How-To Tutorials

The Build Helper plugin Within Maven, there are a number of common tasks which plugins can perform to alter the current project for changes occurring during the build. We have seen the inclusion of new resources in the Remote Resources plugin, and the attachment of a new artifact from the Shade plugin. It is also possible to have a plugin generate new source code and include it for compilation, even though the directory is not included in the POM file. The role of the Build Helper plugin is to provide a set of goals that can help achieve a collection of small but common tasks for which it would not be worth writing a custom plugin. Adding source directories Maven's inability to have multiple source directories in the project model has often been called into question. However, as time has progressed the request has died down as the idea of a standardized source structure took hold. The Build Helper plugin offers the ability to add another source directory or test source directory to that configured in the POM. This is not necessarily to allow a workaround for the deliberate limitation in the project model, but rather to facilitate other use cases that require it. The most common need to use this technique is to assist with the migration of a project in an existing layout to Maven temporarily. Even with this capability it is still recommended not to add multiple source directories without a particular reason—apart from breaking with convention, you may find that some tools that operate based on the values in the POM will not recognize the additional directories as containing source code. The following example illustrates the addition of a source directory: <plugin> <groupId>org.codehaus.mojo</groupId> <artifactId>build-helper-maven-plugin</artifactId> <version>1.1</version> <executions> <execution> <id>add-source</id> <phase>generate-sources</phase> <goals> <goal>add-source</goal> </goals> <configuration> <sources> <source>src/main/more-java</source> </sources> </configuration> </execution> </executions></plugin> The need to use the Build Helper plugin for adding sources is now becoming more rare. Maven plugins that generate source code would be likely to add the extra directory to the project internally without the need for additional configuration. If some other means is used to generate the sources—for example, from a scripting plugin—it is common for the scripting plugin to have a way to add the source directory with fewer configurations than using the Build Helper plugin. However, if the need does arise, the Build Helper plugin will prove itself useful. Attaching arbitrary artifacts A similar scenario that can occur is the generation of additional artifacts that need to be attached to the build process. This means they use the same POM to define them, but are different types of related build artifacts, with their own classifier. The artifacts are installed and deployed to the repository alongside the original. Typically, this will be in the form of another JAR file, possibly generated by one of the scripting plugins that did not attach the artifact itself. However, it could be used for any number of files that need to be stored in the repository alongside the main artifact. Consider the example of deploying the license to the repository—if you were to run the install phase on the given project, you would be able to have the license installed into the local repository alongside the main artifact and its POM. In reality, this particular configuration may be overkill, especially if the licenses are identical across many projects, or can be derived from the POM. However, depending on your deployment needs this possibility can be helpful in ensuring the repository contains the information about an artifact that you need, at the time it was deployed, in addition to any extra build artifacts that might be generated. In our example application, we generated the license in two places—in all the Java modules, and the final distribution. Deploying it along with the final distribution makes some sense, so let's add it to the distribution/pom.xml file: <plugin> <groupId>org.codehaus.mojo</groupId> <artifactId>build-helper-maven-plugin</artifactId> <version>1.1</version> <configuration> <artifacts> <artifact> <file> target/maven-shared-archive-resources/LICENSE </file> <type>txt</type> <classifier>license</classifier> </artifact> </artifacts> </configuration> <executions> <execution> <goals> <goal>attach-artifact</goal> </goals> </execution> </executions></plugin> This goal will execute after the packaging has occurred, but before installation so that it can be attached to the installation (and deployment) process. The file to attach is the license generated earlier by the Remote Resources plugin and is given an extension of .txt and classifier of -license. When running the install phase, we now see the file being processed: [INFO] [build-helper:attach-artifact {execution: default}][INFO] [enforcer:enforce {execution: default}][INFO] [install:install][INFO] Installing /Users/brett/code/06/centrepoint/distribution/target/pom-transformed.xml to /Users/brett/.m2/repository/com/effectivemaven/centrepoint/distribution/1.0-SNAPSHOT/distribution-1.0-SNAPSHOT.pom[INFO] Installing /Users/brett/code/06/centrepoint/distribution/target/centrepoint-1.0-SNAPSHOT-bin.zip to /Users/brett/.m2/repository/com/effectivemaven/centrepoint/distribution/1.0-SNAPSHOT/distribution-1.0-SNAPSHOT-bin.zip[INFO] Installing /Users/brett/code/06/centrepoint/distribution/target/centrepoint-1.0-SNAPSHOT-bin.tar.gz to /Users/brett/.m2/repository/com/effectivemaven/centrepoint/distribution/1.0-SNAPSHOT/distribution-1.0-SNAPSHOT-bin.tar.gz[INFO] Installing /Users/brett/code/06/centrepoint/distribution/target/maven-shared-archive-resources/LICENSE to /Users/brett/.m2/repository/com/effectivemaven/centrepoint/distribution/1.0-SNAPSHOT/distribution-1.0-SNAPSHOT-license.txt Other goals The Build Helper plugin also contains some other goals in the latest release at the time of writing (v1.1) of more specific interest: remove-project-artifact: To clean the local repository of artifacts from the project being built to preserve space and remove outdated files. This may occur if the build no longer produces those files, or if it is necessary to remove older versions. reserve-network-port: Many networked applications may want to use a network port that doesn't conflict with other test cases. This goal can help reserve unique ports to use in the tests. This is useful for starting servers in integration tests and then referencing them in the test cases. However, note that it won't be available when running such tests in a non-Maven environment such as the IDE. The goals available in the Build Helper plugin may increase over time, so if you have some small, common adjustments to make it is a good place to look to first for those utilities. The AntRun plugin and scripting languages Maven was designed to be extended through plugins. Because of the fact that this is so strongly encouraged, there are now many plugins available for a variety of tasks, and the need to write your own customizations, particularly for common tasks, is reduced. However, no two projects are the same, and in some projects, there are likely to be some customizations that will need to be made that are not covered by an existing plugin. While it is virtuous to write a plugin for such cases so that it can be reused in multiple projects, it is also very reasonable to use some form of scripting for short, one off customizations. One simple option is to use the AntRun plugin. Ant still contains the largest available set of build tasks to cover the types of customizations that you might need in your build, and through this plugin you can quickly string together some of these tasks within the Maven life cycle to achieve the outcome that you need. Running simple tasks We have already used the AntRun plugin in the distribution module of the example application. This snippet was used to copy some configuration files into place and create a logs directory, ready for the Assembly plugin to create the archive from: <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-antrun-plugin</artifactId> <version>1.1</version> <executions> <execution> <id>config</id> <phase>process-resources</phase> <configuration> <tasks> <copy todir="${project.build.directory}/generated- resources/appassembler/jsw/centrepoint/conf"> <fileset dir="src/main/conf" /> </copy> <mkdir dir="${project.build.directory}/generated- resources/appassembler/jsw/centrepoint/logs" /> </tasks> </configuration> <goals> <goal>run</goal> </goals> </execution> </executions></plugin> This shows how quick and useful the AntRun plugin can be for simple tasks. However, it also contains a number of other features that can be of benefit to the build for more significant tasks. Interacting with the Maven project As we mentioned in the section, The Build Helper plugin, you can tell the plugin to map some directories to new source directories. This functionality is identical to that of the Build Helper plugin, but is more conveniently located when the directories are being generated by Ant tasks. This can be useful because even though tools are increasingly supplying native Maven plugins in addition to Ant tasks, you might come across a source generation tool that only has an Ant task. In this scenario, you can use the AntRun plugin to run the tool, generate the source code, and use the sourceRoot parameter to have that directory added back into the build life cycle. In addition to injecting source directories back into the life cycle, the AntRun plugin also injects Maven project information into Ant's context. Probably the most important of these is the availability of the project's and plugin's dependencies as Ant path references: maven.compile.classpath: The dependencies in the compile scope (this syntax will look familiar to those that used Maven 1's built in Ant-based files) maven.runtime.classpath: The dependencies in the runtime scope (including the above) maven.test.classpath: The dependencies in the test scope (including both of the above) maven.plugin.classpath: The dependencies of the AntRun plugin itself, including any added via the POM Though we have not needed it in the example application, to illustrate how these two options would work, consider if you needed to use the XJC Ant task from JAXB to generate some sources. JAXB is a Java-to-XML binding framework that can be used to generate Java source code from XML schema (among many other things), using its XJC tool. Though it serves as a suitable example here, you would not be faced with this issue with JAXB itself, as it now offers a Maven plugin. In this example, you might add the following configuration to an AntRun execution in a POM file: <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-antrun-plugin</artifactId> <version>1.3</version> <executions> <execution> <id>xjc</id> <phase>generate-sources</phase> <configuration> <tasks> <taskdef name="xjc" classname="com.sun.tools.xjc.XJCTask" classpathref="maven.plugin.classpath" /> <xjc destdir="${project.build.directory}/xjc" schema="src/main/jaxb/schema.xsd"> <classpath refid="maven.compile.classpath" /> </xjc> </tasks> <sourceRoot>${project.build.directory}/xjc</sourceRoot> </configuration> <goals> <goal>run</goal> </goals> </execution> </executions> <dependencies> <dependency> <groupId>com.sun.xml.bind</groupId> <artifactId>jaxb-xjc</artifactId> <version>2.1.9</version> </dependency> </dependencies></plugin> We see here that the XJC Task is defined using the plugin classpath to locate the task and its dependencies (and that task's artifact is added as a plugin dependency to accommodate this). Additional built-in Ant tasks would also be added as plugin dependencies (such as ant-nodeps). AntRun and Ant versions While in some cases they might be compatible, generally you should use the same version of the Ant optional tasks as the version of Ant itself. The version of Ant used by the plugin is predetermined by what it has been built against. In AntRun v1.3, that is Ant 1.7.1. To use a different version of Ant, consider a different version of the AntRun plugin. Next, the task is run—being passed the project's dependencies and schema to generate the source code from. The source code is output to target/xjc, which is also added as a source directory by the AntRun plugin because of the configuration specified. As the task runs in the generate-sources phase, it is available for compilation in the same way as any other source code. Again, the configuration of AntRun here has been relatively simple, and is completely integrated with the Maven artifact handling and build life cycle such that it would not likely be needed to write a plugin to wrap the tool completely if you were faced with this decision in your environment.

Nobody can tell exactly how many Maven plugins exist today—since, like dependencies they can be retrieved from any specified remote repository, there are likely hundreds to choose from, and likely even more that have been custom written for use within the infrastructure of particular organizations. A common practice for frameworks and tools that require build integration is to publish a Maven plugin to accomplish the task—and it is becoming increasingly common to encounter this as a standard part of the getting started section of a project you might hope to use. However, there are also a number of plugins that would be considered general purpose and handle some extended build cases in a wider variety of projects. While this won't come close to covering all the plugins you are likely to encounter, with these common tools in your arsenal it will cover many of your Maven build needs, reducing the need for you to write your own plugins. The Remote Resources plugin Most projects will use the Resources plugin at some point, even if it isn't configured directly—it is standard in the default life cycle for any packaging that produces some type of artifact, bundling the resources found in src/main/resources. However, what if you wanted to share those resources among multiple projects? The best approach to doing that is to store the resources in the repository and retrieve them for use in multiple builds—and that is where the Remote Resources plugin comes in. First, we should note that this is not the only alternative for handling the scenario. The Dependency plugin's unpack goal is also quite capable of unpacking an artifact full of resources directly into the location that will be packaged. However, the Remote Resources plugin offers several advantages: Re-integration with the resources life cycle so that retrieved resources will automatically be processed in any goals in the process-resources phase. The ability to perform additional processing on the resources (including the optional use of Velocity templates to generate the resources) before inclusion. A specific bundle generation goal for creating the resource artifact in the first place. These advantages can make the plugin very effective at dealing with some common scenarios. For example the inspiration for the creation of the plugin, and one of its more common uses, is to place aggregated license files within the final artifact. There are other scenarios where the dependency:unpack goal remains more suitable. It is best to select the Remote Resources plugin when the files will be incorporated into the resources life cycle and the Dependency plugin when the files will be utilized independently. Let's look at how to create a license file for our Centrepoint application. We will do this in two steps—the creation of the resource bundle that provides the generic resources for any project by the same organization, and the processing of the module resources. Creating a Remote Resource bundle Remote Resource bundles are regular JAR files packaged with additional information generated by the remote resource plugin's bundle goal. Creating a module follows the same process as with other JAR files. In the example application, we will create the module outside of the Centrepoint multi-module hierarchy, so that it could (theoretically) be used by other projects from the same organization. This could be anywhere in source control, but we will assume it sits side-by-side with the effectivemaven-parent module in the workspace. $ mvn archetype:generate -DartifactId=license-resources -DgroupId=com.effectivemaven As this is not going to be a code project, the src/main/java and src/test directories can be removed from the generated content. We then continue to add the parent project to the POM, so the result looks like the following: <project xsi_schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd"> <modelVersion>4.0.0</modelVersion> <parent> <groupId>com.effectivemaven</groupId> <artifactId>effectivemaven-parent</artifactId> <version>1-SNAPSHOT</version> <relativePath>../effectivemaven-parent/pom.xml</relativePath> </parent> <artifactId>license-resources</artifactId> <version>1.0-SNAPSHOT</version> <name>License Resource Bundle</name> </project> We will add the Remote Resources plugin shortly, but first let's create the resources that will be bundled. These are added to the src/main/resources like regular resources. Consider the following Velocity template file, src/main/resources/LICENSE.vm: ## License Generator #macro(showUrl $url) #if($url) ($url) #end #end This software is distributed under the following license(s): #foreach ($l in $project.licenses) - $l.name #showUrl ($l.url) #end #if (!$projectsSortedByOrganization.isEmpty()) The software relies on a number of dependencies. The individual licenses are outlined below. #set ($keys = $projectsSortedByOrganization.keySet()) #foreach ($o in $keys) From: '$o.name' #showUrl($o.url) #set ($projects = $projectsSortedByOrganization.get($o)) #foreach ($p in $projects) - $p.name #showUrl ($p.url) $p.artifact #foreach ($l in $p.licenses) License: $l.name #showUrl ($l.url) #end #end #end #end For those not familiar with Velocity, the purpose of this is to first iterate through the project's licenses and list them, then secondly iterate through the project's dependencies (grouped by the organization they are from) and list their license. The $projectsSortedByOrganization variable is a special one added by the Remote Resources plugin to assist in this task. Before we can move on to use the bundle, we need to add the plugin to the bundle project like so: <build> <plugins> <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-remote-resources-plugin</artifactId> <version>1.0</version> <executions> <execution> <goals> <goal>bundle</goal> </goals> </execution> </executions> </plugin> </plugins> </build> This goal is required to generate a bundle manifest, the contents of which tell the plugin which resources to process when it is later called on to do so. With this all in place, we can now install the bundle into the local repository, ready for use: license-resources$ mvn install If you were to inspect the contents of the generated JAR file, you would see both the LICENSE.vm file in the root, and the bundle manifest in META-INF/maven/remoteresources.xml. You would also find that the Velocity template is unmodified—the contents will be executed when the bundle is later processed in the target project, which we will proceed to look at now. Processing Remote Resources in a project Using the resource bundle we have created is now quite straightforward. We start by adding the folllowing to the build section of modules/pom.xml file of Centrepoint: <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-remote-resources-plugin</artifactId> <version>1.0</version> <executions> <execution> <goals> <goal>process</goal> </goals> </execution> </executions> <configuration> <resourceBundles> <resourceBundle> com.effectivemaven:license-resources:1.0-SNAPSHOT </resourceBundle> </resourceBundles> </configuration> </plugin>   Here we have added a list of resource bundle artifacts to the configuration for the process goal, in the familiar shorthand artifact notation of groupId:artifactId:version. It has been added to the modules POM so that the license is included in the JAR files, but not included in the other non-code modules such as the documentation (which already generates a copy of the license from the reporting plugins). Normally, you should use a released version of the license bundle, not a snapshot as we have here (as we have not yet covered the release process!). Since the bundle is configured directly and not through a dependency, the Release plugin will not detect this unresolved snapshot later. Now, if we build a module such as store-api, we will see the license included in the root directory of the JAR file with the following content: This software is distributed under the following license(s): - The Apache Software License, Version 2.0 (http://www.apache.org/licenses/LICENSE-2.0.txt) The software relies on a number of dependencies. The individual licenses are outlined below. From: 'Apache Maven 2: Effective Implementations Book' (http://www.effectivemaven.com/) - Centrepoint Data Model com.effectivemaven.centrepoint:model:jar:1.0-SNAPSHOT License: The Apache Software License, Version 2.0 (http://www.apache.org/licenses/LICENSE-2.0.txt) From: 'Google' (http://www.google.com/) - Guice (http://code.google.com/p/google-guice/) com.google.code.guice:guice:pom:1.0 License: The Apache Software License, Version 2.0 (http://www.apache.org/licenses/LICENSE-2.0.txt) This is a good start, but we don't really need to include our own artifacts in the list, so we go back to the plugin declaration in modules/pom.xml and add another line of configuration: <configuration> <excludeGroupIds>${project.groupId}</excludeGroupIds> <resourceBundles> ... Regenerating the above artifact will alter the license to remove the dependencies from the project's group. A different case is the final distribution. As this is not part of the modules hierarchy, first we need to include the plugin definition identical to the one added previously. In the sample code for this article, you will notice that this has been taken a step further with the version and common configuration pushed into a pluginManagement section of the Centrepoint parent POM, and just the execution of the plugin goal remains in the modules and distribution POM files. We can now build the assembly as usual: distribution$ mvn clean install Upon inspecting the generated assemblies, you will not see the license file included yet. This is because the Assembly plugin does not pick up Maven resources by default, as it does not participate in the normal life cycle. To include the license file, we must alter the assembly descriptor distribution/src/main/assembly/bin.xml and add the following file set: <fileSet> <directory>target/maven-shared-archive-resources</directory> <outputDirectory>/</outputDirectory> </fileSet> The directory given is the standard location in which the Remote Resources plugin stores the resources it has processed, so if you decide to configure that differently in your own projects you would need to change this to the corresponding location. Upon building the assembly again we will see that the license has been generated, and that it includes the licenses of dependencies outside of the Centepoint application. As you can see, the distributed application depends on Jetty (also under the Apache License 2.0), which includes some portions of Glassfish (under the CDDL 1.0 License). While the above technique can be very helpful in constructing some useful information about your project and its dependencies, it cannot be guaranteed to produce complete licensing information for a project. The method relies on accurate information in the POMs of your dependencies, and this can sometimes be inaccurate (particularly when using public repositories such as the Maven Central Repository). If you are redistributing your files, always confirm that you have correctly recorded any necessary licensing information that must accompany them! The Remote Resources plugin is also capable of covering other scenarios that are particularly suited to license handling or more generally recording information about the project it is being processed for. These include: The supplementalDataModels configuration option that allows you to fill in incomplete or incorrect metadata for a project dependency before the resources are processed (to avoid particular problems as described above). The appendedResourcesDirectory, which allows you to store the above models in a separate file. The properties configuration, which allows the injection of other build properties into the Velocity templates. However, with this in mind, remember that the Remote Resources plugin is often just as suitable for any type of reusable resource, even if it is a static file. The Build Number plugin In Maven Mojos, the goals within a plugin are always designed to be simple tasks. Their aim is to do one thing, and do it well. A good example of this is the Build Number plugin. This simple plugin has one goal (create), with one purpose—to obtain a suitable build number and expose it to the build through properties or a file. While the plugin focuses on exposing the current Subversion revision, it is capable of generating an incremented build number (stored in a specified properties file), and a representation of the current system date and time. This feature can be very useful in identifying the exact heritage of a particular build. The build number generated by the plugin is different to that used by Maven to identify snapshots or artifact versions. While it is possible that you might mark your version using the information it generates, this plugin is typically used to record information about a particular build—whether it is a snapshot, or a release—within the artifact itself as a permanent record. Using the plugin is straightforward. By adding the goal to the project, the Subversion revision and a timestamp property will be exposed from the point that it is run onwards. <plugin> <groupId>org.codehaus.mojo</groupId> <artifactId>buildnumber-maven-plugin</artifactId> <version>1.0-beta-1</version> <executions> <execution> <phase>generate-resources</phase> <goals> <goal>create</goal> </goals> </execution> </executions> </plugin> In this example, we execute the plugin in the generate-resources phase so that the properties are available to any resource processing. Note that the values could be used with the Remote Resources plugin that we have just seen. There are two things to take into consideration with this configuration, however. Firstly, not all source builds will be Subversion checkouts, but the plugin does not verify that. To work around this potential problem, you can put the goal into a profile: <profile> <id>buildnumber</id> <activation> <file> <exists>.svn</exists> </file> </activation> <plugin> <groupId>org.codehaus.mojo</groupId> <artifactId>buildnumber-maven-plugin</artifactId> ... This particular activation check will cause the profile to be used within a Subversion checkout (that is, if .svn exists in the current directory), and to skip the plugin if not. In this case, the properties will not be set (or the file will not be created), so the code using these must take that into account. Secondly, how the values will be accessed needs to be given careful consideration. For example, it is unlikely that you want to create a convoluted build processing step to filter the value into a particular JSP file to appear in a web application. For the sake of keeping the build simple (and speedy), it is best to write the values into a single file that the application can then load from its classpath. This can be achieved by creating a filtered resource that contains references to the values. The advantage of this method is that it is automatic if you have already configured filtered resources, and automatically ends up in the classpath of the application code that can load the file as a resource.

We have discussed some of the techniques earlier in Search Engine Optimization using Sitemaps in Drupal 6 article which mainly covered XML sitemaps. The Google spider is quite smart, but then the possibility of them missing pages on your site is also quite high. You may have pages that are not in navigation anymore or you have moved a link to a piece of content so that it's not easily accessible. A possibility is also that your site is very big for Google to just crawl it all without completely pulling all your server's resources. The solution to this is sitemaps. Google News XML Sitemap Google has created one of the most popular news sources on the Internet just by collecting and organizing news articles from other sites. It's called Google News and if you are running a news web site then you know how powerful it can be for picking up your comment. One front page article can generate 50,000 or more visitors in an hour or two. To be listed in Google News takes more than luck. You need to write great content and proactively seek to create timely and news-worthy content. If you've done that and you're still not showing up in Google news then it's time to create a Google News XML Sitemap. The Google News sitemap generator module was originally created by Adam Boyse at Webopius and is being maintained by Dave Reid. Thanks to both of you! Setting up the Google News sitemap generator module Carry out the following steps to set up the Google News sitemap generator module: Download the Google News sitemap module from http://drupal.org/project/googlenews and install it just like a normal Drupal module. Go to http://www.yourDrupalsite.com/admin/settings/googlenews or go to your admin screen, and click the Administer | Site Configuration | Google News sitemap feed link. You'll see a screen similar to the following screenshot: Select the content types that you wish to show up in the news feed. If all your story content types are newsworthy, pick Story. Your blog or page content types are probably not a good fit and selecting them may hurt the chances of your content being approved by Google. Click on Save configuration. Point your browser to http://www.yourDrupalsite.com/googlenews.xml and double check that you can see the sitemap, as shown in the following screenshot: Submitting your Google News sitemap to Google News Once you've assembled your new articles for a single publication label, submit them to Google News sitemaps by carrying out the following steps: Check Google News to see if your site is already included. If not, you can request inclusion by visiting the following link, http://www.google.com/support/news_pub/bin/request.py?ctx=answer. The inclusion process may take up to a few weeks, and you'll only be able to submit a News sitemap once this process is complete. If your site is already showing up in Google News then proceed. If not, you should wait a couple of weeks and try again. Log in to Google Webmaster Tools by pointing your browser to http://www.google.com/webmasters/tools/. On the Webmaster Tools Dashboard, click on Add next to the site you want to submit. From the Choose type drop-down menu, select News sitemap, and then type the sitemap URL, in this case http://www.yourDrupalsite.com/googlenews.xml. In the list, select the publication label for the articles. You can select only one label for each sitemap. Click on OK. URL list The XML Sitemap is the ideal choice because it allows you to specify a lot of information about the content of your site. But, say for some reason that you can't install an XML Sitemap. Maybe there's a conflict with another module that you just have to have. Perhaps your server doesn't have the power to handle the large overhead that an XML sitemap needs for large sites. Or, possibly you want to submit a sitemap to a search engine that doesn't support XML yet. Well, there is an alternative. It's not as robust but it is a functional, albeit rudimentary, solution. Just make a list of every URL in your site and put the list in one big text document with one URL on each line. Too much work, you say? Good thing there is a Drupal module that does all the work for you. It's called the URL list module. It's maintained by David K. Norman. Thank you, David! Setting up a URL list sitemap Download the Sitemap module from http://drupal.org/project/urllist and install it just like a normal Drupal module. Go to http://www.yourDrupalsite.com/admin/settings/urllist or go to your admin screen and click the Administer | Site Configuration | URL list link. You'll see the URL list screen, as shown in the following screenshot: You can adjust the settings to keep track of who accessed the URL list to submit your site to Yahoo! and to help you authenticate with Yahoo! However, you can leave all these settings untouched for now. Point your browser to http://www.yourDrupalsite.com/urllist.txt (http://www.yourDrupalsite.com/?q=urllist.txt if you don't have clean URLs installed) and you'll see your URL list sitemap, as shown in the following screenshot: You can submit this sitemap to Google, Yahoo!, and many other search engines in lieu of an XML sitemap. Just follow the same steps as defined in the Submit your XML Sitemap to Google section above but use # http://www.yourDrupalsite.com/urllist.txt as the URL. Remember to use http://www.yourDrupalsite.com/?q=urllist.txt if Google has problems with your URL.

Customizing Google Maps Google Maps has a comprehensive API for interacting with maps on your website. MooTools can be used to load the Google Maps engine at the correct time. It can also act as a bridge between the map and other HTML elements on your site. To get started, you will first need to get an API key to use Google Maps on your domain. You can sign up for a free key at http://code.google.com/apis/maps/signup.html. Even if you are working on your local computer, you still need the key. For instance, if the base URL of your Joomla installation is http://localhost/joomla, you will enter localhost as the domain for your API key. Once you have an API key ready, create the file basicmap.js in the /components/com_js folder, and fill it with the following code: window.addEvent('domready', function() { if (GBrowserIsCompatible()) { var map = new GMap2($('map_canvas')); map.setCenter(new GLatLng(38.89, -77.04), 12); window.onunload=function() { GUnload(); }; }}); The entire script is wrapped within a call to the MooTools-specific addEvent() member function of window. Because we want this code to execute once the DOM is ready, the first parameter is the event name 'domready'. The second parameter is an anonymous function containing our code. What does the call to function() do?Using function() in JavaScript is a way of creating an anonymous function. This way, you can create functions that are used in only one place (such as event handlers) without cluttering the namespace with a needless function name. Also, the code within the anonymous function operates within its own scope; this is referred to as a closure. Closures are very frequently used in modern JavaScript frameworks, for event handling and other distinct tasks. Once inside of the function, GBrowserIsCompatible() is used to determine if the browser is capable of running Google Maps. If it is, a new instance of GMap2() is declared and bound to the HTML element that has an id of 'map_canvas' and is stored into map. The call to $('map_canvas') is a MooTools shortcut for document.GetElementById(). Next, the setCenter() member function of map is called to tell Google Maps where to center the map and how far to zoom in. The first parameter is a GLatLng() object, which is used to set the specific latitude and longitude of the map's center. The other parameter determines the zoom level, which is set to 12 in this case. Finally, the window.onunload event is set to a function that calls GUnload(). When the user navigates away from the page, this function removes Google Maps from memory, to prevent memory leaks. With our JavaScript in place, it is now time to add a function to the controller in /components/com_js/js.php that will load it along with some HTML. Add the following basicMap() function to this file: function basicMap(){ $key = 'DoNotUseThisKeyGetOneFromCodeDotGoogleDotCom'; JHTML::_('behavior.mootools'); $document =& JFactory::getDocument(); $document->addScript('http://maps.google.com/maps?file=api&v= 2&key=' . $key); $document->addScript( JURI::base() . 'components/com_js/basicmap.js'); ?> <div id="map_canvas" style="width: 500px; height: 300px"></div> <?php} The basicMap() function starts off by setting $key to the API key received from Google. You should replace this value with the one you receive at http://code.google.com/apis/maps/signup.html. Next, JHTML::_('behavior.mootools'); is called to load MooTools into the <head> tag of the HTML document. This is followed by getting a reference to the current document object through the getDocument() member function of JFactory. The addScript() member function is called twice—once to load in the Google Maps API (using our key), then again to load our basicmap.js script. (The Google Maps API calls in all of the functions and class definitions beginning with a capital 'G'.) Finally, a <div> with an id of 'map_canvas' is sent to the browser. Once this function is in place and js.php has been saved, load index.php?option=com_js&task=basicMap in the browser. Your map should look like this: We can make this map slightly more interesting by adding a marker to a specific address. To do so, add the highlighted code below to the basicmap.js file: window.addEvent('domready', function() { if (GBrowserIsCompatible()) { var map = new GMap2($('map_canvas')); map.setCenter(new GLatLng(38.89, -77.04), 12); var whitehouse = new GClientGeocoder(); whitehouse.getLatLng('1600 Pennsylvania Ave NW', function(latlng) { marker = new GMarker( latlng ); marker.bindInfoWindowHtml('<strong>The White House</strong>'); map.addOverlay(marker); }); window.onunload=function(){ GUnload(); }; }}); This code sets whitehouse as an instance of the GClientGeocoder class. Next, the getLatLng() member function of GClientGeocoder is called. The first parameter is the street address to be looked up. The second parameter is an anonymous function where the GLatLng object is passed once the address lookup is complete. Within this function, marker is set as a new GMarker object, which takes the passed-in latlng object as a parameter. The bindInfoWindowHTML() member function of GMarker is called to add an HTML message to appear in a balloon above the marker. Finally, the maker is passed into the addOverlay() member function of GMap2, to place it on the map. Save basicmap.js and then reload index.php?option=com_js&task=basicMap. You should now see the same map, only with a red pin. When you click on the red pin, your map should look like this: Interactive Maps These two different maps show the basic functionality of getting Google Maps on your own website. These maps are very basic; you could easily create them at maps.google.com then embed them in a standard Joomla! article with the HTML code they provide you. However, you would not have the opportunity to add functions that interact with the other elements on your page. To do that, we will create some more HTML code and then write some MooTools-powered JavaScript to bridge our content with Google Maps. Open the /components/com_js/js.php file and add the following selectMap() function to the controller: function selectMap(){ $key = 'DoNotUseThisKeyGetOneFromCodeDotGoogleDotCom'; JHTML::_('behavior.mootools'); $document =& JFactory::getDocument(); $document->addScript('http://maps.google.com/maps?file=api&v =2&key=' . $key); $document->addScript( JURI::base() . 'components/com_js/selectmap.js'); ?> <div id="map_canvas" style="width: 500px; height: 300px"></div> <select id="map_selections"> <option value="">(select...)</option> <option value="1200 K Street NW">Salad Surprises</option> <option value="1221 Connecticut Avenue NW">The Daily Dish</option> <option value="701 H Street NW">Sushi and Sashimi</option> </select><?php} This function is almost identical to basicMap() except for two things—selectmap.js is being added instead of basicmap.js, and a <select> element has been added beneath the <div>. The <select> element has an id that will be used in the JavaScript. The options of the <select> element are restaurants, with different addresses as values. The JavaScript code will bind a function to the onChange event so that the marker will move as different restaurants are selected.

Ring chart The ring chart is identical to the pie chart, except that it renders as a ring versus a complete pie. In addition to sharing all the properties similar to the pie chart, it also defines the following rendering property : Options Property Group Property name Description section-depth This property defines the percentage of the radius to render the section as. The default value is set to 0.5. Ring chart example For this example, simply open the defined pie chart example and select the Ring chart type. Also, set the section-depth to 0.1, in order to generate the following effect: Multi pie chart The multi pie chart renders a group of pie charts, based on a category dataset. This meta-chart renders individual series data as a pie chart, each broken into individual categories within the individual pie charts. The multi pie chart utilizes the common properties defined above, including the category dataset properties. In addition to the standard set of properties, it also defines the following two properties: Options Property Group Property name Description label-format This label defines how each item within a chart is rendered. The default value is set to "{0}". The format string may also contain any of the following: {0}: To render the item name {1}: To render the item value {2}: To render the item percentage in relation to the entire pie chart by-row This value defaults to True. If set to False, the series and category fields are reversed, and individual charts render series information. Note that the horizontal, series-color, stacked and stacked-percent properties do not apply to this chart type. Multi pie chart example This example demonstrates the distribution of purchased item types, based on payment type. To begin, create a new report. You'll reuse the bar chart's SQL query. Now, place a new Chart element into the Report Header. Edit the chart, selecting Multi Pie as the chart type. To configure the dataset for this chart, select ITEMCATEGORY as the category-column. Set the value-columns property to QUANTITY and the series-by-field to PAYMENTTYPE. Waterfall chart The waterfall chart displays a unique stacked bar chart that spans categories. This chart is useful when comparing categories to one another. The last category in a waterfall chart normally equals the total of all the other categories to render appropriately, but this is based on the dataset, not the chart rendering. The waterfall chart utilizes the common properties defined above, including the category dataset properties. The stacked property is not available for this chart. There are no additional properties defined for the waterfall chart. Waterfall chart example In this example, you'll compare by type, the quantity of items in your inventory. Normally, the last category would be used to display the total values. The chart will render the data provided with or without a summary series, so you'll just use the example SQL query from the bar chart example. Add a Chart element to the Report Header and select Waterfall as the chart type. Set the category-column to ITEMCATEGORY, the value-columns to QUANTITY, and the series-by-value property to Quantity. Now, apply your changes and preview the results. Bar line chart The bar line chart combines the bar and line charts, allowing visualization of trends with categories, along with comparisons. The bar line chart is unique in that it requires two category datasets to populate the chart. The first dataset populates the bar chart, and the second dataset populates the line chart. The bar line chart utilizes the common properties defined above, including the category dataset properties. This chart also inherits the properties from both the bar chart, as well as the line chart. This chart also has certain additional properties, which are listed in the following table: Required Property Group Property name Description bar-data-source The name of the first dataset required by the bar line chart, which populates the bars in the chart. This value is automatically populated with the correct name. line-data-source The name of the second dataset required by the bar line chart, which populates the lines in the chart. This value is automatically populated with the correct name. Bar Options Property Group Property name Description ctgry-tick-font Defines the Java font that renders the Categories. Line Options Property Group Property name Description line-series-color Defines the color in which to render each line series. line-tick-fmt Specifies the Java DecimalFormat string for rendering the Line Axis Labels lines-label-font Defines the Java font to use when rendering line labels. line-tick-font Defines the Java font to use when rendering the Line Axis Labels. As part of the bar line chart, a second y-axis is defined for the lines. The property group Y2-Axis is available with similar properties as the standard y-axis. Bar line chart example To demonstrate the bar line chart, you'll reuse the SQL query from the area chart example. Create a new report, and add a Chart element to the Report Header. Edit the chart, and select Bar Line as the chart type. You'll begin by configuring the first dataset. Set the category-column to ITEMCATEGORY, the value-columns to COST, and the series-by-value property to Cost. To configure the second dataset, set the category-column to ITEMCATEGORY, the value-columns to SALEPRICE, and the series-by-value property to Sale Price. Set the x-axis-label-width to 2.0, and reduce the x-font size to 7. Also, set show-legend to True. You're now ready to preview the bar line chart. Bubble chart The bubble chart allows you to view three dimensions of data. The first two dimensions are your traditional X and Y dimensions, also known as domain and range. The third dimension is expressed by the size of the individual bubbles rendered. The bubble chart utilizes the common properties defined above, including the XY series dataset properties. The bubble chart also defines the following properties: Options Property Group Property name Description max-bubble-size This value defines the diameter of the largest bubble to render. All other bubble sizes are relative to the maximum bubble size. The default value is 0, so this value must be set to a reasonable value for rendering of bubbles to take place. Note that this value is based on pixels, not the domain or range values. The bubble chart defines the following additional dataset property: Required Property Group Property name Description z-value-columns This is the data source column to use for Z value, which specifies the bubble diameter relative to the maximum bubble size. Bubble chart example In this example, you need to define a three dimensional SQL query to populate the chart. You'll use inventory information, and calculate Item Category Margin: SELECT"INVENTORY"."ITEMCATEGORY","INVENTORY"."ONHAND","INVENTORY"."ONORDER","INVENTORY"."COST","INVENTORY"."SALEPRICE","INVENTORY"."SALEPRICE" - "INVENTORY"."COST" MARGINFROM"INVENTORY"ORDER BY"INVENTORY"."ITEMCATEGORY" ASC Now that you have a SQL query to work with, add a Chart element to the Report Header and select Bubble as the chart type. First, you'll populate the correct dataset fields. Set the series-by-field property to ITEMCATEGORY. Now, set the X, Y, and Z value columns to ONHAND, SALEPRICE, and MARGIN. You're now ready to customize the chart rendering. Set the x-title to On Hand, the y-title to Sales Price, the max-bubble-size to 100, and the show-legend property to True. The final result should look like this:

How BAM differs from traditional business intelligence The Oracle SOA Suite stores the state of all processes in a database in documented schemas so why do we need yet another reporting tool to provide insight into our processes and services? In other words how does BAM differ from traditional BI (Business Intelligence)? In traditional BI, reports are generated and delivered either on a scheduled basis or in response to a user request. Any changes to the information will not be reflected until the next scheduled run or until a user requests the report to be rerun. BAM is an event-driven reporting tool that generates alerts and reports in real time, based on a continuously changing data stream, some of whose data may not be in the database. As events occur in the Services and Processes, the business has defined they are captured by BAM and reports and views are updated in real time. Where necessary these updated reports are delivered to users. This delivery to users can take several forms. The best known is the dashboard on users' desktops that will automatically update without any need for the user to refresh the screen. There are also other means to deliver reports to the end user, including sending them via a text message or an email. Traditional reporting tools such as Oracle Reports and Oracle Discoverer as well as Oracles latest Business Intelligence Suite can be used to provide some real-time reporting needs but they do not provide the event driven reporting that gives the business a continuously updating view of the current business situation. Event Driven Architecture Event Driven Architecture (EDA) is about building business solutions around responsiveness to events. Events may be simple triggers such as a stock out event or they may be more complex triggers such as the calculations to realize that a stock out will occur in three days. An Event Driven Architecture will often take a number of simple events and then combine them through a complex event processing sequence to generate complex events that could not have been raised without aggregation of several simpler events. Oracle BAM scenarios Oracle Business Activity Monitoring is typically used to monitor two distinct types of real-time data. Firstly it may be used to monitor the overall state of processes in the business. For example it may be used to track how many auctions are currently running, how many have bids on them, and how many have completed in the last 24 hours (or other time periods). Secondly it may be used to track in real-time Key Performance Indicators or KPIS. For example it may be used to provide a real-time updating dashboard to a seller to show the current total value of all the sellers' auctions and to track this against an expected target. In the first case, we are interested in how business processes are progressing and are using BAM to identify bottlenecks and failure points within those processes. Bottlenecks can be identified by too much time being spent on given steps in the process. BAM allows us to compute the time taken between two points in a process, such as the time between order placement and shipping, and provide real-time feedback on those times. Similarly BAM can be used to track the percentage drop-out rate between steps in a sales process, allowing the business to take appropriate action. In the second case, our interest is on some aggregate number, such as our total liabilities should we win all the auctions we are bidding on. This requires us to aggregate results from many events, possibly performing some kind of calculation on them to provide us with a single KPI that gives an indication to the business of how things are going. BAM allows us to continuously update this number in real on a dashboard without the need for continued polling. It also allows us to trigger alerts, perhaps through email or SMS, to notify an individual, when a threshold is breached. In both cases reports delivered can be customized based on the individual receiving the report. BAM architecture It may seem odd to have a section on architecture in the middle of a article about how to effectively use BAM, but key to successful utilization of BAM is an understanding of how the different tiers relate to each other. Logical view The following diagram represents a logical view of how BAM operates. Events are acquired from one or more sources through event acquisition and then normalized, correlated, and stored in event storage (generally a memory area in BAM that is backed up to disc). The report cache generates reports based on events in storage and then delivers those reports, together with real-time updates through the report delivery layer. Event processing is also performed on events in storage, and when defined conditions are met, alerts will be delivered through the alert delivery service. Physical view To better understand the physical view of the architecture of BAM, we have divided this section into four parts. Let us discuss these in detail. Capture This logical view maps onto the physical BAM components shown in the following diagram. Data acquisition in the SOA Suite is handled by sensors in BPEL and ESB. BAM can also receive events from JMS message queues and access data in databases (useful for historical comparison). For complex data formats or for other data sources then Oracle Data Integrator (ODI is a separate product to the SOA Suite) is recommended by Oracle. Although potentially less efficient and more work than running ODI, it is also possible to use adapters to acquire data from multiple sources and feed it into BAM through ESB or BPEL. At the data capture level we need to think of the data items that we can provide to feed the reports and alerts that we desire to generate. We must consider the sources of that data and the best way to load it into BAM. Store Once the data is captured, it is then stored in a normalized form in the Active Data Cache (ADC). This storage facility has the ability to do simple correlation based on fields within the data, and multiple data items received from the acquisition layer may update just a single object in the data cache. For example the state of a given BPEL process instance may be represented by a single object in the ADC and all updates to that process state will just update that single data item rather than creating multiple data items. Process Reports are run based on user demand. Once a report is run it will update the user's screen on a real time basis. Where multiple users are accessing the same report only one instance of the report is maintained by the report server. As events are captured and stored in real time the report engine will continuously monitor them for any changes that need to be made to those reports which are currently active. When changes are detected that impact active reports, then the appropriate report will be updated in memory and the updates sent to the user screen. In addition to the event processing required to correctly insert and update items in the ADC, there is also a requirement to monitor items in the ADC for events that require some sort of action to be taken. This is the job of the event processor. This will monitor data in the ADC to see if registered thresholds on values have been exceeded or if certain time-outs have expired. The event processor will often need to perform calculations across multiple data items to do this. Deliver Delivery of reports takes place in two ways. First, users request reports to be delivered to their desktop by selecting views within BAM. These reports are delivered as HTML pages within a browser and are updated whenever the underlying data used in the report changes. The second approach is that reports are sent out as a result of events being triggered by the Event Processing Engine. In the latter case, the report may be delivered by email, SMS, or voice messaging using the notifications service. A final option available for these event generated reports is to invoke a web service to take some sort of automated action. Closing the loop While monitoring what is happening is all very laudable, it is only of benefit if we actually do something about what we are monitoring. BAM provides the real-time monitoring ability very well but it also provides the facility to invoke other services to respond to undesirable events such as stock outs. The ability to invoke external services is crucial to the concept of a closed loop control environment where as a result of monitoring we are able to reach back into the processes and either alter their execution or start new ones. For example when a stock out or low stock event is raised then the message centre could invoke a web service requesting a supplier to send more stock to replenish inventory. Placing this kind of feedback mechanism in BAM allows us to trigger events across multiple applications and locations in a way that may not be possible within a single application or process. For example, in response to a stock out, instead of requesting our supplier to provide more stock, we may be monitoring stock levels in independent systems and, based on stock levels elsewhere, may redirect stock from one location to another. BAM platform anomaly In 10g SOA Suite, BAM runs only as a Windows application. Unlike the rest of SOA Suite, it does not run on a JEE Application Server and it can only run on the Windows platform. In the next release, 11g, BAM will be provided as a JEE application that can run on a number of application servers and operating systems. User interface Development in Oracle BAM is done through a web-based user interface. This user interface gives access to four different applications that allow you to interact with different parts of BAM. These are: Active Viewer for giving access to reports; this relates to the deliver stage for user requested reports. Active Studio for building reports; this relates to the 'process' stage for creating reports. Architect for setting up both inbound and outbound events. Data elements are defined here as data sources. Alerts are also configured here. This covers setting up, acquire and store stages as well as the deliver stage for alerts. Administrator for managing users and roles as well as defining the types of message sources. We will not examine the applications individually but will take a task-focused look at how to use them as part of providing some specific reports. Monitoring process state Now that we have examined how BAM is constructed, let us use this knowledge to construct some simple dashboards that track the state of a business process. We will instrument a simple version of an auction process. The process is shown in the following figure: An auction is started and then bids are placed until the time runs out at which point the auction is completed. This is modelled in BPEL. This process has three distinct states: Started Bid received Completed We are interested in the number of auctions in each state as well as the total value of auctions in progress. One needs to follow these steps to build the dashboard: Define our data within the Active Data Cache Create sensors in BPEL and map to data in the ADC Create suitable reports Run the reports Defining data objects Data in BAM is stored in data objects. Individual data objects contain the information that is reported in BAM dashboards and may be updated by multiple events. Generally BAM will report against aggregations of objects, but there is also the ability for reports to drill down into individual data objects. Before defining our data objects let's group them into an Auction folder so they are easy to find. To do this we use the BAM Architect application and select Data Objects which gives us the following screen: We select Create subfolder to create the folder and give it a name Auction. We then select Create folder to actually create the folder and we get a confirmation message to tell us that the folder was created. Notice that once created, the folder also appears in the Folders window on the left-hand side of the screen. Now we have our folder we can create a data object. Again we select Data Objects from the drop-down menu. To define the data objects that are to be stored in our Active Data Cache, we open the Auction folder if it is not already open and selectCreate Data Object. If we don't select the Auction folder then we pick it later when filling in the details of the data object. We need to give our object a unique name within the folder and optionally provide it with a tip text that helps explain what the object does when the mouse is moved over it in object listings. Having named our object we can now create the data fields by selecting Add a field. When adding fields we need to provide a name and type as well as indicating if they must contain data; the default Nullable does not require a field to be populated. We may also optionally indicate if a field should be public "available for display" and what if any tool tip text it should have. Once all the data fields have been defined then we can click Create Data Object to actually create the object as we have defined it. We are then presented with a confirmation screen that the object has been created. Grouping data into hierarchies When creating a data object it is possible to specify Dimensions for the object. A dimension is based on one or more fields within the object. A given field can only participate in one dimension. This gives the ability to group the object by the fields in the given dimension. If multiple fields are selected for a single dimension then they can be layered into a hierarchy, for example to allow analysis by country, region, and city. In this case all three elements would be selected into a single dimension, perhaps called geography. Within geography a hierarchy could be set up with country at the top, region next, and finally city at the bottom, allowing drill down to occur in views. Just as a data object can have multiple dimensions, a dimension can also have multiple hierarchies. A digression on populating data object fields In the previous discussion, we mentioned the Nullable attribute that can be attached to fields. This is very important as we do not expect to populate all or even most of the fields in a data object at one moment in time. Do not confuse data objects with the low level events that are used to populate them. Data objects in BAM do not have a one-to-one correspondence with the low level events that populate them. In our auction example there will be just one auction object for every auction. However there will be at least two and usually more messages for every auction; one message for the auction starting, another for the auction completing, and additional messages for each bid received. These messages will all populate or in some cases overwrite different parts of the auction data object. The table shows how the three messages populate different parts of the data object. Message Auction ID State Highest bid Reserve Expires Seller Highest bidder Auction Started Inserted Inserted Inserted Inserted Inserted Inserted   Bid Received   Updated Updated       Updated Auction Finished   Updated           Summary In this article we have explored how Business Activity Monitoring differs from and is complementary to more traditional Business Intelligence solutions such as Oracle Reports and Business Objects. We have explored how BAM can allow the business to monitor the state of business targets and Key Performance Indicators, such as the current most popular products in a retail environment or the current time taken to serve customers in a service environment.

The Microsoft SQL Server 2008 Reporting Services Report Builder 2.0 tool can be installed from a standalone installer available at this Microsoft site, http://download.microsoft.com/download/a/f/6/af64f194-8b7e-4118-b040-4c515a7dbc46/ReportBuilder.msi. The same file is also available from a collection of download files when you access the Microsoft SQL Server 2008 Feature Pack, October 2008 at http://www.microsoft.com/downloads/details.aspx?FamilyId=228DE03F-3B5A-428A-923F-58A033D316E1&displaylang=en. Report Builder overview In the present version of SQL Server 2008 [Enterprise Evaluation edition] there  are two Report Builders available. Report Builder 1.0, which has remained as a program that can be launched from the Report Manager, and the new Report Builder 2.0, which is a stand alone report authoring tool that needs to be independently launched. Although Report Builder 1.0 can access Report Models built with Visual Studio 2008 and the Report Manager, it cannot be used to create reports using those models. It also does not work with Reports generated by Visual Studio 2008/BIDS/Report Builder 2.0. The errors can be summarized as follows: When you try to access the Report Server 2008 from the link provided on the Report Builder 1.0 interface you get the following error message: Specifying credentials in a URL is not supported When you try to open a report created using VS2008/BIDS/ReportBuilder2.0 using the Open Report… and Open File… navigational items in Report Builder 1.0 you get the following error message: System.IO.StreamReader: The Report element was not found Report Builder 1.0 allows you to access Report Models created with VS2008/BIDS/Report Manager and even allows you create a report in design view but this report cannot be processed on the Report Server. If you try to do so, you get the following error message: MemoryStream length must be non-negative and less than 2^31-1-origin. Parameter name: offset; Remote GDI stream version: ?. Expected version: 11.0.1 In this article the Report Builder 2.0 interface will be described along with the new features that are incorporated into this version. Report Builder 2.0 is admirably suited to address all items in the Report Definition Language of 2008. One of the important features of Report Builder 2.0 is the empowerment it provides business users to create ad hoc reports using the Report Models built on the databases they use. In this article you will be learning mostly about the Report Builder 2.0  interface details and working with it to create reports or modify them. It may be noted that Report Builder generates 2008 compliant RDL files as described in http://download.microsoft.com/download/6/5/7/6575f1c8-4607-48d2-941d-c69622e11c32/RDL_spec_08.pdf and therefore, cannot work with reports generated using 2005 technology. Report Builder 2.0 user interface description Report Builder is a report authoring tool and the basic procedure for authoring a report consists of the following steps: Report planning Connecting to a source of data Extracting a dataset from source Designing the report and data binding Previewing the report Although deploying the report is not included in the above, Report Builder can deploy the report as well. It is not always necessary to deploy a completed report, as any part of a report definition file can be deployed. This makes modifying a report on the server very flexible. In the following sections, the various parts of the Report Builder interface will be described starting at the very top and going to the bottom of the interface The menu for file operations Report Builder 2.0 can be accessed from Start | All Programs | Microsoft SQL Server 2008 Report Builder | Report Builder 2.0. This brings up the Report Builder Interface 2.0 as shown with the design area containing two icons: Table or Matrix and Chart. Each of these will launch a  related wizard which will step you through the various tasks. The Report Builder 2.0 interface is very similar to Office 2007. More than one instance of Report Builder can be launched. At the very top of the following screen shown you have the undo and redo controls as well as a save icon. When you click on the save icon the Save as Report window gets displayed as shown. Here you provide a name for the report. The default save extension is  *.rdl and it will be saved to the report server. It may also be persisted to a folder on your machine. Clicking on the Office Button (top left) opens a drop-down window shown in the following screenshot: In this window, you can carry out a number of tasks such as creating a new report, opening an existing report, saving a report, and saving a report with a different name. The Save button saves it to the default location seen earlier and Save as invokes the same window to save the report with a different name as seen earlier displying the report server instance as the Save to location. The Recent Documents pane shows the more recent reports created with this tool. New allows you to create a new report. When you click on Open, the following Open Report window gets displayed with the default location http://Hodentek2:8080/ReportServer_SANGAM/My Reports. You will also notice the message: This folder is not available because the My Reports feature is not enabled on the computer. Also the Open Reports window allows you look for reports with the extension .rdl. Therefore, unless the My Reports feature is enabled, this window is unusable. This is supposed to be possible from Report Manager but there are no controls in Report Manager that would do this. An alternative was suggested by one of the MSDN forum moderators (see http://social.msdn.microsoft.com/forums/en-US/sqlreportingservices/thread/6c695160-29e8-4185-be6d-5fe027a6975c/). Hands-on exercise (Part 2) will describe how you may enable My Reports. The idea of My Reports is similar to My Documents where each user can keep his reports. When the Options button (in the previous screenshot) is clicked it opens the window Report Builder Options window with two tabbed pages Settings and Resource shown as follows: Here you can view, as well as modify, Report Builder settings. The defaults are more than adequate to work with the examples in this book. Clicking on the Resources button brings up this interesting window which enables you to interact with Microsoft regarding SSRS activities, concerns, community, and so on. If you are serious about Reporting Services, these are very valuable links. The About button when clicked can provide you with Report Builder version information. The ribbon The main menu consists of Home, Insert, and View menu items which are part of the "ribbon". The ribbon introduced by Microsoft in Office 2007 is actually a container for other toolbar items. The ribbon is the replacement for the classic menus, toolbars, and is supposed to be more efficient and discoverable by the user. In fact you see a lot more on the "ribbon" than in the classic menu. Home The next figure shows the Home menu with its toolbar arranged from left to right and divided into sections. The Run toolbar item with the title Views when clicked would run the report open in the design view (in fact, even without a report open in the design view, the report can be run. The result would be the current date and time getting displayed in the center of the screen of an untitled report which has just ExecutionTime as the only item in the report). The Font, Paragraph, Border, and Number toolbar sections become enabled if parts of a report need editing. The formatting of textboxes in the report, the formatting of numbers in the report, and the alignment of components in the layout can all be independently managed using these toolbar items. Insert When you click on the Insert menu item on the "ribbon", the tabbed page for this item is displayed as shown in the following screenshot: It has four sections: Data Regions, Report Items, Subreports, and Header & Footer. These are all the normal items that are used either individually or together to make up a report. There can be more than one data region in a report. Data Regions In the Data Regions section you have both the Tablix (Table, Matrix, and List) and the graphic controls that can be bound to data—the Chart and the Gauge. Gauge is new in SQL Server Reporting Services 2008. Chart and gauge implementations are the off shoot of collaboration with Dundas (http://www.dundas.com/). Report Builder is built in such a way that the dataset must be defined before any of the data regions are added to the report body. For the purpose of describing the various data regions in this section, it is assumed (in order to get the screen shots shown here) that a dataset has been defined and the default wizards on the design surface have been removed. Table The Table is meant for displaying data retrieved from a database either all data detailed in groups or a combination (some grouped and some detailed) of both. It has a fixed number of columns which can be adjusted at design time. The table length expands to accommodate the rows. Data can be grouped by a single field or by multiple fields. Expression designer can be used in grouping as well. The grouping is carried out by creating row groups. Static rows can be added for row headings (labels) and totals. Aggregates for groups can be added. Both detailed data as well as grouped data can be hidden initially and the user can interactively reveal the data needed by drill downs. When you click on Insert | Table | Insert Table and then click on the design surface you can add a table to the design area. The table appears as shown with handles to adjust its dimensions. The table can be dragged to any other location on the design surface (the body of the report) as well. After placing the table, which by default has three columns and two rows, when you click on any other part of the design area you will see the table as shown. When you hover over the cell marked Data on the table you will see a little icon. This icon is a minimized version of the dataset fields. The grayed out feature that surrounds the table indicate the position of the rows and columns of the table. It also shows such other features as whether it is a detail, or whether it is a group. In the case of group, within a group the feature would indicate the nesting schematically as well. When you want to increase the size of a column or a row you can drag the double headed arrow that gets displayed when your cursor is placed between two columns or between two cells as shown. When you click on the dataset icon in the cell Data you get a drop-down list containing the fields in the dataset as shown. You can choose any of the fields to occupy the cell you clicked and the corresponding header will be added to the table. In this particular dataset there are nine fields and you can choose any of them to occupy the cell. When you right-click on a cell, a drop-down menu will be available. It can be used for the following: Work with the highlighted textbox (each cell of the table is a textbox) including to copy, cut, delete, and paste contents. Work with the properties of the Textbox. Populate the textbox with an expression using the expression builder. The expression builder gets displayed when fx Expression is clicked. Use Select to select the body or the Tablix. Insert a new column or a new row. Columns can be added to the right or the left of the clicked cell and rows can be added above or below the clicked cell. Delete columns and rows. Add a group. Both row and column groups can be added. When you click on the properties of the textbox, the Text Box Properties window is displayed. The textbox has several properties which are arranged on the left as a list with each item having its own page as shown. The Help button on any of the pages will take you directly to the definition of the properties and is extremely useful. In the General page, you can make changes to the elements in the Name, Value, and Sizing options page as shown. The Value is one which you choose among the column values (from the drop-down) from the dataset. You may also add a text for the ToolTip, which will display this text when the report is generated and this cell is accessed by hovering over it in the report. Alternatively you can set the Value and Tooltip using fx—the button that brings up the Expression window. In the Number page you can set the number and date data type formatting options for the cell that contains a number or a date. This is what you normally would find in most Microsoft products such as Excel and Access. In the Alignment page you can choose the vertical and horizontal alignments as well as the padding of the textbox content from the edges of the cell. Similarly the Font and Border properties are the same ones you find in most Microsoft products. The Fill property lets you add or change background color to the report as well as add a graphic element. The graphic element can be embedded, external, or originate from a database (being one of the fields accessed). Expressions can be developed to set a desired color for the Fill. The Visibility of the textbox can be any of Show, Hide, Show or Hide based on an expression. In each of these cases the visibility can be toggled when another table cell is clicked (which can be chosen). This page also gives access to the Expression window which is similar to the MS Access expression builder. The Interactive Sorting page allows you to define interactive sorting options on  the textbox. Matrix Matrix provides a similar functionality (roughly speaking rows against columns) to cross-tab reports in MS Access (http://aspalliance.com/1041_Creating_a_Crosstab_Report_in_Visual_Studio_2005_Using_Crystal_Reports.all) and Pivot Table dynamic views (http://www.aspfree.com/c/a/MS-SQL-Server/On-Accessing-Data-From-An-OLAP-Server-Using-MS-Excel/3/). The matrix should have at least one row group and one column group. The matrix can expand both ways to accommodate the data, horizontally for column groups and vertically for row groups. The matrix cells (intersection of rows and columns) display summary information (aggregates). When you click on Insert Matrix in the Insert menu and drop it on the design area of Report Builder 2.0, it gets displayed as shown in the following figure: Now if you click inside the boundary of the (2x2) empty matrix you will see more features of the matrix as shown in the following screenshot. The basic elements are the ColumnGroup (Column Groups), the RowGroup (Row Groups), and the Data. The group information is also displayed as shown by overlaid lines pointing to them. There needs to be a minimum of one group and one column for the matrix and there could be a hierarchy of column and row groups. The row and column group cells have their own properties which can be displayed when you right-click on them as shown in the next screenshot for the row group. When you right-click on the cell marked Rows, the following drop-down menu  pops up. In addition to the properties that you can set for the textbox in that cell, you have additional submenu items that work with the grouping and totaling. These are part of representing data in a matrix. Each of the Tablix for the Rows and Columns has the additional submenu items which are shown here for the Rows. Similar ones apply for the Columns as well. These are useful when you want to create nested groups. With the Matrix design interface in SQL Server 2005 this would not have been possible. Add Group Row Group Parent Group... Child Group... -------------------- Adjacent Above Adjacent Below Row Group Delete Group Group Properties Add Total Before After In addition to the above, each of the items Rows and Columns cells has the following items as well. These specify how new columns and rows are inserted with reference to the current cell as shown. The differences are due to the geometrical positions that are allowed for the new columns or rows as shown. For the "Columns" cell: Insert Column Inside Group-Left Inside Group-Right ------------------ Outside Group-Left Outside Group-Right Insert Row Inside Group-Above Inside Group-Below ------------------ Outside Group_Above For the "Rows" cell: Insert Column Inside Group-Left Inside Group-Right ------------------ Outside Group-Left Insert Row Inside Group-Above Inside Group-Below ------------------ Outside Group_Above Outside Group_Below Besides using a cell as a starting point, one could also use the rows as a whole or column as a whole to add further structure as shown in the next figure. Of course you need to use the proper submenu option to arrive at a particular matrix structure. Clicking at the indicated points would let you choose the structure you want for your matrix. If you click at the location shown for the Tablix you could choose to the delete the whole matrix. The Tablix graphical arrangement gives you the maximum flexibility in extending the matrix in 2-dimensions. List The list data region repeats for each row of data. List element provides a single container for the data which can be used to generate what are called Free Form Reports. In this kind of report there is no rigid structure such as a table for the data. You can also place a list inside another list or even a chart inside a list. You can drag a column from a dataset and drop it into the list. You can work with the list using the properties of the Rectangle it contains as well as its Tablix properties. As described earlier, the design interface is very flexible and you can leverage all features provided by the Tablix structure like displaying details and adding groups either independent, or nested. The properties pages described earlier allow you to sort and filter grouped data. When you drop a List on the design surface you will see just a single cell as shown. You can change its dimensions to suit your needs. When you click on the List you can access its handles as shown: When you add a List, there is one column and one row (just one cell). This can be extended in both directions by choosing the appropriate submenu items. These can be displayed by right-clicking on the handles as shown:

Technically, AJAX is an acronym standing for Asynchronous JavaScript and XML. The technologies involved in an AJAX solution include: JavaScript, to capture interactions with the user or other browser-related events The XMLHttpRequest object, which allows requests to be made to the server without interrupting other browser tasks XML files on the server, or often other similar data formats such as HTML or JSON More JavaScript, to interpret the data from the server and present it on the page Many frameworks have sprung up to assist developers in taming it, because of the inconsistencies in the browsers' implementations of the XMLHttpRequest object; jQuery is no exception. Let us see if AJAX can truly perform miracles. Loading data on demand Underneath all the hype and trappings, AJAX is just a means of loading data from the server to the web browser, or client, without a visible page refresh. This data can take many forms, and we have many options for what to do with it when it arrives. We'll see this by performing the same basic task in many ways. We are going to build a page that displays entries from a dictionary, grouped by the starting letter of the dictionary entry. The HTML defining the content area of the page will look like this: <div id="dictionary"></div> Yes, really! Our page will have no content to begin with. We are going to use jQuery's various AJAX methods to populate this <div> with dictionary entries. <div class="letters"> <div class="letter" id="letter-a"> <h3><a href="#">A</a></h3> </div> <div class="letter" id="letter-b"> <h3><a href="#">B</a></h3> </div> <div class="letter" id="letter-c"> <h3><a href="#">C</a></h3> </div> <div class="letter" id="letter-d"> <h3><a href="#">D</a></h3> </div></div> As always, a real-world implementation should use progressive enhancement to make the page function without requiring JavaScript. Here, to simplify our example, the links do nothing until we add behaviors to them with jQuery. As always, a real-world implementation should use progressive enhancement to make the page function without requiring JavaScript. Here, to simplify our example, the links do nothing until we add behaviors to them with jQuery. Adding a few CSS rules, we get a page that looks like this: Now we can focus on getting content onto the page. Appending HTML AJAX applications are often no more than a request for a chunk of HTML. This technique, sometimes referred to as AHAH (Asynchronous HTTP and HTML), is almost trivial to implement with jQuery. First we need some HTML to insert, which we'll place in a file called a.html alongside our main document. This secondary HTML file begins: <div class="entry"> <h3 class="term">ABDICATION</h3> <div class="part">n.</div> <div class="definition"> An act whereby a sovereign attests his sense of the high temperature of the throne. <div class="quote"> <div class="quote-line">Poor Isabella's Dead, whose abdication</div> <div class="quote-line">Set all tongues wagging in the Spanish nation.</div> <div class="quote-line">For that performance 'twere unfair to scold her:</div> <div class="quote-line">She wisely left a throne too hot to hold her.</div> <div class="quote-line">To History she'll be no royal riddle &mdash;</div> <div class="quote-line">Merely a plain parched pea that jumped the griddle.</div> <div class="quote-author">G.J.</div> </div> </div></div><div class="entry"> <h3 class="term">ABSOLUTE</h3> <div class="part">adj.</div> <div class="definition"> Independent, irresponsible. An absolute monarchy is one in which the sovereign does as he pleases so long as he pleases the assassins. Not many absolute monarchies are left, most of them having been replaced by limited monarchies, where the sovereign's power for evil (and for good) is greatly curtailed, and by republics, which are governed by chance. </div></div> The page continues with more entries in this HTML structure. Rendered on its own, this page is quite plain:   Note that a.html is not a true HTML document; it contains no <html>, <head>, or <body>, all of which are normally required. We usually call such a file a snippet or fragment; its only purpose is to be inserted into another HTML document, which we'll accomplish now: $(document).ready(function() { $('#letter-a a').click(function() { $('#dictionary').load('a.html'); return false; });}); The .load() method does all our heavy lifting for us! We specify the target location for the HTML snippet by using a normal jQuery selector, and then pass the URL of the file to be loaded as a parameter to the method. Now, when the first link is clicked, the file is loaded and placed inside <div id="dictionary">. The browser will render the new HTML as soon as it is inserted:   Note that the HTML is now styled, whereas before it was plain. This is due to the CSS rules in the main document; as soon as the new HTML snippet is inserted, the rules apply to its tags as well. When testing this example, the dictionary definitions will probably appear instantaneously when the button is clicked. This is a hazard of working on our applications locally; it is hard to account for delays in transferring documents across the network. Suppose we added an alert box to display after the definitions are loaded: $(document).ready(function() { $('#letter-a a').click(function() { $('#dictionary').load('a.html'); alert('Loaded!'); return false; });}); However, when this particular code is tested on a production web server, the alert will quite possibly have come and gone before the load has completed, due to network lag. This happens because all AJAX calls are by default asynchronous. Otherwise, we'd have to call it SJAX, which hardly has the same ring to it! Asynchronous loading means that once the HTTP request to retrieve the HTML snippet is issued, script execution immediately resumes without waiting. Sometime later, the browser receives the response from the server and handles it. This is generally desired behavior; it is unfriendly to lock up the whole web browser while waiting for data to be retrieved. If actions must be delayed until the load has been completed, jQuery provides a callback for this. An example will be provided below.   Working with JavaScript objects Pulling in fully-formed HTML on demand is very convenient, but there are times when we want our script to be able to do some processing of the data before it is displayed. In this case, we need to retrieve the data in a structure that we can traverse with JavaScript. With jQuery's selectors, we could traverse the HTML we get back and manipulate it, but it must first be inserted into the document. A more native JavaScript data format can mean even less code. Retrieving a JavaScript object As we have often seen, JavaScript objects are just sets of key-value pairs, and can be defined succinctly using curly braces ({}). JavaScript arrays, on the other hand, are defined on the fly with square brackets ([]). Combining these two concepts, we can easily express some very complex and rich data structures. The term JavaScript Object Notation (JSON) was coined by Douglas Crockford to capitalize on this simple syntax. This notation can offer a concise alternative to the sometimes-bulky XML format: { "key": "value", "key 2": [ "array", "of", "items" ]} For information on some of the potential advantages of JSON, as well as implementations in many programming languages, visit http://json.org/ . We can encode our data using this format in many ways. We'll place some dictionary entries in a JSON file we'll call b.json, which begins as follows: [ { "term": "BACCHUS", "part": "n.", "definition": "A convenient deity invented by the...", "quote": [ "Is public worship, then, a sin,", "That for devotions paid to Bacchus", "The lictors dare to run us in,", "And resolutely thump and whack us?" ], "author": "Jorace" }, { "term": "BACKBITE", "part": "v.t.", "definition": "To speak of a man as you find him when..." }, { "term": "BEARD", "part": "n.", "definition": "The hair that is commonly cut off by..." }, To retrieve this data, we'll use the $.getJSON() method, which fetches the file and processes it, providing the calling code with the resulting JavaScript object. Global jQuery functions To this point, all jQuery methods that we've used have been attached to a jQuery object that we've built with the $() factory function. The selectors have allowed us to specify a set of DOM nodes to work with, and the methods have operated on them in some way. This $.getJSON() function, however, is different. There is no logical DOM element to which it could apply; the resulting object has to be provided to the script, not injected into the page. For this reason, getJSON() is defined as a method of the global jQuery object (a single object called jQuery or $ defined once by the jQuery library), rather than of an individual jQuery object instance (the objects we create with the $() function). If JavaScript had classes like other object-oriented languages, we'd call $.getJSON() a class method. For our purposes, we'll refer to this type of method as a global function; in effect, they are functions that use the jQuery namespace so as not to conflict with other function names. To use this function, we pass it the file name as before: $(document).ready(function() { $('#letter-b a').click(function() { $.getJSON('b.json'); return false; });}); This code has no apparent effect when we click the link. The function call loads the file, but we have not told JavaScript what to do with the resulting data. For this, we need to use a callback function. The $.getJSON() function takes a second argument, which is a function to be called when the load is complete. As mentioned before, AJAX calls are asynchronous, and the callback provides a way to wait for the data to be transmitted rather than executing code right away. The callback function also takes an argument, which is filled with the resulting data. So, we can write: $(document).ready(function() { $('#letter-b a').click(function() { $.getJSON('b.json', function(data) { }); return false; });}); Here we are using an anonymous function as our callback, as has been common in our jQuery code for brevity. A named function could equally be provided as the callback. Inside this function, we can use the data variable to traverse the data structure as necessary. We'll need to iterate over the top-level array, building the HTML for each item. We could do this with a standard for loop, but instead we'll introduce another of jQuery's useful global functions, $.each(). Instead of operating on a jQuery object, this function takes an array or map as its first parameter and a callback function as its second. Each time through the loop, the current iteration index and the current item in the array or map are passed as two parameters to the callback function. $(document).ready(function() { $('#letter-b a').click(function() { $.getJSON('b.json', function(data) { $('#dictionary').empty(); $.each(data, function(entryIndex, entry) { var html = '<div class="entry">'; html += '<h3 class="term">' + entry['term'] + '</h3>'; html += '<div class="part">' + entry['part'] + '</div>'; html += '<div class="definition">'; html += entry['definition']; html += '</div>'; html += '</div>'; $('#dictionary').append(html); }); }); return false; });}); Before the loop, we empty out <div id="dictionary"> so that we can fill it with our newly-constructed HTML. Then we use $.each() to examine each item in turn, building an HTML structure using the contents of the entry map. Finally, we turn this HTML into a DOM tree by appending it to the <div>. This approach presumes that the data is safe for HTML consumption; it should not contain any stray < characters, for example. All that's left is to handle the entries with quotations, which takes another $.each() loop: $(document).ready(function() { $('#letter-b a').click(function() { $.getJSON('b.json', function(data) { $('#dictionary').empty(); $.each(data, function(entryIndex, entry) { var html = '<div class="entry">'; html += '<h3 class="term">' + entry['term'] + '</h3>'; html += '<div class="part">' + entry['part'] + '</div>'; html += '<div class="definition">'; html += entry['definition']; if (entry['quote']) { html += '<div class="quote">'; $.each(entry['quote'], function(lineIndex, line) { html += '<div class="quote-line">' + line + '</div>'; }); if (entry['author']) { html += '<div class="quote-author">' + entry['author'] + '</div>'; } html += '</div>'; } html += '</div>'; html += '</div>'; $('#dictionary').append(html); }); }); return false; });}); With this code in place, we can click the B link and confirm our results:   The JSON format is concise, but not forgiving. Every bracket, brace, quote, and comma must be present and accounted for, or the file will not load. In most browsers, we won't even get an error message; the script will just silently fail. Executing a script Occasionally we don't want to retrieve all the JavaScript we will need when the page is first loaded. We might not know what scripts will be necessary until some user interaction occurs. We could introduce <script> tags on the fly when they are needed, but a more elegant way to inject additional code is to have jQuery load the .js file directly. Pulling in a script is about as simple as loading an HTML fragment. In this case, we use the global function $.getScript(), which, like its siblings, accepts a URL locating the script file: $(document).ready(function() { $('#letter-c a').click(function() { $.getScript('c.js'); return false; });}); Scripts fetched in this way are run in the global context of the current page. This means they have access to all globally-defined functions and variables, notably including jQuery itself. We can therefore mimic the JSON example to prepare and insert HTML on the page when the script is executed, and place this code in c.js:. var entries = [ { "term": "CALAMITY", "part": "n.", "definition": "A more than commonly plain and..." }, { "term": "CANNIBAL", "part": "n.", "definition": "A gastronome of the old school who..." }, { "term": "CHILDHOOD", "part": "n.", "definition": "The period of human life intermediate..." }, { "term": "CLARIONET", "part": "n.", "definition": "An instrument of torture operated by..." }, { "term": "COMFORT", "part": "n.", "definition": "A state of mind produced by..." }, { "term": "CORSAIR", "part": "n.", "definition": "A politician of the seas." }];var html = '';$.each(entries, function() { html += '<div class="entry">'; html += '<h3 class="term">' + this['term'] + '</h3>'; html += '<div class="part">' + this['part'] + '</div>'; html += '<div class="definition">' + this['definition'] + '</div>'; html += '</div>';});$('#dictionary').html(html); Now clicking on the C link has the expected result: Loading an XML document XML is part of the acronym AJAX, but we haven't actually loaded any XML yet. Doing so is straightforward, and mirrors the JSON technique fairly closely. First we'll need an XML file d.xml containing some data we wish to display, excerpted here: <?xml version="1.0" encoding="UTF-8"?><entries> <entry term="DEFAME" part="v.t."> <definition> To lie about another. To tell the truth about another. </definition> </entry> <entry term="DEFENCELESS" part="adj."> <definition> Unable to attack. </definition> </entry> <entry term="DELUSION" part="n."> <definition> The father of a most respectable family, comprising Enthusiasm, Affection, Self-denial, Faith, Hope, Charity and many other goodly sons and daughters. </definition> <quote author="Mumfrey Mappel"> <line>All hail, Delusion! Were it not for thee</line> <line>The world turned topsy-turvy we should see; </line> <line>For Vice, respectable with cleanly fancies, </line> <line>Would fly abandoned Virtue's gross advances. </line> </quote> </entry> <entry term="DIE" part="n."> <definition> The singular of "dice." We seldom hear the word, because there is a prohibitory proverb, "Never say die." At long intervals, however, some one says: "The die is cast," which is not true, for it is cut. The word is found in an immortal couplet by that eminent poet and domestic economist, Senator Depew: </definition> <quote> <line>A cube of cheese no larger than a die</line> <line>May bait the trap to catch a nibbling mie.</line> </quote> </entry></entries> This data could be expressed in many ways, of course, and some would more closely mimic the structure we established for the HTML or JSON used earlier. Here, however, we're illustrating some of the features of XML designed to make it more readable to humans, such as the use of attributes for term and part rather than tags. $(document).ready(function() { $('#letter-d a').click(function() { $.get('d.xml', function(data) { }); return false; });}); This time it's the $.get() function that does our work. In general, this function simply fetches the file at the supplied URL and provides the plain text to the callback. However, if the response is known to be XML because of its server-supplied MIME type, the callback will be handed the XML DOM tree. Fortunately, as we have already seen, jQuery has substantial DOM traversing capabilities. We can use the normal .find(), .filter() and other traversal methods on the XML document just as we would on HTML: $(document).ready(function() { $('#letter-d a').click(function() { $.get('d.xml', function(data) { $('#dictionary').empty(); $(data).find('entry').each(function() { var $entry = $(this); var html = '<div class="entry">'; html += '<h3 class="term">' + $entry.attr('term') + '</h3>'; html += '<div class="part">' + $entry.attr('part') + '</div>'; html += '<div class="definition">'; html += $entry.find('definition').text(); var $quote = $entry.find('quote'); if ($quote.length) { html += '<div class="quote">'; $quote.find('line').each(function() { html += '<div class="quote-line">' + $(this).text() + '</div>'; }); if ($quote.attr('author')) { html += '<div class="quote-author">' + $quote.attr('author') + '</div>'; } html += '</div>'; } html += '</div>'; html += '</div>'; $('#dictionary').append($(html)); }); }); return false; });}); This has the expected effect when the D link is clicked: This is a new use for the DOM traversal methods we already know, shedding some light on the flexibility of jQuery's CSS selector support. CSS syntax is typically used to help beautify HTML pages, and thus selectors in standard .css files use HTML tag names such as div and body to locate content. However, jQuery can use arbitrary XML tag names, such as entry and definition here, just as readily as the standard HTML ones. The advanced selector engine inside jQuery facilitates finding parts of the XML document in much more complicated situations, as well. For example, suppose we wanted to limit the displayed entries to those that have quotes that in turn have attributed authors. To do this, we can limit the entries to those with nested <quote> elements by changing entry to entry:has(quote). Then we can further restrict the entries to those with author attributes on the <quote> elements by writing entry:has(quote[author]). The line with the initial selector now reads: $(data).find('entry:has(quote[author])').each(function() { This new selector expression restricts the returned entries correspondingly:

We are going to add and edit a lot of information for manufacturers, vendors, and product categories. Actually, in this article, our VirtueMart shop will really take shape with products we want to sell. Catalogue management The product catalog for an online shop comprises of the products we sell in the shop. Whatever products we want to sell should be added to this product catalog first. Once products are added to the catalog, customers can browse the products and decide to buy whatever they need. Therefore, managing the catalog is one of the primary tasks of the shop owner. Products that we add to the catalog need to be organized to help customers easily find the right products. In VirtueMart, customers can sort the products by product categories and manufacturers. Therefore, before adding products to the catalog, we will look into managing manufacturers and product categories. Managing manufacturers In VirtueMart, whenever we add a product to the catalog, we also need to assign a manufacturer for that product. In reality, every product has a manufacturer, and for better management of the shop, we should be able to find products by their manufacturer. Therefore, first step will be to identify the manufacturers and enter their information in VirtueMart store. We can also categorize the manufactures as publishers, software developers, and so on. Adding a manufacturer category There is a default manufacturer category for use in VirtueMart. We can use that default category for creating a manufacturer. However, when we are selling large number of products from a large number of manufacturers, classifying them into categories will be convenient for managing the manufacturers. For adding a manufacturer, in the VirtueMart administration panel, click on Manufacturer | Add Manufacturer Category. This shows Manufacturer Category Form: In the Manufacturer Category Form, provide information for the Category Name and the Category Description fields. Once these are provided, click the Save icon in the toolbar to save the manufacturer category. In the same process, you can add as many categories as you want. Adding a manufacturer For adding a manufacturer, in the VirtueMart administration panel, select Manufacturer | Add Manufacturer. This shows Add Information screen: In the Add Information screen, type the manufacturer's name, their URL, email address, and a brief description. In the Manufacturer Category field, select the category. The drop-down list will show the manufacturer categories you created earlier. Once all the information is provided in this screen, click the Save icon in the toolbar to save the manufacturer information. Listing the manufacturer categories Once you have added the manufacturer categories, you can view the list of manufacturer categories by selecting Manufacturer | List Manufacturer Categories. This shows Manufacturer Category List screen: In the Manufacturer Category List screen, you will see all manufacturer categories you have created. From this screen, you can add a new category by clicking the New icon in the toolbar. Similarly, you can remove a category by clicking on the trash icon in Remove column, or by selecting the categories and clicking the Remove icon in the toolbar. You can edit a category by clicking on the category name. To view the list of manufacturers, click on the Manufacturer List link in the Manufacturers column, or select Manufacturer | List Manufacturers. This shows Manufacturer List screen displaying all manufacturers you have added: From the Manufacturer List screen, you can create a new manufacturer, remove one or more manufacturers, and edit any manufacturer. For editing a manufacturer, click on the manufacturer's name or the Update link in Admin column. This will bring up the Add Information screen again. You can also create a new manufacturer by clicking the New icon in the toolbar. From the Manufacturer Category List screen, you may think that clicking on the Manufacturer List link against each category will display the manufacturers added to that category only. Ideally, this should be the case. However, until VirtueMart 1.1.2, it shows the list of manufacturers from all the categories. We hope this will be fixed in the upcoming releases of VirtueMart. Managing vendors The idea of multiple vendors is something what you can see on Amazon.com. Different vendors add their products to sell, when the order is placed, the store notifies the vendor to fulfill the order. The main store usually gets a commission from the vendor for each sell made through the store. However, VirtueMart's vendors feature is still in its infancy and does not yet function properly. You can add multiple vendors in VirtueMart, and assign products to the vendors. However, adding vendors has no effect on selling any product on the VirtueMart store, except when applying different vendor-specific tax rates and shopper groups. At the moment, it also helps to identify products from different vendors. In the following sections, you will see how to add and manage vendors. Vendor category Like manufacturers, you can also create vendor categories. For creating vendor categories, go to Vendor | Add Vendor Category. This displays Vendor Category Form: In the Vendor Category Form, type the name of the category and its description. Then click the Save icon in the toolbar. You can add as many categories as you want. Before trying to add vendor categories, first plan how you are going to categorize your vendors (for example, based on the product they sell or their location). Have a full category tree on hand and then start creating categories. Adding vendor Once you have created the necessary vendor categories, you can proceed to adding vendors. For adding vendors, click on Vendor | Add Vendor. This displays the Add Information screen: CautionNote that there is a warning sign at the top of Add Information screen. It warns you about using the vendor feature as it is in the 'Alpha' or pre-mature stage. Also note that we have used Simple Layout for displaying it. If you try adding a vendor from Extended Layout, you will open up an edit screen for existing vendor information, which you already added during the initial configuration of the shop. Up until VirtueMart 1.1.2, a bug has been encountered and which will hopefully be fixed in future releases when it crosses 'Alpha' stage. The Add Information screen shows three tabs: Store, Store Information, and Contact Information. From the Store tab, add the vendor's store name, company name, logo, web site URL, minimum purchase order value, and minimum amount for free shipping. You can also configure the currency symbol, decimal points, decimal symbol, thousand separator, positive format, and negative format. In the Store Information tab (seen in the previous screenshot), you can add the address of the store, city, state/province/region, zip/postal code, phone, currency and vendor category. The vendor categories you have created earlier will be available in Vendor Category drop-down list. In the Contact Information tab (seen in the previous screenshot), you can set the contact details of the vendor, such as name, title, phone, fax, email. You can also add a brief description of the vendor which will be displayed in the vendor details page in the store. Type a brief description in the Description rich-text editing box. In the Terms of Service rich-text editing box, provide terms of service applicable for that vendor. Once information in all the three tabs are provided, click the Save icon in the toolbar to add the vendor.

PHx in action Let us learn our need of PHx by building a new functionality for our site that lets us add profiles of our family members and friends. We will add a new page called 'Family and Friends' that will show the list of all the individuals that we add. Once the user clicks on an individual, it will show certain details such as name, relationship to you, occupation, web site. This is easy to implement; all we have to do is create the template variables for each of the fields, and create a template that uses these template variables. So, to display the Occupation, the template will have a code similar to the following: Occupation: [*occupation*] Though this might appear to work initially, it has a small glitch in it. When we are entering the personal details of an individual, we may not want to enter all of the values for every individual. In the case of not having a value for the variable, it looks cleaner to not show the label at all instead of leaving it blank. In our case—if we have no value for occupation—it will look cleaner to not show the label Occupation. So here comes a need for displaying certain text only if the template variable—in this case, occupation—has a value. We can do this using PHx without having to write a snippet. Installing PHx To download PHx, use the following steps: Download PHx from http://MODxcms.com/PHx-1006.html. Extract the contents of the downloaded file. Create a directory called phx in the assets/plugins folder of your MODx installation. Copy all the files within the extracted folder to the assets/plugins/phx folder. Create a new plug-in using the MODx Manager interface: Click on the Manage Resources menu item in the Resources menu Click on the Plugins tab Click on the New Plugin link Fill it with the following details: Field Name Field Value Plugin Name PHx Plugin Code Contents of the file phx.plugin.txt in the extracted folder System Events | OnParseDocument Checked      6.Click on Save. Adding Family and Friends documents Let us create a page that lists all the members from the Family or Friends group. This document will be a container that will have a document for each member that you would like to add. Hence, just as you have learned earlier, a call to the Ditto snippet can get you all the documents that a container holds. Create a page with the following details: Field Name Field Value Title Family and Friends Uses template Learning MODx default template Modify the page created in the previous step to have the following code. (Note that we need to know the ID of the created page for the code and hence, we are modifying it after creating it.) <ul> [!Ditto? &parents=`65` &tpl=`familyandfriendslist`!]</ul> Here, 65 is the ID of the created document. We give the ID of this document here as we will be adding the other documents as child documents of this document. In the above Ditto call, we have indicated that we are using a custom chunk to control the appearance of the listing. Create a chunk with the following details, to show a neat list of the documents that represent a member with the title and a link to the document. Field Name Field Value Chunk name familyandfriendslist Existing Category Learning MODx Chunk Code <li> <h3><a href="[~[+id+]~]">[+title+]</a></h3> </li>

Obtaining the SDK If you are running the Enterprise network, it is likely that the SDK has been provided to you as a binary. Alternatively, you can check out the Enterprise source code and build it yourself. In the Enterprise SVN repository, specific releases are tagged. So if you wanted 2.2.0, for example, you'd check out V2.2.0-ENTERPRISE-FINAL. The Enterprise SVN repository for the Enterprise network is password-protected. Consult your Alfresco representative for the URL, port, and credentials that are needed to obtain the Enterprise source code. Labs network users can either download the SDK as a binary from SourceForge (https://sourceforge.net/project/showfiles.php?group_id=143373&package_id=189441) or check out the Labs source code and build it. The SVN URL for the Labs source code is svn://svn.alfresco.com. In the Labs repository, nothing is tagged. You must check out HEAD. Step-by-Step: Building Alfresco from Source Regardless of whether you are using Enterprise or Labs, if you've decided to build from the source it is very easy to do it. At a high level, you simply check out the source and then run Ant. If you've opted to use the pre-compiled binaries, skip to the next section. Otherwise, let's use Ant to create the same ZIP/TAR file that is available on the download page. To do that, follow these steps: Check out the source from the appropriate SVN repository, as mentioned earlier. Set the TOMCAT_HOME environment variable to the root of your Apache Tomcat install directory. Navigate to the root of the source directory, then run the default Ant target: ant build.xml ant build.xml It will take a few minutes to build everything. When it is done, run the distribute task like this: ant -f continuous.xml distribute Again, it may take several minutes for this to run. When it is done, you should see several archives in the build|dist directory. For example, running this Ant task for Alfresco 3.0 Labs produces several archives. The subset relevant to the article includes: alfresco-labs-sdk-*.tar.gz alfresco-labs-sdk-*.zip alfresco-labs-tomcat-*.tar.gz alfresco-labs-tomcat-*.zip alfresco-labs-war-*.tar.gz alfresco-labs-war-*.zip alfresco-labs-wcm-*.tar.gz alfresco-labs-wcm-*.zip You should extract the SDK archive somewhere handy. The next step will be to import the SDK into Eclipse. Setting up the SDK in Eclipse Nothing about Alfresco requires you to use Eclipse or any other IDE. But Eclipse is very widely used and the Alfresco SDK distribution includes Eclipse projects that can easily be imported into Eclipse, so that's what these instructions will cover. In addition to the Alfresco JARs, dependent JARs, Javadocs, and source code, the SDK bundle has several Eclipse projects. Most of the Eclipse projects are sample projects showing how to write code for a particular area of Alfresco. Two are special, however. The SDK AlfrescoEmbedded project and the SDK AlfrescoRemote project reference all of the JARs needed for the Java API and the Web Services API respectively. The easiest way to make sure your own Eclipse project has everything it needs to compile is to import the projects bundled with the SDK into your Eclipse workspace, and then add the appropriate SDK projects to your project's build path. Step-by-Step: Importing the SDK into Eclipse Every developer has his or her own favorite way of configuring tools. If you are going to work with multiple versions of Alfresco, you should use version-specific Eclipse workspaces. For example, you might want to have a workspace-alfresco-2.2 workspace as well as a workspace-alfresco-3.0 workspace, each with the corresponding Alfresco SDK projects imported. Then, if you need to test customizations against a different version of the Alfresco SDK, all you have to do is switch your workspace, import your customization project if it isn't in the workspace already, and build it. Let's go ahead and set this up. Follow these steps: In Eclipse, select File|Switch Workspace or specify a new workspace location. This will be your workspace for a specific version of the Alfresco SDK so use a name such as workspace-alfresco-3.0. Eclipse will restart with an empty workspace. Make sure the Java compiler compliance level preference is set to 5.0 (Window|Preferences|Java|Compiler). If you forget to do that, Eclipse won't be able to build the projects after they are imported. Select File|Import|Existing Projects into Workspace. For the root directory, specify the directory where the SDK was uncompressed. For the root directory, specify the directory where the SDK was uncompressed. You want the root SDK directory, not the Samples directory. Select all of the projects that are listed and click Import. After the import, Eclipse should be able to build all projects cleanly. If not, double-check the compiler compliance level. If that is set but there are still errors, make sure you imported all SDK projects including SDK AlfrescoEmbedded and SDK AlfrescoRemote. Now that the files are in the workspace, take a look at the Embedded project. That's quite a list of dependent JAR files! The Alfresco-specific JARs all start with alfresco-. It depends on what you are doing, of course, but the JAR that is referenced most often is likely to be alfresco-repository.jar because that's where the bulk of the API resides. The SDK comes with zipped source code and Javadocs, which are both useful references (although the Javadocs are pretty sparse). It's a good idea to tell Eclipse where those files are, so you can drill in to the Alfresco source when debugging. To do that, right-click on the Alfresco JAR, and then select Properties. You'll see panels for Java Source Attachment and Javadoc Location that you can use to associate the JAR with the appropriate source and Javadoc archives. The following image shows the Java Source Attachment for alfresco-repository.jar: The following image shows the Javadoc Location panel for alfresco-repository.jar. Source and Javadoc are provided for each of the Alfresco JARs, as shown in the following table. Note that source and Javadoc for everything is available. This is open source software after all, not just all bundled with the SDK: Alfresco JAR Source archive Javadoc archive alfresco-core.jar Src|core-src.zip Doc|api|core-doc.zip alfresco-remote-api.jar Src|remote-api-src.zip Doc|api|remote-api-doc.zip alfresco-web-client.jar src|web-client-src.zip doc|api|web-client-doc.zip alfresco-repository.jar src|repository-src.zip doc|api|repository-doc.zip

In today's world, many server-side applications make use of XML to structure data because XML is a standard way of representing structured information. It is easy to work with, and people can easily read, write, and understand XML without the need of any specialized skills. The XML standard is widely accepted and used in server communications such as Simple Object Access Protocol (SOAP) based web services. XML stands for eXtensible Markup Language. The XML standard specification is available at http://www.w3.org/XML/. Adobe Flex provides a standardized ECMAScript-based set of API classes and functionality for working with XML data. This collection of classes and functionality provided by Flex are known as E4X. You can use these classes provided by Flex to build sophisticated Rich Internet Applications using XML data. XML basics XML is a standard way to represent categorized data into a tree structure similar to HTML documents. XML is written in plain-text format, and hence it is very easy to read, write, and manipulate its data. A typical XML document looks like this: <book>    <title>Flex 3 with Java</title>    <author>Satish Kore</author>    <publisher>Packt Publishing</publisher>    <pages>300</pages> </book> Generally, XML data is known as XML documents and it is represented by tags wrapped in angle brackets (< >). These tags are also known as XML elements. Every XML document starts with a single top-level element known as the root element. Each element is distinguished by a set of tags known as the opening tag and the closing tag. In the previous XML document, <book> is the opening tag and </book> is the closing tag. If an element contains no content, it can be written as an empty statement (also called self-closing statement). For example, <book/> is as good as writing <book></book>. XML documents can also be more complex with nested tags and attributes, as shown in the following example: <book ISBN="978-1-847195-34-0">   <title>Flex 3 with Java</title>   <author country="India" numberOfBooks="1">    <firstName>Satish</firstName>    <lastName>Kore</lastName> </author>   <publisher country="United Kingdom">Packt Publishing</publisher>   <pages>300</pages> </book> Notice that the above XML document contains nested tags such as <firstName> and <lastName> under the <author> tag. ISBN, country, and numberOfBooks, which you can see inside the tags, are called XML attributes. To learn more about XML, visit the W3Schools' XML Tutorial at http://w3schools.com/xml/. Understanding E4X Flex provides a set of API classes and functionality based on the ECMAScript for XML (E4X) standards in order to work with XML data. The E4X approach provides a simple and straightforward way to work with XML structured data, and it also reduces the complexity of parsing XML documents. Earlier versions of Flex did not have a direct way of working with XML data. The E4X provides an alternative to DOM (Document Object Model) interface that uses a simpler syntax for reading and querying XML documents. More information about other E4X implementations can be found at http://en.wikipedia.org/wiki/E4X. The key features of E4X include: It is based on standard scripting language specifications known as ECMAScript for XML. Flex implements these specifications in the form of API classes and functionality for simplifying the XML data processing. It provides easy and well-known operators, such as the dot (.) and @, to work with XML objects. The @ and dot (.) operators can be used not only to read data, but also to assign data to XML nodes, attributes, and so on. The E4X functionality is much easier and more intuitive than working with the DOM documents to access XML data. ActionScript 3.0 includes the following E4X classes: XML, XMLList, QName, and Namespace. These classes are designed to simplify XML data processing into Flex applications. Let's see one quick example: Define a variable of type XML and create a sample XML document. In this example, we will assign it as a literal. However, in the real world, your application might load XML data from external sources, such as a web service or an RSS feed. private var myBooks:XML =   <books publisher="Packt Pub">    <book title="Book1" price="99.99">    <author>Author1</author>    </book>    <book title="Book2" price="59.99">    <author>Author2</author>    </book>    <book title="Book3" price="49.99">    <author>Author3</author>    </book> </books>; Now, we will see some of the E4X approaches to read and parse the above XML in our application. The E4X uses many operators to simplify accessing XML nodes and attributes, such as dot (.) and attribute identifier (@), for accessing properties and attributes. private function traceXML():void {    trace(myBooks.book.(@price < 50.99).@title); //Output: Book3    trace(myBooks.book[1].author); //Output: Author2    trace(myBooks.@publisher); //Output: Packt Pub    //Following for loop outputs prices of all books    for each(var price in myBooks..@price) {    trace(price);    } } In the code above, we are using a conditional expression to extract the title of the book(s) whose price is set below 50.99$ in the first trace statement. If we have to do this manually, imagine how much code would have been needed to parse the XML. In the second trace, we are accessing a book node using index and printing its author node's value. And in the third trace, we are simply printing the root node's publisher attribute value and finally, we are using a for loop to traverse through prices of all the books and printing each price. The following is a list of XML operators: Operator Name Description    @   attribute identifier Identifies attributes of an XML or XMLList object.     { }     braces(XML) Evaluates an expression that is used in an XML or XMLList initializer.   [ ]     brackets(XML) Accesses a property or attribute of an XML or XMLList object, for example myBooks.book["@title"].     + concatenation(XMLList) Concatenates (combines) XML or XMLList values into an XMLList object.     += concatenation assignment (XMLList) Assigns expression1 The XML object An XML class represents an XML element, attribute, comment, processing instruction, or a text element. We have used the XML class in our example above to initialize the myBooks variable with an XML literal. The XML class is included into an ActionScript 3.0 core class, so you don't need to import a package to use it. The XML class provides many properties and methods to simplify XML processing, such as ignoreWhitespace and ignoreComments properties, used for ignoring whitespaces and comments in XML documents respectively. You can use the prependChild() and appendChild() methods to prepend and append XML nodes to existing XML documents. Methods such as toString() and toXMLString() allow you to convert XML to a string. An example of an XML object: private var myBooks:XML = <books publisher="Packt Pub"> <book title="Book1" price="99.99"> <author>Author1</author> </book> <book title="Book2" price="120.00"> <author>Author2</author> </book> </books>;   In the above example, we have created an XML object by assigning an XML literal to it. You can also create an XML object from a string that contains XML data, as shown in the following example: private var str:String = "<books publisher="Packt Pub"> <book title="Book1" price="99.99"> <author>Author1</author> </book> <book title="Book2" price="59.99"> <author>Author2</author> </book> </books>"; private var myBooks:XML = new XML(str); trace(myBooks.toXMLString()); //outputs formatted xml as string If the XML data in string is not well-formed (for example, a closing tag is missing), then you will see a runtime error. You can also use binding expressions in the XML text to extract contents from a variable data. For example, you could bind a node's name attribute to a variable value, as in the following line: private var title:String = "Book1" var aBook:XML = <book title="{title}">; To read more about XML class methods and properties, go through Flex 3 LiveDocs at http://livedocs.adobe.com/flex/3/langref/XML.html. The XMLList object As the class name indicates, XMLList contains one or more XML objects. It can contain full XML documents, XML fragments, or the results of an XML query. You can typically use all of the XML class's methods and properties on the objects from XMLList. To access these objects from the XMLList collection, iterate over it using a for each… statement. The XMLList provides you with the following methods to work with its objects: child(): Returns a specified child of every XML object children(): Returns specified children of every XML object descendants(): Returns all descendants of an XML object elements(): Calls the elements() method of each XML object in the XMLList. Returns all elements of the XML object parent(): Returns the parent of the XMLList object if all items in the XMLList object have the same parent attribute(attributeName): Calls the attribute() method of each XML object and returns an XMLList object of the results. The results match the given attributeName parameter attributes(): Calls the attributes() method of each XML object and returns an XMLList object of attributes for each XML object contains(): Checks if the specified XML object is present in the XMLList copy(): Returns a copy of the given XMLList object length(): Returns the number of properties in the XMLList object valueOf(): Returns the XMLList object For details on these methods, see the ActionScript 3.0 Language Reference. Let's return to the example of the XMLList: var xmlList:XMLList = myBooks.book.(@price == 99.99); var item:XML; for each(item in xmlList) { trace("item:"+item.toXMLString()); } Output: item:<book title="Book1" price="99.99"> <author>Author1</author> </book> In the example above, we have used XMLList to store the result of the myBooks.book.(@price == 99.99); statement. This statement returns an XMLList containing XML node(s) whose price is 99.99$. Working with XML objects The XML class provides many useful methods to work with XML objects, such as the appendChild() and prependChild() methods to add an XML element to the beginning or end of an XML object, as shown in the following example: var node1:XML = <middleInitial>B</middleInitial> var node2:XML = <lastName>Kore</lastName> var root:XML = <personalInfo></personalInfo> root = root.appendChild(node1); root = root.appendChild(node2); root = root.prependChild(<firstName>Satish</firstName>); The output is as follows: <personalInfo> <firstName>Satish</firstName> <middleInitial>B</middleInitial> <lastName>Kore</lastName> </personalInfo> You can use the insertChildBefore() or insertChildAfter() method to add a property before or after a specified property, as shown in the following example: var x:XML = <count> <one>1</one> <three>3</three> <four>4</four> </count>; x = x.insertChildBefore(x.three, "<two>2</two>"); x = x.insertChildAfter(x.four, "<five>5</five>"); trace(x.toXMLString()); The output of the above code is as follows: <count> <one>1</one> <two>2</two> <three>3</three> <four>4</four> <five>5</five> </count>

Data transformation with External Tables One of the main uses of the External Tables is their support of the ETL process, allowing the user to perform a data load that is transformed to the target format without an intermediate stage table. Let's read an External Table whose contents are: This data can be loaded in a single command to multiple tables. Let's create several tables with the same structure: SQL> desc amount_jan Name Null? Type ----------------- -------- ------------ REGION VARCHAR2(16) AMOUNT NUMBER(3) Now issue the command to send the data from the external table to the different tables. INSERT ALL INTO AMOUNT_JAN (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_FEB (REGION, AMOUNT) VALUES(COUNTRY, FEB) INTO AMOUNT_MAR (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_APR (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_MAY (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_JUN (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_JUL (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_AUG (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_SEP (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_OCT (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_NOV (REGION, AMOUNT) VALUES(COUNTRY, JAN) INTO AMOUNT_DEC (REGION, AMOUNT) VALUES(COUNTRY, JAN)SELECT COUNTRY, JAN, FEB, MAR, APR, MAY, JUN, JUL, AUG, SEP, OCT, NOV, DECFROM REGION_REVENUE; In this example, we will perform a conditional insert to different tables depending on the value of the amount column. We will first create three tables, one for low, another for average, and a third for high amounts: SQL> create table low_amount( 2 region varchar2(16), 3 month number(2), 4 amount number(3));Table created.SQL> create table high_amount as select * from low_amount;Table created. Now we can read the External Table and have the data inserted conditionally to one of three mutually exclusive targets. INSERT ALL WHEN ( JAN <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '01', JAN ) WHEN ( FEB <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '02', FEB ) WHEN ( MAR <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '03', MAR ) WHEN ( APR <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '04', APR ) WHEN ( MAY <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '05', MAY ) WHEN ( JUN <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '06', JUN ) WHEN ( JUL <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '07', JUL ) WHEN ( AUG <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '08', AUG ) WHEN ( SEP <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '09', SEP ) WHEN ( OCT <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '10', OCT ) WHEN ( NOV <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '11', NOV ) WHEN ( DEC <= 500 ) THEN INTO LOW_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '12', DEC ) WHEN ( JAN > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '01', JAN ) WHEN ( FEB > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '02', FEB ) WHEN ( MAR > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '03', MAR ) WHEN ( APR > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '04', APR ) WHEN ( MAY > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '05', MAY ) WHEN ( JUN > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '06', JUN ) WHEN ( JUL > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '07', JUL ) WHEN ( AUG > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '08', AUG ) WHEN ( SEP > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '09', SEP ) WHEN ( OCT > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '10', OCT ) WHEN ( NOV > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '11', NOV ) WHEN ( DEC > 500 ) THEN INTO HIGH_AMOUNT( REGION, MONTH, AMOUNT) VALUES ( COUNTRY, '12', DEC )SELECT COUNTRY, JAN, FEB, MAR, APR, MAY, JUN, JUL, AUG, SEP, OCT, NOV, DECFROM REGION_REVENUE; Extending the alert.log analysis with External Tables Reading the alert.log from the database is a useful feature which can help you to find any outstanding error messages reported in this file. create table ALERT_LOG ( text_line varchar2(512)) organization external ( type ORACLE_LOADER default directory BACKGROUND_DUMP_DEST access parameters( records delimited by newline nobadfile nodiscardfile nologfile ) location( 'alert_beta.log') ); Once the External Table has been created, the alert.log file can be queried just like any other regular table. SQL> select text_line from alert_log 2 where text_line like 'ORA-%';TEXT_LINE-----------------------------------------------------------------ORA-1109 signalled during: ALTER DATABASE CLOSE NORMAL...ORA-00313: open failed for members of log group 1 of thread 1ORA-00312: online log 1 thread 1: '/u01/oracle/oradata/beta/redo01.log'ORA-27037: unable to obtain file statusORA-00313: open failed for members of log group 2 of thread 1ORA-00312: online log 2 thread 1: '/u01/oracle/oradata/beta/redo02.log'ORA-27037: unable to obtain file statusORA-00313: open failed for members of log group 3 of thread 1ORA-00312: online log 3 thread 1: '/u01/oracle/oradata/beta/redo03.log'ORA-27037: unable to obtain file status Querying the alert.log file up to this phase is useful just to see the contents of the file and look for basic ORA-% strings. This could also be achieved by using the alert.log link in the Enterprise Manager (EM). The alert.log file can be queried by means of the EM, but as this can only be viewed from the EM in an interactive mode, you can only rely on the preset alerts. If further automatic work needs to be done, then it is useful to do some more work with the alert analysis tool. A temporary table can be used to store the contents of the ALERT_LOG table, along with an extra TIMESTAMP column, so it can be queried in detail in an EM-like manner. create global temporary table TMP_ALERT_LOG ( LINE_NO NUMBER(6), TIMESTAMP DATE, TEXT_LINE VARCHAR2(512))on commit preserve rows; A bit of PLSQL programming is necessary so the ALERT_LOG file can be modified and inserted into the TMP_ALERT_LOG, (enabling further queries can be done). declarecursor alertLogCur is select ROWNUM, TEXT_LINE from ALERT_LOG;currentDate date;altertLogRec ALERT_LOG.TEXT_LINE%TYPE;testDay varchar2(10);begincurrentDate := sysdate;for alertLogInst in alertLogCur loop -- fetch row and determine if this is a date row testDay := substr(alertLogInst.text_line, 1, 3); if testDay = 'Sun' or testDay = 'Mon' or testDay = 'Tue' or testDay = 'Wed' or testDay = 'Thu' or testDay = 'Fri' or testDay = 'Sat' then -- if this is a date row, it sets the current logical record date currentDate := to_date( alertlogInst.text_line, 'Dy Mon DD HH24:MI:SS YYYY'); end if; insert into TMP_ALERT_LOG values( alertLogInst.rownum, currentDate, alertLogInst.text_line );end loop;end;/ As the contents of the alert.log end up in a temporary table, more than one DBA can query it at the same time, or restrict the DBA's accessibilities. There is no need to manage the purge and maintenance of the table after the session has ended, it can be indexed and there is little overhead by means of this procedure. Moreover, as this is a temporary object, minimum redo log information is generated. Once the external ALERT_LOG and the temporary ALERT_LOG tables have been created, it is possible to perform, not only filters by date (provided by Enterprise Manager) but also any query against the alert.log file. SELECT TIMESTAMP, TEXT_LINEFROM TMP_ALERT_LOGWHERE TIMESTAMP IN ( SELECT TIMESTAMP FROM TMP_ALERT_LOG WHERE TEXT_LINE LIKE 'ORA-%')AND TIMESTAMP BETWEEN SYSDATE-30 AND SYSDATEORDER BY LINE_NO; Further treatment can be done on this concept to look for specific error messages, analyze specific time frames and perform drill down analysis. This procedure can be extended to read the trace files or any other text file from the database. Reading the listener.log from the database One particular extension of the above procedure is to read the listener.log file. This file has a specific star-delimited field file format which can be advantageous, and eases the read by means of the Loader driver. The file format is as follows: 21-JUL-2008 00:39:50 * (CONNECT_DATA=(SID=beta)(CID=(PROGRAM=perl)(HOST=alpha.us.oracle.com)(USER=oracle))) * (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.2.10)(PORT=8392)) * establish * beta * 021-JUL-2008 00:39:56 * (CONNECT_DATA=(SID=beta)(CID=(PROGRAM=perl)(HOST=alpha.us.oracle.com)(USER=oracle))) * (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.2.10)(PORT=8398)) * establish * beta * 021-JUL-2008 00:40:16 * service_update * beta * 021-JUL-2008 00:41:19 * service_update * beta * 021-JUL-2008 00:44:43 * ping * 0 The file has a format that can be deduced from the above data sample: TIMESTAMP * CONNECT DATA [* PROTOCOL INFO] * EVENT [* SID] * RETURN CODE As you can see this format, even though it is structured, it may have a different number of fields, so at loading time this issue must be considered. In order for us to map this table to the database, we should consider the variable number of fields to have the External Table created. We'll create a temporary table so that this doesn't create an additional transactional overhead. Now, let's create an External Table based on this format that points to $ORACLE_HOME/network/log: create directory NETWORK_LOG_DIRas '$ORACLE_HOME/network/log'; Now, let's create the external table: create table LISTENER_LOG ( TIMESTAMP date, CONNECT_DATA varchar2(2048), PROTOCOL_INFO varchar2(64), EVENT varchar2(64), SID varchar2(64), RETURN_CODE number(5))organization external ( type ORACLE_LOADER default directory NETWORK_LOG_DIR access parameters ( records delimited by NEWLINE nobadfile nodiscardfile nologfile fields terminated by "*" LDRTRIM reject rows with all null fields ( "TIMESTAMP" char date_format DATE mask "DD-MON-YYYY HH24:MI:SS ", "CONNECT_DATA", "PROTOCOL_INFO", "EVENT", "SID", "RETURN_CODE" ) ) location ('listener.log'))reject limit unlimited; The structure of interest is specified above, so there will be several rows rejected. Seeing as this file is not fully structured, you will find some non formatted information; the bad file and the log file are not meaningful in this context. Another application of the LISTENER_LOG External Table is usage trend analysis. This query can be issued to detect usage peak hours. SQL> select to_char(round(TIMESTAMP, 'HH'), 'HH24:MI') HOUR, 2 lpad('#', count(*), '#') CX 3 from listener_log 4 group by round(TIMESTAMP, 'HH') 5 order by 1;HOUR CX----- ------------------------------------------------14:00 ###15:00 ##########################16:00 ######################17:00 #####################18:00 #####################19:00 ############### Reading the listener.log file this way allows the DBA not only to keep track of the listener behavior, but also it allows a security administrator to easily spot hacking attempts. Let's find out who is trying to access the database with sqlplus.exe. SQL> select timestamp, protocol_info 2 from listener_log 3 where connect_data like '%sqlplus.exe%' 4 /TIMESTAMP PROTOCOL_INFO-------------------- --------------------------------------------------------01-SEP-2008 14:30:37 (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.2.101)(PORT=3651))01-SEP-2008 14:31:08 (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.2.101)(PORT=3666))01-SEP-2008 14:31:35 (ADDRESS=(PROTOCOL=tcp)(HOST=192.168.2.101)(PORT=3681)) The use of External Tables to analyze the listener.log can be used not only to have an in-database version of the listener.log perform periodic and programmatic analysis of the listener behavior, but also to determine usage trends and correlate information with the audit team so that unauthorized connection programs can be easily and quickly spotted. Further useful applications can be found by reading the listener.log file. There are two fields that must be further parsed to get information out of them, but parsing those fields goes beyond the scope of this article. The structure that the analysis should consider is detailed next: Connect String SID: The Database Oracle SID, which is populated if the connection was performed by SID, otherwise it is NULL. CID: It contains two subfields, PROGRAM and HOST. SERVER: This field indicates the connection type, either dedicated or shared. SERVICE_NAME: This field is populated when the connection is performed by a Service instead of SID. COMMAND: The command issued by the user. SERVICE: Present only when listener commands are issued. FAILOVER_MODE: In Real Application Clusters (RAC) environments this field is used if the client performed a connection due to a failover. It shows the failover mode used. Protocol PROTOCOL: Indicates the used to perform the connection; this will be TCP most of the times. HOST: This is the client's IP Address. PORT: The port number of the oracle server used to establish the connection. Mapping XML files as External Tables XML has become a de facto information exchange format, which is why oracle has included the XML Database (XDB) feature from 9.2.0. However, it requires the data to be actually loaded into the database before it can be processed. An External Table allows the user to take a quick look at the contents of the external file prior to performing any further processing. In this example an External Table is created out of an XML file. This file is read by means of a CLOB field, and some further XDB commands can be issued against the external XML file to extract and view data. Let's create the external XML file first: create table EMPLOYEES_XML (xmlFile CLOB)organization external ( type ORACLE_LOADER default directory EXTTABDIR access parameters ( fields (xmllob char terminated by ',') column transforms (xmlFile from lobfile(xmllob)) ) location('employees.dat'))reject limit unlimited; The employees.dat file contains the file name of the XML file to load as an external CLOB file. This file, for the purpose of the demo, contains the file name: employees.xml. Now the file can be queried from the database as if it was a regular table with a single XML column. Dynamically changing the external reference When managing External Tables, there should be an easy way to redefine the external source file. It is enough to change the External Table properties by means of an ALTER TABLE command. Let's create a stored procedure that performs this task by means of a dynamically generated DDL command. This procedure, named Change_External_Table redefines the location property. Using a stored program unit is a flexible way to perform this task. create procedure change_external_table( p_table_name in varchar2, p_file_name in varchar2) isbeginexecute immediate 'alter table '|| p_table_name|| ' location ('''|| p_file_name|| ''')' ;exceptionwhen othersthenraise_application_error(sqlcode,sqlerrm) ;end ;/ Oracle 11g External Table enhancements External Tables work the same in 10g and in 11g, so there are no differences when working with these two versions. When working with Data Pump External Tables, and one single row proves defective, the data set reading operation is aborted. An enhancement in this 11g release prevents the data load aborting, thus saving reprocessing time. Summary Managing data with External Tables is a means not only for mapping external flat files as regular (but limited) tables inside the database, but also a tool to more efficiently perform administrative tasks such as programmatically processing database log files such as the alert.log or the listener.log files. It can be used to easily view external XML formatted files from inside the database without actually loading the file to the database. It can also be used as a means of unloading data in temporary external storage to exchange data among different Oracle versions. This particular feature allows the user to easily build an Oracle Datamart that allows the pre-formatting and summarization of data from the source, enabling it to be directly inserted into the target data warehouse.

The main focus of the Spring Web Flow Framework is to deliver the infrastructure to describe the page flow of a web application. The flow itself is a very important element of a web application, because it describes its structure, particularly the structure of the implemented business use cases. But besides the flow which is only in the background, the user of your application is interested in the Graphical User Interface (GUI). Therefore, we need a solution of how to provide a rich user interface to the users. One framework which offers components is JavaServer Faces (JSF). With the release of Spring Web Flow 2, an integration module to connect these two technologies, called Spring Faces has been introduced. This article is no introduction to the JavaServer Faces technology. It is only a description about the integration of Spring Web Flow 2 with JSF. If you have never previously worked with JSF, please refer to the JSF reference to gain knowledge about the essential concepts of JavaServer Faces. JavaServer Faces (JSF)—a brief introductionThe JavaServer Faces (JSF) technology is a web application framework with the goal to make the development of user interfaces for a web application (based on Java EE) easier. JSF uses a component-based approach with an own lifecycle model, instead of a request-driven approach used by traditional MVC web frameworks. The version 1.0 of JSF is specified inside JSR (Java Specification Request) 127 (http://jcp.org/en/jsr/detail?id=127). To use the Spring Faces module, you have to add some configuration to your application. The diagram below depicts the single configuration blocks. These blocks are described in this article. The first step in the configuration is to configure the JSF framework itself. That is done in the deployment descriptor of the web application—web.xml. The servlet has to be loaded at the startup of the application. This is done with the <load-on-startup>1</load-on-startup> element. <!-- Initialization of the JSF implementation. The Servlet is not used at runtime --> <servlet> <servlet-name>Faces Servlet</servlet-name> <servlet-class>javax.faces.webapp.FacesServlet</servlet-class> <load-on-startup>1</load-on-startup> </servlet> <servlet-mapping> <servlet-name>Faces Servlet</servlet-name> <url-pattern>*.faces</url-pattern> </servlet-mapping> For the work with the JavaServer Faces, there are two important classes. These are the javax.faces.webapp.FacesServlet and the javax.faces.context.FacesContext classes.You can think of FacesServlet as the core base of each JSF application. Sometimes that servlet is called an infrastructure servlet. It is important to mention that each JSF application in one web container has its own instance of the FacesServlet class. This means that an infrastructure servlet cannot be shared between many web applications on the same JEE web container.FacesContext is the data container which encapsulates all information that is necessary around the current request.For the usage of Spring Faces, it is important to know that FacesServlet is only used to instantiate the framework. A further usage inside Spring Faces is not done. To be able to use the components from Spring Faces library, it's required to use Facelets instead of JSP. Therefore, we have to configure that mechanism. If you are interested in reading more about the Facelets technology, visit the Facelets homepage from java.net with the following URL: https://facelets.dev.java.net. A good introduction inside the Facelets technology is the http://www.ibm.com/developerworks/java/library/j-facelets/ article, too. The configuration process is done inside the deployment descriptor of your web application—web.xml. The following sample shows the configuration inside the mentioned file. <context-param> <param-name>javax.faces.DEFAULT_SUFFIX</param-name> <param-value>.xhtml</param-value></context-param> As you can see in the above code, the configuration parameter is done with a context parameter. The name of the parameter is javax.faces.DEFAULT_SUFFIX. The value for that context parameter is .xhtml. Inside the Facelets technology To present the separate views inside a JSF context, you need a specific view handler technology. One of those technologies is the well-known JavaServer Pages (JSP) technology. Facelets are an alternative for the JSP inside the JSF context. Instead, to define the views in JSP syntax, you will use XML. The pages are created using XHTML. The Facelets technology offers the following features: A template mechanism, similar to the mechanism which is known from the Tiles framework The composition of components based on other components Custom logic tags Expression functions With the Facelets technology, it's possible to use HTML for your pages. Therefore, it's easy to create the pages and view them directly in a browser, because you don't need an application server between the processes of designing a page The possibility to create libraries of your components The following sample shows a sample XHTML page which uses the component aliasing mechanism of the Facelets technology. <!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd"><html > <body> <form jsfc="h:form"> <span jsfc="h:outputText" value="Welcome to our page: #{user.name}" disabled="#{empty user}" /> <input type="text" jsfc="h:inputText" value="#{bean.theProperty}" /> <input type="submit" jsfc="h:commandButton" value="OK" action="#{bean.doIt}" /> </form> </body></html> The sample code snippet above uses the mentioned expression language (for example, the #{user.name} expression accesses the name property from the user instance) of the JSF technology to access the data. What is component aliasingOne of the mentioned features of the Facelets technology is that it is possible to view a page directly in a browser without that the page is running inside a JEE container environment. This is possible through the component aliasing feature. With this feature, you can use normal HTML elements, for example an input element. Additionally, you can refer to the component which is used behind the scenes with the jsfc attribute. An example for that is <input type="text" jsfc="h:inputText" value="#{bean.theProperty}" /> . If you open this inside a browser, the normal input element is used. If you use it inside your application, the h:inputText element of the component library is used     The ResourceServlet One main part of the JSF framework are the components for the GUI. These components often consist of many files besides the class files. If you use many of these components, the problem of handling these files arises. To solve this problem, the files such as JavaScript and CSS (Cascading Style Sheets) can be delivered inside the JAR archive of the component. If you deliver the file inside the JAR file, you can organize the components in one file and therefore it is easier for the deployment and maintenance of your component library. Regardless of the framework you use, the result is HTML. The resources inside the HTML pages are required as URLs. For that, we need a way to access these resources inside the archive with the HTTP protocol. To solve that problem, there is a servlet with the name ResourceServlet (package org.springframework.js.resource). The servlet can deliver the following resources: Resources which are available inside the web application (for example, CSS files) Resources inside a JAR archive The configuration of the servlet inside web.xml is shown below: <servlet> <servlet-name>Resource Servlet</servlet-name> <servlet-class>org.springframework.js.resource.ResourceServlet</servlet-class> <load-on-startup>0</load-on-startup></servlet> <servlet-mapping> <servlet-name>Resource Servlet</servlet-name> <url-pattern>/resources/*</url-pattern></servlet-mapping> It is important that you use the correct url-pattern inside servlet-mapping. As you can see in the sample above, you have to use /resources/*. If a component does not work (from the Spring Faces components), first check if you have the correct mapping for the servlet. All resources in the context of Spring Faces should be retrieved through this Servlet. The base URL is /resources. Internals of the ResourceServlet ResourceServlet can only be accessed via a GET request. The ResourceServlet servlet implements only the GET method. Therefore, it's not possible to serve POST requests. Before we describe the separate steps, we want to show you the complete process, illustrated in the diagram below: For a better understanding, we choose an example for the explanation of the mechanism which is shown in the previous diagram. Let us assume that we have registered the ResourcesServlet as mentioned before and we request a resource by the following sample URL: http://localhost:8080/ flowtrac-web-jsf/resources/css/test1.css. How to request more than one resource with one requestFirst, you can specify the appended parameter. The value of the parameter is the path to the resource you want to retrieve. An example for that is the following URL: http://localhost:8080/ flowtracweb-jsf/resources/css/test1.css?appended=/css/test2.css. If you want to specify more than one resource, you can use the delimiter comma inside the value for the appended parameter. A simple example for that mechanism is the following URL: http://localhost:8080/ flowtrac-web-jsf/resources/css/test1.css?appended=/css/test2.css, http://localhost:8080/flowtrac-web-jsf/resources/css/test1.css?appended=/css/test3.css. Additionally, it is possible to use the comma delimiter inside the PathInfo. For example: http://localhost:8080/flowtrac-web-jsf/resources/css/test1.css,/css/test2.css. It is important to mention that if one resource of the requested resources is not available, none of the requested resources is delivered. This mechanism can be used to deliver more than one CSS in one request. From the view of development, it can make sense to modularize your CSS files to get more maintainable CSS files. With that concept, the client gets one CSS, instead of many CSS files. From the view of performance optimization, it is better to have as few requests for rendering a page as possible. Therefore, it makes sense to combine the CSS files of a page. Internally, the files are written in the same sequence as they are requested. To understand how a resource is addressed, we separate the sample URL into the specific parts. The example URL is a URL on a local servlet container which has an HTTP connector at port 8080. See the following diagram for the mentioned separation: The table below describes the five sections of the URL that are shown in the previous diagram:

The advantage of separating out decision points as external rules is that we not only ensure that each rule is used in a consistent fashion, but in addition make it simpler and quicker to modify; that is we only have to modify a rule once and can do this with almost immediate effect, thus increasing the agility of our solution. Business Rule concepts Before we implement our first rule, let's briefly introduce the key components which make up a Business Rule. These are: Facts: Represent the data or business objects that rules are applied to. Rules: A rule consists of two parts, an IF part which consists of one or more tests to be applied to fact(s), and a THEN part, which lists the actions to be carried out should the test to evaluate to true Rule Set: As the name implies, it is just a set of one or more related rules that are designed to work together . Dictionary: A dictionary is the container of all components that make up a business rule, it holds all the facts, rule sets, and rules for a business rule. In addition, a dictionary may also contain functions, variables, and constraints. We will introduce these in more detail later in this article. To execute a business rule, you submit one or more facts to the rules engine. It will apply the rules to the facts, that is each fact will be tested against the IF part of the rule and if it evaluates to true, then it will perform the specified actions for that fact. This may result in the creation of new facts or the modification of existing facts (which may result in further rule evaluation). Leave approval rule To begin with, we will write a simple rule to automatically approve a leave request that is of type Vacation and only for 1 day's duration. A pretty trivial example, but once we've done this we will look at how to extend this rule to handle more complex examples. Using the Rule Author In SOA Suite 10.1.3 you use the Rule Author, which is a browser based interface for defining your business rules. To launch the Rule Author within your browser go to the following URL: http://<host name>:<port number>/ruleauthor/ This will bring up the Rule Author Log In screen. Here you need to log in as user that belongs to the rule-administrators role. You can either log in as the user oc4jadmin (default password Welcome1), which automatically belongs to this group, or define your own user. Creating a Rule Repository Within Oracle Business Rules, all of our definitions (that is facts, constraints, variables, and functions) and rule sets are defined within a dictionary. A dictionary is held within a Repository. A repository can contain multiple dictionaries and can also contain multiple versions of a dictionary. So, before we can write any rules, we need to either connect to an existing repository, or create a new one. Oracle Business Rules supports two types of repository—File based and WebDAV. For simplicity we will use a File based repository, though typically in production you want to use a WebDAV based repository as this makes it simpler to share rules between multiple BPEL Processes. WebDAV is short for Web-based Distributed Authoring and Versioning. It is an extension to HTTP that allows users to collaboratively edit and manage files (that is business rules in our case) over the Web. To create a File based repository click on the Repository tab within the Rule Author, this will display the Repository Connect screen as shown in the following screenshot: From here we can either connect to an existing repository (WebDAV or File based) or create and connect to a new file-based repository. For our purposes, select a Repository Type of File, and specify the full path name of where you want to create the repository and then click Create. To use a WebDAV repository, you will first need to create this externally from the Rule Author. Details on how to do this can be found in Appendix B of the Oracle Business Rules User Guide (http://download.oracle.com/docs/cd/B25221_04/web.1013/b15986/toc.htm). From a development perspective it can often be more convenient to develop your initial business rules in a file repository. Once complete, you can then export the rules from the file repository and import them into a WebDAV repository. Creating a dictionary Once we have connected to a repository, the next step is to create a dictionary. Click on the Create tab, circled in the following screenshot, and this will bring up the Create Dictionary screen. Enter a New Dictionary Name (for example LeaveApproval) and click Create. This will create and load the dictionary so it's ready to use. Once you have created a dictionary, then next time you connect to the repository you will select the Load tab (next to the Create tab) to load it. Defining facts Before we can define any rules, we first need to define the facts that the rules will be applied to. Click on the Definitions tab, this will bring up the page which summarizes all the facts defined within the current dictionary. You will see from this that the rule engine supports three types of facts: Java Facts, XML Facts, and RL Facts. The type of fact that you want to use really depends on the context in which you will be using the rules engine. For example, if you are calling the rule engine from Java, then you would work with Java Facts as this provides a more integrated way of combining the two components. As we are using the rule engine with BPEL then it makes sense to use XML Facts. Creating XML Facts The Rule Author uses XML Schemas to generate JAXB 1.0 classes, which are then imported to generate the corresponding XML Facts. For our example we will use the Leave Request schema, shown as follows for convenience: <?xml version="1.0" encoding="windows-1252"?> <xsd:schema targetNamespace="http://schemas.packtpub.com/LeaveRequest" elementFormDefault="qualified" > <xsd:element name="leaveRequest" type="tLeaveRequest"/> <xsd:complexType name="tLeaveRequest"> <xsd:sequence> <xsd:element name="employeeId" type="xsd:string"/> <xsd:element name="fullName" type="xsd:string" /> <xsd:element name="startDate" type="xsd:date" /> <xsd:element name="endDate" type="xsd:date" /> <xsd:element name="leaveType" type="xsd:string" /> <xsd:element name="leaveReason" type="xsd:string"/> <xsd:element name="requestStatus" type="xsd:string"/> </xsd:sequence> </xsd:complexType> </xsd:schema> Using JAXB, particularly when used in conjunction with BPEL, places a number of constraints on how we define our XML Schemas, including: When defining rules, the Rule Author can only work with globally defined types. This is because it's unable to introspect the properties (i.e. attributes and elements) of global elements. Within BPEL you can only define variables based on globally defined elements. The net result is that any facts we want to pass from BPEL to the rules engine (or vice versa) must be defined as global elements for BPEL and have a corresponding global type definition so that we can define rules against it. The simplest way to achieve this is to define a global type (for example tLeaveRequest in the above schema) and then define a corresponding global element based on that type (for example, leaveRequest in the above schema). Even though it is perfectly acceptable with XML Schemas to use the same name for both elements and types, it presents problems for JAXB, hence the approach taken above where we have prefixed every type definition with t as in tLeaveRequest. Fortunately this approach corresponds to best practice for XML Schema design. The final point you need to be aware of is that when creating XML facts the JAXB processor maps the type xsd:decimal to java.lang.BigDecimal and xsd:integer to java.lang.BigInteger. This means you can't use the standard operators (for example >, >=, <=, and <) within your rules to compare properties of these types. To simplify your rules, within your XML Schemas use xsd:double in place of xsd:decimal and xsd:int in place of xsd:integer. To generate XML facts, from the XML Fact Summary screen (shown previously), click Create, this will display the XML Schema Selector page as shown: Here we need to specify the location of the XML Schema, this can either be an absolute path to an xsd file containing the schema or can be a URL. Next we need to specify a temporary JAXB Class Directory in which the generated JAXB classes are to be created. Finally, for the Target Package Name we can optionally specify a unique name that will be used as the Java package name for the generated classes. If we leave this blank, the package name will be automatically generated based on the target namespace of the XML Schema using the JAXB XML-to-Java mapping rules. For example, our leave request schema has a target namespace of http://schemas.packtpub.com/LeaveRequest; this will result in a package name of com.packtpub.schemas.leaverequest. Next click on Add Schema; this will cause the Rule Author to generate the JAXB classes for our schema in the specified directory. This will update the XML Fact Summary screen to show details of the generated classes; expand the class navigation tree until you can see the list of all the generated classes, as shown in the following screenshot: Select the top level node (that is com) to specify that we want to import all the generated classes. We need to import the TLeaveRequest class as this is the one we will use to implement rules and the LeaveRequest class as we need this to pass this in as a fact from BPEL to the rules engine. The ObjectFactory class is optional, but we will need this if we need to generate new LeaveRequest facts within our rule sets. Although we don't need to do this at the moment it makes sense to import it now in case we do need it in the future. Once we have selected the classes to be imported, click Import (circled in previous screenshot) to load them into the dictionary. The Rule Author will display a message to confirm that the classes have been successfully imported. If you check the list of generated JAXB classes, you will see that the imported classes are shown in bold. In the process of importing your facts, the Rule Author will assign default aliases to each fact and a default alias to all properties that make up a fact, where a property corresponds to either an element or an attribute in the XML Schema. Using aliases Oracle Business Rules allows you to specify your own aliases for facts and properties in order to define more business friendly names which can then be used when writing rules. For XML facts if you have followed standard naming conventions when defining your XML Schemas, we typically find that the default aliases are clear enough and that if you start defining aliases it can actually cause more confusion unless applied consistently across all facts. Hiding facts and properties The Rule Author lets you hide facts and properties so that they don't appear in the drop downs within the Rule Author. For facts which have a large number of properties, hiding some of these can be worth while as it can simplify the creation of rules. Another obvious use of this might be to hide all the facts based on elements, since we won't be implementing any rules directly against these. However, any facts you hide will also be hidden from BPEL, so you won't be able to pass facts of these types from BPEL to the rules engine (or vice versa). In reality, the only fact you will typically want to hide will be the ObjectFactory (as you will have one of these per XML Schema that you import). Saving the rule dictionary As you define your business rules, it makes sense to save your work at regular intervals. To save the dictionary, click on the Save Dictionary link in the top right hand corner of the Rule Author page. This will bring up the Save Dictionary page. Here either click on the Save button to update the current version of the dictionary with your changes or, if you want to save the dictionary as a new version or under a new dictionary name, then click on the Save As link and amend the dictionary name and version as appropriate.
