have to try a couple of times before you start seeing any variation.
