How-To Tutorials

Grok offers some tools for testing, and in fact, a project created by grokproject (as the one we have been extending) includes a functional test suite. In this article, we are going to discuss testing a bit and then write some tests for the functionality that our application has so far. Testing helps us avoid bugs, but it does not eliminate them completely, of course. There are times when we will have to dive into the code to find out what's going wrong. A good set of debugging aids becomes very valuable in this situation. We'll see that there are several ways of debugging a Grok application and also try out a couple of them. Testing It's important to understand that testing should not be treated as an afterthought. As mentioned earlier, agile methodologies place a lot of emphasis on testing. In fact, there's even a methodology called Test Driven Development (TDD), which not only encourages writing tests for our code, but also writing tests before any other line of code. There are various kinds of testing, but here we'll briefly describe only two: Unit testing Integration or functional tests Unit testing The idea of unit testing is to break a program into its constituent parts and test each one of them in isolation. Every method or function call can be tested separately to make sure that it returns the expected results and handles all of the possible inputs correctly. An application which has unit tests that cover the majority of its lines of code, allows its developers to constantly run the tests after a change, and makes sure that modifications to the code do not break the existing functionality. Functional tests Functional tests are concerned with how the application behaves as a whole. In a web application, this means how it responds to a browser request and whether it returns the expected HTML for a given call. Ideally, the customer himself has a hand in defining these tests, usually through explicit functionality requirements or acceptance criteria. The more formal the requirements from the customer are, the easier it is to define appropriate functional tests. Testing in Grok Grok highly encourages the use of both kinds of tests, and in fact, includes a powerful testing tool that is automatically configured with every project. In the Zope world—from where Grok originated—a lot of value is placed in a kind of tests known as "doctests", so Grok comes with a sample test suite of this kind. Doctests A doctest is a test that's written as a text file, with lines of code mixed with explanations of what the code is doing. The code is written in a way that simulates a Python interpreter session. As tests exercise large portions of the code (ideally 100%), they usually offer a good way of finding out of what an application does and how. So, if an application has no written documentation, its tests would be the next obvious way of finding out what it does. Doctests take this idea further by allowing the developer to explain in the text file exactly what each test is doing. Doctests are especially useful for functional testing, because it makes more sense to document the high-level operations of a program. Unit tests, on the other hand, are expected to evaluate the program bit by bit and it can be cumbersome to write a text explanation for every little piece of code. A possible drawback of doctests is that they can make the developer think that he needs no other documentation for his project. In almost all of the cases, this is not true. Documenting an application or package makes it immediately more accessible and useful, so it is strongly recommended that doctests should not be used as a replacement for good documentation. We'll show an example of using doctests in the Looking at the test code section of this article. Default test setup for Grok projects As mentioned above, Grok projects that are started with the grokproject tool already include a simple functional test suite by default. Let's examine it in detail. Test configuration The default test configuration looks for packages or modules that have the word 'tests' in their name and tries to run the tests inside. For functional tests, any files ending with .txt or .rst are considered. For functional tests that need to simulate a browser, a special configuration is needed to tell Grok which packages to initialize in addition to the Grok infrastructure (usually the ones that are being worked on). The ftesting.zcml file in the package directory has this configuration. This also includes a couple of user definitions that are used by certain tests to examine functionality specific to a certain role, such as manager. Test files Besides the already mentioned ftesting.zcml file, in the same directory, there is a tests.py file added by grokproject, which basically loads the ZCML declarations and registers all of the tests in the package. The actual tests that are included with the default project files are contained in the app.txt file. These are doctests that do a functional test run by loading the entire Grok environment and imitating a browser. We'll take a look at the contents of the file soon, but first let's run the tests. Running the tests As part of the project's build process, a script named test is included in the bin directory when you create a new project. This is the test runner and calling it without arguments, finds and executes all of the tests in the packages that are included in the configuration. We haven't added a single test so far, so if we type bin/test in our project directory, we'll see more or less the same thing that doing that on a new project would show: $ bin/testRunning tests at level 1 Running todo.FunctionalLayer tests: Set up in 12.319 seconds. Running: ...2009-09-30 15:00:47,490 INFO sqlalchemy.engine.base.Engine.0x...782c PRAGMA table_info("users") 2009-09-30 15:00:47,490 INFO sqlalchemy.engine.base.Engine.0x...782c () Ran 3 tests with 0 failures and 0 errors in 0.465 seconds. Tearing down left over layers: Tear down todo.FunctionalLayer ... not supported The only difference between our output to that of a newly created Grok package is in the sqlalchemy lines. Of course, the most important part of the output is the "penultimate" line, which shows the number of tests that were run and whether there were any failures or errors. A failure means that some test didn't pass, which means that the code is not doing what it's supposed to do and needs to be checked. An error signifies that the code crashed unexpectedly at some point, and the test couldn't even be executed, so it's necessary to find the error and correct it before worrying about the tests. The test runner The test runner program looks for modules that contain tests. The test can be of three different types: Python tests, simple doctests, and full functionality doctests. To let the test runner know, which test file includes which kind of tests, a comment similar to the following is placed at the top of the file: Do a Python test on the app. :unittest: In this case, the Python unit test layer will be used to run the tests. The other value that we are going to use is "doctest" when we learn how to write doctests. The test runner then finds all of the test modules and runs them in the corresponding layer. Although unit tests are considered very important in regular development, we may find functional tests more necessary for a Grok web application, as we will usually be testing views and forms, which require the full Zope/Grok stack to be loaded to work. That's the reason why we find only functional doctests in the default setup. Test layers A test layer is a specific test setup which is used to differentiate the tests that are executed. By default, there is a test layer for each of the three types of tests handled by the test runner. It's possible to run a test layer without running the others and also to name new test layers to be able to cluster together tests that require a specific setup. Invoking the test runner As shown above, running bin/test will start the test runner with the default options. It's also possible to specify a number of options, and the most important ones are summarized below. In the following table, command-line options are shown to the left. Most options can be expressed with a short form (one dash) or a long form (two dashes). Arguments for the option in question are shown in uppercase. -s PACKAGE, --package=PACKAGE, --dir=PACKAGE Search the given package's directories for tests. This can be specified more than once, to run tests in multiple parts of the source tree. For example, when refactoring interfaces, you don't want to see the way you have broken setups for tests in other packages. You just want to run the interface tests. Packages are supplied as dotted names. For compatibility with the old test runner, forward and backward slashes in package names are converted to dots. (In the special case of packages, which are spread over multiple directories, only directories within the test search path are searched.) -m MODULE, --module=MODULE Specify a test-module filter as a regular expression. This is a case sensitive regular expression, which is used in search (not match) mode, to limit which test modules are searched for tests. The regular expressions are checked against dotted module names. In an extension of Python regexp notation, a leading "!" is stripped and causes the sense of the remaining regexp to be negated (so "!bc" matches any string that does not match "bc", and vice versa). The option can specy multiple test-module filters. Test modules matching any of the test filters are searched. If no test-module filter is specified, then all of the test modules are used. -t TEST, --test=TEST Specify a test filter as a regular expression. This is a case sensitive regular expression, which is used in search (not match) mode, to limit which tests are run. In an extension of Python regexp notation, a leading "!" is stripped and causes the sense of the remaining regexp to be negated (so "!bc" matches any string that does not match "bc", and vice versa). The option can specify multiple test filters. Tests matching any of the test filters are included. If no test filter is specified, then all of the tests are executed. --layer=LAYER Specify a test layer to run. The option can be given multiple times to specify more than one layer. If not specified, all of the layers are executed. It is common for the running script to provide default values for this option. Layers are specified regular expressions that are used in search mode, for dotted names of objects that define a layer. In an extension of Python regexp notation, a leading "!" is stripped and causes the sense of the remaining regexp to be negated (so "!bc" matches any string that does not match "bc", and vice versa). The layer named 'unit' is reserved for unit tests, however, take note of the -unit and non-unit options. -u, --unit Executes only unit tests, ignoring any layer options. -f, --non-unit Executes tests other than unit tests. -v, --verbose Makes output more verbose. Increment the verbosity level. -q, --quiet Makes the output minimal by overriding any verbosity options. Looking at the test code Let's take a look at the three default test files of a Grok project, to see what each one does. ftesting.zcml As we explained earlier, ftesting.zcml is a configuration file for the test runner. Its main objective is to help us set up the test instance with users, so that we can test different roles according to our needs. <configure i18n_domain="todo" package="todo" > <include package="todo" /> <include package="todo_plus" /> <!-- Typical functional testing security setup --> <securityPolicy component="zope.securitypolicy.zopepolicy.ZopeSecurityPolicy" /> <unauthenticatedPrincipal id="zope.anybody" title="Unauthenticated User" /> <grant permission="zope.View" principal="zope.anybody" /> <principal id="zope.mgr" title="Manager" login="mgr" password="mgrpw" /> <role id="zope.Manager" title="Site Manager" /> <grantAll role="zope.Manager" /> <grant role="zope.Manager" principal="zope.mgr" /> As shown in the preceding code, the configuration simply includes a security policy, complete with users and roles and the packages that should be loaded by the instance, in addition to the regular Grok infrastructure. If we run any tests that require an authenticated user to work, we'll use these special users. The includes at the top of the file just make sure that all of the Zope Component Architecture setup needed by our application is performed prior to running the tests. tests.py The default test module is very simple. It defines the functional layer and registers the tests for our package: import os.path import z3c.testsetup import todo from zope.app.testing.functional import ZCMLLayer ftesting_zcml = os.path.join( os.path.dirname(todo.__file__), 'ftesting.zcml') FunctionalLayer = ZCMLLayer(ftesting_zcml, __name__, 'FunctionalLayer', allow_teardown=True) test_suite = z3c.testsetup.register_all_tests('todo') After the imports, the first line gets the path for the ftesting.zcml file, which then is passed to the layer definition method ZCMLLayer. The final line in the module tells the test runner to find and register all of the tests in the package. This will be enough for our testing needs in this article, but if we needed to create another non-Grok package for our application, we would need to add a line like the last one to it, so that all of its tests are found by the test runner. This is pretty much boilerplate code, as only the package name has to be changed.

Maintaining a log of data changes The system will show the history of our data changes only if we have already activated the Maintain Change Log feature. There are two ways of activating this feature: Role-based: This feature can be set up in the Role, which is associated with the user, upon login to the ADempiere client. To activate this auditing feature, navigate to the Menu | System Admin | General Rules | Security | Role window. Set the active tab to Role, and select your targeted role. Find and select the Maintain Change Log checkbox, as shown in the following screenshot: Table based: You can activate this feature based on the Table. The Table is a place where you save information in your databases. Activate this feature by logging in with the System user ID and System Administrator as the role. Open the Menu | Application Dictionary | Table and Column window. Find your table, and select the Maintain Change Log checkbox Standard window fields When you enter or view information in part C of the ADempiere window, there will be a couple of standard fields available. Client and Organization fields ADempiere has a feature to set up both multi-client and multi-organizational transactions. You can set up as many clients and organizations as you need. We will discuss how to set up clients and organizations later. To segregate information, the Client and Organization fields are used to save both the client (or company) and the organization (or division) information in each ADempiere information or data. The following screenshot shows us an example of the client and organization fields in the Business Partner window:   Active checkbox fields Within certain windows, there is another standard field available. This is known as the Active checkbox. Generally, this checkbox should be available in a window that is used to enter some data that is being repeatedly used within applications as references (something similar to master data). Some examples of windows that contain Active checkboxes are Warehouse,Business Partner, Price List, and so on. Although this master data will not to be used in your further transactions, you are advised to not remove or delete this information for data integrity purposes. Instead, mark these information records as inactive by deselecting the Active checkbox. Performing tasks The ADempiere window has editing features, similar to other applications that run on operating systems such as Linux and Microsoft Windows. However, it has several additional features that are unique to ADempiere itself. Data management Take a look at the main menu (part A) and toolbar (part B) area of your window. A list of icons related to data and record management is as follows: Icon Description Shortcut New: Click on this button when you want to add some information or data. F2 Save: After you finish entering or updating your data, click on this button to save the information to the database. F4 Cancel: Use this button to cancel or ignore your changes. Esc Copy Record: Duplicate the value of existing records to new records Shift+F2 Delete: Delete active records. For some data, you cannot delete the records. This is intended for auditing purposes. Instead, you can set their status to inactive. F3 Delete multiple: Delete selected records or items. You will be prompted with a Delete Selected Items window, which contains a list of record IDs and document numbers, before proceeding with the deletion. Ctrl+D ReQuery: Get the latest data, for the active records, from the databases. F5 Grid Toggle: Show detailed information of one record only. This is suitable for adding (entering) or editing data. F8 Grid Toggle: Shows the list of data or records in a grid mode. F8

First Normal Form Violation in Dimension table Let’s revisit the author problem in the book dimension. The AUTHOR column contains multiple authors, a first-normal-form violation, which prevents us from querying book or sales by author. BOOK dimension table BOOK_SK TITLE AUTHOR PUBLISHER CATEGORY SUB-CATEGORY 1 Programming in Java King, Chan Pac Programming Java 2 Learning Python Simpson Pac Programming Python 3 Introduction to BIRT Chan, Gupta, Simpson (Editor) Apes Reporting BIRT 4 Advanced Java King, Chan Apes Programming Java Normalizing and spinning off the authors into a dimension and adding an artificial BOOK AUTHOR fact solves the problem; it is an artificial fact as it does not contain any real business measure.  Note that the Editor which is an author’s role is also “normalized” into its column in the AUTHOR table (It is related to author, but not actually an author’s name). AUTHOR table AUTHOR_SK AUTHOR_NAME 1 King 2 Chan 3 Simpson 4 Gupta BOOK AUTHOR table BOOK_SK AUTHOR_SK ROLE COUNT 1 1 Co-author 1 1 2 Co-author 1 2 3 Author 1 3 2 Co-author 1 3 3 Editor 1 3 4 Co-author 1 4 1 Co-author 1 4 2 Co-author 1 Note the artificial COUNT measure which facilitates aggregation always has a value of numeric 1. SELECT name, SUM(COUNT) FROM book_author ba, book_dim b, author_dim aWHERE ba.book_sk = b.book_sk AND ba.author_sk = a.author_skGROUP BY name You might need to query sales by author, which you can do so by combining the queries of each of the two stars (the two facts) on their common dimension (BOOK dimension), producing daily book sales by author. SELECT dt, title, name, role, sales_amt FROM (SELECT book_sk, dt, title, sales_amt FROM sales_fact s, date_dim d, book_dim b WHERE s.book_sk = b.book_sk AND s.date_sk = d.date_sk) sales, (SELECT b.book_sk, name, role FROM book_author ba, book_dim b, author_dim a WHERE ba.book_sk = b.book_sk AND ba.author_sk = a.author_sk) authorWHERE sales.book_sk = author.book_sk Single Column with Repeating Value in Dimension table Columns like the PUBLISHER, though not violating any normal form, is also good to get normalized, which we accomplish by adding an artificial fact, PUBLISHED BOOK fact, and its own dimension, PUBLISHER dimension. This normalization is not exactly the same as that in normalizing first-normal-form violation; the PUBLISHER dimension can correctly be linked to the SALES fact, the publisher surrogate key must be added though in the SALES fact. PUBLISHER table   PUBLISHER_SK PUBLISHER 1 Pac 2 Apes BOOK PUBLISHER table BOOK_SK PUBLISHER_SK COUNT 1 1 1 1 2 1 2 3 1 3 2 1 3 3 1 3 4 1 4 1 1 4 2 1 Related Columns with Repeating Value in Dimension table CATEGORY and SUB-CATEGORY columns are related, they form a hierarchy. Each of them can be normalized into its own dimension, but they need to be all linked into one artificial fact. Non-Measure Column in Fact table The ROLE column inside the BOOK AUTHOR fact is not a measure; it violates the dimensional modeling norm; to resolve we just need to spin it off into its own dimension, effectively normalizing the fact table. ROLE dimension table and sample rows   ROLE_SK ROLE 1 Author 2 Co-Author 3 Editor BOOK AUTHOR table with normalized ROLE BOOK_SK AUTHOR_SK ROLE_SK COUNT 1 1 2 1 1 2 2 1 2 3 1 1 3 2 2 1 3 3 3 1 3 4 2 1 4 1 2 1 4 2 2 1   Summary This article shows that both dimensional table and fact table in a dimensional model can be normalized without violating its modeling norm. If you have read this article, you may be interested to view : Solving Many-to-Many Relationship in Dimensional Modeling

At the start of a training session, a student from the class asks the following question: I have just installed ADempiere on my computer and launched the ADempiere Web Start client to log in to the application. However, I do not understand what to do with the application's screens. Even though I am already familiar with Microsoft Windows, the structure of these screens is quite new for me. Could you please explain these screens to me? This is not a naive question. Like all new users who do not have experience in operating ERP software applications, this student needs to know the purpose of the screen along with information on the buttons, tabs, and so on inside each screen. Once the users know the main function of a certain screen, they will use and operate the software more effectively. The Connection aspect of ADempiere Our pre-installed ADempiere application will contain a sample company data called GardenWorld company. To make ourselves familiar with ADempiere, we will access this company data, using a predefined user ID and password. Launch your ADempiere application server, and then launch the ADempiere Web Start client. Checking the ADempiere client version With ADempiere patches being frequently available, we need to know the version of ADempiere client that we are working on. In the ADempiere Web Start client/fat client (not web-based version), through the ADempiere Login window, you can find the information that indicates the version of ADempiere in use. In this window, you can find the ADempiere client version by examining the information in the format 3.4.2s+P20091109. With this information, the system tells you that you are using: The ADempiere 3.4.2s (stable) version The latest patches installed on the system released on November, 09 2009 The predefined user ID and password Coming to the ADempiere Login window, the system supplies us with a GardenAdmin User ID and an obscured Password. The question is: What exactly is the GardenAdmin password? Within your current connection window, the system will serve us with the GardenAdmin user ID. However, this is not the only user ID that is available. Our ADempiere installation has a common list of user IDs and passwords, as mentioned in the following table: No User ID Password 1 System System 2 SuperUser System 3 GardenAdmin GardenAdmin 4 GardenUser GardenUser We can try all of these user IDs in the Adempiere Login window. When typing these user IDs and passwords, check the Caps Lock status. The system will check the capitalization of the characters being typed. When supplied with a wrong password, you will get a User does not match password error message. After typing your GardenAdmin password, you will be directed to the Defaults tab of the Adempiere Login window. Here, you have an option to set the Role, Client, Organization, Warehouse, Date, and Printer values. Leave the information as it is, and click on the OK button. You are now playing with a preconfigured GardenWorld sample client. Understanding the Client and System users With the default ADempiere installation, we can group users into the following types: Client users System users The type of user is determined by the kind of Role being used when connecting to the ADempiere system. A Client user is a type of user who has the rights to access Client information (for example, GardenWorld Client), whereas a System user is a type of user who has the rights to perform system-related tasks, such as accessing and configuring the Application Dictionary through the System Client. With the Application Dictionary, you can perform low-level configuration, such as: Configure the Table and Column definitions to save your data Construct a Window, Tab, and fields to build your ADempiere window Set up a Report and Process to generate your reports Most of these parts can be done without altering the ADempiere source code. Any information in the Application Dictionary is user-extensible and can include user-specific configuration.   The GardenAdmin user ID is an example of a Client user. This user ID should be able to connect to the ADempiere server with the GardenWorld Admin or the GardenWorld User role. The System and SuperUser user IDs are examples of System users. When logging in to the ADempiere system, these IDs can connect with the System Administrator role.   SuperUser can be used to access both System and Client information. Changing our ADempiere server connection During our testing phase, it's quite common to have multiple ADempiere servers. At least, we will have both a demo and a production ADempiere application server environment. You can choose your target ADempiere server by clicking on the Server field on the Adempiere Login w indow, as shown in the following screenshot: During ADempiere installation, you will see an ADempiere Connection window. Complete the Application Host field with the target IP address (or computer name) of the ADempiere server, and leave the other fields with their default values. Ensure the connection between the client and the server computer by clicking on the Test Application Server button. If this button displays a green check mark, then the system will automatically put the information in the database connection information into this window. You can verify the database connection by clicking on the Test Database button. When both of these buttons display a green check mark, this means that we have successfully connected to both, the ADempiere server and the database server. Finalize this task by clicking on the OK button.

I wanted to encapsulate this article with the latest version of Blender (being 2.5), I would not do so not until everyone gets comfortable with it and who knows, on one of my proceeding articles, we might delve more into an introduction of the new version. But for now, let’s be courteous enough to use the fully functional 2.49 version of Blender. If you don’t have it right now, I suggest you head over to http://www.blender.org/download/get-blender/ and grab your own copy. And you also might want to have a copy of the latest GIMP from http://www.gimp.org/downloads/. REQUIREMENTS: Skill level: Intermediate Blender 2.49b (stable) GIMP 2.6.8 INTRODUCTION: So basically, we’ll use Blender’s modeling tools, material indexes, powerful texture system, basic UV unwrapping, some lighting techniques, and of course the node compositor which is built-in in Blender. I dedicate this article to my family and the whole Blender community who have been very supportive of me during my past years of struggle and learning. It was just a wish before that someday hopefully I might be able to get the hang of using this application as much as I did with GIMP and finally somehow, it did happen. REFERENCE PHASE: Before we even begin doing modeling and firing up Blender itself, let’s get ourselves some decent reference images to base our model. Anything will do; it depends entirely on your tastes and preferences. Doing a quick Google search, here’s some that I found: MODELING PHASE: After studying carefully the shape and size of our reference soda cans, we can now proceed and start creating our basis shape for the entire process. I think this might be a good time to say this line, “Fire up Blender!” Depending on your User Defaults and Preferences, your startup screen might look a bit differently than mine and your default object on the scene might be different too. If you have objects other than a cube on your scene, kindly, delete them first since we’re only going to use the cube as our starting point. So if you don’t have one right now, go ahead and add it from the Spacebar > Add > Mesh > Cube menu. Adding a Cube to the Scene You might have wondered why a Cube and not a Cylinder. It’s because we don’t want to work on some extra polygons, just a few points will do. And we would be using some of Blender’s Modifiers to add contours and interpolations in between points to achieve smooth curves on the segments. With our cube on the scene now, go ahead and select it (Right Mouse Button [RMB]), then press CTRL+ 2 on your keyboard to add a Subsurf Modifier on the selected object or click the Editing (F9) button and scroll until you see the Modifiers tab then click Add Modifier and finally choose Subsurf. This will add a new modifier on our current stack. Adding a Subsurf Modifier After doing this, modify some of the subsurf options accordingly. Go ahead and change the Render Levels value to 3, or if you wish to, you could also change the Levels value to 3 such that what you see in your viewport is what you get on the render, but at the cost of a bit of a slowdown on your viewport (depending on the power your computer has). But still, despite adding a Subdivision Surface/Subsurf modifier on our Cube, why does it look polygonal still? That is because by default, the faces’ interpolation around the neighboring ones is set to Solid, that’s why we see this sharp edged transition in between faces. To make it smoother, just go ahead and click on the Editing(F9) button and scroll until you see the Links and Materials tab then click Set Smooth, or in Edit Mode, press W on your keyboard to bring up the Specials Menu and choose Set Smooth. Voila! Smoothing out the Geometry After this step, go to front view by pressing Numpad 1 on your numeric keypad and go to Edit Mode by pressing TAB, or choosing it from the Mode dropdown on the bottom of your 3D view. Select the top-most four vertices and move them 1 Blender Unit up along the Z-axis, do this by holding down the Ctrl key to constrain your movements on increments of 1, then press Z on your keyboard to constrain your movement on the z-axis only and not elsewhere. Moving the Top-most Vertices along Z

The article won't attempt to reproduce doit documentation, but will explain how it could be used to solve a specific problem in a practical way. For a complete introduction of doit, and a description of all its features, please refer to the project documentation. Debian packaging or bazaar knowledge isn't required to follow the discussion, but it would be helpful. Background When working on a project's source code, a developer usually needs to perform different repetitive administrative tasks that are required to compile, test and distribute the source code. In general, those tasks are pretty similar from project to project; although, the details may greatly vary depending on the application type, target platform, software development cycle, etc. As a consequence, the implementation of custom scripts that automate them is needed as a part of the maintenance of the source code. Given that, this is a very common problem, many task automation tools have been created, make is one of the most well-known among them and is used as a reference to compare with other similar tools. As the reader probably knows, make provides an imperative way to automate small tasks by defining in a file (a makefile) a series of rules that have a target file, multiple dependency files and a set of commands. To reach a given target, make must ensure that target file isn't outdated and that all the dependency files are present before running the commands that will generate the target file. During this process, the evaluation of other rules might be needed to fulfill the required dependencies. Although this approach may look simple, it has been really successful in many projects for years. However, since it tries to solve a general problem, it doesn't perfectly fit in every situation. This fact has led to the creation of similar tools that attempt to address some of the drawbacks of make.: The makefile format forces the developer to learn a new mini-language. Rules are statically defined. Just one target file per rule is allowed. With the advent of dynamic programming languages, a new generation of make-like tools that solved those issues were designed. For example, rake did a really good job in providing a familiar environment for ruby developers who wanted to use an advanced task automation tool without having to learn something new other than an API. With regard to python developers, many of these tools are currently available for them with different goals in their designs. One that I find particularly interesting is doit because it doesn't have any of the make problems listed above. In particular: It's really simple to use because it uses python itself as the language to write the configuration statements needed. Tasks, the equivalent to make's rules, may have as many targets as needed, which makes things simpler when the execution of a command entails the creation of multiple files. Task themselves aren't defined in the configuration, but task generators. This is really flexible when dependencies and/or targets depend on variables that need to be evaluated at run time. The problem Let's imagine that we are working on checkbox-editor, a simple python project hosted in Launchpad that provides an easy GTK interface to write test cases for checkbox. The way the application is delivered to users is by means of .deb packages for the latest Ubuntu distributions in a Personal Package Archive or PPA, so we'd like to be able to: Package the application at any time. Install the package locally for testing. Upload the package automatically to a PPA. Fortunately, the project's trunk branch already has the configuration files needed to generate a .deb package using the usual set of tools, so we're going to focus on the process of writing the file needed to generate and upload the desired packages. Of course, since we don't like to waste our time, we only want to generate the files needed for packaging when necessary; that's is to say, we're going to follow make's approach of generating target files only when they aren't up-to-date. Tasks In this section, a file that contains the tasks generators, which are required to automate the package generation using doit, will be created step by step. The same way as a makefile is created with all the rules for make; in doit, the default file name with the task generators is dodo.py. Of course, another file name can be used by passing an argument to doit, but we'll stick to the usual name in this example. In the code snippets that will be displayed in the following sections, some global variables will be used mainly to get the name of some files. For now, just assume that they're available in the task generators methods. The code that calculates those variables value will be shown at the end of the article. Identification There are two different classes of packages: source and binary ones. Binary packages are the ones that are compiled for an specific architecture, and that are expected to be installed directly into the destination hardware without any problem. These are the type of packages that we need to generate to accomplish the goal of installing a package locally for testing purposes. Hence, two of the tasks that we need to automate are the generation of the binary package and it's installation. Source packages are useful to distribute the source code of an application in a platform independent way, so that anyone can take a look at the code, fix it or compile it for another architecture if needed. This is also the package that must be uploaded to a Launchpad PPA, since it will take care to compile it for different architectures and publish the binary packages for them. Consequently, two more tasks that should be automated are the generation of a source package and the upload to the Launchpad PPA. Before creating any package is generated, we also need to generate a copy of the source code with the latest changes. This is not absolutely needed; but it's advised since the package generation process creates some temporary files. The diagram of the tasks that have just been identified is the following: Tasks that should be automated Code The first task before any package generation is copying the source code to a new directory (for example, pkg), to keep the development directory clean from the temporary files created during the packaging process. The code that implements this task is as follows: 1 def task_code(): 2 """ 3 Create package directory and copy source files 4 (bzr branch not used to take into account uncommited changes) 5 """ 6 def copy_file(from_file, to_file): 7 dir = os.path.dirname(to_file) 8 if dir and not os.path.isdir(dir): 9 os.makedirs(dir) 10 print from_file, '=>', to_file 11 shutil.copyfile(from_file, to_file) 12 shutil.copystat(from_file, to_file) 13 return True 14 15 yield {'name': 'clean', 16 'actions': None, 17 'clean': ['rm -rf pkg']} 18 19 for target, dependency in zip(PKG_FILES, SRC_FILES): 20 yield {'name': dependency, 21 'actions': [(copy_file, (dependency, target))], 22 'dependencies': [dependency], 23 'targets': [target]}

Installing SquirrelMail SquirrelMail may be installed either though a package or directly from source. While no source code compilation takes place in either method, upgrades are made easier using the packages. Many of the various Linux and Unix distributions include the SquirrelMail package. Install the appropriate package from your distribution to use the binary method. On many Linux distributions, this may be an RPM file that begins with squirrelmail…. However, an updated version of SquirrelMail may not be included or available for your specific distribution. The following are the advantages of using the version of SquirrelMail provided with a Linux distribution: It will be very simple to install SquirrelMail. It will require much less configuration as it will be configured to use the standard locations chosen by your Linux distributer. Updates will be very easy to apply, and migration issues may be dealt with by the package management system. The following are the disadvantages of using the version of SquirrelMail provided with a Linux distribution: It may not be the latest version. For example, a more recent version that may fix a security vulnerability may have been released, but Linux distributors may not have created a new package yet. Sometimes Linux distributions alter packages by applying patches. These patches may affect the operation of the package, and may make getting support or help more difficult. Source installation If you do not install SquirrelMail through your distribution, you will need to obtain the appropriate tarball. To do so, visit the SquirrelMail website at http://www.squirrelmail.org , and click download it here. At the time of writing, this link is http://www.squirrelmail.org/download.php There are two versions available for download, a stable version and a development version. Unless you have specific reasons for choosing otherwise, it is generally best to choose the stable version. Download and save this file to an intermediate location. $ cd /tmp$ wget http://squirrelmail.org/countdl.php?fileurl=http%3A%2F%2Fprdownloads.sourceforge.net%2Fsquirrelmail%2Fsquirrelmail-1.4.19.tar.gz Next, unpack the tarball (.tar.gz) file. You may use the following command: $ tar xfz squirrelmail-1.4.19.tar.gz Move the folder just created to your web root folder. This is the directory from which Apache serves pages. In this case, we will assume that /var/www/html is your web root. We will also rename the clumsy squirrelmail-1.4.3a folder to a more simple mail folder. You will need to have superuser root privileges in order to do this on most systems. # mv squirrelmail-1.4.19 /var/www/html/mail# cd /var/www/html/mail Here we have used the name mail, so the URL that users will use will be http://www.sitename.com/mail. You can choose another name, such as webmail,and use that directory name instead of mail in the commands that you enter. It is also useful and secure to create a data directory for SquirrelMail that is outside the main web root, so that this folder will be inaccessible from the Web. # mv /var/www/html/mail/data /var/www/sqmdata It is important to make this newly created folder writable by the web server. To be able to do this, you must know the user and group that your web server runs under. This may be nobody and nobody, apache and apache, or something else. You will want to verify this; it will be listed in your httpd.conf file as the User and Group entries. # chown -R nobody:nobody /var/www/sqmdata Finally, we will create a directory to store attachments. This directory is special in that, although the web server should have write access to write the attachments, it should not have read access. We create this directory and assign the correct permissions with the following commands: # mkdir /var/www/sqmdata/attachments# chgrp -R nobody /var/www/sqmdata/attachments# chmod 730 /var/www/sqmdata/attachments SquirrelMail has now been properly installed. All of the folders have been set up with correct permissions that will secure intermediate files from prying eyes. If a user aborts a message that contains an uploaded attachment,the attachment file on the web server will not be removed. It is a goodpractice to create a cron job on the server that erases excess files fromthe attachment directory. For example, create a file called remove_orphaned_attachments and place it in the /etc/cron.dailydirectory. Edit the file to have these lines:#!/bin/sh#!/bin/shrm `find /var/www/sqmdata/attachments -atime +2 | grep -v"."| grep -v _`This will run daily and search the SquirrelMail attachments directory forfiles which are orphaned, and delete them.

Streams is all about the rules; literally. The action context that a Streams process takes is governed by the rule conditions. When you create a rule, Oracle generates system conditions, and evaluation contexts, that are used to evaluate each LCR to determine if the action context for the process should be accomplished. We have already addressed a number of these system conditions during our TAG discussion; for instance INCLUDE_TAGGED_LCR=FALSE generates a system evaluation for theLCR$_ROW_RECORD_TYPE :dml.is_null_tag='Y' subprogram. For more information on LCR Types, reference Oracle Database PL/SQL Packages and Types Reference manual. You can control what system evaluations are included in the rule by the parameter values you specify, as well as add user-defined evaluations with the AND_CONDITION parameter. There is a lot going on under the calm surface water of rules. Understanding how this activity flows together will help you become more advanced in creating rules to manipulate your Streams throughout your current environment. So, let's grab our snorkels and masks, and stick our heads under the surface and take a look. Rule components Rules have three components: conditions, evaluation context, and action context. These components coordinate with the "when", "what", and "how" of the LCR being processed. The conditions tell the Streams process "when" the LCR should be processed, the evaluation context defines "what" data/information the Streams process uses to process the LCR, and the action context tells the Streams process "how" to handle the LCR. Rule conditions The rule condition is essentially the "where clause". The conditions are evaluated against the properties of the LCR and return either TRUE or FALSE The conditions can contain compound expressions and operators (AND, OR, NOT, and so on).The final evaluation returned from the condition (TRUE or FALSE) is the final result of all the compound expressions. An example of a system-generated condition would be that of our good friend :dml.is_null_tag = 'Y' (generated by the INCLUDE_TAGGED_LCR=FALSE parameter of the DBMS_STREAMS_ADM.ADD_*_RULE procedures). On rule creation, the condition is passed in as a string (so make sure to escape any single quotes within the string). ':dml.get_object_owner() = ''OE'' and :dml.get_tag() =HEXTORAW(''22'')' It is important to remember that you want to keep your rule conditions as simple as possible. Complex rule conditions can have a significant impact on performance. The rule condition created by our Sub-Setting example is an example of a complex rule as it includes a PL/SQL call to a function. Also, rule conditions that contain NOT, or != can also impact performance. Rule Evaluation Context The rule evaluation context defines data external to the LCR properties that can be referenced in the rule conditions. This is comparable to the SQL statement from clause. This reference is a database object that contains the external data. The evaluation context provides the rule conditions with the necessary information for interpreting and evaluating the conditions that reference external data. If the evaluation context references objects, the rule owner must have the proper privileges to reference the object (select and execute) as the rule condition is evaluated in the schema of the evaluation context owner. Information contained in an Evaluation Context might include table aliases used in the condition, variable names and types, and/or a function to use to evaluate the rules to which the evaluation context is assigned. Evaluation Context structure can get a bit confusing. To get a better feel of it, you may want to start by looking at the following database views: DBA/ALL/USER_EVALUATION_CONTEXT_TABLES: table alias used DBA/ALL/USER_EVALUATION_CONTEXT_VARS: variable types used DBA/ALL/USER_EVALUATION_CONTEXTS: functions used Streams system created rules (created using DBMS_STREAMS_ADM) will create rules using the standard Oracle-supplied SYS.STREAMS$_EVALUATION_CONTEXT rule evaluation context. This evaluation context is composed of a variable_types> list for the :dml and :ddl variables, and the evaluation function SYS.DBMS_STREAMS_INTERNAL.EVALUATION_CONTEXT_FUNCTION as seen in the previous DBA views. You can create your own evaluation context using the DBMS_RULE_ADM.CREATE_EVALUATION_CONTEXT procedure: DBMS_RULE_ADM.CREATE_EVALUATION_CONTEXT(evaluation_context_name IN VARCHAR2,table_aliases IN SYS.RE$TABLE_ALIAS_LIST DEFAULT NULL,variable_types IN SYS.RE$VARIABLE_TYPE_LIST DEFAULT NULL,evaluation_function IN VARCHAR2 DEFAULT NULL,evaluation_context_comment IN VARCHAR2 DEFAULT NULL); If you create a custom Evaluation Context that uses the SYS.DBMS_STREAMS_INTERNAL.EVALUATION_CONTEXT_FUNCTION, it must include the same variables and types as in the SYS.STREAMS$_EVALUATION_CONTEXT (a.k.a. :dml and :ddl). Variable_types> can be defined using SYS.RE$VARIABLE_TYPE_LIST, which in turn accepts individual variable types defined using SYS.RE$VARIABLE_TYPE. Similarly, if you create a custom function to use as the evaluation function, it must have the following signature: FUNCTION evaluation_function_name(rule_set_name IN VARCHAR2,evaluation_context IN VARCHAR2,event_context IN SYS.RE$NV_LIST DEFAULT NULL,table_values IN SYS.RE$TABLE_VALUE_LIST DEFAULT NULL,column_values IN SYS.RE$COLUMN_VALUE_LIST DEFAULT NULL,variable_values IN SYS.RE$VARIABLE_VALUE_LIST DEFAULT NULL,attribute_values IN SYS.RE$ATTRIBUTE_VALUE_LIST DEFAULT NULL,stop_on_first_hit IN BOOLEAN DEFAULT FALSE,simple_rules_only IN BOOLEAN DEFAULT FALSE,true_rules OUT SYS.RE$RULE_HIT_LIST,maybe_rules OUT SYS.RE$RULE_HIT_LIST);RETURN BINARY_INTEGER; Where the returned BINARY_INTEGER value must be one of the following: DBMS_RULE_ADM.EVALUATION_SUCCESSDBMS_RULE_ADM.EVALUATION_CONTINUEDBMS_RULE_ADM.EVALUATION_FAILURE For more information on creating custom Evaluation Contexts and evaluation functions and Rule Types, refer to the Oracle Database PL/SQL Packages and Types Reference manual, and The Oracle Streams Extended Examples manual. Once an Evaluation Context is created it can be assigned to a rule or a rule set using the evaluation_context parameter of the appropriate DBMS_RULE_ADM procedure. The Evaluation Context for a Rule can be different than the Evaluation Context for a Rule Set to which the Rule might be assigned. The bottom line is that a Rule must be able to associate itself with an Evaluation Context at some level. We will revisit this concept as we discuss Rule Creation a little later on this section. Action Context The rule action context is just that, the action information that the rule evaluation engine returns to the client application, to be acted upon by the client application, when the rule evaluates to true. This is not the action itself, but values to be used by the action code that are specific to the rule. The action context is of the SYS.RE$NV_LIST type, which contains an array of name-value pairs and is associated to a rule condition. A rule condition can only have one action context. The action context itself is optional and can contain zero to many name-value pairs. The SYS.RE$NV_LIST has the following construct: TYPE SYS.RE$NV_LIST AS OBJECT(actx_list SYS.RE$NV_ARRAY); Subprograms are: ADD_PAIR (name IN VARCHAR2,value IN ANYDATA);GET_ALL_NAMES ()RETURN SYS.RE$NAME_ARRAY;GET_VALUE (name IN VARCHAR2)RETURN ANYDATA;REMOVE_PAIR (name IN VARCHAR2); For more information on creating and populating Action Contexts types, refer to the Oracle Database PL/SQL Packages and Types Reference manual. For more information on Rule components refer to the Oracle Streams Concepts and Administration manual.

Rule based transformation—eat your heart out transformers! As with all good rules, some are made to be broken; or maybe changed. In some circumstances we need to have rules that govern change. In Advance Replication, a number one rule is that a replicated table must have the same structure at all master sites. The column names and data types have to be identical or the "apply" of a deferred transaction will fail. With Streams, we can now break this rule by adding a new rule that allows the LCR to "morph" to a new structure. We call this ability Rule Based Transformation; and it is done via complex rules and action context. When you plan your Rule Based Transformation design, you want to remember that Rule Based Transformation rules are only evaluated with positive Rule Sets. If the Rule Set is negative, the Rule Based Transformation is ignored. Declarative versus User Created In the real world, there are many ways to accomplish the same thing; just as there are many ways to model data. You may run into a situation where the table structure in one master database may be different from the structure of the table in another master database but data must be replicated between them. It could be that a table column at one master is a VARCHAR2, but is a DATE at another master site. Or perhaps the column does not exist at all. Rule Based Transformation provides the ability to capture the LCR and convert it to the necessary structure needed to apply it at the destination site. This is not to be confused with transformations accomplished via the DBMS_TRANSFORMATION package. That is a different fish (and doesn't swim in this stream). A special note concerning SUBSET Rules and transformations. A SUBSET Rule has an internal row_migration transformation assigned to it when it is created. This internal transformation will always be the first one executed before any other transformations. Another thing to keep in mind is the amount of "transformation" that will be applied to the LCR. If extensive transformations need to be made to the LCR, you may wish to consider using a custom DML handler instead to take advantage of the apply parallel capabilities. The remainder of this section is going to use the premise that we have an LCR that we need to change a column name for, before we send it out from the source site. The LCR is generated on a table which has a different column name than the corresponding table at all the other sites. This being the case, we are going to create the transformation at the Capture process. There are two ways to accomplish this; either by using a declarative transformation or a user created transformation. We will review each, and then apply the method to our LCR that needs a column name change. Depending on the Transformation type, you can use one of the following views to find information concerning the transformation: Declarative: DBA_STREAMS_TRANSFORMATIONS User Created: DBA_STREAMS_TRANSFORM_FUNCTION Declarative Transformation As of 10g, Oracle provides commonly used transformations in the DBMS_STREAMS_ADM package. These transformations are referred to as declarative transformations. Declarative transformations only work with row LCR's (aka DML LCR's). The row LCR can be a Streams captured LCR (basic or synchronous), or a user created message. The procedures allow you to add transformation rules to do the following: Add a column (DBMS_STREAMS_ADM.ADD_COLUMN) Delete a column (DBMS_STREAMS_ADM.DELETE_COLUMN) Rename a column (DBMS_STREAMS_ADM.RENAME_COLUMN) Rename a table (DBMS_STREAMS_ADM.RENAME_TABLE) Rename a schema (DBMS_STREAMS_ADM.RENAME_SCHEMA) Special considerations when DBMS_STREAMS_ADM.ADD_COLUMN Be aware that the DBMS_STREAMS_ADM.ADD_COLUMN procedure does not support a number of data types. These include: LOBS (BLOB, CLOB, NCLOB, BFILE, and so on) LONG, LONG RAW, and so on ROWID User-defined types (including object types, REFs, varrays, nested tables, and so on) Oracle-supplied types (including ANY types, XML types, spatial types, and media types) For more information on DBMS_STREAMS_ADM Declarative Transformation subprograms, please refer to the Oracle Database PL/SQL Packages and Types Reference. For our purposes, we want to use the DBMS_STREAMS_ADM.RENAME_COLUMN to create a declarative transformation. In our example, we will work with the JOB_HISTORY table from the Oracle Example HR Schema. We will assume that at our source database the HR.JOB_HISTORY table has a column named DEPARTMENT_ID, and at the destination database the corresponding column in the HR.JOB_HISTORY is DEPT_ID. Declarative Transformations can only be added to an existing rule. If the rules specifi ed do not exist, an error is raised. Also, the transformation will be owned by STRM_ADMIN so make sure you have explicitly granted all privileges on HR.JOB_HISTORY to STRM_ADMIN. First we find the rule to which we wish to add the declarative transformation, logged in as STRM_ADMIN we can look at the USER_RULES view: SQL> select * from user_rules;RULE_NAME------------------------------RULE_CONDITION-------------------------------------RULE_EVALUATION_CONTEXT_OWNER RULE_EVALUATION_CONTEXT_NAME------------------------------ ------------------------------RULE_ACTION_CONTEXT(ACTX_LIST(NVN_NAME, NVN_VALUE()))--------------------------------------------------------------RULE_COMMENT--------------------------------------------------------------HR1((:dml.get_object_owner() = 'HR') and :dml.get_source_database_name()= 'STRM1')SYS STREAMS$_EVALUATION_CONTEXTHR2((:ddl.get_object_owner() = 'HR' or :ddl.get_base_table_owner() ='HR') and :ddl.get_source_database_name() = 'STRM1' )SYS STREAMS$_EVALUATION_CONTEXT HR1 is our Row LCR (:dml) rule, so we will add To create our declarative transformation Rule, we issue the following command: beginDBMS_STREAMS_ADM.RENAME_COLUMN(rule_name => 'strm_admin.HR1',table_name => 'HR.JOB_HISTORY',from_column_name => 'DEPARTMENT_ID',to_column_name => 'DEPT_ID',value_type => '*', -- defaultstep_number => 0, --defaultoperation => 'ADD' -–default);end;/ We can now check the rule in the USER_RULES view: SQL> select * from user_rules where rule_name = 'HR1';RULE_NAME------------------------------RULE_CONDITION-------------------------------------------------------------RULE_EVALUATION_CONTEXT_OWNER RULE_EVALUATION_CONTEXT_NAME------------------------------ ------------------------------RULE_ACTION_CONTEXT(ACTX_LIST(NVN_NAME, NVN_VALUE()))-------------------------------------------------------------RULE_COMMENT-------------------------------------------------------------HR1((:dml.get_object_owner() = 'HR') and :dml.get_source_database_name()= 'STRM1')SYS STREAMS$_EVALUATION_CONTEXTRE$NV_LIST(RE$NV_ARRAY(RE$NV_NODE('STREAMS$_INTERNAL_TRANS',ANYDATA()))) Notice that the RULE_COMMENT now has an entry indicating the inclusion of the transformation rule. We can also look at the DBA_STREAMS_TRANSFORMATION view: SQL> select rule_owner, rule_name, transform_type,2 from_column_name, to_column_name, value_type,3 declarative_type, precedence, step_number4 from dba_streams_transformations;RULE_OWNER------------------------------RULE_NAME TRANSFORM_TYPE------------------------------ --------------------------FROM_COLUMN_NAME TO_COLUMN_NAME VAL-------------------- -------------------- ---DECLARATIVE_TYPE PRECEDENCE STEP_NUMBER-------------------- ---------- -----------STRM_ADMINHR1 DECLARATIVE TRANSFORMATIONDEPARTMENT_ID DEPT_ID *RENAME COLUMN 2 0 To remove the declarative transformation from the rule, we use the same procedure we used to create the transformation, but set the operation parameter to REMOVE: beginDBMS_STREAMS_ADM.RENAME_COLUMN(rule_name => 'strm_admin.HR1',table_name => 'HR.JOB_HISTORY',from_column_name => 'DEPARTMENT_ID',to_column_name => 'DEPT_ID',operation => 'REMOVE' -–default);end;/ Note: Removing the declarative transformation does not clear the RULE_COMMENT we see in the USER_RULES view. However, it does clear the entry from the DBA_STREAMS_TRANSFORMATION view . For more detailed information on using the DBMS_STREAMS_ADM.RENAME_COLUMN, and other declarative transformation procedures, please refer to the Oracle PL/SQL Packages and Types Reference, and the Oracle Streams Concepts and Administration Guide. User Created Rule Based Transformations (UCRBT) You can also create your own Rule Based Transformations. These transformations are referred to as user-created transformations (imagine that). The steps for creating a UCRBT are pretty basic. Create the PL/SQL function that performs the transformation. The function should receive the LCR as a SYS.ANYDATA IN parameter The function should return either an LCR a SYS.ANYDATA or STREAMS$_ANYDATA_ARRAY If the function returns a STREAMS$_ANYDATA_ARRAY, it can only be associated with a capture rule Grant the EXECUTE privilege on the function to the appropriate user as necessary. Create or locate the rules for which the transformation will be used. Set the custom rule-based transformation for each rule by running the SET_RULE_TRANSFORM_FUNCTION procedure. In this example, we will setup a UCRBT that makes the same transformation as the previous declarative transformation. The UCRBT is going to be owned by STRM_ADMIN so make sure you have explicitly granted all privileges on HR.JOB_HISTORY to STRM_ADMIN. The code for this example can be found in the UCRBT.sql code file. First we create the PL/SQL function to accomplish the transformation; STRM_ADMIN will be the function owner, so make sure you are logged in as STRM_ADMIN in this example: CREATE OR REPLACE FUNCTION DEPT_COLNAME_CHANGE (evt IN SYS.AnyData)RETURN SYS.AnyData ISlcr SYS.LCR$_ROW_RECORD;obj_name VARCHAR2(30);rc NUMBER;BEGINIF evt.GetTypeName='SYS.LCR$_ROW_RECORD' THENrc := evt.getObject(lcr);obj_name := lcr.GET_OBJECT_NAME();IF obj_name = 'JOB_HISTORY' THENlcr.RENAME_COLUMN('DEPARTMENT_ID','DEPT_ID','*');RETURN SYS.ANYDATA.ConvertObject(lcr);END IF;END IF;RETURN evt;END;/ Because STRM_ADMIN is the function owner, we do not need to grant EXECUTE on the function. If the function was created in a different schema, then we would want to explicitly grant execute on the function to STRM_ADMIN. Next we determine which rule to which to add the transformation function. You can either create a new rule at this point, or use an existing rule. We will use our HR1 rule from above (we can do this because we removed the Declarative RENAME_COLUMN transformation from the rule in our last step of the Declarative Transformation example). select * from dba_rules; Then, we use the DBMS_STREAMS_ADM.SET_RULE_TRANSFORM_FUNCTION procedure to add the transformation function to the desired rule: BEGINDBMS_STREAMS_ADM.SET_RULE_TRANSFORM_FUNCTION(rule_name => 'HR1',transform_function => 'strm_admin.DEPT_COLNAME_CHANGE');END;/ We will now see the transformation in the DBA/ALL_STREAMS_TRANSFORM_FUNCTION view: SQL> select * from all_streams_transform_function;RULE_OWNER------------------------------RULE_NAME VALUE_TYPE------------------------------ --------------------TRANSFORM_FUNCTION_NAME CUSTOM_TYPE----------------------------------- -----------STRM_ADMINHR1 SYS.VARCHAR2"STRM_ADMIN"."DEPT_COLNAME_CHANGE" ONE TO ONE For more detailed information on UCRBT, please reference the Usage Notes for the DBMS_STREAMS_ADM.SET_RULE_TRANSFORM_FUNCTION procedure in the Oracle PL/SQL Packages and Types Reference, and the Oracle Streams Concepts and Administration Guide. Transformation Order of Execution It is possible to have a combination of declarative and user defined transformations assigned to a single rule. This being the case, how do you know which ones get executed when? Especially, if you have not assigned step numbers. There is a default order of execution for transformation that help keep the rule from running amuck. If the rule is a Subset rule, then Row Migration is always executed first Next are Declarative Rule based transformations These are further ordered by the step number specified for each transformation if they have been assigned. If the step numbers are not assigned, the transformations are executed in the following order: Delete_Column Rename_Column Add_Column Rename_Table Rename_Schema Last (but not the least), the User Created Rule-Based Transformation is executed.

Due to the fact that writing a Java app to control your Twitter account is quite a long process and requires several features, I intend to divide this article in several sections, so you can see in extreme detail all the bells and whistles involved in writing Java applications. Downloading and installing NetBeans for your developing platform To download NetBeans, open a web browser window and go to the NetBeans website. Then click on the Download button and select the All IDE download bundle. After downloading NetBeans, install it with the default options. Creating your SwingAndTweet project Open NetBeans and select File | New Project to open the New Project dialog. Now select Java from the Categories panel and Java Application from the Projects panel. Click on Next to continue. The New Java Application dialog will show up next. Type SwingAndTweet in the Project Name field, mark the Use Dedicated Folder for Storing Libraries option, deselect the Create Main Class box (we’ll deal with that later), make sure the Set as Main Project box is enabled and click on Next to continue: NetBeans will create the SwingAndTweet project and will show it under the Projects tab, in the NetBeans main window. Right click on the project’s name and select JFrame Form... in the pop-up menu: The New JFrame Form window will appear next. Type SwingAndTweetUI in the Class Name field, type swingandtweet in the Package field and click on Finish to continue: NetBeans will open the SwingAndTweetUI frame in the center panel of the main screen. Now you’re ready to assemble your Tweeter Java application! Now let me explain a little bit about what we did in the previous exercise: First, we created a new Java application called SwingAndTweet. Then we created a Swing JFrame component and we named it SwingAndTweetUI, because this is going to act as the foundation, where we’re going to put all the other Swing components required to interact with Twitter. Now I’m going to show you how to download and integrate the Twitter4J API to your SwingAndTweetJava application. Downloading and integrating the Twitter4J API into your NetBeans environment For us to be able to use the powerful classes and methods from the Twitter4J API, we need to tell NetBeans where to find them and integrate them into our Java applications. Open a web browser window, go to http://repo1.maven.org/maven2/net/homeip/yusuke/twitter4j/ and search for the latest twitter4j.2.X.X.jar file, or download the most recent version at the time of this writing from here:http://repo1.maven.org/maven2/net/homeip/yusuke/twitter4j/2.0.9/twitter4j-2.0.9.jar. Once you download it in your computer, go to NetBeans, right-click on the SwingAndTweet project and select Properties from the context menu. Once at the project properties screen, select the Libraries category under the Categories panel, click on the Add JAR/Folder... button at the middle-right part of the screen to open the Add JAR/Folder dialog, navigate to the directory where you downloaded the twitter4j-2.X.X.jar file and double click on it to add it to your project’s library path: Click on OK to close the Project Properties dialog and return to the NetBeans main screen. Ok, you have integrated the Twitter4J API to your SwingAndTweet application. Now, let’s see how to log into your Twitter account from our Java application... Logging into Twitter from Java and seeing your last Tweet In the following exercise, I’ll show you how easy it is to start communicating with Twitter from a Java application, thanks to the Twitter class from the Twitter4J API. You‘ll also learn how to check your last tweet through your Java application. Let’s see how to log into a Twitter account: Go to the Palette window and locate the JLabel component under the Swing Controls section; then drag and drop it into the TweetAndSwing JFrame component: Now drag a Button and a Text Editor, too. Once you have the three controls inside the SwingAndTweetUI JFrame control, arrange them as shown below: The next step is to change their names and captions, to make our application look more professional. Right click on the JLabel1 control, select Edit from the context menu, type My Last Tweet and hit Enter. Do the same procedure with the other two controls: erase the text in the jTextField1 control and type Login in the jButton1 control. Rearrange the jLabel1 and jTextField1 controls, and drag one of the ends of jTextField1 to increase its length all you can. Once done, your application will look like this: And now, let’s inject some life to our application! Double click on the JButton1 control to open your application’s code window. You’ll be inside a java method called jButton1ActionPerformed. This method will execute every time you click on the Login button, and this is where we’re going to put all the code for logging into your Twitter account. Delete the // TODO add your handling code here: line and type the following code inside the JButton1ActionPerformed method: Remember to replace username and password with your real Twitter username and password. If you look closely at the line numbers, you‘ll notice there are five error icons on lines 82, 84, 85,  88 and 89. That’s because we need to add some import lines at the beginning of your code, to indicate NetBeans where to find the Twitter and JOptionPane classes, and the TwitterException. Scroll up until you locate the package swingandtweet; line; then add the following lines: Now all the errors will disappear from your code. To see your Java application in action, press F6 or select Run  Run | Main Project from the NetBeans main menu. The Run Project window will pop up, asking you to select the main class for your project. The swingandtweet.SwingAndTweetUI class will already be selected, so just click on OK to continue. Your SwingAndTweetUI application window will appear next, showing the three controls you created. Click on the Login button and wait for the SwingAndTweet application to validate your Twitter username and password. If they’re correct, the following dialog will pop up: Click on OK to return to your SwingAndTweet application. Now you will see your last tweet on the textbox control: If you want to be really sure it’s working, go to your Twitter account and update your status through the Web interface; for example, type Testing my Java app. Then return to your SwingAndTweet application and click on the Login button again to see your last tweet. The textbox control will now reflect your latest tweet: As you can see, your SwingAndTweet Java application can now communicate with your Twitter account! Click on the X button to close the window and exit your SwingAndTweet application.

N-way replication refers to a Streams environment where there are multiple sources. In this article, we will still use the STRM1 and STRM2 databases but with a little twist; making both databases the source. By making both STRM1 and STRM2 sources, we need to first consider a couple of unique situations and do a little more pre-planning, specifically for N-Way replication. The concepts and techniques used to configure a 2-way replication can then be used to scale to N-way replication. We all need to crawl before we run, the better you crawl (understand) this article, the easier it will be to scale up to N-way replication. Pay close attention and learn the technique so that you can implement it well. We need to repeat this—Streams is not Failover. We need to repeat this—Streams is not Failover. No, that is not a typo. The authors are passionate about Streams and want to see you successfully implement it. To successfully implement Streams, you need to know not to step into the trap of using it for Failover. Both authors have done some work where Failover was the requirement. Streams is not a Failover solution. Failover is handled by Oracle Data Guard, NOT Oracle Streams. Streams is about distributing the data to multiple locations. On more than one occasion, Streams was used as a Failover technology because it can distribute data to multiple locations. Do not fall into the trap of using the wrong tool for the wrong job. Streams distributes (replicates) data. As such, there will always be some difference between the databases in a Streams environment. All replication technology has this problem. The only time where all of the databases are in sync is, when there is no activity and all replication has been applied to all target locations. If you need Failover, then use the proper tool. Oracle Data Guard is for Failover. It has the necessary processes to guarantee a different level of failover from a primary site to a secondary site, whereas Streams is a Replication tool that distributes data. Just remember the following, when there is a discussion of Replication and Failover that comes up: Streams distributes data, it is built for replication Data Guard is built for Failover Pre-planning for N-way replication When we set up N-way replication, we must consider the possibility of a collision of data. Since we have multiple sources of data, it is possible for the exact same data to be inputted on any or all of the sources at the exact same time. When this happens, it is a conflict. This example is just one type of conflict that can happen in N-way replication environments. The types of conflict that can occur are as follows: Update conflict: When transactions from different databases try to update the same row at nearly the same time. Delete conflict: When one transaction deletes a row and the next transaction tries to update or delete the row. Transactions originate from different databases. Unique conflict: When transactions from different databases violate a primary or unique constraint, the first transaction is accepted. The second transaction obtains the conflict. Foreign key conflict : This happens when a transaction from a Source tries to insert a child record before the parent record exists. The good news is that Oracle has provided built-in conflict resolution in Streams that solves the most common situations. The built-in solutions are as follows: OVERWRITE DISCARD MAXIMUM MINIMUM We will provide an example of conflict resolution after we build our N-way replication. In our case, we will use MAXIMUM. As part of the pre-planning for N-way replication, we highly suggest creating a simple table such as the Setup Table. Avoiding Conflict As conflict requires additional pre-planning and configuration, one begins to wonder, "Are there techniques so that we can configure N-way replication without the possibility of conflict?" The simple answer to the question is "Yes". The not-so simple answer is that there is some configuration magic that needs to be done and the devil is in the details. Limiting who and what can be updated is one method of avoiding conflict. Think of it this way— there is no conflict if we agree to who and what can update the specific data. User 1 can only update his specific data and no one else can do that. Similarly, user 2 can only update his specific data. So, user 1 and user 2 can never cause a conflict. Now this may be a little bit difficult depending on the application. This can be implemented with the use of offset sequences. One sequence produces only odd values, and another produces only even values. We could also use a combination of sequence and some unique characteristics of the database.

SHADING PHASE: It feels so good that we’ve gone past the modeling phase already.  Now we tell our tin can how it is made and what it is made of. In this stage, we’ll just quickly add some basic materials and shading to our current object and distinguish some of its parts for later texturing. Let’s go ahead and select our main tin can mesh in Object Mode and press F5 on your keyboard or click the Shading (F5) button then go to Materials sub button to activate the materials menu. Go to the Links and Pipeline tab and click Add New to create a new material block. Creating a New Material Rename the currently added material into “metal” and adjust the material settings accordingly (as seen in the screenshot below). The only settings I adjusted are the color, specularity, and reflectivity. Metal Material Settings Copy the same material settings to the opener and the circle object (I don’t know what it’s called). But instead of manually selecting each and every object and then adding or browsing through the materials menu, what we’ll do is just link whatever settings the main metal material has such that when we change the material, it will readily reflect those changes to the other objects as well. We do that by first selecting the objects that will inherit the material, then select last the object that has the reference material, in this case, the main soda can. Then press CTRL+L on your keyboard and choose Materials. Materials Linking If we do a render right now, here’s how it will look like: Initial Render Not that convincing yet. But we’ll deal with that shortly.   Two down. Next thing on the list: textures. TEXTURING PHASE: During my career in 3D, texturing has been one of the things I’ve been very scared of, probably because I was just too reluctant to learn or even know it and another is the concept of another dimension called UVW, which seems pretty daunting at first. But somehow, I got over it and am very happy that however scary it seemed to me before, it’s how lovely it is to have now.  Hopefully though, even with just letting you see a tid bit of info about basic texturing, you get the idea. Right now, we’ll just deal with some basic procedural textures and image textures with decent UV mapping techniques.  Let’s get it on! With our main tin can body selected, switch to Edit Mode if you haven’t yet by pressing TAB on your keyboard or accessing it through the Mode dropdown on the bottom part of your 3D viewport screen. Rotate your view and select the back-most part of the vertical edge loop that we’ll use. Then press CTRL+E and choose Mark Seam. What this will do is tell Blender that this part of the mesh is where the unwrapping and unfolding will take place and tear from. After applying the Mark Seam, you’ll see a thick line drawn across the edges you’ve selected. Confused? See the screenshot below. Creating the Edge Seam After we’ve marked the necessary edges and seams, we can now proceed and select parts of the mesh that we want to be unwrapped.  But before that, let’s just go ahead for awhile and add some procedural textures to the metal material to simulate the brushed metal texture. Let’s go back and head over to our Shading (F5) > Materials menu and browse over to the Textures panel and click Add New to create a new texture slot. After this, head over to the Texture Buttons (F6), rename the texture to brushed, choose a Cloud texture, and change the Noise Size to .005 and the Noise Depth to 4.  Leave the other default values as it is, we might not need them. Adding a New Texture and Some Texture Settings Let’s get back to our Material Settings and scroll over to the Texture panel and head over to the Map Input tab and the Map To tab. Under Map Input, change the mapping as seen in the screenshot below. Under Map To, make it affect the Col and Nor options which stands for Color and Normal (or bump mapping) respectively. Change the Nor value to something low like 0.20 and also change the color to something a tad darker than the original color of the material. Texture Mapping Settings Doing a render now, this is what we see: Basic Render with Procedural Texture   Now we can go ahead and proceed on UV mapping an image texture to the tin can body itself. Since the last time we went into Edit Mode, we’ve created an Edge Seam to derive our UV mapping from, so we’ll take it from there. Select all of the vertices that we want our label/sticker to be wrapped on, as exemplified here, the four middle rows of vertices are selected. Middle Four Rows of Vertices Selected Split your screen so that the left most side would have our model and the right of it would be the UV/Image Editor Window. While at the UV/Image Editor Window, open and browse the image that you want to be wrapped on the body of your can by going to Image > Open on the header menu of the window. Screen Split and Image Opened Hover your mouse cursor over to the 3D viewport and press U then choose Unwrap. What this will do is intelligently unwrap your selected edges according to how you marked your seams and will preview the selection on your UV/Image editor window. Unwrapping Selection into UV Right now, the way Blender unwrapped our selection is already good enough, but looking closely at it, we see non-straight lines which we do not want since we wished for our texture to be mapped correctly according to the lines that our object represent. We fix this by selecting the necessary vertices in the UV/Image editor, just like how we normally select vertices in the 3D Viewport, then press S for Scale, and if you want it to be straight horizontally, follow it up with a Y then press 0 to straighten it, and if you want it vertically, do an X then press 0.  After everything has been straightened up, select the whole set of edges and scale them a bit such that they’re not touching the border because this might cause problems later if we disregarded doing that. Edges Straightened But still, something just doesn’t look right now. Even though we’ve actually corrected the edges the way they are now, their size is inappropriate for our label. If we are going to see the mapping right now, we’d see only half of the word “Pepsi” since that’s only where our selection is at. To address this, simply select all of the edges and scale them along the y-axis (while at the UV/Image Editor Window). That should fix it. Now, if we’re going to render our can, we won’t see anything but the same thing that we saw on our last render. Why? Because we haven’t told Blender yet to use the image we uwrapped our mesh on; how is it going to be mapped and where. Go to Edit Mode and select the vertices that encompass the parts we used for the unwrapping awhile back and go to Editing (F9) then go to Links and Materials tab and click New on the right hand side to create a new material index. This is a very important part here. If we didn’t do it, our mapping for the image would go haywire, so I highly suggest you follow me on this. You’ll notice that after pressing the New button, a new name appears above with the current name of our material appended with a .001, what that means is that a new material datablock has already been added. However, nothing is assigned to it yet, so while at the same place in the Links and Materials tab and the vertices still selected in our 3D Viewport, click the Assign button to make this group of vertices be a user of the newly created material. This technique is called material indexing, where a single object could have multiple materials assigned to it depending on the way its mesh is constructed. Creating a New Material Index for the Label Let’s head over to the Material options once again and rename our newly created material into something more appropriate. Let’s name it “label”.  And create a new texture, name it “pepsi” and make it an Image Texture. On the image options of the texture, click on the drop-down menu and browse for the image we just opened before. Image Texture Options Then finally, choose the mapping options. Map it to UV and just enable the Col option. Image Texture Mapping Options Before we do a render, it’s a good idea to pack our images into our blend file so whenever we open our files elsewhere, the images that come along with it stays intact. Do this by going to File > External Data > Pack into .blend file (you’ll notice a gift box icon appear on your header after doing this) and in the UV/Image Editor press the Gift box icon. Packing the Images with the .blend File So now, if we do a test render, here’s how it will look like: Render with Textures   Almost there. Next, we light up the scene better. Let’s go!

In this article by Audra Hendrix, Bogdan Brinzarea and Cristian Darie, authors of AJAX and PHP: Building Modern Web Applications 2nd Edition, we will discuss the usage of an AJAX-enabled data grid plugin, jqGrid. One of the most common ways to render data is in the form of a data grid. Grids are used for a wide range of tasks from displaying address books to controlling inventories and logistics management. Because centralizing data in repositories has multiple advantages for organizations, it wasn't long before a large number of applications were being built to manage data through the Internet and intranet applications by using data grids. But compared to their desktop cousins, online applications using data grids were less than stellar - they felt cumbersome and time consuming, were not always the easiest things to implement (especially when you had to control varying access levels across multiple servers), and from a usability standpoint, time lags during page reloads, sorts, and edits made online data grids a bit of a pain to use, not to mention the resources that all of this consumed. As you are a clever reader, you have undoubtedly surmised that you can use AJAX to update the grid content; we are about to show you how to do it! Your grids can update without refreshing the page, cache data for manipulation on the client (rather than asking the server to do it over and over again), and change their looks with just a few keystrokes! Gone forever are the blinking pages of partial data and sessions that time out just before you finish your edits. Enjoy! In this article, we're going to use a jQuery data grid plugin named jqGrid. jqGrid is freely available for private and commercial use (although your support is appreciated) and can be found at: http://www.trirand.com/blog/. You may have guessed that we'll be using PHP on the server side but jqGrid can be used with any of the several server-side technologies. On the client side, the grid is implemented using JavaScript's jQuery library and JSON. The look and style of the data grid will be controlled via CSS using themes, which make changing the appearance of your grid easy and very fast. Let's start looking at the plugin and how easily your newly acquired AJAX skills enable you to quickly add functionality to any website. Our finished grid will look like the one in Figure 9-1:   Figure 9-1: AJAX Grid using jQuery Let's take a look at the code for the grid and get started building it. Implementing the AJAX data grid The files and folders for this project can be obtained directly from the code download(chap:9) for this article, or can be created by typing them in. We encourage you to use the code download to save time and for accuracy. If you choose to do so, there are just a few steps you need to follow: Copy the grid folder from the code download to your ajax folder. Connect to your ajax database and execute the product.sql script. Update config.php with the correct database username and password. Load http://localhost/ajax/grid to verify the grid works fine - it should look just like Figure 9-1. You can test the editing feature by clicking on a row, making changes, and hitting the Enter key. Figure 9-2 shows a row in editing mode:     Figure 9-2: Editing a row Code overview If you prefer to type the code yourself, you'll find a complete step-by-step exercise a bit later in this article. Before then, though, let's quickly review what our grid is made of. We'll review the code in greater detail at the end of this article. The editable grid feature is made up of a few components: product.sql is the script that creates the grid database config.php and error_handler.php are our standard helper scripts grid.php and grid.class.php make up the server-side functionality index.html contains the client-side part of our project The scripts folder contains the jQuery scripts that we use in index.html   Figure 9-3: The components of the AJAX grid The database Our editable grid displays a fictional database with products. On the server side, we store the data in a table named product, which contains the following fields: product_id: A unique number automatically generated by auto-increment in the database and used as the Primary Key name: The actual name of the product price: The price of the product for sale on_promotion: A numeric field that we use to store 0/1 (or true/false) values. In the user interface, the value is expressed via a checkbox The Primary Key is defined as the product_id, as this will be unique for each product it is a logical choice. This field cannot be empty and is set to auto-increment as entries are added to the database: CREATE TABLE product( product_id INT UNSIGNED NOT NULL AUTO_INCREMENT, name VARCHAR(50) NOT NULL DEFAULT '', price DECIMAL(10,2) NOT NULL DEFAULT '0.00', on_promotion TINYINT NOT NULL DEFAULT '0', PRIMARY KEY (product_id)); The other fields are rather self-explanatory—none of the fields may be left empty and each field, with the exception of product_id, has been assigned a default value. The tinyint field will be shown as a checkbox in our grid that the user can simply set on or off. The on-promotion field is set to tinyint, as it will only need to hold a true (1) or false (0) value. Styles and colors Leaving the database aside, it's useful to look at the more pertinent and immediate aspects of the application code so as to get a general overview of what's going on here. We mentioned earlier that control of the look of the grid is accomplished through CSS. Looking at the index.html file's head region, we find the following code: <link rel="stylesheet" type="text/css" href="scripts/themes/coffee/grid.css" title="coffee" media="screen" /><link rel="stylesheet" type="text/css" media="screen" href="themes/jqModal.css" /> Several themes have been included in the themes folder; coffee is the theme being used in the code above. To change the look of the grid, you need only modify the theme name to another theme, green, for example, to modify the color theme for the entire grid. Creating a custom theme is possible by creating your own images for the grid (following the naming convention of images), collecting them in a folder under the themes folder, and changing this line to reflect your new theme name. There is one exception here though, and it affects which buttons will be used. The buttons' appearance is controlled by imgpath: 'scripts/themes/green/images', found in index.html; you must alter this to reflect the path to the proper theme. Changing the theme name in two different places is error prone and we should do this carefully. By using jQuery and a nifty trick, we will be able to define the theme as a simple variable. We will be able to dynamically load the CSS file based on the current theme and imgpath will also be composed dynamically. The nifty trick involves dynamically creating the < link > tag inside head and setting the appropriate href attribute to the chosen theme. Changing the current theme simply consists of changing the theme JavaScript variable. JqModal.css controls the style of our pop-up or overlay window and is a part of the jqModal plugin. (Its functionality is controlled by the file jqModal.js found in the scripts/js folder.) You can find the plugin and its associated CSS file at: http://dev.iceburg.net/jquery/jqModal/   In addition, in the head region of index.html, there are several script src declarations for the files used to build the grid (and jqModal.js for the overlay): <script src="scripts/jquery-1.3.2.js" type="text/javascript"></script><script src="scripts/jquery.jqGrid.js" type="text/javascript"></script><script src="scripts/js/jqModal.js" type="text/javascript"></script><script src="scripts/js/jqDnR.js" type="text/javascript"></script> There are a number of files that are used to make our grid function and we will talk about these scripts in more detail later. Looking at the body of our index page, we find the declaration of the table that will house our grid and the code for getting the grid on the page and populated with our product data. <script type="text/javascript">var lastSelectedId;$('#list').jqGrid({ url:'grid.php', //name of our server side script. datatype: 'json', mtype: 'POST', //specifies whether using post or get//define columns grid should expect to use (table columns) colNames:['ID','Name', 'Price', 'Promotion'], //define data of each column and is data editable? colModel:[ {name:'product_id',index:'product_id', width:55,editable:false}, //text data that is editable gets defined {name:'name',index:'name', width:100,editable:true, edittype:'text',editoptions:{size:30,maxlength:50}},//editable currency {name:'price',index:'price', width:80, align:'right',formatter:'currency', editable:true},// T/F checkbox for on_promotion {name:'on_promotion',index:'on_promotion', width:80, formatter:'checkbox',editable:true, edittype:'checkbox'} ],//define how pages are displayed and paged rowNum:10, rowList:[5,10,20,30], imgpath: 'scripts/themes/green/images', pager: $('#pager'), sortname: 'product_id',//initially sorted on product_id viewrecords: true, sortorder: "desc", caption:"JSON Example", width:600, height:250, //what will we display based on if row is selected onSelectRow: function(id){ if(id && id!==lastSelectedId){ $('#list').restoreRow(lastSelectedId); $('#list').editRow(id,true,null,onSaveSuccess); lastSelectedId=id; } },//what to call for saving edits editurl:'grid.php?action=save'});//indicate if/when save was successfulfunction onSaveSuccess(xhr){ response = xhr.responseText; if(response == 1) return true; return false;}</script>

There are many exciting changes and additions to Domino Designer 8.5. We will begin with the introduction of the Eclipse based integrated development environment. Domino Designer 8.5, which is also known as Domino Designer on Eclipse or DDE, takes advantage of Eclipse technology to deliver a more powerful developer environment. The look and feel is more consistent with Notes client version 8.x. The new UI will be examined at a high level. The next major feature addition that will be covered is XPages. XPages are a new type of design element being introduced in the 8.5 release that will revolutionize Domino Web Applications. XPages enable application developers to quickly and easily create rich Domino web applications with a Web 2.0 look and feel. Finally, we will review improvements to CSS support, enhancements to HTML generation, JavaScript controls, a new method related to ID Vault: ResetUserPassword, and changes to web services. Domino Designer on Eclipse Now in 8.5 the Domino Designer client is based on Eclipse, as the Notes client was in 8.x. Eclipse is an award-winning, open source platform for the construction of powerful software development tools and rich desktop applications. This architectural change allows the new designer client to become an open source pluggable environment. By allowing the use of plugins, objects can be built, re-used, and shared. Some of the differences in the new 8.5 Designer client can be seen when examining the processes associated with Domino Designer. It is useful to know how they relate to one another and what component each controls. Prior to release 8.5 designer clients, when you launched designer.exe, nlnotes.exe would be spawned. This is the process in which pre-8.5 Domino Designer ran. Now in the 8.5 Designer client, designer.exe loads and spawns nlnotes.exe. On faster machines, designer.exe shows up briefly, and may not be seen at all. Then the notes2.exe process spawns and designer.exe quits. notes2.exe is the Java process that corresponds to the Eclipse shell. Finally, nlnotes.exe spawns ntaskldr.exe after DDE opens. Some other things you may notice are that launch and exit take longer than in previous versions. This is due to the Eclipse startup and shutdown sequences. This can lead to problems on exit or launch. If you experience a problem with launch or exit, it may be due to one of the following issues. Due to the longer exit time, the user may have initiated launch before all prior processes had been killed, or the user may have initiated the launch sequence multiple times. It is also possible that, on prior exit, the client did not shut down all processes. With a few exceptions, the launch process will be able to compensate for these errors. However, if you still can't launch or exit the 8.5 designer client, you can try the following, manually. Kill the nlnotes.exe and notes2.exe processes with the task manager, or if the client still will not launch or exit, log off the system to completely kill all process threads. The new Eclipse-based GUI Now that the 8.5 Designer client is Eclipse based, there is a new UI. The default perspective in 8.5 is the Domino Designer perspective. There are other perspectives available in Domino Designer 8.5, each suited to a particular task. You can select a different perspective from the menu, select Window | Open Perspective | Other, as seen in the following screenshot: Not all perspectives have a corresponding layout in the UI. Perspectives can be customized to suit individual preferences. One way is by resizing the views and editors. You can resize views and editors in one of two ways. Click the Maximize/Restore button located in the title bar of the view or editor. Or, click and drag the border of a view or editor. Views and editors can also be hidden by clicking the view Close button. Use the menu pick Window | Show Eclipse Views to reopen closed views. You can use this menu pick to open any Eclipse view, including those from other perspectives. To return to the current perspective's default layout use the menu pick Window | Reset Perspective.... XPages For a while now it has been difficult to create elegant web applications for Notes/Domino. XPages are a new type of design element being introduced in the 8.5 release, that will allow application developers to quickly and easily create rich Domino web applications with a Web 2.0 look and feel. Applications built using XPages are supported for web use only, for the 8.5 release. To enhance the appearance and functionality for web use, existing applications can be extended to utilize XPages. The standard design elements must be included in the database for use in the Notes client and the application. If a new application is targeted for both Notes client and web users, then you can also include XPages for use on the Web. XPages are built on top of JSF, or Java Server Faces, technology. XPages also have built-in Ajax support, which allows application developers to take advantage of Ajax features such as type-ahead and partial page refresh. They are created in pure XML markup. When the application developer adds controls to XPages using drag and drop, the XML is generated automatically. XPages does not require any additional steps to install on a Domino server. When you create a new XPage in an application, you start with a blank page similar to what you see when a new form or page is created. You then build the XPage by dragging and dropping controls onto the XPage to add functionality. A wide array of controls is available out of the box, which enables application developers to quickly and easily get a web application up and running. Some examples of the controls available are a pager, rich text editor, date picker, tabbed panel, and many more. Controls can also be combined into a single object, called a custom control. Custom controls are similar to sub-forms, as they can be used in other XPages in the current application or copied into other applications for reuse. Just like with sub-forms, if a change is made to a custom control in an application, that change is propagated out to all other instances of that custom control in that application. There is a default system template in the 8.5 release that uses XPages. The discussion template has been enhanced to include XPages in 8.5. Improvements to CSS Support Now in Domino Designer 8.5 you can edit and create CSS. Previously, you would have to use an external editor to do this. Not only can you create custom stylesheets, but you can import existing ones. You can also group your favorite stylesheets and script resources into a theme to provide a common look and feel in your application and map style classes to UI controls. This will save developer time and effort when adding CSS to applications. To create a new stylesheet: Click File | New | Style Sheet Resource from the main Eclipse menu. In the New Style Sheet dialog box, do the following: In the Name field, type the name of the stylesheet. By default, Domino Designer adds a CSS file extension to this name In the Application field, select an application for the stylesheet. Click OK Another method of creating a stylesheet, is by double-clicking Resources | Style Sheets in the Applications navigator and then clicking New Style Sheet in the editor.

The webmail solution A webmail solution is a program or a series of scripts that is run on a server, is accessible over the web, and provides access to e-mail functions similar to a conventional mail client. It is used by Yahoo! Mail, Microsoft Hotmail, Microsoft Outlook Web Access, and Gmail as the primary interface to their e-mail solutions. You may already be familiar with various forms of webmail. Though we will be examining the SquirrelMail webmail solution specifically, the benefits and drawbacks of SquirrelMail apply to most webmail systems in the market. From this point of view, we will approach the issue from a general perspective, and then in detail for the SquirrelMail package. The benefits This section will focus on the advantages offered by installing and maintaining a webmail solution. As with any list, it is not entirely comprehensive. Many benefits will be specific to a particular case; it is important to carefully examine and consider how the following qualities impact your individual situation. The main benefits we will explore in this section are as follows: Easy and quick access with little or no setup Easy remote access No need to maintain client software or configuration Provision of a user interface to configure mail server options Possible security benefits Easy and quick access Although well suited to certain situations, traditional mail access solutions can often be difficult to set up and maintain. Generally, this involves installing software on a client's local computer and configuring it. This can be difficult, especially in cases where users need to set up the software themselves. Configuration can often be even more problematic as some users may not be competent enough to follow even a very detailed set of instructions. These instructions also need to be provided and maintained for many different mail clients on many different platforms. However, a webmail solution does not have most of these problems. All of the user's settings can be configured on the server as the application itself resides on the server. This translates to almost zero set up time for the user. Once they have received their login credentials, they can visit the webmail site and instantly have access to all of their mail. The user is able to access the site instantly to send and receive e-mail. As the Internet is so common now, many users will be familiar with webmail sites such as Google Mail and Windows Live Hotmail, which offer free e-mail services. However, the user interface provided by an open source package may be more primitive and lack some visual features. Squirrelmail provides access to e-mail, including the ability to send and receive attachments, and offers a good user interface. It is also worth mentioning that a webmail solution can offer what certain traditional mail clients call groupware features. These features let groups communicate and coordinate in ways that complement e-mail communication. Examples of groupware components are private calendars, shared calendars, meeting scheduling, To-do lists, and other similar tools. These applications can be preconfigured so that a user can instantly begin using them without having to configure them on their own. Several SquirrelMail plugins which implement these features are available from the SquirrelMail website. Easy remote access Another problem with traditional mail access software is that it is not portable, as an e-mail client needs to be installed and configured on a computer. Once it has been downloaded, installed, and configured on a particular computer, it is accessible only on that computer. Without webmail, users on the road will not be able to access e-mail from friends' computers, mobile devices, or Internet booths at airports. However, in a webmail solution, e-mail can be accessed from any location with an Internet connection. Employees can access their work e-mail from any computer with an Internet connection and a suitable browser. As the administrator, you can choose to permit or deny users from accessing e-mail in insecure situations. By requiring the connection to be encrypted, you can ensure that when a user is in a remote location, their communication with the server is secure. No need to maintain clients Even if software mail clients have been installed and properly configured, they must be maintained. When a new version is released, all clients must be updated. This is not necessarily an easy task. Software that does not work as expected can result in a large number of support-desk calls. Updating the software on each client can be a very large administrative burden. In fact, many expensive software packages are designed for the specific purpose of updating software on individual machines automatically. Despite this, problems specific to each local machine often arise and must be solved individually. It may also be difficult to convey instructions or notifications to remote branch locations or remote workers. With a webmail solution, this is not necessary. In contrast to this, a webmail solution is centrally maintained and administered. The webmail application resides on the server. With webmail, only the web server and the webmail package need to be upgraded. Any exceptions or problems that arise can be dealt with before or during the upgrade. The software upgrade itself can be run through on a test system before it is deployed on a live system. Although changes in settings are rare with SquirrelMail, it is possible to update a user's settings to make them compatible with the changes introduced in an updated version. Additionally, while upgrading or changing a mail server platform, testing effort can be greatly reduced as only supported browser versions need to be tested. It is advisable to mandate particular browser versions for corporate computers. In contrast with e-mail clients, there is no need to test on all of the possible clients and software platforms. Configuring mail server interface via the user interface Many traditional desktop e-mail clients provide only e-mail functionality and nothing more. Often there is no support for other essential tasks (such as changing the access password) that are performed on behalf of a mail user. Certain configuration options that reside on the server may require additional software applications or external solutions to provide for these needs. Examples of mail server options that may need to be configured include each user's password and junk mail filtering settings. In the case of the SquirrelMail webmail application, many plugins have been developed that provide these features. For example, a user is able to change his/her password directly from the webmail interface. Also, there are plugins and systems that allow users to easily sign up without any direct human intervention. This may be useful if you are interested in providing a service where users can sign up without needing an administrative overhead. Possible security benefits This issue can be seen in two different ways—it is for this reason that the title is listed as "Possible" security benefits. Nonetheless, this is still an interesting point to examine. In the software client access model, e-mail is traditionally downloaded onto the local user's computer, being stored in one or more personal folders. From a security perspective, this may be a bad thing. Users of the system may not be as conscientious or knowledgeable about computer security as a trained computer administrator might be. It is often much easier to gain unauthorized access to an end user's computer than a properly configured and secured server. The implication is that someone who stole a company laptop might be able to access all the e-mail stored on that computer. There is one more disadvantage associated with the client access model. Even if an employee is terminated, he/she may still have access to all of the e-mail that  resides on his/her local office computer. It may take a certain amount of time before important information may be secured. A disgruntled worker might easily connect an external storage source to their local office computer and download any data they desire. It is also worth noting that in a webmail model, all e-mail is centrally stored. If an attacker were to gain access to the central e-mail server, he/she might access all the e-mail stored on that server. However, it is possible that an attacker will gain access to all the e-mail if the central mail server is compromised even if a webmail system is not used. The disadvantages This section focuses on the disadvantages resulting from providing and supporting a webmail solution. The warning given in the previous section applies: This list is not entirely comprehensive. Each situation is unique, and may bring its unique disadvantages. We will go over the following disadvantages of a webmail solution: Performance issues Compatibility with large e-mail volumes Compatibility with e-mail attachments Security issues Performance The traditional e-mail client is designed in the client-server model. One mail server accepts and delivers e-mail to and from other mail servers. However, a desktop mail client can offer many additional productivity-enhancing features such as message sorting, searching, contact list management, attachment handling, along with more recent ones such as spam filtering and message encryption. Each of these features may require a certain amount of processing power. The required level of processing power may be negligible when it comes to storing one user's e-mail on a desktop computer, but providing these features may be problematic when applied on a larger scale to a single server. When examining the performance issue, it is important to consider the number of potential users that will access the webmail application and size a server accordingly. A single server may be able to easily handle something like 300 users, but if the number of users increases significantly, server load may become an issue. For example, searching through several years' archived mail may take a few seconds on a client's computer. When one user performs this task using webmail, the load will be similar. However, if many clients request this operation at short intervals or concurrently, it may be difficult for the server to process all the requests in a timely manner. This may result in pages being served at a slower rate or, in extreme circumstances, the server failing to respond. Optimally, load testing in the appropriate conditions should be performed if there is any concern that a server may not be able to handle a particular load of users. Compatibility with large e-mail volumes The webmail solution is not well suited to large mail volumes. This disadvantage is related to the previous one, but is more related to the amount of data sent. Even with a relatively low number of users, a large volume of e-mails may be difficult to manage in a webmail application. There are mainly the following two reasons for this: Firstly, every e-mail viewed and every folder listed must be sent from the server each time. With a traditional e-mail client, the client software can manage e-mail messages, creating lists and views to suit the user. However, with a webmail solution, this is performed on the server. So, if there are many users, this overhead may use a significant proportion of the server's resources. Secondly, each interaction with the webmail application requires a Hypertext Transfer Protocol (HTTP) request and response. These messages will typically be larger than those between an e-mail server and a desktop e-mail client. There may also be less parallelism when using a webmail client, inother words, fewer things going on at the same time. A desktop e-mail client may be able to check for new e-mails in several folders at the same time, but a webmail client will typically perform these tasks one after the other, if they occur automatically at all.
