Exploring SE for Android

Chapter 1. Linux Access Controls

Android is an operating system composed of two distinct components. The first component is a forked mainline Linux kernel and shares almost everything in common with Linux. The second component, which will be discussed later, is the user space portion, which is very custom and Android specific. Since the Linux kernel underpins this system and is responsible for the majority of access control decisions, it is the logical place to begin a detailed look at Android.

In this chapter we will:

Examine the basics of Discretionary Access Control
Introduce Linux permissions flags and capabilities
Trace syscalls as we validate access policies
Make the case for more robust access control technology
Discuss Android exploits that leverage problems with Discretionary Access Control

Linux's default and familiar access control mechanism is called Discretionary Access Control (DAC). This is just a term that means permissions regarding access to an object are at the discretion of its creator/owner.

In Linux, when a process invokes most system calls, a permission check is performed. As an example, a process wishing to open a file would invoke the open() syscall. When this syscall is invoked, a context switch is performed, and the operating system code is executed. The OS has the ability to determine whether a file descriptor should be returned to the requesting process or not. During this decision-making process, the OS checks the access permissions of both the requesting process and the target file it wishes to obtain the file descriptor to. Either the file descriptor or EPERM is returned, dependent on whether the permission checks pass or fail respectively.

Linux maintains data structures in the kernel for managing these permission fields, which are accessible from user space, and ones that should be familiar to Linux and *NIX users alike. The first set of access control metadata belongs to the process, and forms a portion of its credential set. The common credentials are user and group. In general, we use the term group to mean both primary group and possible secondary group(s). You can view these permissions by running the ps command:

$ ps -eo pid,comm,user,group,supgrp
PID COMMAND         USER     GROUP    SUPGRP
1 init            root     root     -
...
 2993 system-service- root     root     root
 3276 chromium-browse bookuser sudo fuse bookuser
...

As you can see, we have processes running as the users root and bookuser. You can also see that their primary group is only one part of the equation. Processes also have a secondary set of groups called supplementary groups. This set might be empty, indicated by the dash in the SUPGRP field.

The file we wish to open, referred to as the target object, target, or object also maintains a set of permissions. The object maintains USER and GROUP, as well as a set of permission bits. In the context of the target object, USER can be referred to as owner or creator.

$ ls -la
total 296
drwxr-xr-x 38 bookuser bookuser  4096 Aug 23 11:08 .
drwxr-xr-x  3 root     root      4096 Jun  8 18:50 ..
-rw-rw-r--  1 bookuser bookuser   116 Jul 22 13:13 a.c
drwxrwxr-x  4 bookuser bookuser  4096 Aug  4 16:20 .android
-rw-rw-r--  1 bookuser bookuser   130 Jun 19 17:51 .apport-ignore.xml
-rw-rw-r--  1 bookuser bookuser   365 Jun 23 19:44 hello.txt
-rw-------  1 bookuser bookuser 19276 Aug  4 16:36 .bash_history
...

If we look at the preceding command's output, we can see that hello.txt has a USER of bookuser and GROUP as bookuser. We can also see the permission bits or flags on the left-hand side of the output. There are seven fields to consider as well. Each empty field is denoted with a dash. When printed with ls, the first fields can get convoluted by semantics. For this reason, let's use stat to investigate the file permissions:

$ stat hello.txt
  File: `hello.txt'
  Size: 365         Blocks: 8          IO Block: 4096   regular file
Device: 801h/2049d  Inode: 1587858     Links: 1
Access: (0664/-rw-rw-r--)  Uid: ( 1000/bookuser)   Gid: ( 1000/bookuser)
Access: 2014-08-04 15:53:01.951024557 -0700
Modify: 2014-06-23 19:44:14.308741592 -0700
Change: 2014-06-23 19:44:14.308741592 -0700
 Birth: -

The first access line is the most compelling. It contains all the important information for the access controls. The second line is just a timestamp letting us know when the file was last accessed. As we can see, USER or UID of the object is bookuser, and GROUP is bookuser as well. The permission flags, (0664/-rw-rw-r--), identify the two ways that permission flags are represented. The first, the octal form 0664, condenses each three-flag field into one of the three base-8 (octal) digits. The second is the friendly form, -rw-rw-r--, equivalent to the octal form but easier to interpret visually. In either case, we can see the leftmost field is 0, and the rest of our discussions will ignore it. That field is for setuid and setgid capabilities, which is not important for this discussion. If we convert the remaining octal digits, 664, to binary, we get 110 110 100. This binary representation directly relates to the friendly form. Each triple maps to read, write, and execute permissions. Often you will see this permission triple represented as RWX. The first triple are the permissions given to USER, the second are the permissions given to GROUP, and the third is what is given to OTHERS. Translating to conventional English would yield, "The user, bookuser, has permission to read from and write to hello.txt. The group, bookuser, has permission to read from and write to hello.txt, and everyone else has permission only to read from hello.txt." Let's test this with some real-world examples.

Changing permission bits

Let's test the access controls in the example running processes as user bookuser. Most processes run in the context of the user that invoked them (excluding setuid and getuid programs), so any command we invoke should inherit our user's permissions. We can view it by issuing:

$ groups bookuser
bookuser : bookuser sudo fuse

My user, bookuser, is USER bookuser, GROUP bookuser and SUPGRP sudo and fuse.

To test for read access, we can use the cat command, which opens the file and prints its content to stdout:

$ cat hello.txt
Hello, "Exploring SE for Android"
Here is a simple text file for
your enjoyment.
...

We can introspect the syscalls executed by running the strace command and viewing the output:

$ strace cat hello.txt
...
open("hello.txt", O_RDONLY)                   = 3
...
read(3, "Hello, \"Exploring SE for Android\"\n"..., 32768) = 365
...

The output can be quite verbose, so I am only showing the relevant parts. We can see that cat invoked the open syscall and obtained the file descriptor 3. We can use that descriptor to find other accesses via other syscalls. Later we will see a read occurring on file descriptor 3, which returns 365, the number of bytes read. If we didn't have permission to read from hello.txt, the open would fail, and we would never have a valid file descriptor for the file. We would additionally see the failure in the strace output.

Now that read permission is verified, let's try write. One simple way to do this is to write a simple program that writes something to the existing file. In this case, we will write the line my new text\n (refer to write.c.)

Compile the program using the following command:

$ gcc -o mywrite write.c

Now run using the newly compiled program:

$ strace ./mywrite hello.txt

On verification, you will see:

...
open("hello.txt", O_WRONLY)                   = 3
write(3, "my new text\n", 12)           = 12
...

As you can see, the write succeeded and returned 12, the number of bytes written to hello.txt. No errors were reported, so the permissions seem in check so far.

Now let's attempt to execute hello.txt and see what happens. We are expecting to see an error. Let's execute it like a normal command:

$ ./hello.txt
bash: ./hello.txt: Permission denied

This is exactly what we expected, but let's invoke it with strace to gain a deeper understanding of what failed:

$ strace ./hello.txt
...
execve("./hello.txt", ["./hello.txt"], [/* 39 vars */]) = -1 EACCES (Permission denied)
...

The execve system call, which launches processes, failed with EACCESS. This is just the sort of thing one would hope for when no execute permission is given. The Linux access controls worked as expected!

Let's test the access controls in the context of another user. First, we'll create a new user called testuser using the adduser command:

$ sudo adduser testuser
[sudo] password for bookuser:
Adding user `testuser' ...
Adding new group `testuser' (1001) ...
Adding new user `testuser' (1001) with group `testuser' ...
Creating home directory `/home/testuser' ...
...

Verify the USER, GROUP, and SUPGRP of testuser:

$ groups testuser
testuser : testuser

Since the USER and GROUP do not match any of the permissions on a.S, all accesses will be subject to the OTHERS permissions checks, which if you recall, is read only (0664).

Start by temporarily working as testuser:

$ su testuser
Password:
testuser@ubuntu:/home/bookuser$

As you can see, we are still in bookuser's home directory, but the current user has been changed to testuser.

We will start by testing read with the cat command:

$ strace cat hello.txt
...
open("hello.txt", O_RDONLY)                   = 3
...
read(3, "my new text\n", 32768)         = 12
...

Similar to the earlier example, testuser can read the data just fine, as expected.

Now let's move on to write. The expectation is that this will fail without appropriate access:

$ strace ./mywrite hello.txt
...
open("hello.txt", O_WRONLY)                   = -1 EACCES (Permission denied)
...

As expected, the syscall operation failed. When we attempt to execute hello.txt as testuser, this should fail as well:

$ strace ./hello.txt
...
execve("./hello.txt", ["./hello.txt"], [/* 40 vars */]) = -1 EACCES (Permission denied)
...

Now we need to test the group access permissions. We can do this by adding a supplementary group to testuser. To do this, we need to exit to bookuser, who has permissions to execute the sudo command:

$ exit
exit
$ sudo usermod -G bookuser testuser

Now let's check the groups of testuser:

$ groups testuser
testuser : testuser bookuser

As a result of the previous usermod command testuser now belongs to two groups: testuser and bookuser. That means when testuser accesses a file or other object (such as a socket) with the group bookuser, the GROUP permissions, rather than OTHERS, will apply to it. In the context of hello.txt, testuser can now read from and write to the file, but not execute it.

Switch to testuser by executing the following command:

$ su testuser

Test read by executing the following command:

$ strace cat ./hello.txt
...
open("./hello.txt", O_RDONLY)                 = 3
...
read(3, "my new text\n", 32768)         = 12
...

As before, testuser is able to read the file. The only difference is that it can now read the file through the access permissions of OTHERS and GROUP.

Test write by executing the following command:

$ strace ./mywrite hello.txt
...
open("hello.txt", O_WRONLY)                   = 3
write(3, "my new text\n", 12)           = 12
...

This time, testuser was able to write the file as well, instead of failing with the EACCESS permission error shown before.

Attempting to execute the file should still fail:

$ strace ./hello.txt
execve("./hello.txt", ["./hello.txt"], [/* 40 vars */]) = -1 EACCES (Permission denied)
...

These concepts are the foundation of Linux access control permission bits, users and groups.

Changing owners and groups

Using hello.txt for exploratory work in the previous sections, we have shown how the owner of an object can allow various forms of access by managing the permission bits of the object. Changing the permissions is accomplished using the chmod syscall. Changing the user and/or group is done with the chown syscall. In this section, we will investigate the details of these operations in action.

Let's start by granting read and write permissions only to the owner of hello.txt file, bookuser.

$ chmod 0600 hello.txt
$ stat hello.txt
  File: `hello.txt'
  Size: 12          Blocks: 8          IO Block: 4096   regular file
Device: 801h/2049d  Inode: 1587858     Links: 1
Access: (0600/-rw-------)  Uid: ( 1000/bookuser)   Gid: ( 1000/bookuser)
Access: 2014-08-23 12:34:30.147146826 -0700
Modify: 2014-08-23 12:47:19.123113845 -0700
Change: 2014-08-23 12:59:04.275083602 -0700
 Birth: -

As we can see, the file permissions are now set to only allow read and write access for bookuser. A thorough reader could execute the commands from earlier sections in this chapter to verify that permissions work as expected.

Changing the group can be done in a similar fashion with chown. Let's change the group to testuser:

$ chown bookuser:testuser hello.txt
chown: changing ownership of `hello.txt': Operation not permitted

This did not work as we intended, but what is the issue? In Linux, only privileged processes can change the USER and GROUP fields of objects. The initial USER and GROUP fields are set during object creation from the effective USER and GROUP, which are checked when attempting to execute that process. Only processes create objects. Privileged processes come in two forms: those running as the almighty root and those that have their capabilities set. We will dive into the details of capabilities later. For now, let's focus on the root.

Let's change the user to root to ensure executing the chown command will change the group of that object:

$ sudo su
# chown bookuser:testuser hello.txt
Now, we can verify the change occurred successfully:
# stat hello.txt
  File: `hello.txt'
  Size: 12          Blocks: 8          IO Block: 4096   regular file
Device: 801h/2049d  Inode: 1587858     Links: 1
Access: (0600/-rw-------)  Uid: ( 1000/bookuser)   Gid: ( 1001/testuser)
Access: 2014-08-23 12:34:30.147146826 -0700
Modify: 2014-08-23 12:47:19.123113845 -0700
Change: 2014-08-23 13:08:46.059058649 -0700
 Birth: -

Capabilities model

For many operations on Linux, the object permission model doesn't quite fit. For instance, changing UID and GID requires some magical USER known as root. Suppose you have a long running service that needs to utilize some of these capabilities. Perhaps this service listens to kernel events and creates the device nodes for you? Such a service exists, and it's called ueventd or user event daemon. This daemon traditionally runs as root, which means if it is compromised, it could potentially read your private keys from your home directory and send them back to the attacker. This might be an extraordinary example, but it's meant to showcase that running processes as root can be dangerous. Suppose you could start a service as the root user and have the process change its UID and GID to something not privileged, but retain some smaller set of privileged capabilities to do its job? This is exactly what the capabilities model in Linux is.

The capabilities model in Linux is an attempt to break down the set of permissions that root has into smaller subsets. This way, processes can be confined to the set of minimum privileges they need to perform their intended function. This is known as least privilege, a key ideology when securing systems that minimizes the amount of damage a successful attack can do. In some instances, it can even prevent a successful attack from occurring by blocking an otherwise open attack vector.

There are many capabilities. The man page for capabilities is the de facto documentation. Let's take a look at the CAP_SYS_BOOT capability:

$ man capabilities
...
CAP_SYS_BOOT
       Use reboot(2) and kexec_load(2).

This means a process running with this capability can reboot the system. However, that process can't arbitrarily change USERS and GROUP as it could if it was running as root or with CAP_DAC_READ_SEARCH. This limits what an attacker can do:

<FROM MAN PAGE>
CAP_DAC_READ_SEARCH
      Bypass file read permission checks and directory read and execute permission checks.

Now suppose the case where our restart process runs with CAP_CHOWN. Let's say it uses this capability to ensure that when a restart request is received, it backs up a file from each user's home directory to a server before restarting. Let's say this file is ~/backup, the permissions are 0600, and USER and GROUP are the respective user of that home directory. In this case, we have minimized the permissions as best we can, but the process could still access the users SSH keys and upload those either by error or attack. Another approach to this would be to set the group to backup and run the process with GROUP backup. However, this has limitations. Suppose you want to share this file with another user. That user would require a supplementary group of backup, but now the user can read all of the backup files, not just the ones intended. An astute reader might think about the bind mounts, however the process doing the bind mounts and file permissions also runs with some capability, and thus suffers from this granularity problem as well.

The major issue, and the case for another access control system can be summarized by one word, granularity. The DAC model doesn't have the granularity required to safely handle complex access control models or to minimize the amount of damage a process can do. This is particularly important on Android, where the entire isolation system is dependent on this control, and a rogue root process can compromise the whole system.

Glancing at Android vulnerabilities

With our newly found understanding of the DAC permission model and some of its limitations, let's look at some Android exploits against it. We will cover only a few exploits to understand how the DAC model failed.

Skype vulnerability

CVE-2011-1717 was released in 2011. In this exploit, the Skype application left a SQLite3 database world readable (something analogous to 0666 permissions). This database contained usernames and chat logs, and personal data such as name and e-mail. An application called Skypwned was able to demonstrate this capability. This is an example of how being able to change the permissions on your objects could be bad, especially when the case opens READ to OTHERS.

GingerBreak

CVE-2011-1823 showcases a root attack on Android. The volume management daemon (vold) on Android is responsible for the mounting and unmounting of the external SD card. The daemon listens for messages over a NETLINK socket. The daemon never checked where the messages were sourced from, and any application could open and create a NETLINK socket to send messages to vold. Once the attacker opened the NETLINK socket, they sent a very carefully crafted message to bypass a sanity check. The check tested a signed integer for a maximum bound, but never checked it for negativity. It was then used to index an array. This negative access would lead to memory corruption and, with a proper message, could result in the execution of arbitrary code. The GingerBreak implementation resulted in an arbitrary user gaining root privileges, a textbook privilege execution attack. Once rooted, the device's sandboxes were no longer valid.

Rage against the cage

CVE-2010-EASY is a setuid exhaustion via fork bomb attack. It successfully attacks the adb daemon on Android, which starts life as root and downgrades its permissions if root is not needed. This attack keeps adb as root and returns a root shell to the user. In Linux kernel 2.6, the setuid system call returns an error when the number of running processes RLIMIT_NPROC is met. The adb daemon code does not check the return of setuid, which leaves a small race window open for the attacker. The attacker needs to fork enough processes to reach RLIMIT_NPROC and then kill the daemon. The adb daemon downgrades to shell UID and the attacker runs the program as shell USER, thus the kill will work. At this point, the adb service is respawned, and if RLIMIT_NPROC is maxed out, setuid will fail and adb will stay running as root. Then, running adb shell from a host returns a nice root shell to the user.

MotoChopper

CVE-2013-2596 is a vulnerability in the mmap functionality of a Qualcomm video driver. Access to the GPU is provided by apps to do advanced graphics rendering such as in the case of OpenGL calls. The vulnerability in mmap allows the attacker to mmap kernel address space, at which point the attacker is able to directly change their kernel credential structure. This exploit is an example where the DAC model was not at fault. In reality, outside of patching the code or removing direct graphics access, nothing but programming checks of the mmap bounds could have prevented this attack.
