Learning Network Forensics: Identify and safeguard your network against both internal and external threats, hackers, and malware attacks

Network forensic investigations can be very time consuming and complex. These investigations are usually very sensitive in nature and can be extremely time critical as well. To be an effective network forensics Bond, we need to develop the following characteristics:

There is a considerable overlap between incident response and network forensics in the corporate world, with information security professionals being tasked with both the roles. To help simplify the understanding of the process, we have come up with the easy-to-remember TAARA framework:

This is pictorially represented in the following image:

Threats or attacks that originate from within the network or organization are classified as internal threats. These can be intentional or unintentional.

Typically, such threats involve an insider with a mala fide intention, insider knowledge and/or access. This insider is looking to steal, misuse, modify, corrupt, or destroy enterprise resources. Quite naturally, the insider has no intention of getting caught and hence, makes every attempt to cover their tracks. However, as we will see later in this chapter, every interaction with the crime scene leaves a trace as per Locard's exchange principle.

Weak and ill-defined rules, network policies, security systems, and so on aid and abet such insiders. Unlimited and unmonitored access of network resources and data by the users are a sure recipe for disaster. Improperly implemented controls, random permissions, unsecured physical access to server rooms, and poor password hygiene contribute to serious threats to the network resources.

External threats are those that originate from outside the perimeter of the network. This could be from individuals, groups, or even governments. A spate of network attacks world-wide have been traced to state actors such as China, North Korea, and even the USA. Revelations by Snowden have opened everyone's eyes to the real threat of state-sponsored surveillance.

External threats come in all shapes and sizes. Just like internal threats, these can be intentional or unintentional. There are all sorts of people out there who want to get into your network. Some want to do it to get the information you store, some do it to shut down your network, some do it as they did not like the statement your company's CEO gave out last Wednesday, and some want to do it just because they can. Let's leave motivations aside for the moment. I say for the moment as a part of our network forensics investigations requires answering the Why part of the equation at a later date.

Any outsider wanting access to your network has to carry out a number of concrete steps before they can gain access of any sort. It's best to be disabused of the notion that, like in the movies, a hacker sits before his computer, starts typing, and has Administrator-level access within a couple of minutes. That is unadulterated fiction.

The first step any attacker has to take is to reconnoiter the target. Just as any good or accomplished thief will case the neighborhood to identify the potential targets, locate their weak spots, plan the right time to break in, and figure out a way to get in; any criminal with the intent to get into the network has to undergo a similar process. This process is called footprinting. This consists of a number of steps followed by scanning for open UDP & TCP ports, which can be exploited. An attempt is then made to try and get the password via multiple means such as social engineering, password lists, brute forcing, or rainbow tables. This mode of password discovery is the most difficult method of getting into the network. Another example would be to exploit the weakness such as unpatched OS and run programs that exploit a vulnerable software leading to open access, followed by privilege escalation to administrator level.

Once in, the accomplished spy will not do anything to give away the fact that they have administrator-level access. It is only script kiddies or publicity-hungry hackers that go ahead to deface websites to earn their two minutes of fame or notoriety.

The next objective is to create a backdoor for uninterrupted access and take every precaution to cover their tracks.

It can be months and, in some cases, years before an intrusion of such sort can be discovered or detected. That is the holy grail of the attacker. Spying undetected! Forever!

However, that is exactly where you come in, Mr. 007. You have to figure out what's going on in the network. At times, this needs to be done extremely covertly. Once the data breach is detected, you need to go into your licensed to kill mode to identify such intrusions and gather all the evidence of the related processes!

You need to identify the perpetrator, interrogate him or the witnesses (forensic interrogation of data packets, media, and memory) to identify the what, when, where, why, and how.

No study of digital investigations can be considered well begun without an understanding of the underpinning of the science. Locard's exchange principle is the foundation on which scientific investigation methodologies are built.

Dr Edmond Locard (1877-1966) was a French scientist who worked with the French Secret Service in the First World War. He was a pioneer in forensic science and criminology. He developed a methodology to identify the nature and cause of death of French soldiers and prisoners by examining the wounds, damage stains, and other marks on the body.

He was known as the Sherlock Holmes of France.

He is often credited with saying every contact leaves a trace!

He speculated that anybody or anything that enters or leaves the crime scene (interaction with the crime scene) either leaves something behind or leaves with something from it (inadvertently or intentionally) and this can be used as forensic evidence. Let's consider a murder. Anybody that walks into a murder spot may leave the evidence of their presence in the form of footprints, fingerprints, and so on. Similarly, when someone leaves the crime scene, they may take specks of blood with them, local dust may adhere to their shoes, and so on.

How does this translate into the network world?

Essentially, every attempt to communicate with a device on the network leaves a trace somewhere; this could be at firewalls, intrusion detection systems, routers, event logs, and so on. Similarly, any attempt by an internal miscreant to access unauthorized resources will also leave a trace. This is depicted in the following image:

Locard's exchange principle in a digital world

Let's take the example of a phishing attack. As we are all aware, it begins with an innocuous mail with a massively appealing subject. The phishing mail may carry a payload in the form of an attachment (for example, a Trojan) or have a link that leads to a similar result. In this case, according to Locard's exchange principle, the two entities interacting would be the affected computer and the computer sending out the phish. Some of the evidence in this case would be the e-mail itself, Trojan horse/malware/keylogger, stolen passwords, changed passwords, attempts to cover tracks, and so on. The backdoor, once discovered, could reveal a lot of details and the IP addresses of devices that control it or receive the stolen data would also count as evidence. The command and control center for the phishing operation (if identified) would also be a goldmine of evidence.

As a network 007, it is our job to figure out what is going on and draw our conclusions accordingly.

As the name suggests, this model consists of seven layers. Each of these are explained in the following:

As the data travels between layers, each layer adds or removes its header to the data unit. At the destination, each added header is removed one-by-one until the receiving application gets the data that is intended for it.

The TCP/IP model

The TCP/IP model consists of only four layers. These are application, transport, internet, and network.

These layers are shown in the following table:

Layer Name	Description
Application	This is responsible for applications and processes running on the network
Transport	This provides end-to-end data delivery
Internet	This makes datagrams and handles data routing
Network	This allows access to the physical network

Let's take a look at each of these one by one, starting from the network interface layer and working our way upwards.

• Network layer: The network (or network interface layer, as it is also known) is the bedrock of the TCP/IP model. This drives the signals across the network. It transmits and receives bits over the network hardware such as co-axial or twisted pair copper cable. This exists over the physical layer and includes the following protocols:

  • Ethernet

  • Token-ring

  • Frame relay

  • FDDI

  • X.25

  • RS-232

  • v.35

• Internet layer: The Internet layer is at the heart of the TCP/IP model. This packages the data into IP datagrams and performs routing for these datagrams based on the source and destination information in the header. The protocols used at this layer include the following:

  • Internet Protocol (IP)

  • Internet Control Message Protocol (ICMP)

  • Address Resolution Protocol (ARP)

  • Reverse Address Resolution Protocol (RARP)

• Transport layer: This layer manages the communication session between the host computers. During the data transportation process, this defines the level of service and the connection status. The transport layer uses the following protocols:

  • Transmission Control Protocol (TCP)

  • User Datagram Protocol (UDP)

  • Real-time Transport Protocol (RTP)

• Application layer: The application layer combines the functions of the OSI application, presentation, and session layers. This layer defines how the host programs interface with transport layer services as well as their related application protocols. Some of the protocols in this layer are as follows:

  • Simple Mail Transfer Protocol (SMTP)

  • HTTP

  • FTP

  • Telnet

  • Simple Network Management Protocol (SNMP)

  • DNS

  • Trivial File Transfer Protocol (TFTP)

  • X-Windows

The following image depicts both models in graphic form. It also shows their interrelation:

Understanding the concept of interconnection between networks/Internet

In 1966, the Defense Advanced Research Project Agency Network, implemented a research network of networks. This consisted of connecting several computer networks based on different protocols.

This threw up a unique problem of having to define a common interconnection protocol on top of the local protocols. The Internet Protocol (IP) plays this role by defining unique addresses for a network device and host machines. The following diagram depicts this interconnection of devices using IP routing:

Whenever we see a stranger that we want to speak to, it always helps if we speak the same language. In computer world, the language of communication is called a protocol. IP is one of the languages that multiple computers use to communicate with each other as a part of the layered architecture model.

On top of the IP, there are TCP, UDP, and some others.

There are two versions of the IP being used, as follows:

The Internet Protocol has the following two main functions:

How does it work?

It splits or breaks up the initial data (that is to be sent) into datagrams. Each datagram will have a header, including the IP address and the port number of the destination. Datagrams are then sent to selected gateways, that is, IP routers. These routers are connected to the local network and to an IP service provider network at the same time. These routers start the relay process, wherein datagrams are transferred from gateway to gateway until they arrive at their final destination.

The following diagram illustrates this concept in a simple-to-understand manner:

Whenever two hosts communicate with each other using the Internet Protocol, there is no need for a continuous connection. One host sends the data to another via a data packet. Each packet header contains the source destination addresses as well as the sequence number and is treated as an independent unit of data. The TCP is responsible for reading the packet headers and putting the packets in the correct sequence so that the message is readable.

Today, the most widely used version of IP is the IPv4. However, IPv6 is also beginning to be supported. IPv6 was introduced when it was realized that IPv4 addresses were running out. The exponential increase in the number of devices connected to the Internet resulted in the anticipation of IPv4 address exhaustion. IPv6 provides for much longer addresses and also the possibility of many more Internet users. IPv6 includes the capabilities of IPv4 and any server that can support IPv6 packets can also support IPv4 packets.

Structure of an IP packet

Let's take a look at the following structure of an IP packet:

• The IP's functionality and limitations are defined by the fields at the beginning of the packet. This is called the frame header.

• The source and destination address fields have 32 bits allocated to encode their data.

• Various additional information, such as the total packet length in bytes, is encoded in 16 bytes in the remainder of the header.

Normally, the application layer sends the data that is to be transmitted to the transport layer. The transport layer adds a header and sends it to the Internet layer. The Internet layer adds its own header to this and sends it to the network layer for physical transmission in the form of an IP datagram. The network layer adds its own frame header and footer and then physically transmits it over the network.

At the other end, when the datagram is received, this process is reversed and the different headers are stripped as the data moves from layer to layer. The following diagram represents how headers are added and removed as we move from layer to layer:

Datagram headers as we move from layer to layer

IP packets are a basic service that do not guarantee safe delivery. TCP remedies this by adding the following elements:

Before sending the data, TCP requires the computers that are communicating to establish a connection with each other:

TCP/IP communications

Whereas IP is limited to sending 64-kb data streams, large data streams can be sent as one big stream of data using TCP. TCP does this by breaking up the data stream into separate data packets. Each packet is numbered and its sequence number is stored in the header. On arrival, these disparate packets are reassembled using sequence and sequence acknowledgement numbers. TCP specifies the port numbers. This improves the capabilities over IP. Every TCP/IP machine can communicate using 65,536 different ports or sockets.

All data in a TCP packet is accompanied by a header. The header contains information related to the source port, destination port, sequence number, sequence acknowledgement number, and some miscellaneous header data.

Similar to the TCP, the UDP is also built on top of the IP. It has the same packet-size limit (64 kb) as IP; however, it allows specifying port numbers. This provides 65,536 different ports, which is the same as TCP. Therefore, every machine has two sets of 65,536 ports: one for TCP and the other for UDP.

The difference between the two is that UDP is a connection-less protocol, without any error detection facility. It only provides support for data transmission from one end to other without any verification. As it does not do any further verification, UDP is very fast. This is its main feature and it is extremely useful in sending small and repetitive data at a very high speed. Some examples of this are audio and video streaming, games, time information that is continuously streamed, and so on.

On top of the TCP/IP layers is the application layer. The Internet Engineering Task Force (IETF) definition document for the application layer in the Internet protocol suite is RFC 1123. The application layer's role is to support network applications by the means of application protocols.

Some of the application protocols include the following:

Newer applications can also spawn additional application protocols such as BitTorrent, Bitcoin, eDonkey, and so on.

When we connect our network to the outside world (I know, I know, we have to!), we introduce the possibility of outsiders attempting to exploit our network, stealing our data, infecting our systems with viruses and Trojans, or overloading our servers, thus impacting and impeding our performance.

However, if our network were disconnected from the outside world, threats would still exist. In fact, most surveys and studies (as mentioned earlier) point to the indisputable fact that most of the threats (over 50%) are caused by intentional or unintentional activities performed by insiders.

While it is rarely possible to isolate or air gap a business network from the outside world, even if we were to do so, there is no guarantee that it would ensure network security.

Based on this understanding, we must consider both internal and external threats.

The data that resides on the networks is the lifeblood of any organization. The confidentiality aspect of network security involves keeping the data private.

This entails restricting physical access to the networked devices and components as well as logical access to the node data and network traffic.

To do this, network administrators set up firewalls and intrusion detection & prevention systems. Access control lists (ACL) prevent unauthorized access to the network resources. Encrypted network traffic prevents any data leakage caused by traffic interception by an attacker. Specific credentials, such as usernames and passwords, are required to access the network resources.

Snowden's revelations are an example of a breach of the confidentiality goal of network security. The recent headlines relating to the data leakage at Sony Pictures is another glaring example.

Networks have data in motion. Should an attacker gain access to a network, they would have the ability to silently modify/tamper with the traffic that would cause, at the very least, a misunderstanding between the people communicating and at the other end of the spectrum, it could cause irreparable harm to the people and organizations.

The examples of network security violations that affect the integrity goal include the following:

A number of organizations deploy a data integrity solution to perform origin authentication and verify that the traffic is originating from the source that should be sending it.

Data at rest and in transit is actually performing a task for the organization. As long as this data or information is accessible to authorized and authenticated users, the task can be performed. The moment an incident interrupts the access, preventing the users from performing their tasks, the availability goal of network security is breached.

There have been a number of high-profile examples of availability compromise in the past, as shown in the following:

Today, some of the most common attacks compromising the availability goal are flood attacks, logic/software attacks, mail bombing, DoS attacks, accidental DoS attacks, and distributed denial-of-service (DDoS) attacks.

Just as all humans have weaknesses, networks too have weaknesses. These are known as vulnerabilities. Vulnerability, in an information system, is a weakness that an attacker leverages to gain unauthorized access to the system or its data.

The usual modus operandi to take advantage of a network vulnerability is to write a program that does this. These kind of programs are called exploits. Most exploits are malicious in nature. As the name suggests, an exploit is meant to exploit the system's weakness.

Vulnerabilities can be of many types. Some examples are shown as follows:

As we are all aware, a chain is only as strong as its weakest link. In the case of network security, the weakest link is usually human. Statistics show that an insider usually launches the most amount of attacks against information assets. Thus, most organizations set up controls to prevent insider abuse.
