How-To Tutorials

7019 Articles
Packt
09 Jul 2015
29 min read
Save for later

Process of designing XenDesktop® deployments

Packt
09 Jul 2015
29 min read
In this article by, Govardhan Gunnala and Daniele Tosatto, authors of the book Mastering Citrix® XenDesktop®, we will discuss the process of designing XenDesktop® deployments. The uniqueness of the XenDesktop architecture is its modular five layer model. It covers all the key decisions in designing the XenDesktop deployment. User layer: Defines the users and their requirements Access layer: Defines how the users will access the resources Desktop/resource layer: Defines what resources will be delivered Control layer: Defines managing and maintaining the solution Hardware layer: Defines what resources it needs for implementing the chosen solution (For more resources related to this topic, see here.) While FMA is simple at a high level, its implementation can become complex depending on the technologies/options that are chosen for each component across the layers of FMA. Along with great flexibility, comes the responsibility of diligently choosing the technologies/options for fulfilling your business requirements. Importantly, the decisions made in the first three layers impact the last two layers of the deployment. It means that fixing a wrong decision anywhere in the first three layers during/after implementation stage would have less or no scope, and may even lead to implement the solution from the scratch again. Your design decisions speak for your solution's effectiveness in helping with the given business requirements. The layered architecture of the XenDesktop FMA, featuring the components at each layer is given in the following diagram. Each component of XenDesktop will fall under one of the layers shown in the succeeding diagram. We'll see what decisions are to be made for each of these components at each layer in the next sub section. Decisions to be made at each layer I will have to write a separate book for discussing all the possible technologies/options that are available at each layer. Following is a highly summarized list of the decisions to be made at each layer. This will help you in realizing the breadth of designing XenDesktop. This high level coverage of the various options will help you in locating and considering all the possible options that are available for making the right decisions and avoiding any slippages and missing any considerations. User layer The user layer refers to the specification of the users who will utilize the XenDesktop deployment. A business requirement statement may mention that the service users can either be the internal business users or the external customers accessing the service from Internet. Furthermore, both of these users may also need mobile access to the XenDesktop services. The Citrix receiver is the only component that belongs to the user layer, and XenDesktop is dependent on it for successfully delivering a XenDesktop session. By correlating this technical aspect with the preceding business requirement statement, one needs to consider all the possible aspects of receiver software on the client devices. This involves making the following decisions: Endpoint/user devices related: What are the devices that the users are supposed to access the services from? Who owns and administrates those devices throughout their lifecycle? Endpoints supported: Corporate computers, laptops, or mobiles running on Windows or thin clients. User smart devices, such as Android tablets, Apple iPads, and so on. In case of service providers, the endpoints can usually be any device and they need to be supported. Endpoint ownership: Device management includes security, availability, and compliance. Maintaining the responsibility of the devices on network. Endpoint lifecycle: Devices become either outdated or limited very quickly. Define minimum device hardware requirements to run your business workloads. Endpoint form factor: Choose the devices that may either be fully featured or have limited thin clients, or be a mix of both to support features, such as HDX graphics, multi-monitors, and so on. Thin client selection: Choose if the thin clients, such as Dell Wyse Zero clients, running on the limited functionality operating systems would suffice your user requirements. Understand its licensing cost. Receiver selection: Once you determine your endpoint device and its capabilities, you need to decide on the receiver selection that can be run on the devices. The greatest thing is that receiver is available for almost any device. Receiver type: Choose the receiver that is required for your device. Since the Receiver software for each platform (OS) differs, it is important to use the appropriate Receiver software for your devices while considering the platform that it runs on. You can download the appropriate Receiver software for your device from http://www.Citrix.com/go/receiver.html page. Initial deployment: Receiver is like any other software that will fit into your overall application portfolio. Determine how you would deploy this application on your devices. For corporate desktops and mobiles, you may use the enterprise application deployment and the mobile device management software. Otherwise, the users will be prompted to install it when they access the StoreFront URL, or they can even download it from Citrix for facilitating the installation process. For user-managed mobile devices, you can get it from the respective Windows or Google Apple stores/marketplaces. Initial configuration: Similar to other applications, Receiver requires certain initial configuration. It can be configured either manually or by using a provisioning file, group policy, and e-mail based discovery. Keeping the Receiver software up-to-date: Once you have installed Receiver on user devices, you will also require a mechanism for deploying the updates to Receiver. This can also be the way of initial deployments. Access layer An access layer refers to the specification of how the users gain access to the resources. A business requirement statement may usually state that the users should be validated for gaining access, and the access should be secured when the user is connected over the Internet. The technical components that fall under this layer include firewall(s), NetScaler, and StoreFront. These components play a broader role in the overall networking infrastructure of the company, which also includes the XenDesktop, as well as complete Citrix solutions in the environment. Their key activities include firewalling, external to internal IP address NATing, NetScaler Gateway to secure the connection between the virtual desktop and the user device, global load balancing, user validation/authentication, and GUI presentation of the enumerated resources to the end users. It involves making the following decisions: Authentication: Authentication point: A user can be authenticated at the NetScaler Gateway or StoreFront. Authentication policy: Various business use cases and compliance makes certain modes of authentication mandatory. You can choose from the different authentication methods supported at: StoreFront: Basic authentication by using a username and a password; Domain Pass-through, the NS Gateway pass-through, smart card, and even unauthenticated access. NetScaler Gateway: LDAP, RADIUS (token), client certificates. StoreFront: The decisions that are to be made around the scope of StoreFront are as follows: Unauthenticated access: Provides access to the users who don't require a username and a password, but they are still able to access the administrator allowed resources. Usually, this fits well with public or Kiosk systems. High availability: Making the StoreFront servers available at all times. Hardware load balancing, DNS Round Robin, Windows network load balancing, and so on. Delivery controller high availability and StoreFront: Building high availability for the delivery controller is recommended since they are needed for forming successful connections. Defining more than one delivery controller for the stores makes StoreFront auto failover to the next server in the list. Security - Inbound traffic: Consider securing the user connection to virtual desktops from the internal StoreFront and the external NetScaler Gateway. Security – Backend traffic: Consider securing the communication between the StoreFront and the XML services running on the controller servers. As these will be within the internal network, they can be secured by using the internal private certificate. Routing Receiver with Beacons: Receiver supports websites called Beacons to identify whether the user connection is internal or external. StoreFront provides Receiver with the http(s) addresses of the Beacon points during the initial connection. Resource Presentation: StoreFront presents a webpage, which provides self-service of the resources by the user. Scalability: The StoreFront server load and capacity for the user workload. Multi-site App synchronization: StoreFront can connect to the controllers at multiple site deployments. StoreFront can replicate the user subscribed applications across the servers. NetScaler Gateway: In the NetScaler Gateway, the decision regarding the secured external user access from public Internet involves the following: Topology: NetScaler supports two topologies: 1-Arm (normal security) and 2-Arm (high security). High availability: The NetScaler Gateways can be configured in pairs to provide high availability. Platform: NetScaler is available in different platforms, such as VPX, MDX, and SDX. They have different SSL throughput and SSL Transaction Per Second (TPS) metrics. Pre-authentication policy: Specifies about the Endpoint Analysis (EPA) scans for evaluating whether the endpoints meet the pre-set security criteria. This is available when NetScaler is chosen as the authentication point. Session management: The session policies define the overall user experience by classifying the endpoints into mobile and non-mobile devices. Session profile defines the details needed for gaining access to the environment. These are in two forms: SSLVPN and HDX proxy. Preferred data center: In multi-active data center deployments, StoreFront can determine the user resources primary data center and NetScaler can direct the user connections to that. Static and dynamic methods are used for specifying the preferred data center. Desktop/resource layer The desktop or resource layer refers to the specification of which resources (applications and desktops) users will receive. This layer comes with various options, which are tailored for business user roles and their requirements. This layer makes XenDesktop a better fit for achieving the varying user needs across each of their departments. It includes specification of the FlexCast model (type of desktop), user personalization, and delivering the application to the users in the desktop session. An example business requirement statement may specify that all the permanent employees would require a desktop with all the basic applications pre-installed based on their team and role, with their user settings and data to be retained. For all the contract employees, provide a basic desktop with controlled access to the applications on-demand and do not retain their user data. It includes various components, such as profile management solutions (including Windows profiles, the Citrix profile management, AppSense), Citrix print server, Windows operating systems, application delivery, and so on. It involves making decisions, such as: Images: It involves choosing the FlexCast model that is tailored to the user requirements, thereby delivering the expected desktop behavior to the end users, as follows: Operating system related: It requires choosing the desktop or the server operating systems for your master image, which depends on the FlexCast model that you are choosing from. Hosted Shared Hosted VDI: Pooled-static, pooled-random, pooled with PvD, dedicated, existing, physical/remote PC, streamed and streamed with PvD Streamed VHD Local VM On-demand apps Local apps In case of the desktop OS, it's also important to choose the right OS architecture according to the 32-bit or 64-bit processor architecture of the desktop. Computer policies: Define the controls over the user connection, security and bandwidth settings, devices or connection types, and so on. Specify all the policy features similar to that of the user policies. Machine catalogs: Define your catalog settings, including the FlexCast model, AD computer accounts, provisioning method, OS of the base image, and so on. Delivery groups: Assign desktops or applications to the user groups. Application folders: This is a tidy interface feature in Studio for organizing the applications into folders for easy management. StoreFront integration: This is an option for specifying the StoreFront URL for the Receiver in the master image so that the users will be auto connected to the storefront in the session. Resource allocation: This defines the hardware resources for the desktop VMs. It primarily involves hosts and storage. Depending on your estimated workloads, you can define the resources, such as number of virtual processors (vCPU), amount of virtual memory (vRAM), storage requirements for the needed disk space, and also the following resources Graphics (GPU): For the advanced use cases, you may choose to allocate the pass-through GPU, hardware vGPU, or the software vGPUs. IOPS: Depending on the operating system, the FlexCast model, and estimated workloads, you can analyze the overall IOPS load from the system and plan the corresponding hardware to support that load. Optimizations: Depending on the operating system, you can apply various optimizations to Windows that run on the master image. This greatly reduces the overall load later. Bandwidth requirements: Bandwidth can be a limiting factor in case of WAN and remote user connections of slow networks. Bandwidth consumption and user experience depend on various factors, such as the operating system being used, the application design, and screen resolution. To retain high user experience, it's important to consider the bandwidth requirements and optimization technologies, as follows: Bandwidth minimizing technologies: These include Quality of Service (QoS), HDX RealTime, and WAN Optimization, with Citrix's own CloudBridge solution. HDX Encoding Method: HDX encoding method also affects the bandwidth usage. For XenDesktop 7.x, there are three encoding methods that are available. These will appropriately be employed by the HDX protocol. These are Desktop Composition Redirection, H.264 Enhanced SuperCodec, and Legacy Mode (XenDesktop 5.X Adaptive Display). Session Bandwidth: Bandwidth needed in a session depends on the user interaction with desktop and applications. Latency: HDX can typically perform well up to 300 ms latency and the experience begins to degrade as latency increases. Personalization: This is an essential element of the desktop environment. It involves the decisions that are critical for the end user experience/acceptance and for the overall success of the solution during implementation. Following are the decisions that are involved in personalization. User profiles: This involves the decisions that are related to the user login, roaming of their settings, and seamless profile experience across overall Windows network: Profile type: Choose which profile type works for your user requirements. Possible options include local, roaming, mandatory, and hybrid profile with Citrix Profile Management. Citrix Profile Management provides various additional features, such as profile streaming, active write back, and configuring profiles using an .ini file, and so on. Folder redirection: This option saves the user's application settings in the profile. Represents special folders, such as AppData, Desktop, and so on. Folder exclusion: This option is for setting the exclusion of folders that are to be saved in the user profile. Usually, it refers to the local and IE Temp folders of a user profile. Profile caching: Caching profiles on a local system improves the user login experience and it occurs by default. You need to consider this depending on the type of virtual desktop FlexCast mode. Profile permissions: Specify whether the administrator needs access to the user profiles based on information sensitivity. Profile path: The decision to place the user profiles on a network location for high availability. It affects the logon performance depending on how close the profile is to the virtual desktop from which the user is logging on. It can be managed either from Active Directory or through Citrix Profile Management. User profile replication between data centers: This involves making the user profiles highly available and supporting the profile roaming among multiple data centers. User policies: Involves the decision regarding deploying the user settings and controlling those using management policies providing consistent settings for users, such as: Preferred policy engine: This requires choosing the policy processing for the Windows systems. The Citrix policies can be defined and managed from either Citrix Studio or the Active Directory group policy. Policy filtering: The Citrix policies can be applied to the users and their desktop with the various filter options that are available in the Citrix policy engine. If the group policies have been used, then you'll use the group policy filtering options. Policy precedence: The Citrix policies are processed in the order of LCSDOU (Local, Citrix, Site, Domain, OU policies). Baseline policy: This defines the policy with default and common settings for all the desktop images. Citrix provides the policy templates that suit specific business use cases. A baseline should cover security requirements, common network conditions, and managing the user device or the user profile requirements. Such a baseline can be configured using the security policies, connection-based policies, device-based policies, and profile-based policies. Printing: This is one of the most common desktop user requirements. XenDesktop supports printing, which can work for various scenarios. The printing technology involves deploying and using appropriate drivers. Provisioning printers: These can either be a static or dynamic set of printers. The options for dynamic printers do and do not auto-create all the client printers and auto-create the non-network client printers only. You can also set the options for session printers through the Citrix policy, which can include either static or dynamic printers. Furthermore, you can also set proximity printers. Managing print drivers: This option can be configured so that printer drivers are auto-installed during the session creation. It can be installed by using either the generic Citrix universal printer driver, or the manual option. You can also have all the known drivers preinstalled on the master image. Citrix even provides the Citrix universal print server, which extends XenDesktop universal printing support to network printing. Print job routing: It can be routed among client device or through the network server. The ICA protocol is used for compressing and sending data. Personal vDisk: Desktops with personal vDisks retain the user changes. Choosing the personal vDisk depends on the user requirements and the FlexCast Model that was opted for. Personal vDisk can be set to thin provisioned for estimated growth, but it can't be shrunk later. Applications: The application separation into another layer improves the scalability of the overall desktop solution. Applications are critical elements, which the users require from a desktop environment: Application delivery method: Applications can be installed on the base image, on the Personal vDisks, streamed into the session, or through the on-demand XenApp hosted mode. It also depends on application compatibility, and it requires technical expertise and tools, such as AppDNA, for effectively resolving them. Application streaming: XenDesktop supports App-V to build isolated application packages, which can be streamed to desktops. 16-bit legacy application delivery: If there are any legacy 16-bit applications to be supported, then you can choose from the 32 bit OS, VM hosted App, or a parallel XenApp5 deployment. Control layer Control layer speaks about all the backend systems that are required for managing and maintaining the overall solution through its life cycle. The control layer includes most of the XenDesktop components that are further classified into categories, such as resource/access controllers, image/desktop controllers, and infrastructure controllers. These respectively correspond to the first three layers of FMA, as shown here: Resource/access controllers: Supports the access layer Image/desktop controllers: Supports the desktop/resource layer Infrastructure controllers: Provides the underlying hardware for the overall FMA components/environment This layer involves the specification of capacity, configuration, and the topology of the environment. Building required/planned redundancy for each of these components enables achieving the enterprise business capabilities, such as HA, scalability, disaster recovery, load balancing, and so on. Components and technologies that operate under this layer include Active Directory, group policies, site database, Citrix licensing, XenDesktop delivery controllers, XenClient hypervisor, the Windows server and the Desktop operating systems, provisioning services, which can be either MCS or PVS and their controllers, and so on. An example business requirement statement may be as follows: Build a highly available desktop environment for a fast growing business users group. We currently have a head count of 30 users, which is expected to double in a year. It involves making the following decisions: Infrastructure controllers: It includes common infrastructure, which is required for XenDesktop to function in the Windows domain network. Active Directory: This is used for the authentication and authorization of users in a Citrix environment. It's also responsible for providing and synchronizing time on the systems, which is critical for Kerberos. For the most part, your AD structure will be in-place, and it may require certain changes for accommodating your XenDesktop requirements, such as: Forest design: It involves choosing the AD forest and domain decisions, such as multi-domain, multi-forest, domain and forest trusts, and so on, which will define the users of the XenDesktop resources. Site design: It involves choosing the number of sites that represent your geographical locations, the number of domain controllers, the subnets that accommodate the IP addresses, site links for replication, and so on. Organizational unit structure: Planning the OU structure for easier management of XenDesktop Workers and VDAs. In the case of multi-forest deployment scenarios (as supported in App Orchestration), having the same OU structure is critical. Naming standards: Planning proper conventions for XenDesktop AD objects, which includes users, security groups, XenDesktop servers, OUs, and so on. User groups: This helps in choosing the individual user names or groups. The user security groups are recommended as they reduce validation to just one object despite the number of users in it. Policy control: This helps in planning GPOs ordering and sizing, inheritance, filtering, enforcement, blocking, and loopback processing for reducing the overall processing time on the VDAs and servers. Database: Citrix uses the Microsoft SQL server database for most of its products, as follows: Edition: Microsoft ships the SQL server database in different editions, which provide varying features and capabilities. Using the standard edition for typical XenDesktop production deployments is recommended. For larger/enterprise deployments, depending on the requirement, a higher edition may be required. Database and Transaction Log Sizing: This involves estimating the storage requirements for the Site Configuration database, Monitoring database, and configuration logging databases. Database Location: By default, the Configuration Logging and the Monitoring databases are located within the Site Configuration database. Separating these into separate databases and relocating the Monitoring database to a different SQL server is recommended. High availability: Choose from VM-level HA, Mirroring, AlwaysOn Failover Cluster, and AlwaysOn Availability Groups. Database Creation: Usually, the database is automatically recreated during the XenDesktop installation. Alternatively, they can be created by using the scripts. Citrix licensing: Citrix licensing for XenDesktop requires the existence of a Citrix license server on the network. You can install and manage the multiple Citrix licenses. License type: Choose from user, device, and concurrent licenses. Version: Citrix's new license servers are backward compatible. Sizing: A license server can be scaled out to support a higher number of license requests per second. High availability: License server comes with a 30 day grace period to usually help in recovering from failures. High Availability for license server can be implemented through Window clustering technology or duplication of the virtual server. Optimization: Optimize the number of the receiving and processing threads depending on your hardware. This is generally required in large and heavily-loaded enterprise environments. Resource controllers: The resource controllers include the XenDesktop, the XenApp controllers, and the XenClient synchronizer, as shown here: XenDesktop and XenApp delivery controller. Number of sites: It is considered to have been based on network, risk tolerance, security requirements. Delivery controller sizing: Delivery controller scalability is based on CPU utilization. The more processor cores are available, the more virtual desktops a controller can support. High availability: Always plan for the N+1 deployment of the controllers for achieving the HA. Then, update the controllers' details on VDA through policy. Host connection configuration: Host connections define the hosts, storage repositories, and guest network to be used by the virtual machines on hypervisors. XML service encryption: The XML service protocol running on delivery controllers uses clear text for exchanging all data except passwords. Consider using an SSL encryption for sending the StoreFront data over a secure HTTP connection. Server OS load management: The default maximum number of sessions per server has been set to 250. Using real time usage monitoring and loading analysis, you can define appropriate load management policies. Session PreLaunch and Session Linger: Designed for helping the users in quickly accessing the applications by starting the sessions before they are requested (session prelaunch) and by keeping the user sessions active after a user closes all the applications in a session (session linger). XenClient synchronizer: It includes considerations for its architecture, processor specification, memory specification, network specification, high availability, the SQL database, remote synchronizer servers, storage repository size and location, and external access, and Active Directory integration. Image controllers: This includes all the image provisioning controllers. MCS is built-into the delivery controller. We'll have PVS considerations, such as the following: Farms: A farm represents the top level of the PVS infrastructure. Depending on your networking and administration boundaries, you can define the number of farms to be deployed in your environment. Sites: Each Farm consists of one or more sites, which contain all the PVS objects. While multiple sites share the same database, the target devices can only failover to the other Provisioning Servers that are within the same site. Your networking and organization structure determines the number of sites in your deployment. High availability: If implemented, PVS will be a critical component of the virtual desktop infrastructure. HA should be considered for its database, PVS servers, vDisks and storage, networking and TFTP, and so on. Bootstrap delivery: There are three methods in which the target device can receive the bootstrap program. This can be done by using the DHCP options, the PXE broadcasts, and the boot device manager. Write cache placement: Write cache uniquely identifies the target device by including the target device's MAC address and disk identifier. Write cache can be placed on the following: Cache on the Device Hard Drive, Cache on the Device Hard Drive Persisted, Cache in the Device RAM, Cache in the Device RAM with overflow on the hard disk, and Cache on the Provisioning Server Disk, and Cache on the Provisioning Server Disk Persisted. vDisk format and replication: PVS supports the use of fixed-size or dynamic vDisks. vDisks hosted on a SAN, local, or Direct Attached Storage must be replicated between the vDisk stores whenever a vDisk is created or changed. It can be replicated either manually or automatically. Virtual or physical servers, processor and memory: The virtual Provisioning Servers are preferred when sufficient processor, memory, disk and networking resources are guaranteed. Scale up or scale out: Determining whether to scale up or scale out the servers requires considering factors like redundancy, failover times, datacenter capacity, hardware costs, hosting costs, and so on. Bandwidth requirements and network configuration: PVS can boot 500 devices simultaneously. A 10Gbps network is recommended for provisioning services. Network configuration should consider the PVS Uplink, the Hypervisor Uplink, and the VM Uplink. Recommended switch settings include either Disable Spanning Tree or Enable Portfast, Storm Control, and Broadcast Helper. Network interfaces: Teaming the multiple network interfaces with link aggregation can provide a greater throughput. Consider the NIC features TCP Offloading and Receive Side Scaling (RSS) while selecting NICs. Subnet affinity: It is a load balancing algorithm, which helps in ensuring that the target devices are connected to the most appropriate Provisioning Server. It can be configured to Best Effort and Fixed. Auditing: By default, the auditing feature is disabled. When enabled, the audit trail information is written in the provisioning services database along with the general configuration data. Antivirus: The antivirus software can cause file-locking issues on the PVS server by contending with the files being accessed by PVS Services. The vDisk store and the write cache should be excluded from any antivirus scans in order to prevent file contention issues. Hardware layer The hardware layer involves choosing the right capacity, make, and hardware features of the backend systems that are required for the overall solution as defined in the control layer. In-line with the control layer, the hardware layer decisions will change if any of the first three layer decisions are changed. Components and technologies that operate under this layer include server hardware, storage technologies, hard disks and the RAID configurations, hypervisors and their management software, backup solutions, monitoring, network devices and connectivity, and so on. It involves making the decisions shown here: Hardware Sizing: The hardware sizing is usually done in two ways. The first, and the preferred, way is to plan ahead and purchase the hardware based on the workload requirements. The second way to size the hosts to use the existing hardware in the best configuration to support the different workload requirements, as follows: Workload separation: Workloads can either be separated into dedicated resource clusters or be mixed in the same physical hosts. Control host sizing: The VM resource allocation for each control component should be determined in the control layer and it should be allocated accordingly. Desktop host sizing: This involves choosing the physical resources required for the virtual desktops as well as the hosted server deployments. It includes estimating the pCPU, pRAM, GPU, and the number of hosts. Hypervisors: This involves choosing from the supported hypervisors that include major players, such as Hyper-V, XenServer, and ESX. Choosing from these requires considering a vast range of parameters, such as host hardware - processor and memory, storage requirements, network requirements, scale up/out, and host scalability. Further considerations to be made also include the following: Networking: Networks, physical NIC, NIC teaming, virtual NICs—hosts, virtual NICs—guests, and IP addressing VM provisioning: Templates High availability: Microsoft Hyper-V: Failover clustering, cluster shared volumes, CSV cache VMware ESXi: VMware vSphere high availability cluster Citrix XenServer: XenServer high availability by using the server pool Monitoring: Use the hypervisor specific vendor provided management and monitoring tools for hypervisor monitoring; use hardware specific vendor provided monitoring tools for hardware level monitoring. Backup and recovery: Backup method and components to be backed up. Storage: Storage architecture, RAID level, numbers of disks, disk type, storage bandwidth, tiered storage, thin provisioning, and data de-duplication Disaster recovery Data center utilization: The XenDesktop deployments can leverage multiple data centers for improving the user performance and the availability of resources. Multiple data centers can be deployed in an active/active or an active/passive configuration. An active/active configuration allows for both data centers to be utilized, although the individual users are tied to a specific location. Data center connectivity: An active/active data center configuration utilizing GSLB (Global Server Load Balancing) ensures that the users will be able to establish a connection even if one datacenter is unavailable. In the active/active configuration, the considerations that should be made are as follows: data center failover time, application servers, and StoreFront optimal routing. Capacity in the secondary data center: Planning of the secondary data center capacity is determined by the cost and by the management to support full capacity in each data center. A percent of the overall users, or a percent of the users per application, may be considered for the secondary data center facility. Then, it also needs the consideration of the type and amount of resources that will be made available in a failover scenario. Tools for designing XenDesktop® In the previous section, we saw a broad list of components, technologies, and configuration options, and so on, which we learned are involved in the process of designing the XenDesktop deployment. Obviously, designing the XenDesktop deployment for large, advanced, and complex business scenarios is a mammoth task, which requires operational knowledge of a broad range of technologies. Understanding the maze of this complexity, Citrix constantly helps the customers with great learning resources through handbooks, reviewer guides, blueprints, online eDocs, and training sessions. To ease the life of technical architects and XenDesktop designing and deployment consultants, Citrix has developed an online designing portal called Project Accelerator, which automates, streamlines, and covers all the broad aspects that are involved in the XenDesktop deployment. Project Accelerator Citrix designed the Project Accelerator web based designing tool, and it is available to the customers after they login. Its design is based on the Citrix consulting best practices for the XenDesktop deployment and implementation. It follows the layered FMA and allows you to create a close to deployment architecture. It covers all the key decisions and facilitates modifying them and evaluating their impact on the overall architecture. Upon completion of the design, it generates an architectural diagram and a deployment sizing plan. One can define more than one project and customize them in parallel to achieve multiple deployment plans. I highly recommended starting your Production XenDesktop deployment with the Project Accelerator architecture and the sizing design. Virtual Desktop Handbook Citrix provides the handbook along with new XenDesktop releases. The handbook covers the latest features of that XenDesktop version and provides detailed information on the design decisions. It provides all the possible options for each of the decisions involved, and these options are evaluated and validated in an in-depth manner by the Citrix Solutions lab. They include the Citrix Consulting leading best practices as well. This helps architects and engineers to consider the recommended technologies, and then evaluate them further for fulfilling the business requirements. The Virtual Desktop Handbook for latest the version of XenDesktop, that is, 7.x, can be found at: http://support.Citrix.com/article/CTX139331. XenDesktop® Reviewer's Guide The Reviewer's Guide is also released along with the new versions of XenDesktop. They are designed for helping businesses in quickly installing and configuring the XenDesktop for evaluation. They provide a step-by-step screencast of the installation and configuration wizards of XenDesktop. This provides practical guidance to the IT administrators for successfully installing and delivering the XenDesktop sessions. The XenDesktop Reviewers Guide for the latest version of XenDesktop, that is, 7.6, can be found at https://www.citrix.com/content/dam/citrix/en_us/documents/products-solutions/xendesktop-reviewers-guide.pdf. Summary We learnt the decision making that is involved in designing the XenDesktop in general, and we also saw the deployment designs of the complex environments involving the cloud capabilities. We also saw different tools for designing XenDesktop. Resources for Article: Further resources on this subject: Understanding Citrix®Provisioning Services 7.0 [article] Installation and Deployment of Citrix Systems®' CPSM [article] Designing, Sizing, Building, and Configuring Citrix VDI-in-a-Box [article]
Read more
  • 0
  • 0
  • 9311

article-image-clustering-and-other-unsupervised-learning-methods
Packt
09 Jul 2015
19 min read
Save for later

Clustering and Other Unsupervised Learning Methods

Packt
09 Jul 2015
19 min read
In this article by Ferran Garcia Pagans, author of the book Predictive Analytics Using Rattle and Qlik Sense, we will learn about the following: Define machine learning Introduce unsupervised and supervised methods Focus on K-means, a classic machine learning algorithm, in detail We'll create clusters of customers based on their annual money spent. This will give us a new insight. Being able to group our customers based on their annual money spent will allow us to see the profitability of each customer group and deliver more profitable marketing campaigns or create tailored discounts. Finally, we'll see hierarchical clustering, different clustering methods, and association rules. Association rules are generally used for market basket analysis. Machine learning – unsupervised and supervised learning Machine Learning (ML) is a set of techniques and algorithms that gives computers the ability to learn. These techniques are generic and can be used in various fields. Data mining uses ML techniques to create insights and predictions from data. In data mining, we usually divide ML methods into two main groups – supervisedlearning and unsupervisedlearning. A computer can learn with the help of a teacher (supervised learning) or can discover new knowledge without the assistance of a teacher (unsupervised learning). In supervised learning, the learner is trained with a set of examples (dataset) that contains the right answer; we call it the training dataset. We call the dataset that contains the answers a labeled dataset, because each observation is labeled with its answer. In supervised learning, you are supervising the computer, giving it the right answers. For example, a bank can try to predict the borrower's chance of defaulting on credit loans based on the experience of past credit loans. The training dataset would contain data from past credit loans, including if the borrower was a defaulter or not. In unsupervised learning, our dataset doesn't have the right answers and the learner tries to discover hidden patterns in the data. In this way, we call it unsupervised learning because we're not supervising the computer by giving it the right answers. A classic example is trying to create a classification of customers. The model tries to discover similarities between customers. In some machine learning problems, we don't have a dataset that contains past observations. These datasets are not labeled with the correct answers and we call them unlabeled datasets. In traditional data mining, the terms descriptive analytics and predictive analytics are used for unsupervised learning and supervised learning. In unsupervised learning, there is no target variable. The objective of unsupervised learning or descriptive analytics is to discover the hidden structure of data. There are two main unsupervised learning techniques offered by Rattle: Cluster analysis Association analysis Cluster analysis Sometimes, we have a group of observations and we need to split it into a number of subsets of similar observations. Cluster analysis is a group of techniques that will help you to discover these similarities between observations. Market segmentation is an example of cluster analysis. You can use cluster analysis when you have a lot of customers and you want to divide them into different market segments, but you don't know how to create these segments. Sometimes, especially with a large amount of customers, we need some help to understand our data. Clustering can help us to create different customer groups based on their buying behavior. In Rattle's Cluster tab, there are four cluster algorithms: KMeans EwKm Hierarchical BiCluster The two most popular families of cluster algorithms are hierarchical clustering and centroid-based clustering: Centroid-based clustering the using K-means algorithm I'm going to use K-means as an example of this family because it is the most popular. With this algorithm, a cluster is represented by a point or center called the centroid. In the initialization step of K-means, we need to create k number of centroids; usually, the centroids are initialized randomly. In the following diagram, the observations or objects are represented with a point and three centroids are represented with three colored stars: After this initialization step, the algorithm enters into an iteration with two operations. The computer associates each object with the nearest centroid, creating k clusters. Now, the computer has to recalculate the centroids' position. The new position is the mean of each attribute of every cluster member. This example is very simple, but in real life, when the algorithm associates the observations with the new centroids, some observations move from one cluster to the other. The algorithm iterates by recalculating centroids and assigning observations to each cluster until some finalization condition is reached, as shown in this diagram: The inputs of a K-means algorithm are the observations and the number of clusters, k. The final result of a K-means algorithm are k centroids that represent each cluster and the observations associated with each cluster. The drawbacks of this technique are: You need to know or decide the number of clusters, k. The result of the algorithm has a big dependence on k. The result of the algorithm depends on where the centroids are initialized. There is no guarantee that the result is the optimum result. The algorithm can iterate around a local optimum. In order to avoid a local optimum, you can run the algorithm many times, starting with different centroids' positions. To compare the different runs, you can use the cluster's distortion – the sum of the squared distances between each observation and its centroids. Customer segmentation with K-means clustering We're going to use the wholesale customer dataset we downloaded from the Center for Machine Learning and Intelligent Systems at the University of California, Irvine. You can download the dataset from here – https://archive.ics.uci.edu/ml/datasets/Wholesale+customers#. The dataset contains 440 customers (observations) of a wholesale distributor. It includes the annual spend in monetary units on six product categories – Fresh, Milk, Grocery, Frozen, Detergents_Paper, and Delicatessen. We've created a new field called Food that includes all categories except Detergents_Paper, as shown in the following screenshot: Load the new dataset into Rattle and go to the Cluster tab. Remember that, in unsupervised learning, there is no target variable. I want to create a segmentation based only on buying behavior; for this reason, I set Region and Channel to Ignore, as shown here: In the following screenshot, you can see the options Rattle offers for K-means. The most important one is Number of clusters; as we've seen, the analyst has to decide the number of clusters before running K-means: We have also seen that the initial position of the centroids can have some influence on the result of the algorithm. The position of the centroids is random, but we need to be able to reproduce the same experiment multiple times. When we're creating a model with K-means, we'll iteratively re-run the algorithm, tuning some options in order to improve the performance of the model. In this case, we need to be able to reproduce exactly the same experiment. Under the hood, R has a pseudo-random number generator based on a starting point called Seed. If you want to reproduce the exact same experiment, you need to re-run the algorithm using the same Seed. Sometimes, the performance of K-means depends on the initial position of the centroids. For this reason, sometimes you need to able to re-run the model using a different initial position for the centroids. To run the model with different initial positions, you need to run with a different Seed. After executing the model, Rattle will show some interesting information. The size of each cluster, the means of the variables in the dataset, the centroid's position, and the Within cluster sum of squares value. This measure, also called distortion, is the sum of the squared differences between each point and its centroid. It's a measure of the quality of the model. Another interesting option is Runs; by using this option, Rattle will run the model the specified number of times and will choose the model with the best performance based on the Within cluster sum of squares value. Deciding on the number of clusters can be difficult. To choose the number of clusters, we need a way to evaluate the performance of the algorithm. The sum of the squared distance between the observations and the associated centroid could be a performance measure. Each time we add a centroid to KMeans, the sum of the squared difference between the observations and the centroids decreases. The difference in this measure using a different number of centroids is the gain associated to the added centroids. Rattle provides an option to automate this test, called Iterative Clusters. If you set the Number of clusters value to 10 and check the Iterate Clusters option, Rattle will run KMeans iteratively, starting with 3 clusters and finishing with 10 clusters. To compare each iteration, Rattle provides an iteration plot. In the iteration plot, the blue line shows the sum of the squared differences between each observation and its centroid. The red line shows the difference between the current sum of squared distances and the sum of the squared distance of the previous iteration. For example, for four clusters, the red line has a very low value; this is because the difference between the sum of the squared differences with three clusters and with four clusters is very small. In the following screenshot, the peak in the red line suggests that six clusters could be a good choice. This is because there is an important drop in the Sum of WithinSS value at this point: In this way, to finish my model, I only need to set the Number of clusters to 3, uncheck the Re-Scale checkbox, and click on the Execute button: Finally, Rattle returns the six centroids of my clusters: Now we have the six centroids and we want Rattle to associate each observation with a centroid. Go to the Evaluate tab, select the KMeans option, select the Training dataset, mark All in the report type, and click on the Execute button as shown in the following screenshot. This process will generate a CSV file with the original dataset and a new column called kmeans. The content of this attribute is a label (a number) representing the cluster associated with the observation (customer), as shown in the following screenshot: After clicking on the Execute button, you will need to choose a folder to save the resulting file to and will have to type in a filename. The generated data inside the CSV file will look similar to the following screenshot: In the previous screenshot, you can see ten lines of the resulting file; note that the last column is kmeans. Preparing the data in Qlik Sense Our objective is to create the data model, but using the new CSV file with the kmeans column. We're going to update our application by replacing the customer data file with this new data file. Save the new file in the same folder as the original file, open the Qlik Sense application, and go to Data load editor. There are two differences between the original file and this one. In the original file, we added a line to create a customer identifier called Customer_ID, and in this second file we have this field in the dataset. The second difference is that in this new file we have the kmeans column. From Data load editor, go to the Wholesale customer data sheet, modify line 2, and add line 3. In line 2, we just load the content of Customer_ID, and in line 3, we load the content of the kmeans field and rename it to Cluster, as shown in the following screenshot. Finally, update the name of the file to be the new one and click on the Load data button: When the data load process finishes, open the data model viewer to check your data model, as shown here: Note that you have the same data model with a new field called Cluster. Creating a customer segmentation sheet in Qlik Sense Now we can add a sheet to the application. We'll add three charts to see our clusters and how our customers are distributed in our clusters. The first chart will describe the buying behavior of each cluster, as shown here: The second chart will show all customers distributed in a scatter plot, and in the last chart we'll see the number of customers that belong to each cluster, as shown here: I'll start with the chart to the bottom-right; it's a bar chart with Cluster as the dimension and Count([Customer_ID]) as the measure. This simple bar chart has something special – colors. Each customer's cluster has a special color code that we use in all charts. In this way, cluster 5 is blue in the three charts. To obtain this effect, we use this expression to define the color as color(fieldindex('Cluster', Cluster)), which is shown in the following screenshot: You can find this color trick and more in this interesting blog by Rob Wunderlich – http://qlikviewcookbook.com/. My second chart is the one at the top. I copied the previous chart and pasted it onto a free place. I kept the dimension but I changed the measure by using six new measures: Avg([Detergents_Paper]) Avg([Delicassen]) Avg([Fresh]) Avg([Frozen]) Avg([Grocery]) Avg([Milk]) I placed my last chart at the bottom-left. I used a scatter plot to represent all of my 440 customers. I wanted to show the money spent by each customer on food and detergents, and its cluster. I used the y axis to show the money spent on detergents and the x axis for the money spent on food. Finally, I used colors to highlight the cluster. The dimension is Customer_Id and the measures are Delicassen+Fresh+Frozen+Grocery+Milk (or Food) and [Detergents_Paper]. As the final step, I reused the color expression from the earlier charts. Now our first Qlik Sense application has two sheets – the original one is 100 percent Qlik Sense and helps us to understand our customers, channels, and regions. This new sheet uses clustering to give us a different point of view; this second sheet groups the customers by their similar buying behavior. All this information is useful to deliver better campaigns to our customers. Cluster 5 is our least profitable cluster, but is the biggest one with 227 customers. The main difference between cluster 5 and cluster 2 is the amount of money spent on fresh products. Can we deliver any offer to customers in cluster 5 to try to sell more fresh products? Select retail customers and ask yourself, who are our best retail customers? To which cluster do they belong? Are they buying all our product categories? Hierarchical clustering Hierarchical clustering tries to group objects based on their similarity. To explain how this algorithm works, we're going to start with seven points (or observations) lying in a straight line: We start by calculating the distance between each point. I'll come back later to the term distance; in this example, distance is the difference between two positions in the line. The points D and E are the ones with the smallest distance in between, so we group them in a cluster, as shown in this diagram: Now, we substitute point D and point E for their mean (red point) and we look for the two points with the next smallest distance in between. In this second iteration, the closest points are B and C, as shown in this diagram: We continue iterating until we've grouped all observations in the dataset, as shown here: Note that, in this algorithm, we can decide on the number of clusters after running the algorithm. If we divide the dataset into two clusters, the first cluster is point G and the second cluster is A, B, C, D, E, and F. This gives the analyst the opportunity to see the big picture before deciding on the number of clusters. The lowest level of clustering is a trivial one; in this example, seven clusters with one point in each one. The chart I've created while explaining the algorithm is a basic form of a dendrogram. The dendrogram is a tree diagram used in Rattle and in other tools to illustrate the layout of the clusters produced by hierarchical clustering. In the following screenshot, we can see the dendrogram created by Rattle for the wholesale customer dataset. In Rattle's dendrogram, the y axis represent all observations or customers in the dataset, and the x axis represents the distance between the clusters: Association analysis Association rules or association analysis is also an important topic in data mining. This is an unsupervised method, so we start with an unlabeled dataset. An unlabeled dataset is a dataset without a variable that gives us the right answer. Association analysis attempts to find relationships between different entities. The classic example of association rules is market basket analysis. This means using a database of transactions in a supermarket to find items that are bought together. For example, a person who buys potatoes and burgers usually buys beer. This insight could be used to optimize the supermarket layout. Online stores are also a good example of association analysis. They usually suggest to you a new item based on the items you have bought. They analyze online transactions to find patterns in the buyer's behavior. These algorithms assume all variables are categorical; they perform poorly with numeric variables. Association methods need a lot of time to be completed; they use a lot of CPU and memory. Remember that Rattle runs on R and the R engine loads all data into RAM memory. Suppose we have a dataset such as the following: Our objective is to discover items that are purchased together. We'll create rules and we'll represent these rules like this: Chicken, Potatoes → Clothes This rule means that when a customer buys Chicken and Potatoes, he tends to buy Clothes. As we'll see, the output of the model will be a set of rules. We need a way to evaluate the quality or interest of a rule. There are different measures, but we'll use only a few of them. Rattle provides three measures: Support Confidence Lift Support indicates how often the rule appears in the whole dataset. In our dataset, the rule Chicken, Potatoes → Clothes has a support of 48.57 percent (3 occurrences / 7 transactions). Confidence measures how strong rules or associations are between items. In this dataset, the rule Chicken, Potatoes → Clothes has a confidence of 1. The items Chicken and Potatoes appear three times in the dataset and the items Chicken, Potatoes, and Clothes appear three times in the dataset; and 3/3 = 1. A confidence close to 1 indicates a strong association. In the following screenshot, I've highlighted the options on the Associate tab we have to choose from before executing an association method in Rattle: The first option is the Baskets checkbox. Depending on the kind of input data, we'll decide whether or not to check this option. If the option is checked, such as in the preceding screenshot, Rattle needs an identification variable and a target variable. After this example, we'll try another example without this option. The second option is the minimum Support value; by default, it is set to 0.1. Rattle will not return rules with a lower Support value than the one you have set in this text box. If you choose a higher value, Rattle will only return rules that appear many times in your dataset. If you choose a lower value, Rattle will return rules that appear in your dataset only a few times. Usually, if you set a high value for Support, the system will return only the obvious relationships. I suggest you start with a high Support value and execute the methods many times with a lower value in each execution. In this way, in each execution, new rules will appear that you can analyze. The third parameter you have to set is Confidence. This parameter tells you how strong the rule is. Finally, the length is the number of items that contains a rule. A rule like Beer è Chips has length of two. The default option for Min Length is 2. If you set this variable to 2, Rattle will return all rules with two or more items in it. After executing the model, you can see the rules created by Rattle by clicking on the Show Rules button, as illustrated here: Rattle provides a very simple dataset to test the association rules in a file called dvdtrans.csv. Test the dataset to learn about association rules. Further learning In this article, we introduced supervised and unsupervised learning, the two main subgroups of machine learning algorithms; if you want to learn more about machine learning, I suggest you complete a MOOC course called Machine Learning at Coursera: https://www.coursera.org/learn/machine-learning The acronym MOOC stands for Massive Open Online Course; these are courses open to participation via the Internet. These courses are generally free. Coursera is one of the leading platforms for MOOC courses. Machine Learning is a great course designed and taught by Andrew Ng, Associate Professor at Stanford University; Chief Scientist at Baidu; and Chairman and Co-founder at Coursera. This course is really interesting. A very interesting book is Machine Learning with R by Brett Lantz, Packt Publishing. Summary In this article, we were introduced to machine learning, and supervised and unsupervised methods. We focused on unsupervised methods and covered centroid-based clustering, hierarchical clustering, and association rules. We used a simple dataset, but we saw how a clustering algorithm can complement a 100 percent Qlik Sense approach by adding more information. Resources for Article: Further resources on this subject: Qlik Sense's Vision [article] Securing QlikView Documents [article] Conozca QlikView [article]
Read more
  • 0
  • 0
  • 32729

article-image-architecting-and-coding-high-performance-net-applications
Packt
09 Jul 2015
15 min read
Save for later

Architecting and coding high performance .NET applications

Packt
09 Jul 2015
15 min read
In this article by Antonio Esposito, author of Learning .NET High Performance Programming, we will learn about low-pass audio filtering implemented using .NET, and also learn about MVVM and XAML. Model-View-ViewModel and XAML The MVVM pattern is another descendant of the MVC pattern. Born from an extensive update to the MVP pattern, it is at the base of all eXtensible Application Markup Language (XAML) language-based frameworks, such as Windows presentation foundation (WPF), Silverlight, Windows Phone applications, and Store Apps (formerly known as Metro-style apps). MVVM is different from MVC, which is used by Microsoft in its main web development framework in that it is used for desktop or device class applications. The first and (still) the most powerful application framework using MVVM in Microsoft is WPF, a desktop class framework that can use the full .NET 4.5.3 environment. Future versions within Visual Studio 2015 will support built-in .NET 4.6. On the other hand, all other frameworks by Microsoft that use the XAML language supporting MVVM patterns are based on a smaller edition of .NET. This happens with Silverlight, Windows Store Apps, Universal Apps, or Windows Phone Apps. This is why Microsoft made the Portable Library project within Visual Studio, which allows us to create shared code bases compatible with all frameworks. While a Controller in MVC pattern is sort of a router for requests to catch any request and parsing input/output Models, the MVVM lies behind any View with a full two-way data binding that is always linked to a View's controls and together at Model's properties. Actually, multiple ViewModels may run the same View and many Views can use the same single/multiple instance of a given ViewModel. A simple MVC/MVVM design comparative We could assert that the experience offered by MVVM is like a film, while the experience offered by MVC is like photography, because while a Controller always makes one-shot elaborations regarding the application user requests in MVC, in MVVM, the ViewModel is definitely the view! Not only does a ViewModel lie behind a View, but we could also say that if a VM is a body, then a View is its dress. While the concrete View is the graphical representation, the ViewModel is the virtual view, the un-concrete view, but still the View. In MVC, the View contains the user state (the value of all items showed in the UI) until a GET/POST invocation is sent to the web server. Once sent, in the MVC framework, the View simply binds one-way reading data from a Model. In MVVM, behaviors, interaction logic, and user state actually live within the ViewModel. Moreover, it is again in the ViewModel that any access to the underlying Model, domain, and any persistence provider actually flows. Between a ViewModel and View, a data connection called data binding is established. This is a declarative association between a source and target property, such as Person.Name with TextBox.Text. Although it is possible to configure data binding by imperative coding (while declarative means decorating or setting the property association in XAML), in frameworks such as WPF and other XAML-based frameworks, this is usually avoided because of the more decoupled result made by the declarative choice. The most powerful technology feature provided by any XAML-based language is actually the data binding, other than the simpler one that was available in Windows Forms. XAML allows one-way binding (also reverted to the source) and two-way binding. Such data binding supports any source or target as a property from a Model or ViewModel or any other control's dependency property. This binding subsystem is so powerful in XAML-based languages that events are handled in specific objects named Command, and this can be data-bound to specific controls, such as buttons. In the .NET framework, an event is an implementation of the Observer pattern that lies within a delegate object, allowing a 1-N association between the only source of the event (the owner of the event) and more observers that can handle the event with some specific code. The only object that can raise the event is the owner itself. In XAML-based languages, a Command is an object that targets a specific event (in the meaning of something that can happen) that can be bound to different controls/classes, and all of those can register handlers or raise the signaling of all handlers. An MVVM performance map analysis Performance concerns Regarding performance, MVVM behaves very well in several scenarios in terms of data retrieval (latency-driven) and data entry (throughput- and scalability-driven). The ability to have an impressive abstraction of the view in the VM without having to rely on the pipelines of MVC (the actions) makes the programming very pleasurable and give the developer the choice to use different designs and optimization techniques. Data binding itself is done by implementing specific .NET interfaces that can be easily centralized. Talking about latency, it is slightly different from previous examples based on web request-response time, unavailable in MVVM. Theoretically speaking, in the design pattern of MVVM, there is no latency at all. In a concrete implementation within XAML-based languages, latency can refer to two different kinds of timings. During data binding, latency is the time between when a VM makes new data available and a View actually renders it. Instead, during a command execution, latency is the time between when a command is invoked and all relative handlers complete their execution. We usually use the first definition until differently specified. Although the nominal latency is near zero (some milliseconds because of the dictionary-based configuration of data binding), specific implementation concerns about latency actually exist. In any Model or ViewModel, an updated data notification is made by triggering the View with the INotifyPropertyChanged interface. The .NET interface causes the View to read the underlying data again. Because all notifications are made by a single .NET event, this can easily become a bottleneck because of the serialized approach used by any delegate or event handlers in the .NET world. On the contrary, when dealing with data that flows from the View to the Model, such an inverse binding is usually configured declaratively within the {Binding …} keyword, which supports specifying binding directions and trigger timing (to choose from the control's lost focus CLR event or anytime the property value changes). The XAML data binding does not add any measurable time during its execution. Although this, as said, such binding may link multiple properties or the control's dependency properties together. Linking this interaction logic could increase latency time heavily, adding some annoying delay at the View level. One fact upon all, is the added latency by any validation logic. It is even worse if such validation is other than formal, such as validating some ID or CODE against a database value. Talking about scalability, MVVM patterns does some work here, while we can make some concrete analysis concerning the XAML implementation. It is easy to say that scaling out is impossible because MVVM is a desktop class layered architecture that cannot scale. Instead, we can say that in a multiuser scenario with multiple client systems connected in a 2-tier or 3-tier system architecture, simple MVVM and XAML-based frameworks will never act as bottlenecks. The ability to use the full .NET stack in WPF gives us the chance to use all synchronization techniques available, in order to use a directly connected DBMS or middleware tier. Instead of scaling up by moving the application to an increased CPU clock system, the XAML-based application would benefit more from an increased CPU core count system. Obviously, to profit from many CPU cores, mastering parallel techniques is mandatory. About the resource usage, MVVM-powered architectures require only a simple POCO class as a Model and ViewModel. The only additional requirement is the implementation of the INotifyPropertyChanged interface that costs next to nothing. Talking about the pattern, unlike MVC, which has a specific elaboration workflow, MVVM does not offer this functionality. Multiple commands with multiple logic can process their respective logic (together with asynchronous invocation) with the local VM data or by going down to the persistence layer to grab missing information. We have all the choices here. Although MVVM does not cost anything in terms of graphical rendering, XAML-based frameworks make massive use of hardware-accelerated user controls. Talking about an extreme choice, Windows Forms with Graphics Device Interface (GDI)-based rendering require a lot less resources and can give a higher frame rate on highly updatable data. Thus, if a very high FPS is needed, the choice of still rendering a WPF area in GDI is available. For other XAML languages, the choice is not so easy to obtain. Obviously, this does not mean that XAML is slow in rendering with its DirectX based engine. Simply consider that WPF animations need a good Graphics Processing Unit (GPU), while a basic GDI animation will execute on any system, although it is obsolete. Talking about availability, MVVM-based architectures usually lead programmers to good programming. As MVC allows it, MVVM designs can be tested because of the great modularity. While a Controller uses a pipelined workflow to process any requests, a ViewModel is more flexible and can be tested with multiple initialization conditions. This makes it more powerful but also less predictable than a Controller, and hence is tricky to use. In terms of design, the Controller acts as a transaction script, while the ViewModel acts in a more realistic, object-oriented approach. Finally, yet importantly, throughput and efficiency are simply unaffected by MVVM-based architectures. However, because of the flexibility the solution gives to the developer, any interaction and business logic design may be used inside a ViewModel and their underlying Models. Therefore, any success or failure regarding those performance aspects are usually related to programmer work. In XAML frameworks, throughput is achieved by an intensive use of asynchronous and parallel programming assisted by a built-in thread synchronization subsystem, based on the Dispatcher class that deals with UI updates. Low-pass filtering for Audio Low-pass filtering has been available since 2008 in the native .NET code. NAudio is a powerful library helping any CLR programmer to create, manipulate, or analyze audio data in any format. Available through NuGet Package Manager, NAudio offers a simple and .NET-like programming framework, with specific classes and stream-reader for audio data files. Let's see how to apply the low-pass digital filter in a real audio uncompressed file in WAVE format. For this test, we will use the Windows start-up default sound file. The chart is still made in a legacy Windows Forms application with an empty Form1 file, as shown in the previous example: private async void Form1_Load(object sender, EventArgs e) {    //stereo wave file channels    var channels = await Task.Factory.StartNew(() =>        {            //the wave stream-like reader            using (var reader = new WaveFileReader("startup.wav"))            {                var leftChannel = new List<float>();              var rightChannel = new List<float>();                  //let's read all frames as normalized floats                while (reader.Position < reader.Length)                {                    var frame = reader.ReadNextSampleFrame();                   leftChannel.Add(frame[0]);                    rightChannel.Add(frame[1]);                }                  return new                {                    Left = leftChannel.ToArray(),                    Right = rightChannel.ToArray(),                };            }        });      //make a low-pass digital filter on floating point data    //at 200hz    var leftLowpassTask = Task.Factory.StartNew(() => LowPass(channels.Left, 200).ToArray());    var rightLowpassTask = Task.Factory.StartNew(() => LowPass(channels.Right, 200).ToArray());      //this let the two tasks work together in task-parallelism    var leftChannelLP = await leftLowpassTask;    var rightChannelLP = await rightLowpassTask;      //create and databind a chart    var chart1 = CreateChart();      chart1.DataSource = Enumerable.Range(0, channels.Left.Length).Select(i => new        {            Index = i,            Left = channels.Left[i],            Right = channels.Right[i],            LeftLP = leftChannelLP[i],            RightLP = rightChannelLP[i],        }).ToArray();      chart1.DataBind();      //add the chart to the form    this.Controls.Add(chart1); }   private static Chart CreateChart() {    //creates a chart    //namespace System.Windows.Forms.DataVisualization.Charting      var chart1 = new Chart();      //shows chart in fullscreen    chart1.Dock = DockStyle.Fill;      //create a default area    chart1.ChartAreas.Add(new ChartArea());      //left and right channel series    chart1.Series.Add(new Series    {        XValueMember = "Index",        XValueType = ChartValueType.Auto,        YValueMembers = "Left",        ChartType = SeriesChartType.Line,    });    chart1.Series.Add(new Series    {        XValueMember = "Index",        XValueType = ChartValueType.Auto,        YValueMembers = "Right",        ChartType = SeriesChartType.Line,    });      //left and right channel low-pass (bass) series    chart1.Series.Add(new Series    {        XValueMember = "Index",        XValueType = ChartValueType.Auto,        YValueMembers = "LeftLP",        ChartType = SeriesChartType.Line,        BorderWidth = 2,    });    chart1.Series.Add(new Series    {        XValueMember = "Index",        XValueType = ChartValueType.Auto,        YValueMembers = "RightLP",        ChartType = SeriesChartType.Line,        BorderWidth = 2,    });      return chart1; } Let's see the graphical result: The Windows start-up sound waveform. In bolt, the bass waveform with a low-pass filter at 200hz. The usage of parallelism in elaborations such as this is mandatory. Audio elaboration is a canonical example of engineering data computation because it works on a huge dataset of floating points values. A simple file, such as the preceding one that contains less than 2 seconds of audio sampled at (only) 22,050 Hz, produces an array greater than 40,000 floating points per channel (stereo = 2 channels). Just to have an idea of how hard processing audio files is, note that an uncompressed CD quality song of 4 minutes sampled at 44,100 samples per second * 60 (seconds) * 4 (minutes) will create an array greater than 10 million floating-point items per channel. Because of the FFT intrinsic logic, any low-pass filtering run must run in a single thread. This means that the only optimization we can apply when running FFT based low-pass filtering is parallelizing in a per channel basis. For most cases, this choice can only bring a 2X throughput improvement, regardless of the processor count of the underlying system. Summary In this article we got introduced to the applications of .NET high-performance performance. We learned how MVVM and XAML play their roles in .NET to create applications for various platforms, also we learned about its performance characteristics. Next we learned how high-performance .NET had applications in engineering aspects through a practical example of low-pass audio filtering. It showed you how versatile it is to apply high-performance programming to specific engineering applications. Resources for Article: Further resources on this subject: Windows Phone 8 Applications [article] Core .NET Recipes [article] Parallel Programming Patterns [article]
Read more
  • 0
  • 0
  • 3138

article-image-essentials-working-python-collections
Packt
09 Jul 2015
14 min read
Save for later

The Essentials of Working with Python Collections

Packt
09 Jul 2015
14 min read
In this article by Steven F. Lott, the author of the book Python Essentials, we'll look at the break and continue statements; these modify a for or while loop to allow skipping items or exiting before the loop has processed all items. This is a fundamental change in the semantics of a collection-processing statement. (For more resources related to this topic, see here.) Processing collections with the for statement The for statement is an extremely versatile way to process every item in a collection. We do this by defining a target variable, a source of items, and a suite of statements. The for statement will iterate through the source of items, assigning each item to the target variable, and also execute the suite of statements. All of the collections in Python provide the necessary methods, which means that we can use anything as the source of items in a for statement. Here's some sample data that we'll work with. This is part of Mike Keith's poem, Near a Raven. We'll remove the punctuation to make the text easier to work with: >>> text = '''Poe, E. ...     Near a Raven ... ... Midnights so dreary, tired and weary.''' >>> text = text.replace(",","").replace(".","").lower() This will put the original text, with uppercase and lowercase and punctuation into the text variable. When we use text.split(), we get a sequence of individual words. The for loop can iterate through this sequence of words so that we can process each one. The syntax looks like this: >>> cadaeic= {} >>> for word in text.split(): ...     cadaeic[word]= len(word) We've created an empty dictionary, and assigned it to the cadaeic variable. The expression in the for loop, text.split(), will create a sequence of substrings. Each of these substrings will be assigned to the word variable. The for loop body—a single assignment statement—will be executed once for each value assigned to word. The resulting dictionary might look like this (irrespective of ordering): {'raven': 5, 'midnights': 9, 'dreary': 6, 'e': 1, 'weary': 5, 'near': 4, 'a': 1, 'poe': 3, 'and': 3, 'so': 2, 'tired': 5} There's no guaranteed order for mappings or sets. Your results may differ slightly. In addition to iterating over a sequence, we can also iterate over the keys in a dictionary. >>> for word in sorted(cadaeic): ...   print(word, cadaeic[word]) When we use sorted() on a tuple or a list, an interim list is created with sorted items. When we apply sorted() to a mapping, the sorting applies to the keys of the mapping, creating a sequence of sorted keys. This loop will print a list in alphabetical order of the various pilish words used in this poem. Pilish is a subset of English where the word lengths are important: they're used as mnemonic aids. A for statement corresponds to the "for all" logical quantifier, . At the end of a simple for loop we can assert that all items in the source collection have been processed. In order to build the "there exists" quantifier, , we can either use the while statement, or the break statement inside the body of a for statement. Using literal lists in a for statement We can apply the for statement to a sequence of literal values. One of the most common ways to present literals is as a tuple. It might look like this: for scheme in 'http', 'https', 'ftp':    do_something(scheme) This will assign three different values to the scheme variable. For each of those values, it will evaluate the do_something() function. From this, we can see that, strictly-speaking, the () are not required to delimit a tuple object. If the sequence of values grows, however, and we need to span more than one physical line, we'll want to add (), making the tuple literal more explicit. Using the range() and enumerate() functions The range() object will provide a sequence of numbers, often used in a for loop. The range() object is iterable, it's not itself a sequence object. It's a generator, which will produce items when required. If we use range() outside a for statement, we need to use a function like list(range(x)) or tuple(range(a,b)) to consume all of the generated values and create a new sequence object. The range() object has three commonly-used forms: range(n) produces ascending numbers including 0 but not including n itself. This is a half-open interval. We could say that range(n) produces numbers, x, such that . The expression list(range(5)) returns [0, 1, 2, 3, 4]. This produces n values including 0 and n - 1. range(a,b) produces ascending numbers starting from a but not including b. The expression tuple(range(-1,3)) will return (-1, 0, 1, 2). This produces b - a values including a and b - 1. range(x,y,z) produces ascending numbers in the sequence . This produces (y-x)//z values. We can use the range() object like this: for n in range(1, 21):    status= str(n)    if n % 5 == 0: status += " fizz"    if n % 7 == 0: status += " buzz"    print(status) In this example, we've used a range() object to produce values, n, such that . We use the range() object to generate the index values for all items in a list: for n in range(len(some_list)):    print(n, some_list[n]) We've used the range() function to generate values between 0 and the length of the sequence object named some_list. The for statement allows multiple target variables. The rules for multiple target variables are the same as for a multiple variable assignment statement: a sequence object will be decomposed and items assigned to each variable. Because of that, we can leverage the enumerate() function to iterate through a sequence and assign the index values at the same time. It looks like this: for n, v in enumerate(some_list):      print(n, v) The enumerate() function is a generator function which iterates through the items in source sequence and yields a sequence of two-tuple pairs with the index and the item. Since we've provided two variables, the two-tuple is decomposed and assigned to each variable. There are numerous use cases for this multiple-assignment for loop. We often have list-of-tuples data structures that can be handled very neatly with this multiple-assignment feature. Iterating with the while statement The while statement is a more general iteration than the for statement. We'll use a while loop in two situations. We'll use this in cases where we don't have a finite collection to impose an upper bound on the loop's iteration; we may suggest an upper bound in the while clause itself. We'll also use this when writing a "search" or "there exists" kind of loop; we aren't processing all items in a collection. A desktop application that accepts input from a user, for example, will often have a while loop. The application runs until the user decides to quit; there's no upper bound on the number of user interactions. For this, we generally use a while True: loop. Infinite iteration is recommended. If we want to write a character-mode user interface, we could do it like this: quit_received= False while not quit_received:    command= input("prompt> ")    quit_received= process(command) This will iterate until the quit_received variable is set to True. This will process indefinitely; there's no upper boundary on the number of iterations. This process() function might use some kind of command processing. This should include a statement like this: if command.lower().startswith("quit"): return True When the user enters "quit", the process() function will return True. This will be assigned to the quit_received variable. The while expression, not quit_received, will become False, and the loop ends. A "there exists" loop will iterate through a collection, stopping at the first item that meets certain criteria. This can look complex because we're forced to make two details of loop processing explicit. Here's an example of searching for the first value that meets a condition. This example assumes that we have a function, condition(), which will eventually be True for some number. Here's how we can use a while statement to locate the minimum for which this function is True: >>> n = 1 >>> while n != 101 and not condition(n): ...     n += 1 >>> assert n == 101 or condition(n) The while statement will terminate when n == 101 or the condition(n) is True. If this expression is False, we can advance the n variable to the next value in the sequence of values. Since we're iterating through the values in order from the smallest to the largest, we know that n will be the smallest value for which the condition() function is true. At the end of the while statement we have included a formal assertion that either n is 101 or the condition() function is True for the given value of n. Writing an assertion like this can help in design as well as debugging because it will often summarize the loop invariant condition. We can also write this kind of loop using the break statement in a for loop, something we'll look at in the next section. The continue and break statements The continue statement is helpful for skipping items without writing deeply-nested if statements. The effect of executing a continue statement is to skip the rest of the loop's suite. In a for loop, this means that the next item will be taken from the source iterable. In a while loop, this must be used carefully to avoid an otherwise infinite iteration. We might see file processing that looks like this: for line in some_file:    clean = line.strip()    if len(clean) == 0:        continue    data, _, _ = clean.partition("#")    data = data.rstrip()    if len(data) == 0:        continue    process(data) In this loop, we're relying on the way files act like sequences of individual lines. For each line in the file, we've stripped whitespace from the input line, and assigned the resulting string to the clean variable. If the length of this string is zero, the line was entirely whitespace, and we'll continue the loop with the next line. The continue statement skips the remaining statements in the body of the loop. We'll partition the line into three pieces: a portion in front of any "#", the "#" (if present), and the portion after any "#". We've assigned the "#" character and any text after the "#" character to the same easily-ignored variable, _, because we don't have any use for these two results of the partition() method. We can then strip any trailing whitespace from the string assigned to the data variable. If the resulting string has a length of zero, then the line is entirely filled with "#" and any trailing comment text. Since there's no useful data, we can continue the loop, ignoring this line of input. If the line passes the two if conditions, we can process the resulting data. By using the continue statement, we have avoided complex-looking, deeply-nested if statements. It's important to note that a continue statement must always be part of the suite inside an if statement, inside a for or while loop. The condition on that if statement becomes a filter condition that applies to the collection of data being processed. continue always applies to the innermost loop. Breaking early from a loop The break statement is a profound change in the semantics of the loop. An ordinary for statement can be summarized by "for all." We can comfortably say that "for all items in a collection, the suite of statements was processed." When we use a break statement, a loop is no longer summarized by "for all." We need to change our perspective to "there exists". A break statement asserts that at least one item in the collection matches the condition that leads to the execution of the break statement. Here's a simple example of a break statement: for n in range(1, 100):    factors = []    for x in range(1,n):        if n % x == 0: factors.append(x)    if sum(factors) == n:        break We've written a loop that is bound by . This loop includes a break statement, so it will not process all values of n. Instead, it will determine the smallest value of n, for which n is equal to the sum of its factors. Since the loop doesn't examine all values, it shows that at least one such number exists within the given range. We've used a nested loop to determine the factors of the number n. This nested loop creates a sequence, factors, for all values of x in the range , such that x, is a factor of the number n. This inner loop doesn't have a break statement, so we are sure it examines all values in the given range. The least value for which this is true is the number six. It's important to note that a break statement must always be part of the suite inside an if statement inside a for or while loop. If the break isn't in an if suite, the loop will always terminate while processing the first item. The condition on that if statement becomes the "where exists" condition that summarizes the loop as a whole. Clearly, multiple if statements with multiple break statements mean that the overall loop can have a potentially confusing and difficult-to-summarize post-condition. Using the else clause on a loop Python's else clause can be used on a for or while statement as well as on an if statement. The else clause executes after the loop body if there was no break statement executed. To see this, here's a contrived example: >>> for item in 1,2,3: ...     print(item) ...     if item == 2: ...         print("Found",item) ...       break ... else: ...     print("Found Nothing") The for statement here will iterate over a short list of literal values. When a specific target value has been found, a message is printed. Then, the break statement will end the loop, avoiding the else clause. When we run this, we'll see three lines of output, like this: 1 2 Found 2 The value of three isn't shown, nor is the "Found Nothing" message in the else clause. If we change the target value in the if statement from two to a value that won't be seen (for example, zero or four), then the output will change. If the break statement is not executed, then the else clause will be executed. The idea here is to allow us to write contrasting break and non-break suites of statements. An if statement suite that includes a break statement can do some processing in the suite before the break statement ends the loop. An else clause allows some processing at the end of the loop when none of the break-related suites statements were executed. Summary In this article, we've looked at the for statement, which is the primary way we'll process the individual items in a collection. A simple for statement assures us that our processing has been done for all items in the collection. We've also looked at the general purpose while loop. Resources for Article: Further resources on this subject: Introspecting Maya, Python, and PyMEL [article] Analyzing a Complex Dataset [article] Geo-Spatial Data in Python: Working with Geometry [article]
Read more
  • 0
  • 0
  • 2320

article-image-essentials-vmware-vsphere
Packt
09 Jul 2015
7 min read
Save for later

Essentials of VMware vSphere

Packt
09 Jul 2015
7 min read
In this article by Puthiyavan Udayakumar, author of the book VMware vSphere Design Essentials, we will cover the following topics: Essentials of designing VMware vSphere The PPP framework The challenges and encounters faced on virtual infrastructure (For more resources related to this topic, see here.) Let's get started with understanding the essentials of designing VMware vSphere. Designing is nothing but assembling and integrating VMware vSphere infrastructure components together to form the baseline for a virtualized datacenter. It has the following benefits: Saves power consumption Decreases the datacenter footprint and helps towards server consolidation Fastest server provisioning On-demand QA lab environments Decreases hardware vendor dependency Aids to move to the cloud Greater savings and affordability Superior security and High Availability Designing VMware vSphere Architecture design principles are usually developed by the VMware architect in concurrence with the enterprise CIO, Infrastructure Architecture Board, and other key business stakeholders. From my experience, I would always urge you to have frequent meetings to observe functional requirements as much as possible. This will create a win-win situation for you and the requestor and show you how to get things done. Please follow your own approach, if it works. Architecture design principles should be developed by the overall IT principles specific to the customer's demands, if they exist. If not, they should be selected to ensure positioning of IT strategies in line with business approaches. In nutshell, architect should aim to form an effective architecture principles that fulfills the infrastructure demands, following are high level principles that should be followed across any design: Design mission and plans Design strategic initiatives External influencing factors When you release a design to the customer, keep in mind that the design must have the following principles: Understandable and robust Complete and consistent Stable and capable of accepting continuous requirement-based changes Rational and controlled technical diversity Without the preceding principles, I wouldn't recommend you to release your design to anyone even for peer review. For every design, irrespective of the product that you are about to design, try the following approach; it should work well but if required I would recommend you make changes to the approach. The following approach is called PPP, which will focus on people's requirements, the product's capacity, and the process that helps to bridge the gap between the product capacity and people requirements: The preceding diagram illustrates three entities that should be considered while designing VMware vSphere infrastructure. Please keep in mind that your design is just a product designed by a process that is based on people's needs. In the end, using this unified framework will aid you in getting rid of any known risks and its implications. Functional requirements should be meaningful; while designing, please make sure there is a meaning to your design. Selecting VMware vSphere from other competitors should not be a random pick, you should always list the benefits of VMware vSphere. Some of them are as follows: Server consolidation and easy hardware changes Dynamic provisioning of resources to your compute node Templates, snapshots, vMotion, DRS, DPM, High Availability, fault tolerance, auto monitoring, and solutions for warnings and alerts Virtual Desktop Infrastructure (VDI), building a disaster recovery site, fast deployments, and decommissions The PPP framework Let's explore the components that integrate to form the PPP framework. Always keep in mind that the design should consist of people, processes, and products that meet the unified functional requirements and performance benchmark. Always expect the unexpected. Without these metrics, your design is incomplete; PPP always retains its own decision metrics. What does it do, who does it, and how is it done? We will see the answers in the following diagrams: The PPP Framework helps you to get started with requirements gathering, design vision, business architecture, infrastructure architecture, opportunities and solutions, migration planning, fixing the tone for implementing and design governance. The following table illustrates the essentials of the three-dimensional approach and the basic questions that are required to be answered before you start designing or documenting about designing, which will in turn help to understand the real requirements for a specific design: Phase Description Key components Product Results of what? In what hardware will the VM reside? What kind of CPU is required? What is the quantity of CPU, RAM, storage per host/VM? What kind of storage is required? What kind of network is required? What are the standard applications that need to be rolled out? What kind of power and cooling are required? How much rack and floor space is demanded? People Results of who? Who is responsible for infrastructure provisioning? Who manages the data center and supplies the power? Who is responsible for implementation of the hardware and software patches? Who is responsible for storage and back up? Who is responsible for security and hardware support? Process Results of how? How should we manage the virtual infrastructure? How should we manage hosted VMs? How should we provision VM on demand? How should a DR site be active during a primary site failure? How should we provision storage and backup? How should we take snapshots of VMs? How should we monitor and perform periodic health checks? Before we start to apply the PPP framework on VMware vSphere, we will discuss the list of challenges and encounters faced on the virtual infrastructure. List of challenges and encounters faced on the virtual infrastructure In this section, we will see a list of challenges and encounters faced with virtual infrastructure due to the simple reason that we fail to capture the functional and non-functional demands of business users, or do not understand the fit-for-purpose concept: Resource Estimate Misfire: If you underestimate the amount of memory required up-front, you could change the number of VMs you attempt to run on the VMware ESXi host hardware. Resource unavailability: Without capacity management and configuration management, you cannot create dozens or hundreds of VMs on a single host. Some of the VMs could consume all resources, leaving other VMs unknown. High utilization: An army of VMs can also throw workflows off-balance due to the complexities they can bring to provisioning and operational tasks. Business continuity: Unlike a PC environment, VMs cannot be backed up to an actual hard drive. This is why 80 percent of IT professionals believe that virtualization backup is a great technological challenge. Security: More than six out of ten IT professionals believe that data protection is a top technological challenge. Backward compatibility: This is especially challenging for certain apps and systems that are dependent on legacy systems. Monitoring performance: Unlike physical servers, you cannot monitor the performance of VMs with common hardware resources such as CPU, memory, and storage. Restriction of licensing: Before you install software on virtual machines, read the license agreements; they might not support this; hence, by hosting on VMs, you might violate the agreement. Sizing the database and mailbox: Proper sizing of databases and mailboxes is really critical to the organization's communication systems and for applications. Poor design of storage and network: A poor storage design or a networking design resulting from a failure to properly involve the required teams within an organization is a sure-fire way to ensure that this design isn't successful. Summary In this article we covered a brief introduction of the essentials of designing VMware vSphere which focused on the PPP framework. We also had look over the challenges and encounters faced on the virtual infrastructure. Resources for Article: Further resources on this subject: Creating and Managing VMFS Datastores [article] Networking Performance Design [article] The Design Documentation [article]
Read more
  • 0
  • 0
  • 8677

article-image-editors-and-ides
Packt
08 Jul 2015
10 min read
Save for later

Editors and IDEs

Packt
08 Jul 2015
10 min read
In this article by Daniel Blair, the author of the book Learning Banana Pi, you are going to learn about some editors and the programming languages that are available on the Pi and Linux. These tools will help you write the code that will interact with the hardware through GPIO and on the Pi as a server. (For more resources related to this topic, see here.) Choosing your editor There are many different integrated development environments (generally abbreviated as IDEs) to choose from on Linux. When working on the Banana Pi, you're limited to the software that will run on an ARM-based CPU. Hence, options such as Sublime Text are not available. Some options that you may be familiar with are available for general purpose code editing. Some tools are available for the command line, while others are GUI tools. So, depending on whether you have a monitor or not, you will want to choose an appropriate tool. The following screenshot shows some JavaScript being edited via nano on the command line: Command-line editors The command line is a powerful tool. If you master it, you will rarely need to leave it. There are several editors available for the command line. There has been an ongoing war between the users of two editors: GNU Emacs and Vim. There are many editors like nano (which is my preference), but the war tends to be between the two aforementioned editors. The Emacs editor This is my least favorite command-line editor (just my preference). Emacs is a GNU-flavored editor for the command line. It is often installed by default, but you can easily install it if it is missing by running a quick command, as follows: sudo apt-get install emacs Now, you can edit a file via the CLI by using the following code: emacs <command-line arguments> <your file> The preceding code will open the file in Emacs for you to edit. You can also use this to create new files. You can save and close the editor with a couple of key combinations: Ctrl + X and Ctrl + S Ctrl + X and Ctrl + C Thus, your document will be saved and closed. The Vim editor Vim is actually an extension of Vi, and it is functionally the same thing. Vim is a fine editor. Many won't personally go out of their way to not use it. However, people do find it a bit difficult to remember all the commands. If you do get good at it, though, you can code very quickly. You can install Vim with the command line: sudo apt-get install vim Also, there is a GUI version available that allows interaction with the mouse; this is functionally the same program as the Vim command line. You don't have to be confined to the terminal window. You can install it with an identical command: sudo apt-get install vim-gnome You can edit files easily with Vim via the command line for both Vim and Vim-Gnome, as follows: vim <your file> gvim <your file> The gnome version will open the file in a window There is a handy tutorial that you can use to learn the commands of Vim. You can run the tutorial with the help of the following command: vimtutor This tutorial will teach you how to run this editor, which is awesome because the commands can be a bit complicated at first. The following screenshot shows Vim editing the file that we used earlier: The nano editor The nano editor is my favorite editor for the command line. This is probably because it was the first editor that I was exposed to when I started to learn Linux and experiment with the servers and eventually, the Raspberry Pi and Banana Pi. The nano editor is generally considered the easiest to use and is installed by default on the Banana Pi images. If, for some reason, you need to install it, you can get it quickly with the help of the following command: sudo apt-get install nano The editor is easy to use. It comes with several commands that you will use frequently. To save and close the editor, use the following key combinations: Ctrl + O Ctrl + X You can get help at any time by pressing Ctrl + G. Graphic editors With the exception of gVim, all the editors we just talked about live on the command line. If you are more accustomed to graphical tools, you may be more comfortable with a full-featured IDE. There are a couple of choices in this regard that you may be familiar with. These tools are a little heavier than the command-line tools because you will need to not only run the software, but also render the window. This is not as much of a big deal on the Banana Pi as it is on the Raspberry Pi, because we have more RAM to play with. However, if you have a lot of programs running already, it might cause some performance issues. Eclipse Eclipse is a very popular IDE that is available for everything. You can use it to develop all kinds of systems and use all kinds of programming languages. This is a tool that can be used to do professional development. There are a lot of plugins available in this IDE. It is also used to develop apps for Android (although Android Studio is also available now). Eclipse is written in Java. Hence, in order to make it work, you will require a Java Runtime Environment. The Banana Pi should come equipped with the Java development and runtime environments. If this is not the case, they are not difficult to install. In order to grab the proper version of Eclipse and avoid browsing all the specific versions on the website, you can just install it via the command line by entering the following code: sudo apt-get install eclipse Once Eclipse is installed, you will find it in the application menu under programming tools. The following screenshot shows the Eclipse IDE running on the Banana Pi: The Geany IDE Geany is a lighter weight IDE than Eclipse although the former is not quite fully featured. It is a clean UI that can be customized and used to write a lot of different programming languages. Geany was one of the first IDEs I ever used when first exploring Linux when I was a kid. Geany does not come preinstalled on the Banana Pi images, but it is easy to get via the command line: sudo apt-get install geany Depending on what you plan to do code-wise on the Banana Pi, Geany may be your best bet. It is GUI-based and offers quite a bit of functionality. However, it is a lot faster to load than Eclipse. It may seem familiar for Windows users, and they might find it easier to operate since it resembles Windows software. The following screenshot shows Geany on Linux: Both of these editors, Geany and Eclipse, are not specific to a particular programming language, but they both are slightly better for certain languages. Geany tends to be better for web languages such as HTML, PHP, JavaScript, and CSS, while Eclipse tends to be better for compiled languages such as C++, Go, and Java as well as PHP and Ruby with plugins. If you plan to write scripts or languages that are intended to be run from the command line such as Bash, Ruby, or Python, you may want to stick to the command line and use an editor such as Vim or nano. It is worth your time to play around with the editors and find your preferences. Web IDEs In addition to the command line and GUI editors, there are a couple of web-based IDEs. These essentially turn your Pi into a code server, which allows you to run and even execute certain types of code on an IDE written in web languages. These IDEs are great for learning code, but they are not really replacements for the solutions that were listed previously. Google Coder Google Coder is an educational web IDE that was released as an open source project by Google for the Raspberry Pi. Although there is a readily available image for the Raspberry Pi, we can manually install it for the Banana Pi. The following screenshot shows the Google Coder's interface: The setup is fairly straightforward. We will clone the Git repo and install it with Node.js. If you don't have Git and Node.js installed, you can install them with a quick command in the terminal, as follows: sudo apt-get install nodejs npm git Once it is installed, we can clone the coder repo by using the following code: git clone https://github.com/googlecreativelab/coder After it is cloned, we will move into the directory and install it with the help of the following code: cd ~/coder/coder-base/ npm install It may take several minutes to install, even on the Banana Pi. Next, we will edit the config.js file, which will be used to configure the ports and IP addresses. nano config.js The preceding code will reveal the contents of the file. Change the top values to match the following: exports.listenIP = '127.0.0.1'; exports.listenPort = '8081'; exports.httpListenPort = '8080'; exports.cacheApps = true; exports.httpVisiblePort = '8080'; exports.httpsVisiblePort = '8081'; After you change the settings you need, run a server by using Node.js: nodejs server.js You should now be able to connect to the Pi in a browser either on it or on another computer and use Coder. Coder is an educational tool with a lot of different built-in tutorials. You can use Coder to learn JavaScript, CSS, HTML, and jQuery. Adafruit WebIDE Adafruit has developed its own Web IDE, which is designed to run on the Raspberry Pi and BeagleBone. Since we are using the Banana Pi, it will only run better. This IDE is designed to work with Ruby, Python, and JavaScript, to name a few. It includes a terminal via which you can send commands to the Pi from the browser. It is an interesting tool if you wish to learn how to code. The following screenshot shows the interface of the WebIDE: The installation of WebIDE is very simple compared to that of Google Coder, which took several steps. We will just run one command: curl https://raw.githubusercontent.com/adafruit/Adafruit-WebIDE/alpha/scripts/install.sh | sudo sh After a few minutes, you will see an output that indicates that the server is starting. You will be able to access the IDE just like Google Coder—through a browser from another computer or from itself. It should be noted that you will be required to create a free Bit Bucket account to use this software. Summary In this article, we explored several different programming languages, command-line tools, graphical editors, and even some web IDEs. These tools are valuable for all kinds of projects that you may be working on. Resources for Article: Further resources on this subject: Prototyping Arduino Projects using Python [article] Raspberry Pi and 1-Wire [article] The Raspberry Pi and Raspbian [article]
Read more
  • 0
  • 0
  • 8186
Unlock access to the largest independent learning library in Tech for FREE!
Get unlimited access to 7500+ expert-authored eBooks and video courses covering every tech area you can think of.
Renews at $19.99/month. Cancel anytime
article-image-materials-and-why-they-are-essential
Packt
08 Jul 2015
11 min read
Save for later

Materials, and why they are essential

Packt
08 Jul 2015
11 min read
In this article by Ciro Cardoso, author of the book Lumion3D Best Practices, we will see materials, and why they are essential. In the 3D world, materials and textures are nearly as important as the 3D geometry that composes the scene. A material defines the optical properties of an object when hit by a ray of light. In other words, a material defines how the light interacts with the surface, and textures can help not only to control the color (diffuse), but also the reflections and glossiness. (For more resources related to this topic, see here.) It's not difficult to understand that textures are another essential part of a good material, and if your goal is to achieve believable results, you need textures or images of real elements like stone, wood, brick, and other natural elements. Textures can bring detail to your surface that otherwise would require geometry to look good. In that case, how can Lumion help you and, most importantly, what are the best practices to work with materials? Let's have a look at the following section which will provide the answer. A quick overview of Lumion's materials Lumion always had a good library of materials to assign to your 3D model, The reality is that Physically-Based Rendering (PBR) is more of a concept than a set of rules, and each render engine will implement slightly differently. The good news for us as users is that these materials follow realistic shading and lighting systems to accurately represent real-world materials. You can find excellent information regarding PBR on the following sites: http://www.marmoset.co/toolbag/learn/pbr-theory http://www.marmoset.co/toolbag/learn/pbr-practice https://www.allegorithmic.com/pbr-guide More than 600 materials are already prepared to be assigned directly to your 3D model and, by default, they should provide a realistic and appropriate material. The Lumion team has also made an effort to create a better and simpler interface, as you can see in the following screenshot: The interface was simplified, showing only the most common and essential settings. If you need more control over the material, click on the More… button to have access to extra functionalities. One word of caution: the material preview, which in this case is the sphere, will not reflect the changes you perform using the settings available. For example, if you change the main texture, the sphere will continue to show the previous material. A good practice to tweak materials is to assign the material to the surface, use the viewport to check how the settings are affecting the material, and then do a quick render. The viewport will try to show the final result, but there's nothing like a quick render to see how the material really looks when Lumion does all the lighting and shading calculations. Working with materials in Lumion – three options There are three options to work with materials in Lumion: Using Lumion's materials Using the imported materials that you can create on your favorite modeling application Creating materials using Lumion's Standard material Let's have a look at each one of these options and see how they can help you and when they best suit your project. Using Lumion's materials The first option is obvious; you are using Lumion and it makes sense using Lumion's materials, but you may feel constrained by what is available at Lumion's material library. However, instead of thinking, "I only have 600 materials and I cannot find what I need!", you need to look at the materials library also as a template to create other materials. For example, if none of the brick materials is similar to what you need, nothing stops you from using a brick material, changing the Gloss and Reflection values, and loading a new texture, creating an entirely new material. This is made possible by using the Choose Color Map button, as shown in the following screenshot: When you click on the Choose Color Map button, a new window appears where you can navigate to the folder where the texture is saved. What about the second square? The one with a purple color? Let's see the answer in the following section. Normal maps and their functionality The purple square you just saw is where you can load the normal map. And what is a normal map? Firstly, a normal map is not a bump map. A bump map uses a color range from black to white and in some ways is more limited than a normal map. The following screenshots show the clear difference between these two maps: The map on the left is a bump map and you can see that the level of detail is not the same that we can get with a normal map. A normal map consists of red, green, and blue colors that represent the x, y, and z coordinates. This allows a 2D image to represent depth and Lumion uses this depth information to fake lighting details based on the color associated with the 3D coordinate. The perks of using a normal map Why should you use normal maps? Keep in mind that Lumion is a real-time rendering engine and, as you saw previously, there is the need to keep a balance between detail and geometry. If you add too much detail, the 3D model will look gorgeous but Lumion's performance will suffer drastically. On the other hand, you can have a low-poly 3D model and fake detail with a normal map. Using a normal map for each material has a massive impact on the final quality you can get with Lumion. Since these maps are so important, how can you create one? Tips to create normal maps As you will understand, we cannot cover all the different techniques to create normal maps. However, you may find something to suit your workflow in the following list: Photoshop using an action script called nDo: Teddy Bergsman is the author of this fantastic script. It is a free script that creates a very accurate normal map of any texture you load in Photoshop in seconds. To download and see how to install this script, visit the following link: http://www.philipk.net/ndo.html Here you can find a more detailed tutorial on how to use this nDo script: http://www.philipk.net/tutorials/ndo/ndo.html This script has three options to create normal maps. The default option is Smooth, which gives you a blurry normal map. Then you have the Chisel Hard option to generate a very sharp and subtle normal map but you don't have much control over the final result. The Chisel Soft option is similar to the Chisel Hard except that you have full control over the intensity and bevel radius. This script also allows you to sculpt and combine several normal maps. Using the Quixel NDO application: From the same creator, we have a more capable and optimized application called Quixel NDO. With this application, you can sculpt normal maps in real-time, build your own normal maps without using textures, and preview everything with the 3DO material preview. This is quite useful because you don't have to save the normal map and see how it looks in Lumion. 3DO (which comes free with NDO) has a physically based renderer and lets you load a 3D model to see how the texture looks. Find more information including a free trial here: http://quixel.se/dev/ndo GIMP with the normalmap plugin: If you want to use free software, a good alternative is GIMP. There is a great plugin called normalmap, which does good work not only by creating a normal map but also by providing a preview window to see the tweaks you are making. To download this plugin, visit the following link: https://code.google.com/p/gimp-normalmap/ Do it online with NormalMap-Online: In case you don't want to install another application, the best option is doing it online. In that case, you may want to have a look at NormalMap-Online, as shown in the following screenshot: The process is extremely simple as you can see from the preceding screenshot. You load the image and automatically get a normal map, and on the right-hand side there is a preview to show how the normal map and the texture work together. Christian Petry is the man behind this tool that will help to create sharp and accurate normal maps. He is a great guy and if you like this online application, please consider supporting an application that will save you time and money. Find this online tool here: http://cpetry.github.io/NormalMap-Online/ Don't forget to use a good combination of Strength and Blur/Sharp to create a well-balanced map. You need the correct amount of detail; otherwise your normal map will be too noisy in terms of detail. However, Lumion being a user-friendly application gives you a hand on this topic by providing a tool to create a normal map automatically from a texture you import. Creating a normal map with Lumion's relief feature By now, creating a normal map from a texture is not something too technical or even complex, but it can be time consuming if you need to create a normal map for each texture. This is a wise move because it will remove the need for extra detail for the model to look good. With this in mind, Lumion's team created a new feature that allows you to create a normal map for any texture you import. After loading the new texture, the next step is to click on the Create Normal Map button, as highlighted in the following screenshot: Lumion then creates a normal map based on the texture imported, and you have the ability to invert the map by clicking on the Flip Normal Map direction button, as highlighted in the preceding screenshot. Once Lumion creates the normal map, you need a way to control how the normal map affects the material and the light. For that, you need to use the Relief slider, as shown in the following screenshot: Using this slider is very intuitive; you only need to move the slider and see the adjustments on the viewport, since the material preview will not be updated. The previous screenshot is a good example of that, because even when we loaded a wood texture, the preview still shows a concrete material. Again, this means you can easily use the settings from one material and use that as a base to create something completely new. But how good is the normal map that Lumion creates for you? Have a look for yourself in the following screenshot: On the left hand side, we have a wood floor material with a normal map that Lumion created. The right-hand side image is the same material but the normal map was created using the free nDo script for Photoshop. There is a big difference between the image on the left and the image on the right, and that is related to the normal maps used in this case. You can see clearly that the normal map used for the image on the right achieves the goal of bringing more detail to the surface. The difference is that the normal map that Lumion creates in some situations is too blurry, and for that reason we end up losing detail. Before we explore a few more things regarding creating custom materials in Lumion, let's have a look at another useful feature in Lumion. Summary Physically based rendering materials aren't that scary, don't you agree? In reality, Lumion makes this feature almost unnoticeable by making it so simple. You learned what this feature involves and how you can take full advantage of materials that make your render more believable. You learned the importance of using normal maps and how to create them using a variety of tools for all flavors. You also saw how we can easily improve material reflections without compromising the speed and quality of the render. You also learned another key aspect of Lumion: flexibility to create your own materials using the Standard material. The Standard material, although slightly different from the other materials available in Lumion, lets you play with the reflections, glossiness, and other settings that are essential. On top of all of this, you learned how to create textures. Resources for Article: Further resources on this subject: Unleashing the powers of Lumion [article] Mastering Lumion 3D [article] What is Lumion? [article]
Read more
  • 0
  • 0
  • 12207

Packt
08 Jul 2015
8 min read
Save for later

Zabbix and I – Almost Heroes

Packt
08 Jul 2015
8 min read
In this article written by Luciano Alves, author of the book Zabbix Performance Tuning, the author explains that ever since he started working with IT infrastructure, he's been noticing that almost every company, when they start thinking about a monitoring tool, think of trying to know in some way when the system or service will go down before it actually happens. They expect the monitoring tool to create some kind of alert when something is broken. But by this approach, the system administrator will know about an error or system outage only after the error occurs (and maybe, at the same time, users are trying to use those systems). We need a monitoring solution to help us predict system outages and any other situation that our services can be affected by. Our approach with monitoring tools should cover not only our system monitoring but also our business monitoring. Nowadays, any company (small, medium, or large) has some dependency on technologies, from servers and network assets to IP equipment with a lower environmental impact. Maybe you need security cameras, thermometers, UPS, access control devices, or any other IP device by which you can gather some useful data. What about applications and services? What about data integration or transactions? What about user experience? What about a supplier website or system that you depend on? We should realize that monitoring things is not restricted to IT infrastructure, and it can be extended to other areas and business levels as well. (For more resources related to this topic, see here.) After starting Zabbix – the initial steps Suppose you already have your Zabbix server up and running. In a few weeks, Zabbix has helped you save a lot of time while restoring systems. It has also helped you notice some hidden things in your environment—maybe a flapping port in a network switch, or lack of CPU in a router. In a few months, Zabbix and you (of course) are like superstars. During lunch, people are talking about you. Some are happy because you've dealt with a recurring error. Maybe, a manager asks you to find a way to monitor a printer because it's very important to their team, another manager asks you to monitor an application, and so on. The other teams and areas also need some kind of monitoring. They have other things to monitor, not only IT things. But are these people familiar with technical things? Technical words, expressions, flows, and lines of thoughts are not so easy for people with nontechnical backgrounds to understand. Of course, in small and medium enterprises (SME), things will go ahead faster and paths will be shorter, but the scenario is not too different in most cases. You can work alone or in a huge team, but now you have another important partner—Zabbix. An immutable fact is that monitoring things comes with more and more responsibility and reliability. At this point, we have some new issues to solve: How do we create and authenticate a user? When Zabbix's visibility starts growing in your environment, you will need to think how to manage and handle these users. Do you have an LDAP or Microsoft Active Directory that you can use for centralized authentication? Of course, depending on the users you have, you will have more requests. Will you permit any user to access the Zabbix interface? Only a few? And which ones? Is it necessary to create a custom monitor? We know that Zabbix has a lot of built-in keys for gathering data. These keys are available for a good number of operating systems. We also have built-in functions used to gather data using the Intelligent Platform Management Interface (IPMI), Simple Network Management Protocol (SNMP), Open Database Connectivity (ODBC), Java Management Extensions (JMX), user parameters in the Zabbix agent, and so on. However, we need to think about a wide scenario where we need to gather data from somewhere Zabbix hasn't reached yet. Our experience shows us that most of the time, it is necessary to create custom monitors (not one, but a lot of them). Zabbix is a very flexible and easy-to-customize platform. It is possible to make Zabbix do anything you want. However, to learn every new function or to monitor Zabbix, you'll need to think about what kind of extension you'll use. More functions, more data, more load, and more TCP connections! This means that when other teams or areas start putting light on Zabbix, you will need to think about the number of new functions or monitors you will need to get. Then, which language to choose to develop these new things? Maybe you know the C language and you are thinking of using Zabbix modules. Will you use bulk operations to avoid network traffic? The natural growth In most scenarios, natural growth will occur without control. I mean, people are not used to planning this growth. It is very important to keep it under control. When some guys start their Zabbix deployment, they probably do not intend to cater to all company teams, areas, or businesses. They think about their needs and their team only. So, they don't think a lot about user rights, mainly because they are technicians and know mostly about hosts, items, triggers, maps, graphs, screens, and so on. What about users who are not technicians? Will they understand the Zabbix interface easily? Do you know that in Zabbix, we have a lot of paths that reach the same point? The Zabbix interface isn't object-based, which means that users need a lot of clicks to reach (read or write) the information related to an object (hosts, items, graphs, triggers, events, and so on). If you need to see the most recent data gathered from a specific item, you'll need to use the Monitoring menu, then use the Latest data menu, choose the group that the host belongs to, choose your host, and finally search for your item in the table. If you need to see a specific custom graph, use the Graphs menu, which is under Monitoring. Choose the group that the hosts belong to, choose your host, and then search for your graph in a combobox. If you need to know about an active trigger in your host, you'll need to use the Triggers menu, which is under Monitoring. Choose the group that your host belongs to and choose your host. Then, you can see the triggers from that specific host. If you want to include a new item in an existing custom graph, you'll need to access the Hosts menu, which is under Configuration. Choose the group that the hosts belong to, search for your host, and click on the Graphs link. Then you can choose which graph you want to change. There are a lot of clicks required to do simple things. Of course, the steps you just saw are something familiar for guys who have deployed Zabbix, but is this true for other teams too? Maybe, you are thinking right now that it doesn't matter to those guys. But actually, it matters, and it's directly related to Zabbix's growth in your environment. Okay, I think the next two questions will be: are you sure it matters? And why? Let's agree that the actual Zabbix interface isn't very user friendly for nontechnical guys. But according to the path of natural growth, you started gathering data from a lot of things that are not just IT related. Also, you can develop custom charts and any data from Zabbix via API functions. Now you'll have a lot of nontechnical guys trying to use Zabbix data. I'm sure that it will be necessary to create some maps and screens to help these users get the required information quickly and smoothly. The following screenshots show how we can transform the viewing layer of Zabbix into something more attractive: Tactical dashboard Here is what a strategic dashboard may look like: Strategic dashboard The point here is whether your Zabbix deployment is prepared to cater to these types of requirements. Summary We've noticed how Zabbix has evolved in terms of performance issues with each version. Also, you realized the importance of the need to be aware of its new features. Another significant point was to realize that the importance of Zabbix is growing, as the other teams and areas of the company are now aware of the potential of this tool. This movement will take Zabbix to all the corners of a company, which often requires a more open approach as far as monitoring tasks is concerned. Monitoring only servers and network assets will not suffice. Resources for Article: Further resources on this subject: Going beyond Zabbix agents [article] Understanding Self-tuning Thresholds [article] Query Performance Tuning [article]
Read more
  • 0
  • 0
  • 6006

article-image-blueprint-class
Packt
08 Jul 2015
26 min read
Save for later

The Blueprint Class

Packt
08 Jul 2015
26 min read
In this article by Nitish Misra, author of the book, Learning Unreal Engine Android Game Development, mentions about the Blueprint class. You would need to do all the scripting and everything else only once. A Blueprint class is an entity that contains actors (static meshes, volumes, camera classes, trigger box, and so on) and functionalities scripted in it. Looking at our example once again of the lamp turning on/off, say you want to place 10 such lamps. With a Blueprint class, you would just have to create and script once, save it, and duplicate it. This is really an amazing feature offered by UE4. (For more resources related to this topic, see here.) Creating a Blueprint class To create a Blueprint class, click on the Blueprints button in the Viewport toolbar, and in the dropdown menu, select New Empty Blueprint Class. A window will then open, asking you to pick your parent class, indicating the kind of Blueprint class you wish to create. At the top, you will see the most common classes. These are as follows: Actor: An Actor, as already discussed, is an object that can be placed in the world (static meshes, triggers, cameras, volumes, and so on, all count as actors) Pawn: A Pawn is an actor that can be controlled by the player or the computer Character: This is similar to a Pawn, but has the ability to walk around Player Controller: This is responsible for giving the Pawn or Character inputs in the game, or controlling it Game Mode: This is responsible for all of the rules of gameplay Actor Component: You can create a component using this and add it to any actor Scene Component: You can create components that you can attach to other scene components Apart from these, there are other classes that you can choose from. To see them, click on All Classes, which will open a menu listing all the classes you can create a Blueprint with. For our key cube, we will need to create an Actor Blueprint Class. Select Actor, which will then open another window, asking you where you wish to save it and what to name it. Name it Key_Cube, and save it in the Blueprint folder. After you are satisfied, click on OK and the Actor Blueprint Class window will open. The Blueprint class user interface is similar to that of Level Blueprint, but with a few differences. It has some extra windows and panels, which have been described as follows: Components panel: The Components panel is where you can view, and add components to the Blueprint class. The default component in an empty Blueprint class is DefaultSceneRoot. It cannot be renamed, copied, or removed. However, as soon as you add a component, it will replace it. Similarly, if you were to delete all of the components, it will come back. To add a component, click on the Add Component button, which will open a menu, from where you can choose which component to add. Alternatively, you can drag an asset from the Content Browser and drop it in either the Graph Editor or the Components panel, and it will be added to the Blueprint class as a component. Components include actors such as static or skeletal meshes, light actors, camera, audio actors, trigger boxes, volumes, particle systems, to name a few. When you place a component, it can be seen in the Graph Editor, where you can set its properties, such as size, position, mobility, material (if it is a static mesh or a skeletal mesh), and so on, in the Details panel. Graph Editor: The Graph Editor is also slightly different from that of Level Blueprint, in that there are additional windows and editors in a Blueprint class. The first window is the Viewport, which is the same as that in the Editor. It is mainly used to place actors and set their positions, properties, and so on. Most of the tools you will find in the main Viewport (the editor's Viewport) toolbar are present here as well. Event Graph: The next window is the Event Graph window, which is the same as a Level Blueprint window. Here, you can script the components that you added in the Viewport and their functionalities (for example, scripting the toggling of the lamp on/off when the player is in proximity and moves away respectively). Keep in mind that you can script the functionalities of the components only present within the Blueprint class. You cannot use it directly to script the functionalities of any actor that is not a component of the Class. Construction Script: Lastly, there is the Construction Script window. This is also similar to the Event Graph, as in you can set up and connect nodes, just like in the Event Graph. The difference here is that these nodes are activated when you are constructing the Blueprint class. They do not work during runtime, since that is when the Event Graph scripts work. You can use the Construction Script to set properties, create and add your own property of any of the components you wish to alter during the construction, and so on. Let's begin creating the Blueprint class for our key cubes. Viewport The first thing we need are the components. We require three components: a cube, a trigger box, and a PostProcessVolume. In the Viewport, click on the Add Components button, and under Rendering, select Static Mesh. It will add a Static Mesh component to the class. You now need to specify which Static Mesh you want to add to the class. With the Static Mesh actor selected in the Components panel, in the actor's Details panel, under the Static Mesh section, click on the None button and select TemplateCube_Rounded. As soon as you set the mesh, it will appear in the Viewport. With the cube selected, decrease its scale (located in the Details panel) from 1 to 0.2 along all three axes. The next thing we need is a trigger box. Click on the Add Component button and select Box Collision in the Collision section. Once added, increase its scale from 1 to 9 along all three axes, and place it in such a way that its bottom is in line with the bottom of the cube. The Construction Script You could set its material in the Details panel itself by clicking on the Override Materials button in the Rendering section, and selecting the key cube material. However, we are going to assign its material using Construction Script. Switch to the Construction Script tab. You will see a node called Construction Script, which is present by default. You cannot delete this node; this is where the script starts. However, before we can script it in, we will need to create a variable of the type Material. In the My Blueprint section, click on Add New and select Variable in the dropdown menu. Name this variable Key Cube Material, and change its type from Bool (which is the default variable type) to Material in the Details panel. Also, be sure to check the Editable box so that we can edit it from outside the Blueprint class. Next, drag the Key Cube Material variable from the My Blueprint panel, drop it in the Graph Editor, and select Set when the window opens up. Connect this to the output pin of the Construction Script node. Repeat this process, only this time, select Get and connect it to the input pin of Key Cube Material. Right-click in the Graph Editor window and type in Set Material in the search bar. You should see Set Material (Static Mesh). Click on it and add it to the scene. This node already has a reference of the Static Mesh actor (TemplateCube_Rounded), so we will not have to create a reference node. Connect this to the Set node. Finally, drag Key Cube Material from My Blueprint, drop it in the Graph Editor, select Get, and connect it to the Material input pin. After you are done, hit Compile. We will now be able to set the cube's material outside of the Blueprint class. Let's test it out. Add the Blueprint class to the level. You will see a TemplateCube_Rounded actor added to the scene. In its Details panel, you will see a Key Cube Material option under the Default section. This is the variable we created inside our Construction Script. Any material we add here will be added to the cube. So, click on None and select KeyCube_Material. As soon as you select it, you will see the material on the cube. This is one of the many things you can do using Construction Script. For now, only this will do. The Event Graph We now need to script the key cube's functionalities. This is more or less the same as what we did in the Level Blueprint with our first key cube, with some small differences. In the Event Graph panel, the first thing we are going to script is enabling and disabling input when the player overlaps and stops overlapping the trigger box respectively. In the Components section, right-click on Box. This will open a menu. Mouse over Add Event and select Add OnComponentBeginOverlap. This will add a Begin Overlap node to the Graph Editor. Next, we are going to need a Cast node. A Cast node is used to specify which actor you want to use. Right-click in the Graph Editor and add a Cast to Character node. Connect this to the OnComponentBeginOverlap node and connect the other actor pin to the Object pin of the Cast to Character node. Finally, add an Enable Input node and a Get Player Controller node and connect them as we did in the Level Blueprint. Next, we are going to add an event for when the player stops overlapping the box. Again, right-click on Box and add an OnComponentEndOverlap node. Do the exact same thing you did with the OnComponentBeginOverlap node; only here, instead of adding an Enable Input node, add a Disable Input node. The setup should look something like this: You can move the key cube we had placed earlier on top of the pedestal, set it to hidden, and put the key cube Blueprint class in its place. Also, make sure that you set the collision response of the trigger actor to Ignore. The next step is scripting the destruction of the key cube when the player touches the screen. This, too, is similar to what we had done in Level Blueprint, with a few differences. Firstly, add a Touch node and a Sequence node, and connect them to each other. Next, we need a Destroy Component node, which you can find under Components | Destroy Component (Static Mesh). This node already has a reference to the key cube (Static Mesh) inside it, so you do not have to create an external reference and connect it to the node. Connect this to the Then 0 node. We also need to activate the trigger after the player has picked up the key cube. Now, since we cannot call functions on actors outside the Blueprint class directly (like we could in Level Blueprint), we need to create a variable. This variable will be of the type Trigger Box. The way this works is, when you have created a Trigger Box variable, you can assign it to any trigger in the level, and it will call that function to that particular trigger. With that in mind, in the My Blueprint panel, click on Add New and create a variable. Name this variable Activated Trigger Box, and set its type to Trigger Box. Finally, make sure you tick on the Editable box; otherwise, you will not be able to assign any trigger to it. After doing that, create a Set Collision Response to All Channels node (uncheck the Context Sensitive box), and set the New Response option to Overlap. For the target, drag the Activated Trigger Box variable, drop it in the Graph Editor, select Get, and connect it to the Target input. Finally, for the Post Process Volume, we will need to create another variable of the type PostProcessVolume. You can name this variable Visual Indicator, again, while ensuring that the Editable box is checked. Add this variable to the Graph Editor as well. Next, click on its pin, drag it out, and release it, which will open the actions menu. Here, type in Enabled, select Set Enabled, and check Enabled. Finally, add a Delay node and a Destroy Actor and connect them to the Set Enabled node, in that order. Your setup should look something like this: Back in the Viewport, you will find that under the Default section of the Blueprint class actor, two more options have appeared: Activated Trigger Box and Visual Indicator (the variables we had created). Using this, you can assign which particular trigger box's collision response you want to change, and which exact post process volume you want to activate and destroy. In front of both variables, you will see a small icon in the shape of an eye dropper. You can use this to choose which external actor you wish to assign the corresponding variable. Anything you scripted using those variables will take effect on the actor you assigned in the scene. This is one of the many amazing features offered by the Blueprint class. All we need to do now for the remaining key cubes is: Place them in the level Using the eye dropper icon that is located next to the name of the variables, pick the trigger to activate once the player has picked up the key cube, and which post process volume to activate and destroy. In the second room, we have two key cubes: one to activate the large door and the other to activate the door leading to the third room. The first key cube will be placed on the pedestal near the big door. So, with the first key cube selected, using the eye dropper, select the trigger box on the pedestal near the big door for the Activated Trigger Box variable. Then, pick the post process volume inside which the key cube is placed for the Visual Indicator variable. The next thing we need to do is to open Level Blueprint and script in what happens when the player places the key cube on the pedestal near the big door. Doing what we did in the previous room, we set up nodes that will unhide the hidden key cube on the pedestal, and change the collision response of the trigger box around the big door to Overlap, ensuring that it was set to Ignore initially. Test it out! You will find that everything is working as expected. Now, do the same with the remaining key cubes. Pick which trigger box and which post process volume to activate when you touch on the screen. Then, in the Level Blueprint, script in which key cube to unhide, and so on (place the key cubes we had placed earlier on the pedestals and set it to Hidden), and place the Blueprint class key cube in its place. This is one of the many ways you can use Blueprint class. You can see it takes a lot of work and hassle. Let us now move on to Artificial intelligence. Scripting basic AI Coming back to the third room, we are now going to implement AI in our game. We have an AI character in the third room which, when activated, moves. The main objective is to make a path for it with the help of switches and prevent it from falling. When the AI character reaches its destination, it will unlock the key cube, which the player can then pick up and place on the pedestal. We first need to create another Blueprint class of the type Character, and name it AI_Character. When created, double-click on it to open it. You will see a few components already set up in the Viewport. These are the CapsuleComponent (which is mainly used for collision), ArrowComponent (to specify which side is the front of the character, and which side is the back), Mesh (used for character animation), and CharacterMovement. All four are there by default, and cannot be removed. The only thing we need to do here is add a StaticMesh for our character, which will be TemplateCube_Rounded. Click on Add Components, add a StaticMesh, and assign it TemplateCube_Rounded (in its Details panel). Next, scale this cube to 0.2 along all three axes and move it towards the bottom of the CapsuleComponent, so that it does not float in midair. This is all we require for our AI character. The rest we will handle in Level Blueprints. Next, place AI_Character into the scene on the Player side of the pit, with all of the switches. Place it directly over the Target Point actor. Next, open up Level Blueprint, and let's begin scripting it. The left-most switch will be used to activate the AI character, and the remaining three will be used to draw the parts of a path on which it will walk to reach the other side. To move the AI character, we will need an AI Move To node. The first thing we need is an overlapping event for the trigger over the first switch, which will enable the input, otherwise the AI character will start moving whenever the player touches the screen, which we do not want. Set up an Overlap event, an Enable Input node, and a Gate event. Connect the Overlap event to the Enable Input event, and then to the Gate node's Open input. The next thing is to create a Touch node. To this, we will attach an AI Move To node. You can either type it in or find it under the AI section. Once created, attach it to the Gate node's Exit pin. We now need to specify to the node which character we want to move, and where it should move to. To specify which character we want to move, select the AI character in the Viewport, and in the Level Blueprint's Graph Editor, right-click and create a reference for it. Connect it to the Pawn input pin. Next, for the location, we want the AI character to move towards the second Target Point actor, located on the other side of the pit. But first, we need to get its location in the world. With it selected, right-click in the Graph Editor, and type in Get Actor Location. This node returns an actor's location (coordinates) in the world (the one connected to it). This will create a Get Actor Location, with the Target Point actor connect to its input pin. Finally, connect its Return Value to the Destination input of the AI Move To node. If you were to test it out, you would find that it works fine, except for one thing: the AI character stops when it reaches the edge of the pit. We want it to fall off the pit if there is no path. For that, we will need a Nav Proxy Link actor. A Nav Proxy Link actor is used when an AI character has to step outside the Nav Mesh temporarily (for example, jump between ledges). We will need this if we want our AI character to fall off the ledge. You can find it in the All Classes section in the Modes panel. Place it in the level. The actor is depicted by two cylinders with a curved arrow connecting them. We want the first cylinder to be on one side of the pit and the other cylinder on the other side. Using the Scale tool, increase the size of the Nav Proxy Link actor. When placing the Nav Proxy Link actor, keep two things in mind: Make sure that both cylinders intersect in the green area; otherwise, the actor will not work Ensure that both cylinders are in line with the AI character; otherwise, it will not move in a straight line but instead to where the cylinder is located Once placed, you will see that the AI character falls off when it reaches the edge of the pit. We are not done yet. We need to bring the AI character back to its starting position so that the player can start over (or else the player will not be able to progress). For that, we need to first place a trigger at the bottom of the pit, making sure that if the AI character does fall into it, it overlaps the trigger. This trigger will perform two actions: first, it will teleport the AI character to its initial location (with the help of the first Target Point); second, it will stop the AI Move To node, or it will keep moving even after it has been teleported. After placing the trigger, open Level Blueprint and create an Overlap event for the trigger box. To this, we will add a Sequence node, since we are calling two separate functions for when the player overlaps the trigger. The first node we are going to create is a Teleport node. Here, we can specify which actor to teleport, and where. The actor we want to teleport is the AI character, so create a reference for it and connect it to the Target input pin. As for the destination, first use the Get Actor Location function to get the location of the first Target Point actor (upon which the AI character is initially placed), and connect it to the Dest Location input. To stop the AI character's movement, right-click anywhere in the Graph Editor, and first uncheck the Context Sensitive box, since we cannot use this function directly on our AI character. What we need is a Stop Active Movement node. Type it into the search bar and create it. Connect this to the Then 1 output node, and attach a reference of the AI character to it. It will automatically convert from a Character Reference into Character Movement component reference. This is all that we need to script for our AI in the third room. There is one more thing left: how to unlock the key cube. In the fourth room, we are going to use the same principle. Here, we are going to make a chain of AI Move To nodes, each connected to the previous one's On Success output pin. This means that when the AI character has successfully reached the destination (Target Point actor), it should move to the next, and so on. Using this, and what we have just discussed about AI, script the path that the AI will follow. Packaging the project Another way of packaging the game and testing it on your device is to first package the game, import it to the device, install it, and then play it. But first, we should discuss some settings regarding packaging, and packaging for Android. The Maps & Modes settings These settings deal with the maps (scenes) and the game mode of the final game. In the Editor, click on Edit and select Project settings. In the Project settings, Project category, select Maps & Modes. Let's go over the various sections: Default Maps: Here, you can set which map the Editor should open when you open the Project. You can also set which map the game should open when it is run. The first thing you need to change is the main menu map we had created. To do this, click on the downward arrow next to Game Default Map and select Main_Menu. Local Multiplayer: If your game has local multiplayer, you can alter a few settings regarding whether the game should have a split screen. If so, you can set what the layout should be for two and three players. Default Modes: In this section, you can set the default game mode the game should run with. The game mode includes things such as the Default Pawn class, HUD class, Controller class, and the Game State Class. For our game, we will stick to MyGame. Game Instance: Here, you can set the default Game Instance Class. The Packaging settings There are settings you can tweak when packaging your game. To access those settings, first go to Edit and open the Project settings window. Once opened, under the Project section click on Packaging. Here, you can view and tweak the general settings related to packaging the project file. There are two sections: Project and Packaging. Under the Project section, you can set options such as the directory of the packaged project, the build configuration to either debug, development, or shipping, whether you want UE4 to build the whole project from scratch every time you build, or only build the modified files and assets, and so on. Under the Packaging settings, you can set things such as whether you want all files to be under one .pak file instead of many individual files, whether you want those .pak files in chunks, and so on. Clicking on the downward arrow will open the advanced settings. Here, since we are packaging our game for distribution check the For Distribution checkbox. The Android app settings In the preceding section, we talked about the general packaging settings. We will now talk about settings specific to Android apps. This can be found in Project Settings, under the Platforms section. In this section, click on Android to open the Android app settings. Here you will find all the settings and properties you need to package your game. At the top the first thing you should do is configure your project for Android. If your project is not configured, it will prompt you to do so (since version 4.7, UE4 automatically creates the androidmanifest.xml file for you). Do this before you do anything else. Here you have various sections. These are: APKPackaging: In this section, you can find options such as opening the folder where all of the build files are located, setting the package's name, setting the version number, what the default orientation of the game should be, and so on. Advanced APKPackaging: This section contains more advanced packaging options, such as one to add extra settings to the .apk files. Build: To tweak settings in the Build section, you first need the source code which is available from GitHub. Here, you can set things like whether you want the build to support x86, OpenGL ES2, and so on. Distribution Signing: This section deals with signing your app. It is a requirement on Android that all apps have a digital signature. This is so that Android can identify the developers of the app. You can learn more about digital signatures by clicking on the hyperlink at the top of the section. When you generate the key for your app, be sure to keep it in a safe and secure place since if you lose it you will not be able to modify or update your app on Google Play. Google Play Service: Android apps are downloaded via the Google Play store. This section deals with things such as enabling/disabling Google Play support, setting your app's ID, the Google Play license key, and so on. Icons: In this section, you can set your game's icons. You can set various sizes of icons depending upon the screen density of the device you are aiming to develop on. You can get more information about icons by click on the hyperlink at the top of the section. Data Cooker: Finally, in this section, you can set how you want the audio in the game to be encoded. For our game, the first thing you need to set is the Android Package Name which is found in the APKPackaging section. The format of the naming is com.YourCompany.[PROJECT]. Here, replace YourCompany with the name of the company and [PROJECT] with the name of your project. Building a package To package your project, in the Editor go to File | Package Project | Android. You will see different types of formats to package the project in. These are as follows: ATC: Use this format if you have a device that has a Qualcomm Snapdragon processor. DXT: Use this format if your device has a Tegra graphical processing unit (GPU). ETC1: You can use this for any device. However, this format does not accept textures with alpha channels. Those textures will be uncompressed, making your game requiring more space. ETC2: Use this format is you have a MALI-based device. PVRTC: Use this format if you have a device with a PowerVR GPU. Once you have decided upon which format to use, click on it to begin the packaging process. A window will open up asking you to specify which folder you want the package to be stored in. Once you have decided where to store the package file, click OK and the build process will commence. When started, just like with launching the project, a small window will pop up at the bottom-right corner of the screen notifying the user that the build process has begun. You can open the output log and cancel the build process. Once the build process is complete, go the folder you set. You will find a .bat file of the game. Providing you have checked the packaged game data inside .apk? option (which is located in the Project settings in the Android category under the APKPackaging section), you will also find an .apk file of the game. The .bat file directly installs the game from the system onto your device. To do so, first connect your device to the system. Then double-click on the .bat file. This will open a command prompt window.   Once it has opened, you do not need to do anything. Just wait until the installation process finishes. Once the installation is done, the game will be on your device ready to be executed. To use the .apk file, you will have to do things a bit differently. An .apk file installs the game when it is on the device. For that, you need to perform the following steps: Connect the device. Create a copy of the .apk file. Paste it in the device's storage. Execute the .apk file from the device. The installation process will begin. Once completed, you can play the game. Summary In this article, we covered with Blueprints and discussed how they work. We also discussed Level Blueprints and the Blueprint class, and covered how to script AI. We discussed how to package the final product and upload the game onto the Google Play Store for people to download. Resources for Article: Further resources on this subject: Flash Game Development: Creation of a Complete Tetris Game [article] Adding Finesse to Your Game [article] Saying Hello to Unity and Android [article]
Read more
  • 0
  • 0
  • 8688

article-image-why-meteor-rocks
Packt
08 Jul 2015
23 min read
Save for later

Why Meteor Rocks!

Packt
08 Jul 2015
23 min read
In this article by Isaac Strack, the author of the book, Getting Started with Meteor.js JavaScript Framework - Second Edition, has discussed some really amazing features of Meteor that has contributed a lot to the success of Meteor. Meteor is a disruptive (in a good way!) technology. It enables a new type of web application that is faster, easier to build, and takes advantage of modern techniques, such as Full Stack Reactivity, Latency Compensation, and Data On The Wire. (For more resources related to this topic, see here.) This article explains how web applications have changed over time, why that matters, and how Meteor specifically enables modern web apps through the above-mentioned techniques. By the end of this article, you will have learned: What a modern web application is What Data On The Wire means and how it's different How Latency Compensation can improve your app experience Templates and Reactivity—programming the reactive way! Modern web applications Our world is changing. With continual advancements in displays, computing, and storage capacities, things that weren't even possible a few years ago are now not only possible but are critical to the success of a good application. The Web in particular has undergone significant change. The origin of the web app (client/server) From the beginning, web servers and clients have mimicked the dumb terminal approach to computing where a server with significantly more processing power than a client will perform operations on data (writing records to a database, math calculations, text searches, and so on), transform the data and render it (turn a database record into HTML and so on), and then serve the result to the client, where it is displayed for the user. In other words, the server does all the work, and the client acts as more of a display, or a dumb terminal. This design pattern for this is called…wait for it…the client/server design pattern. The diagrammatic representation of the client-server architecture is shown in the following diagram: This design pattern, borrowed from the dumb terminals and mainframes of the 60s and 70s, was the beginning of the Web as we know it and has continued to be the design pattern that we think of when we think of the Internet. The rise of the machines (MVC) Before the Web (and ever since), desktops were able to run a program such as a spreadsheet or a word processor without needing to talk to a server. This type of application could do everything it needed to, right there on the big and beefy desktop machine. During the early 90s, desktop computers got even more beefy. At the same time, the Web was coming alive, and people started having the idea that a hybrid between the beefy desktop application (a fat app) and the connected client/server application (a thin app) would produce the best of both worlds. This kind of hybrid app—quite the opposite of a dumb terminal—was called a smart app. Many business-oriented smart apps were created, but the easiest examples can be found in computer games. Massively Multiplayer Online games (MMOs), first-person shooters, and real-time strategies are smart apps where information (the data model) is passed between machines through a server. The client in this case does a lot more than just display the information. It performs most of the processing (or acts as a controller) and transforms the data into something to be displayed (the view). This design pattern is simple but very effective. It's called the Model View Controller (MVC) pattern. The model is essentially the data for an application. In the context of a smart app, the model is provided by a server. The client makes requests to the server for data and stores that data as the model. Once the client has a model, it performs actions/logic on that data and then prepares it to be displayed on the screen. This part of the application (talking to the server, modifying the data model, and preparing data for display) is called the controller. The controller sends commands to the view, which displays the information. The view also reports back to the controller when something happens on the screen (a button click, for example). The controller receives the feedback, performs the logic, and updates the model. Lather, rinse, repeat! Since web browsers were built to be "dumb clients", the idea of using a browser as a smart app back then was out of question. Instead, smart apps were built on frameworks such as Microsoft .NET, Java, or Macromedia (now Adobe) Flash. As long as you had the framework installed, you could visit a web page to download/run a smart app. Sometimes, you could run the app inside the browser, and sometimes, you would download it first, but either way, you were running a new type of web app where the client application could talk to the server and share the processing workload. The browser grows up Beginning in the early 2000s, a new twist on the MVC pattern started to emerge. Developers started to realize that, for connected/enterprise "smart apps", there was actually a nested MVC pattern. The server code (controller) was performing business logic against the database (model) through the use of business objects and then sending processed/rendered data to the client application (a "view"). The client was receiving this data from the server and treating it as its own personal "model". The client would then act as a proper controller, perform logic, and send the information to the view to be displayed on the screen. So, the "view" for the server MVC was the "model" for the client MVC. As browser technologies (HTML and JavaScript) matured, it became possible to create smart apps that used the Nested MVC design pattern directly inside an HTML web page. This pattern makes it possible to run a full-sized application using only JavaScript. There is no longer any need to download multiple frameworks or separate apps. You can now get the same functionality from visiting a URL as you could previously by buying a packaged product. A giant Meteor appears! Meteor takes modern web apps to the next level. It enhances and builds upon the nested MVC design pattern by implementing three key features: Data On The Wire through the Distributed Data Protocol (DDP) Latency Compensation with Mini Databases Full Stack Reactivity with Blaze and Tracker Let's walk through these concepts to see why they're valuable, and then, we'll apply them to our Lending Library application. Data On The Wire The concept of Data On The Wire is very simple and in tune with the nested MVC pattern; instead of having a server process everything, render content, and then send HTML across the wire, why not just send the data across the wire and let the client decide what to do with it? This concept is implemented in Meteor using the Distributed Data Protocol, or DDP. DDP has a JSON-based syntax and sends messages similar to the REST protocol. Additions, deletions, and changes are all sent across the wire and handled by the receiving service/client/device. Since DDP uses WebSockets rather than HTTP, the data can be pushed whenever changes occur. But the true beauty of DDP lies in the generic nature of the communication. It doesn't matter what kind of system sends or receives data over DDP—it can be a server, a web service, or a client app—they all use the same protocol to communicate. This means that none of the systems know (or care) whether the other systems are clients or servers. With the exception of the browser, any system can be a server, and without exception, any server can act as a client. All the traffic looks the same and can be treated in a similar manner. In other words, the traditional concept of having a single server for a single client goes away. You can hook multiple servers together, each serving a discreet purpose, or you can have a client connect to multiple servers, interacting with each one differently. Think about what you can do with a system like that: Imagine multiple systems all coming together to create, for example, a health monitoring system. Some systems are built with C++, some with Arduino, some with…well, we don't really care. They all speak DDP. They send and receive data on the wire and decide individually what to do with that data. Suddenly, very difficult and complex problems become much easier to solve. DDP has been implemented in pretty much every major programming language, allowing you true freedom to architect an enterprise application. Latency Compensation Meteor employs a very clever technique called Mini Databases. A mini database is a "lite" version of a normal database that lives in the memory on the client side. Instead of the client sending requests to a server, it can make changes directly to the mini database on the client. This mini database then automatically syncs with the server (using DDP of course), which has the actual database. Out of the box, Meteor uses MongoDB and Minimongo: When the client notices a change, it first executes that change against the client-side Minimongo instance. The client then goes on its merry way and lets the Minimongo handlers communicate with the server over DDP. If the server accepts the change, it then sends out a "changed" message to all connected clients, including the one that made the change. If the server rejects the change, or if a newer change has come in from a different client, the Minimongo instance on the client is corrected, and any affected UI elements are updated as a result. All of this doesn't seem very groundbreaking, but here's the thing—it's all asynchronous, and it's done using DDP. This means that the client doesn't have to wait until it gets a response back from the server. It can immediately update the UI based on what is in the Minimongo instance. What if the change was illegal or other changes have come in from the server? This is not a problem as the client is updated as soon as it gets word from the server. Now, what if you have a slow internet connection or your connection goes down temporarily? In a normal client/server environment, you couldn't make any changes, or the screen would take a while to refresh while the client waits for permission from the server. However, Meteor compensates for this. Since the changes are immediately sent to Minimongo, the UI gets updated immediately. So, if your connection is down, it won't cause a problem: All the changes you make are reflected in your UI, based on the data in Minimongo. When your connection comes back, all the queued changes are sent to the server, and the server will send authorized changes to the client. Basically, Meteor lets the client take things on faith. If there's a problem, the data coming in from the server will fix it, but for the most part, the changes you make will be ratified and broadcast by the server immediately. Coding this type of behavior in Meteor is crazy easy (although you can make it more complex and therefore more controlled if you like): lists = new Mongo.Collection("lists"); This one line declares that there is a lists data model. Both the client and server will have a version of it, but they treat their versions differently. The client will subscribe to changes announced by the server and update its model accordingly. The server will publish changes, listen to change requests from the client, and update its model (its master copy) based on these change requests. Wow, one line of code that does all that! Of course, there is more to it, but that's beyond the scope of this article, so we'll move on. To better understand Meteor data synchronization, see the Publish and subscribe section of the meteor documentation at http://docs.meteor.com/#/full/meteor_publish. Full Stack Reactivity Reactivity is integral to every part of Meteor. On the client side, Meteor has the Blaze library, which uses HTML templates and JavaScript helpers to detect changes and render the data in your UI. Whenever there is a change, the helpers re-run themselves and add, delete, and change UI elements, as appropriate, based on the structure found in the templates. These functions that re-run themselves are called reactive computations. On both the client and the server, Meteor also offers reactive computations without having to use a UI. Called the Tracker library, these helpers also detect any data changes and rerun themselves accordingly. Because both the client and the server are JavaScript-based, you can use the Tracker library anywhere. This is defined as isomorphic or full stack reactivity because you're using the same language (and in some cases the same code!) on both the client and the server. Re-running functions on data changes has a really amazing benefit for you, the programmer: you get to write code declaratively, and Meteor takes care of the reactive part automatically. Just tell Meteor how you want the data displayed, and Meteor will manage any and all data changes. This declarative style is usually accomplished through the use of templates. Templates work their magic through the use of view data bindings. Without getting too deep, a view data binding is a shared piece of data that will be displayed differently if the data changes. Let's look at a very simple data binding—one for which you don't technically need Meteor—to illustrate the point. Let's perform the following set of steps to understand the concept in detail: In LendLib.html, you will see an HTML-based template expression: <div id="categories-container">      {{> categories}}   </div> This expression is a placeholder for an HTML template that is found just below it: <template name="categories">    <h2 class="title">my stuff</h2>.. So, {{> categories}} is basically saying, "put whatever is in the template categories right here." And the HTML template with the matching name is providing that. If you want to see how data changes will affect the display, change the h2 tag to an h4 tag and save the change: <template name="categories">    <h4 class="title">my stuff</h4> You'll see the effect in your browser. (my stuff will become itsy bitsy.) That's view data binding at work. Change the h4 tag back to an h2 tag and save the change, unless you like the change. No judgment here...okay, maybe a little bit of judgment. It's ugly, and tiny, and hard to read. Seriously, you should change it back before someone sees it and makes fun of you! Alright, now that we know what a view data binding is, let's see how Meteor uses it. Inside the categories template in LendLib.html, you'll find even more templates: <template name="categories"> <h4 class="title">my stuff</h4> <div id="categories" class="btn-group">    {{#each lists}}      <div class="category btn btn-primary">        {{Category}}      </div>    {{/each}} </div> </template> Meteor uses a template language called Spacebars to provide instructions inside templates. These instructions are called expressions, and they let us do things like add HTML for every record in a collection, insert the values of properties, and control layouts with conditional statements. The first Spacebars expression is part of a pair and is a for-each statement. {{#each lists}} tells the interpreter to perform the action below it (in this case, it tells it to make a new div element) for each item in the lists collection. lists is the piece of data, and {{#each lists}} is the placeholder. Now, inside the {{#each lists}} expression, there is one more Spacebars expression: {{Category}} Since the expression is found inside the #each expression, it is considered a property. That is to say that {{Category}} is the same as saying this.Category, where this is the current item in the for-each loop. So, the placeholder is saying, "add the value of the Category property for the current record." Now, if we look in LendLib.js, we will see the reactive values (called reactive contexts) behind the templates: lists : function () { return lists.find(... Here, Meteor is declaring a template helper named lists. The helper, lists, is found inside the template helpers belonging to categories. The lists helper happens to be a function that returns all the data in the lists collection, which we defined previously. Remember this line? lists = new Mongo.Collection("lists"); This lists collection is returned by the above-mentioned helper. When there is a change to the lists collection, the helper gets updated and the template's placeholder is changed as well. Let's see this in action. On your web page pointing to http://localhost:3000, open the browser console and enter the following line: > lists.insert({Category:"Games"}); This will update the lists data collection. The template will see this change and update the HTML code/placeholder. Each of the placeholders will run one additional time for the new entry in lists, and you'll see the following screen: When the lists collection was updated, the Template.categories.lists helper detected the change and reran itself (recomputed). This changed the contents of the code meant to be displayed in the {{> categories}} placeholder. Since the contents were changed, the affected part of the template was re-run. Now, take a minute here and think about how little we had to do to get this reactive computation to run: we simply created a template, instructing Blaze how we want the lists data collection to be displayed, and we put in a placeholder. This is simple, declarative programming at its finest! Let's create some templates We'll now see a real-life example of reactive computations and work on our Lending Library at the same time. Adding categories through the console has been a fun exercise, but it's not a long-term solution. Let's make it so that we can do that on the page instead as follows: Open LendLib.html and add a new button just before the {{#each lists}} expression: <div id="categories" class="btn-group"> <div class="category btn btn-primary" id="btnNewCat">    <span class="glyphicon glyphicon-plus"></span> </div> {{#each lists}} This will add a plus button on the page, as follows: Now, we want to change the button into a text field when we click on it. So let's build that functionality by using the reactive pattern. We will make it based on the value of a variable in the template. Add the following {{#if…else}} conditionals around our new button: <div id="categories" class="btn-group"> {{#if new_cat}} {{else}}    <div class="category btn btn-primary" id="btnNewCat">      <span class="glyphicon glyphicon-plus"></span>    </div> {{/if}} {{#each lists}} The first line, {{#if new_cat}}, checks to see whether new_cat is true or false. If it's false, the {{else}} section is triggered, and it means that we haven't yet indicated that we want to add a new category, so we should be displaying the button with the plus sign. In this case, since we haven't defined it yet, new_cat will always be false, and so the display won't change. Now, let's add the HTML code to display when we want to add a new category: {{#if new_cat}} <div class="category form-group" id="newCat">      <input type="text" id="add-category" class="form-control" value="" />    </div> {{else}} ... {{/if}} There's the smallest bit of CSS we need to take care of as well. Open ~/Documents/Meteor/LendLib/LendLib.css and add the following declaration: #newCat { max-width: 250px; } Okay, so now we've added an input field, which will show up when new_cat is true. The input field won't show up unless it is set to true; so, for now, it's hidden. So, how do we make new_cat equal to true? Save your changes if you haven't already done so, and open LendLib.js. First, we'll declare a Session variable, just below our Meteor.isClient check function, at the top of the file: if (Meteor.isClient) { // We are declaring the 'adding_category' flag Session.set('adding_category', false); Now, we'll declare the new template helper new_cat, which will be a function returning the value of adding_category. We need to place the new helper in the Template.categories.helpers() method, just below the declaration for lists: Template.categories.helpers({ lists: function () {    ... }, new_cat: function(){    //returns true if adding_category has been assigned    //a value of true    return Session.equals('adding_category',true); } }); Note the comma (,) on the line above new_cat. It's important that you add that comma, or your code will not execute. Save these changes, and you'll see that nothing has changed. Ta-da! In reality, this is exactly as it should be because we haven't done anything to change the value of adding_category yet. Let's do this now: First, we'll declare our click event handler, which will change the value in our Session variable. To do this, add the following highlighted code just below the Template.categories.helpers() block: Template.categories.helpers({ ... }); Template.categories.events({ 'click #btnNewCat': function (e, t) {    Session.set('adding_category', true);    Tracker.flush();    focusText(t.find("#add-category")); } }); Now, let's take a look at the following line of code: Template.categories.events({ This line declares that events will be found in the category template. Now, let's take a look at the next line: 'click #btnNewCat': function (e, t) { This tells us that we're looking for a click event on the HTML element with an id="btnNewCat" statement (which we already created in LendLib.html). Session.set('adding_category', true); Tracker.flush(); focusText(t.find("#add-category")); Next, we set the Session variable, adding_category = true, flush the DOM (to clear up anything wonky), and then set the focus onto the input box with the id="add-category" expression. There is one last thing to do, and that is to quickly add the focusText(). helper function. To do this, just before the closing tag for the if (Meteor.isClient) function, add the following code: /////Generic Helper Functions///// //this function puts our cursor where it needs to be. function focusText(i) { i.focus(); i.select(); }; } //<------closing bracket for if(Meteor.isClient){} Now, when you save the changes and click on the plus button, you will see the input box: Fancy! However, it's still not useful, and we want to pause for a second and reflect on what just happened; we created a conditional template in the HTML page that will either show an input box or a plus button, depending on the value of a variable. This variable is a reactive variable, called a reactive context. This means that if we change the value of the variable (like we do with the click event handler), then the view automatically updates because the new_cat helpers function (a reactive computation) will rerun. Congratulations, you've just used Meteor's reactive programming model! To really bring this home, let's add a change to the lists collection (which is also a reactive context, remember?) and figure out a way to hide the input field when we're done. First, we need to add a listener for the keyup event. Or, to put it another way, we want to listen when the user types something in the box and hits Enter. When this happens, we want to add a category based on what the user typed. To do this, let's first declare the event handler. Just after the click handler for #btnNewCat, let's add another event handler: 'click #btnNewCat': function (e, t) {    ... }, 'keyup #add-category': function (e,t){    if (e.which === 13)    {      var catVal = String(e.target.value || "");      if (catVal)      {        lists.insert({Category:catVal});        Session.set('adding_category', false);      }    } } We add a "," character at the end of the first click handler, and then add the keyup event handler. Now, let's check each of the lines in the preceding code: This line checks to see whether we hit the Enter/Return key. if (e.which === 13) This line of code checks to see whether the input field has any value in it: var catVal = String(e.target.value || ""); if (catVal) If it does, we want to add an entry to the lists collection: lists.insert({Category:catVal}); Then, we want to hide the input box, which we can do by simply modifying the value of adding_category: Session.set('adding_category', false); There is one more thing to add and then we'll be done. When we click away from the input box, we want to hide it and bring back the plus button. We already know how to do this reactively, so let's add a quick function that changes the value of adding_category. To do this, add one more comma after the keyup event handler and insert the following event handler: 'keyup #add-category': function (e,t){ ... }, 'focusout #add-category': function(e,t){    Session.set('adding_category',false); } Save your changes, and let's see this in action! In your web browser on http://localhost:3000, click on the plus sign, add the word Clothes, and hit Enter. Your screen should now resemble the following screenshot: Feel free to add more categories if you like. Also, experiment by clicking on the plus button, typing something in, and then clicking away from the input field. Summary In this article, you learned about the history of web applications and saw how we've moved from a traditional client/server model to a nested MVC design pattern. You learned what smart apps are, and you also saw how Meteor has taken smart apps to the next level with Data On The Wire, Latency Compensation, and Full Stack Reactivity. You saw how Meteor uses templates and helpers to automatically update content, using reactive variables and reactive computations. Lastly, you added more functionality to the Lending Library. You made a button and an input field to add categories, and you did it all using reactive programming rather than directly editing the HTML code. Resources for Article: Further resources on this subject: Building the next generation Web with Meteor [article] Quick start - creating your first application [article] Meteor.js JavaScript Framework: Why Meteor Rocks! [article]
Read more
  • 0
  • 0
  • 4916
article-image-how-to-build-remote-controlled-tv-node-webkit
Roberto González
08 Jul 2015
14 min read
Save for later

How to build a Remote-controlled TV with Node-Webkit

Roberto González
08 Jul 2015
14 min read
Node-webkit is one of the most promising technologies to come out in the last few years. It lets you ship a native desktop app for Windows, Mac, and Linux just using HTML, CSS, and some JavaScript. These are the exact same languages you use to build any web app. You basically get your very own Frameless Webkit to build your app, which is then supercharged with NodeJS, giving you access to some powerful libraries that are not available in a typical browser. As a demo, we are going to build a remote-controlled Youtube app. This involves creating a native app that displays YouTube videos on your computer, as well as a mobile client that will let you search for and select the videos you want to watch straight from your couch. You can download the finished project from https://github.com/Aerolab/youtube-tv. You need to follow the first part of this guide (Getting started) to set up the environment and then run run.sh (on Mac) or run.bat (on Windows) to start the app. Getting started First of all, you need to install Node.JS (a JavaScript platform), which you can download from http://nodejs.org/download/. The installer comes bundled with NPM (Node.JS Package Manager), which lets you install everything you need for this project. Since we are going to be building two apps (a desktop app and a mobile app), it’s better if we get the boring HTML+CSS part out of the way, so we can concentrate on the JavaScript part of the equation. Download the project files from https://github.com/Aerolab/youtube-tv/blob/master/assets/basics.zip and put them in a new folder. You can name the project’s folder youtube-tv  or whatever you want. The folder should look like this: - index.html // This is the starting point for our desktop app - css // Our desktop app styles - js // This is where the magic happens - remote // This is where the magic happens (Part 2) - libraries // FFMPEG libraries, which give you H.264 video support in Node-Webkit - player // Our youtube player - Gruntfile.js // Build scripts - run.bat // run.bat runs the app on Windows - run.sh // sh run.sh runs the app on Mac Now open the Terminal (on Mac or Linux) or a new command prompt (on Windows) right in that folder. Now we’ll install a couple of dependencies we need for this project, so type these commands to install node-gyp and grunt-cli. Each one will take a few seconds to download and install: On Mac or Linux: sudo npm install node-gyp -g sudo npm install grunt-cli -g  On Windows: npm install node-gyp -g npm install grunt-cli -g Leave the Terminal open. We’ll be using it again in a bit. All Node.JS apps start with a package.json file (our manifest), which holds most of the settings for your project, including which dependencies you are using. Go ahead and create your own package.json file (right inside the project folder) with the following contents. Feel free to change anything you like, such as the project name, the icon, or anything else. Check out the documentation at https://github.com/rogerwang/node-webkit/wiki/Manifest-format: { "//": "The // keys in package.json are comments.", "//": "Your project’s name. Go ahead and change it!", "name": "Remote", "//": "A simple description of what the app does.", "description": "An example of node-webkit", "//": "This is the first html the app will load. Just leave this this way", "main": "app://host/index.html", "//": "The version number. 0.0.1 is a good start :D", "version": "0.0.1", "//": "This is used by Node-Webkit to set up your app.", "window": { "//": "The Window Title for the app", "title": "Remote", "//": "The Icon for the app", "icon": "css/images/icon.png", "//": "Do you want the File/Edit/Whatever toolbar?", "toolbar": false, "//": "Do you want a standard window around your app (a title bar and some borders)?", "frame": true, "//": "Can you resize the window?", "resizable": true}, "webkit": { "plugin": false, "user-agent": "Mozilla/5.0 (Macintosh; Intel Mac OS X 10_9_5) AppleWebKit/537.36 (KHTML, like Gecko) Safari/537.36" }, "//": "These are the libraries we’ll be using:", "//": "Express is a web server, which will handle the files for the remote", "//": "Socket.io lets you handle events in real time, which we'll use with the remote as well.", "dependencies": { "express": "^4.9.5", "socket.io": "^1.1.0" }, "//": "And these are just task handlers to make things easier", "devDependencies": { "grunt": "^0.4.5", "grunt-contrib-copy": "^0.6.0", "grunt-node-webkit-builder": "^0.1.21" } } You’ll also find Gruntfile.js, which takes care of downloading all of the node-webkit assets and building the app once we are ready to ship. Feel free to take a look into it, but it’s mostly boilerplate code. Once you’ve set everything up, go back to the Terminal and install everything you need by typing: npm install grunt nodewebkitbuild You may run into some issues when doing this on Mac or Linux. In that case, try using sudo npm install and sudo grunt nodewebkitbuild. npm install installs all of the dependencies you mentioned in package.json, both the regular dependencies and the development ones, like grunt and grunt-nodewebkitbuild, which downloads the Windows and Mac version of node-webkit, setting them up so they can play videos, and building the app. Wait a bit for everything to install properly and we’re ready to get started. Note that if you are using Windows, you might get a scary error related to Visual C++ when running npm install. Just ignore it. Building the desktop app All web apps (or websites for that matter) start with an index.html file. We are going to be creating just that to get our app to run: <!DOCTYPE html><html> <head> <metacharset="utf-8"/> <title>Youtube TV</title> <linkhref='http://fonts.googleapis.com/css?family=Roboto:500,400'rel='stylesheet'type='text/css'/> <linkhref="css/normalize.css"rel="stylesheet"type="text/css"/> <linkhref="css/styles.css"rel="stylesheet"type="text/css"/> </head> <body> <divid="serverInfo"> <h1>Youtube TV</h1> </div> <divid="videoPlayer"> </div> <script src="js/jquery-1.11.1.min.js"></script> <script src="js/youtube.js"></script> <script src="js/app.js"></script> </body> </html> As you may have noticed, we are using three scripts for our app: jQuery (pretty well known at this point), a Youtube video player, and finally app.js, which contains our app's logic. Let’s dive into that! First of all, we need to create the basic elements for our remote control. The easiest way of doing this is to create a basic web server and serve a small web app that can search Youtube, select a video, and have some play/pause controls so we don’t have any good reasons to get up from the couch. Open js/app.js and type the following: // Show the Developer Tools. And yes, Node-Webkit has developer tools built in! Uncomment it to open it automatically//require('nw.gui').Window.get().showDevTools(); // Express is a web server, will will allow us to create a small web app with which to control the playervar express = require('express'); var app = express(); var server = require('http').Server(app); var io = require('socket.io')(server); // We'll be opening up our web server on Port 8080 (which doesn't require root privileges)// You can access this server at http://127.0.0.1:8080var serverPort =8080; server.listen(serverPort); // All the static files (css, js, html) for the remote will be served using Express.// These assets are in the /remote folderapp.use('/', express.static('remote')); With those 7 lines of code (not counting comments) we just got a neat web server working on port 8080. If you were paying attention to the code, you may have noticed that we required something called socket.io. This lets us use websockets with minimal effort, which means we can communicate with, from, and to our remote instantly. You can learn more about socket.io at http://socket.io/. Let’s set that up next in app.js: // Socket.io handles the communication between the remote and our app in real time, // so we can instantly send commands from a computer to our remote and backio.on('connection', function (socket) { // When a remote connects to the app, let it know immediately the current status of the video (play/pause)socket.emit('statusChange', Youtube.status); // This is what happens when we receive the watchVideo command (picking a video from the list)socket.on('watchVideo', function (video) { // video contains a bit of info about our video (id, title, thumbnail)// Order our Youtube Player to watch that video Youtube.watchVideo(video); }); // These are playback controls. They receive the “play” and “pause” events from the remotesocket.on('play', function () { Youtube.playVideo(); }); socket.on('pause', function () { Youtube.pauseVideo(); }); }); // Notify all the remotes when the playback status changes (play/pause)// This is done with io.emit, which sends the same message to all the remotesYoutube.onStatusChange =function(status) { io.emit('statusChange', status); }; That’s the desktop part done! In a few dozen lines of code we got a web server running at http://127.0.0.1:8080 that can receive commands from a remote to watch a specific video, as well as handling some basic playback controls (play and pause). We are also notifying the remotes of the status of the player as soon as they connect so they can update their UI with the correct buttons (if it’s playing, show the pause button and vice versa). Now we just need to build the remote. Building the remote control The server is just half of the equation. We also need to add the corresponding logic on the remote control, so it’s able to communicate with our app. In remote/index.html, add the following HTML: <!DOCTYPE html><html> <head> <metacharset=“utf-8”/> <title>TV Remote</title> <metaname="viewport"content="width=device-width, initial-scale=1, maximum-scale=1"/> <linkrel="stylesheet"href="/css/normalize.css"/> <linkrel="stylesheet"href="/css/styles.css"/> </head> <body> <divclass="controls"> <divclass="search"> <inputid="searchQuery"type="search"value=""placeholder="Search on Youtube..."/> </div> <divclass="playback"> <buttonclass="play">&gt;</button> <buttonclass="pause">||</button> </div> </div> <divid="results"class="video-list"> </div> <divclass="__templates"style="display:none;"> <articleclass="video"> <figure><imgsrc=""alt=""/></figure> <divclass="info"> <h2></h2> </div> </article> </div> <script src="/socket.io/socket.io.js"></script> <script src="/js/jquery-1.11.1.min.js"></script> <script src="/js/search.js"></script> <script src="/js/remote.js"></script> </body> </html> Again, we have a few libraries: Socket.io is served automatically by our desktop app at /socket.io/socket.io.js, and it manages the communication with the server. jQuery is somehow always there, search.js manages the integration with the Youtube API (you can take a look if you want), and remote.js handles the logic for the remote. The remote itself is pretty simple. It can look for videos on Youtube, and when we click on a video it connects with the app, telling it to play the video with socket.emit. Let’s dive into remote/js/remote.js to make this thing work: // First of all, connect to the server (our desktop app)var socket = io.connect(); // Search youtube when the user stops typing. This gives us an automatic search.var searchTimeout =null; $('#searchQuery').on('keyup', function(event){ clearTimeout(searchTimeout); searchTimeout = setTimeout(function(){ searchYoutube($('#searchQuery').val()); }, 500); }); // When we click on a video, watch it on the App$('#results').on('click', '.video', function(event){ // Send an event to notify the server we want to watch this videosocket.emit('watchVideo', $(this).data()); }); // When the server tells us that the player changed status (play/pause), alter the playback controlssocket.on('statusChange', function(status){ if( status ==='play' ) { $('.playback .pause').show(); $('.playback .play').hide(); } elseif( status ==='pause'|| status ==='stop' ) { $('.playback .pause').hide(); $('.playback .play').show(); } }); // Notify the app when we hit the play button$('.playback .play').on('click', function(event){ socket.emit('play'); }); // Notify the app when we hit the pause button$('.playback .pause').on('click', function(event){ socket.emit('pause'); }); This is very similar to our server, except we are using socket.emit a lot more often to send commands back to our desktop app, telling it which videos to play and handle our basic play/pause controls. The only thing left to do is make the app run. Ready? Go to the terminal again and type: If you are on a Mac: sh run.sh If you are on Windows: run.bat If everything worked properly, you should be both seeing the app and if you open a web browser to http://127.0.0.1:8080 the remote client will open up. Search for a video, pick anything you like, and it’ll play in the app. This also works if you point any other device on the same network to your computer’s IP, which brings me to the next (and last) point. Finishing touches There is one small improvement we can make: print out the computer’s IP to make it easier to connect to the app from any other device on the same Wi-Fi network (like a smartphone). On js/app.js add the following code to find out the IP and update our UI so it’s the first thing we see when we open the app: // Find the local IPfunction getLocalIP(callback) { require('dns').lookup( require('os').hostname(), function (err, add, fam) { typeof callback =='function'? callback(add) :null; }); } // To make things easier, find out the machine's ip and communicate itgetLocalIP(function(ip){ $('#serverInfo h1').html('Go to<br/><strong>http://'+ip+':'+serverPort+'</strong><br/>to open the remote'); }); The next time you run the app, the first thing you’ll see is the IP for your computer, so you just need to type that URL in your smartphone to open the remote and control the player from any computer, tablet, or smartphone (as long as they are in the same Wi-Fi network). That's it! You can start expanding on this to improve the app: Why not open the app on a fullscreen by default? Why not get rid of the horrible default frame and create your own? You can actually designate any div as a window handle with CSS (using -webkit-app-region: drag), so you can drag the window by that div and create your own custom title bar. Summary While the app has a lot of interlocking parts, it's a good first project to find out what you can achieve with node-webkit in just a few minutes. I hope you enjoyed this post! About the author Roberto González is the co-founder of Aerolab, “an awesome place where we really push the barriers to create amazing, well-coded designs for the best digital products”. He can be reached at @robertcode.
Read more
  • 0
  • 0
  • 6647

article-image-understanding-mesos-internals
Packt
08 Jul 2015
26 min read
Save for later

Understanding Mesos Internals

Packt
08 Jul 2015
26 min read
 In this article by, Dharmesh Kakadia, author of the book Apache Mesos Essentials, explains how Mesos works internally in detail. We will start off with cluster scheduling and fairness concepts, understanding the Mesos architecture, and we will move on towards resource isolation and fault tolerance implementation in Mesos. In this article, we will cover the following topics: The Mesos architecture Resource allocation (For more resources related to this topic, see here.) The Mesos architecture Modern organizations have a lot of different kinds of applications for different business needs. Modern applications are distributed and they are deployed across commodity hardware. Organizations today run different applications in siloed environments, where separate clusters are created for different applications. This static partitioning of cluster leads to low utilization, and all the applications will duplicate the effort of dealing with distributed infrastructures. Not only is this a wasted effort, but it also undermines the fact that distributed systems are hard to build and maintain. This is challenging for both developers and operators. For developers, it is a challenge to build applications that scale elastically and can handle faults that are inevitable in large-scale environment. Operators, on the other hand, have to manage and scale all of these applications individually in siloed environments. The preceding situation is like trying to develop applications without having an operating system and managing all the devices in a computer. Mesos solves the problems mentioned earlier by providing a data center kernel. Mesos provides a higher-level abstraction to develop applications that treat distributed infrastructure just like a large computer. Mesos abstracts the hardware infrastructure away from the applications from the physical infrastructure. Mesos makes developers more productive by providing an SDK to easily write data center scale applications. Now, developers can focus on their application logic and do not have to worry about the infrastructure that runs it. Mesos SDK provides primitives to build large-scale distributed systems, such as resource allocation, deployment, and monitoring isolation. They only need to know and implement what resources are needed, and not how they get the resources. Mesos allows you to treat the data center just as a computer. Mesos makes the infrastructure operations easier by providing elastic infrastructure. Mesos aggregates all the resources in a single shared pool of resources and avoids static partitioning. This makes it easy to manage and increases the utilization. The data center kernel has to provide resource allocation, isolation, and fault tolerance in a scalable, robust, and extensible way. We will discuss how Mesos fulfills these requirements, as well as some other important considerations of modern data center kernel: Scalability: The kernel should be scalable in terms of the number of machines and number of applications. As the number of machines and applications increase, the response time of the scheduler should remain acceptable. Flexibility: The kernel should support a wide range of applications. It should also support diverse frameworks currently running on the cluster and future frameworks as well. The framework should also be able to cope up with the heterogeneity in the hardware, as most clusters are built over time and have a variety of hardware running. Maintainability: The kernel would be one of the very important pieces of modern infrastructure. As the requirements evolve, the scheduler should be able to accommodate new requirements. Utilization and dynamism: The kernel should adapt to the changes in resource requirements and available hardware resources and utilize resources in an optimal manner. Fairness: The kernel should be fair in allocating resources to the different users and/or frameworks. We will see what it means to be fair in detail in the next section. The design philosophy behind Mesos was to define a minimal interface to enable efficient resource sharing across frameworks and defer the task scheduling and execution to the frameworks. This allows the frameworks to implement diverse approaches toward scheduling and fault tolerance. It also makes the Mesos core simple, and the frameworks and core can evolve independently. The preceding figure shows the overall architecture (http://mesos.apache.org/documentation/latest/mesos-architecture) of a Mesos cluster. It has the following entities: The Mesos masters The Mesos slaves Frameworks Communication Auxiliary services We will describe each of these entities and their role, followed by how Mesos implements different requirements of the data center kernel. The Mesos slave The Mesos slaves are responsible for executing tasks from frameworks using the resources they have. The slave has to provide proper isolation while running multiple tasks. The isolation mechanism should also make sure that the tasks get resources that they are promised, and not more or less. The resources on slaves that are managed by Mesos can be described using slave resources and slave attributes. Resources are elements of slaves that can be consumed by a task, while we use attributes to tag slaves with some information. Slave resources are managed by the Mesos master and are allocated to different frameworks. Attributes identify something about the node, such as the slave having a specific OS or software version, it's part of a particular network, or it has a particular hardware, and so on. The attributes are simple key-value pairs of strings that are passed along with the offers to frameworks. Since attributes cannot be consumed by a running task, they will always be offered for that slave. Mesos doesn't understand the slave attribute, and interpretation of the attributes is left to the frameworks. More information about resource and attributes in Mesos can be found at https://mesos.apache.org/documentation/attributes-resources. A Mesos resource or attribute can be described as one of the following types: Scalar values are floating numbers Range values are a range of scalar values; they are represented as [minValue-maxValue] Set values are arbitrary strings Text values are arbitrary strings; they are applicable only to attributes Names of the resources can be an arbitrary string consisting of alphabets, numbers, "-", "/", ".", "-". The Mesos master handles the cpus, mem, disk, and ports resources in a special way. A slave without the cpus and mem resources will not be advertised to the frameworks. The mem and disk scalars are interpreted in MB. The ports resource is represented as ranges. The list of resources a slave has to offer to various frameworks can be specified as the resources flag. Resources and attributes are separated by a semicolon. For example: --resources='cpus:30;mem:122880;disk:921600;ports:[21000-29000];bugs:{a,b,c}' --attributes='rack:rack-2;datacenter:europe;os:ubuntuv14.4' This slave offers 30 cpus, 102 GB mem, 900 GB disk, ports from 21000 to 29000, and have bugs a, b, and c. The slave has three attributes: rack with value rack-2, datacenter with value europe, and os with value ubuntu14.4. Mesos does not yet provide direct support for GPUs, but does support custom resource types. This means that if we specify gpu(*):8 as part of --resources, then it will be part of the resource that offers to frameworks. Frameworks can use it just like other resources. Once some of the GPU resources are in use by a task, only the remaining resources will be offered. Mesos does not yet have support for GPU isolation, but it can be extended by implementing a custom isolator. Alternately, we can also specify which slaves have GPUs using attributes, such as --attributes="hasGpu:true". The Mesos master The Mesos master is primarily responsible for allocating resources to different frameworks and managing the task life cycle for them. The Mesos master implements fine-grained resource sharing using resource offers. The Mesos master acts as a resource broker for frameworks using pluggable policies. The master decides to offer cluster resources to frameworks in the form of resource offers based on them. Resources offer represents a unit of allocation in the Mesos world. It's a vector of resource available on a node. An offer represents some resources available on a slave being offered to a particular framework. Frameworks Distributed applications that run on top of Mesos are called frameworks. Frameworks implement the domain requirements using the general resource allocation API of Mesos. A typical framework wants to run a number of tasks. Tasks are the consumers of resources and they do not have to be the same. A framework in Mesos consists of two components: a framework scheduler and executors. Framework schedulers are responsible for coordinating the execution. An executor provides the ability to control the task execution. Executors can realize a task execution in many ways. An executor can choose to run multiple tasks, by spawning multiple threads, in an executor, or it can run one task in each executor. Apart from the life cycle and task management-related functions, the Mesos framework API also provides functions to communicate with framework schedulers and executors. Communication Mesos currently uses an HTTP-like wire protocol to communicate with the Mesos components. Mesos uses the libprocess library to implement the communication that is located in 3rdparty/libprocess. The libprocess library provides asynchronous communication with processes. The communication primitives have an actor message passing, such as semantics. The libprocess messages are immutable, which makes parallelizing the libprocess internals easier. Mesos communication happens along with the following APIs: Scheduler API: This is used to communicate with the framework scheduler and master. The internal communication is intended to be used only by the SchedulerDriver API. Executor API: This is used to communicate with an executor and the Mesos slave. Internal API: This is used to communicate with the Mesos master and slave. Operator API: This is the API exposed by Mesos for operators and is used by web UI, among other things. Unlike most Mesos API, the operator API is a synchronous API. To send a message, the actor does an HTTP POST request. The path is composed by the name of the actor followed by the name of the message. The User-Agent field is set to "libprocess/…" to distinguish from the normal HTTP requests. The message data is passed as the body of the HTTP request. Mesos uses protocol buffers to serialize all the messages (defined in src/messages/messages.proto). The parsing and interpretation of the message is left to the receiving actor. Here is an example header of a message sent to master to register the framework by scheduler(1) running at 10.0.1.7:53523 address: POST /master/mesos.internal.RegisterFrameworkMessage HTTP/1.1 User-Agent: libprocess/scheduler(1)@10.0.1.7:53523 The reply message header from the master that acknowledges the framework registration might look like this: POST /scheduler(1)/mesos.internal.FrameworkRegisteredMessage HTTP/1.1 User-Agent: libprocess/master@10.0.1.7:5050 At the time of writing, there is a very early discussion about rewiring the Mesos Scheduler API and Executor API as a pure HTTP API (https://issues.apache.org/jira/browse/MESOS-2288). This will make the API standard and integration with Mesos for various tools much easier without the need to be dependent on native libmesos. Also, there is an ongoing effort to convert all the internal messages into a standardized JSON or protocol buffer format (https://issues.apache.org/jira/browse/MESOS-1127). Auxiliary services Apart from the preceding main components, a Mesos cluster also needs some auxiliary services. These services are not part of Mesos itself, and are not strictly required, but they form a basis for operating the Mesos cluster in production environments. These services include, but are not limited to, the following: Shared filesystem: Mesos provides a view of the data center as a single computer and allows developers to develop for the data center scale application. With this unified view of resources, clusters need a shared filesystem to truly make the data center a computer. HDFS, NFS (Network File System), and Cloud-based storage options, such as S3, are popular among various Mesos deployments. Consensus service: Mesos uses a consensus service to be resilient in face of failure. Consensus services, such as ZooKeeper or etcd, provide a reliable leader election in a distributed environment. Service fabric: Mesos enables users to run a number of frameworks on unified computing resources. With a large number of applications and services running, it's important for users to be able to connect to them in a seamless manner. For example, how do users connect to Hive running on Mesos? How does the Ruby on Rails application discover and connect to the MongoDB database instances when one or both of them are running on Mesos? How is the website traffic routed to web servers running on Mesos? Answering these questions mainly requires service discovery and load balancing mechanisms, but also things such as IP/port management and security infrastructure. We are collectively referring to these services that connect frameworks to other frameworks and users as service fabric. Operational services: Operational services are essential in managing operational aspects of Mesos. Mesos deployments and upgrades, monitoring cluster health and alerting when human intervention is required, logging, and security are all part of the operational services that play a very important role in a Mesos cluster. Resource allocation As a data center kernel, Mesos serves a large variety of workloads and no single scheduler will be able to satisfy the needs of all different frameworks. For example, the way in which a real-time processing framework schedules its tasks will be very different from how a long running service will schedule its task, which, in turn, will be very different from how a batch processing framework would like to use its resources. This observation leads to a very important design decision in Mesos: separation of resource allocation and task scheduling. Resource allocation is all about deciding who gets what resources, and it is the responsibility of the Mesos master. Task scheduling, on the other hand, is all about how to use the resources. This is decided by various framework schedulers according to their own needs. Another way to understand this would be that Mesos handles coarse-grain resource allocation across frameworks, and then each framework does fine-grain job scheduling via appropriate job ordering to achieve its needs. The Mesos master gets information on the available resources from the Mesos slaves, and based on resource policies, the Mesos master offers these resources to different frameworks. Different frameworks can choose to accept or reject the offer. If the framework accepts a resource offer, the framework allocates the corresponding resources to the framework, and then the framework is free to use them to launch tasks. The following image shows the high-level flow of Mesos resource allocation: Mesos two level scheduler Here is the typical flow of events for one framework in Mesos: The framework scheduler registers itself with the Mesos master. The Mesos master receives the resource offers from slaves. It invokes the allocation module and decides which frameworks should receive the resource offers. The framework scheduler receives the resource offers from the Mesos master. On receiving the resource offers, the framework scheduler inspects the offer to decide whether it's suitable. If it finds it satisfactory, the framework scheduler accepts the offer and replies to the master with the list of executors that should be run on the slave, utilizing the accepted resource offers. Alternatively, the framework can reject the offer and wait for a better offer. The slave allocates the requested resources and launches the task executors. The executor is launched on slave nodes and runs the framework's tasks. It is up to the framework scheduler to accept or reject the resource offers. Here is an example of events that can happen when allocating resources. The framework scheduler gets notified about the task's completion or failure. The framework scheduler will continue receiving the resource offers and task reports and launch tasks as it sees fit. The framework unregisters with the Mesos master and will not receive any further resource offers. Note that this is optional and a long running service, and meta-framework will not unregister during the normal operation. Because of this design, Mesos is also known as a two-level scheduler. Mesos' two-level scheduler design makes it simpler and more scalable, as the resource allocation process does not need to know how scheduling happens. This makes the Mesos core more stable and scalable. Frameworks and Mesos are not tied to each other and each can iterate independently. Also, this makes porting frameworks easier. The choice of a two-level scheduler means that the scheduler does not have a global knowledge about resource utilization and the resource allocation decisions can be nonoptimal. One potential concern could be about the preferences that the frameworks have about the kind of resources needed for execution. Data locality, special hardware, and security constraints can be a few of the constraints on which tasks can run. In the Mesos realm, these preferences are not explicitly specified by a framework to the Mesos master, instead the framework rejects all the offers that do not meet its constraints. The Mesos scheduler Mesos was the first cluster scheduler to allow the sharing of resources to multiple frameworks. Mesos resource allocation is based on online Dominant Resource Fairness (DRF) called HierarchicalDRF. In a world of single resource static partitioning, fairness is easy to define. DRF extends this concept of fairness to multi-resource settings without the need for static partitioning. Resource utilization and fairness are equally important, and often conflicting, goals for a cluster scheduler. The fairness of resource allocation is important in a shared environment, such as data centers, to ensure that all the users/processes of the cluster get nearly an equal amount of resources. Min-max fairness provides a well-known mechanism to share a single resource among multiple users. Min-max fairness algorithm maximizes the minimum resources allocated to a user. In its simplest form, it allocates 1/Nth of the resource to each of the users. The weighted min-max fairness algorithm can also support priorities and reservations. Min-max resource fairness has been a basis for many well-known schedulers in operating systems and distributed frameworks, such as Hadoop's fair scheduler (http://hadoop.apache.org/docs/current/hadoop-yarn/hadoop-yarn-site/FairScheduler.html), capacity scheduler (https://hadoop.apache.org/docs/r2.4.1/hadoop-yarn/hadoop-yarn-site/CapacityScheduler.html), Quincy scheduler (http://dl.acm.org/citation.cfm?id=1629601), and so on. However, it falls short when the cluster has multiple types of resources, such as the CPU, memory, disk, and network. When jobs in a distributed environment use different combinations of these resources to achieve the outcome, the fairness has to be redefined. For example, the two requests <1 CPU, 3 GB> and <3 CPU, 1 GB> come to the scheduler. How do they compare and what is the fair allocation? DRF generalizes the min-max algorithm for multiple resources. A user's dominant resource is the resource for which the user has a biggest share. For example, if the total resources are <8 CPU, 5 GB>, then for the user allocation of <2 CPU, 1 GB>, the user's dominant share is maximumOf(2/8,1/5) means CPU. A user's dominant share is the fraction of the dominant resource that's allocated to the user. In our example, it would be 25 percent (2/8). DRF applies the min-max algorithm to the dominant share of each user. It has many provable properties: Strategy proofness: A user cannot gain any advantage by lying about the demands. Sharing incentive: DRF has a minimum allocation guarantee for each user, and no user will prefer exclusive partitioned cluster of size 1/N over DRF allocation. Single resource fairness: In case of only one resource, DRF is equivalent to the min-max algorithm. Envy free: Every user prefers his allocation over any other allocation of other users. This also means that the users with the same requests get equivalent allocations. Bottleneck fairness: When one resource becomes a bottleneck, and each user has a dominant demand for it, DRF is equivalent to min-max. Monotonicity: Adding resources or removing users can only increase the allocation of the remaining users. Pareto efficiency: The allocation achieved by DRF will be pareto efficient, so it would be impossible to make a better allocation for any user without making allocation for some other user worse. We will not further discuss DRF but will encourage you to refer to the DRF paper for more details at http://static.usenix.org/event/nsdi11/tech/full_papers/Ghodsi.pdf. Mesos uses role specified in FrameworkInfo for resource allocation decision. A role can be per user or per framework or can be shared by multiple users and frameworks. If it's not set, Mesos will set it to the current user that runs the framework scheduler. An optimization is to use deny resource offers from particular slaves for a specified time period. Mesos can revoke tasks allocation killing those tasks. Before killing a task, Mesos gives the framework a grace period to clean up. Mesos asks the executor to kill the task, but if it does not oblige the request, it will kill the executor and all of its tasks. Weighted DRF DRF calculates each role's dominant share and allocates the available resources to the user with the smallest dominant share. In practice, an organization rarely wants to assign resources in a complete fair manner. Most organizations want to allocate resources in a weighted manner, such as 50 percent resources to ads team, 30 percent to QA, and 20 percent to R&D teams. To satisfy this command functionality, Mesos implements weighted DRF, where masters can be configured with weights for different roles. When weights are specified, a client's DRF share will be divided by the weight. For example, a role that has a weight of two will be offered twice as many resources as a role with weight of one. Mesos can be configured to use weighted DRF using the --weights and --roles flags on the master startup. The --weights flag expects a list of role/weight pairs in the form of role1=weight1 and role2=weight2. Weights do not need to be integers. We must provide weights for each role that appear in --roles on the master startup. Reservation One of the other most asked questions for requirement is the ability to reserve resources. For example, persistent or stateful services, such as memcache, or a database running on Mesos, would need a reservation mechanism to avoid being negatively affected on restart. Without reservation, memcache is not guaranteed to get a resource offer from the slave, which has all the data and would incur significant time in initialization and downtime for the service. Reservation can also be used to limit the resource per role. Reservation provides guaranteed resources for roles, but improper usage might lead to resource fragmentation and lower utilization of resources. Note that all the reservation requests go through a Mesos authorization mechanism to ensure that the operator or framework requesting the operation has the proper privileges. Reservation privileges are specified to the Mesos master through ACL along with the rest of the ACL configuration. Mesos supports the following two kinds of reservation: Static reservation Dynamic reservation Static reservation In static reservation, resources are reserved for a particular role. The restart of the slave after removing the checkpointed state is required to change static reservation. Static reservation is thus typically managed by operators using the --resources flag on the slave. The flag expects a list of name(role):value for different resources. If a resource is assigned to role A, then only frameworks with role A are eligible to get an offer for that resource. Any resources that do not include a role or resources that are not included in the --resources flag will be included in the default role (default *). For example, --resources="cpus:4;mem:2048;cpus(ads):8;mem(ads):4096" specifies that the slave has 8 CPUs and 4096 MB memory reserved for "ads" role and has 4 CPUs and 2048 MB memory unreserved. Nonuniform static reservation across slaves can quickly become difficult to manage. Dynamic reservation Dynamic reservation allows operators and frameworks to manage reservation more dynamically. Frameworks can use dynamic reservations to reserve offered resources, allowing those resources to only be reoffered to the same framework. At the time of writing, dynamic reservation is still being actively developed and is targeted toward the next release of Mesos (https://issues.apache.org/jira/browse/MESOS-2018). When asked for a reservation, Mesos will try to convert the unreserved resources to reserved resources. On the other hand, during the unreserve operation, the previously reserved resources are returned to the unreserved pool of resources. To support dynamic reservation, Mesos allows a sequence of Offer::Operations to be performed as a response to accepting resource offers. A framework manages reservation by sending Offer::Operations::Reserve and Offer::Operations::Unreserve as part of these operations, when receiving resource offers. For example, consider the framework that receives the following resource offer with 32 CPUs and 65536 MB memory: {   "id" : <offer_id>,   "framework_id" : <framework_id>,   "slave_id" : <slave_id>,   "hostname" : <hostname>,   "resources" : [     {       "name" : "cpus",       "type" : "SCALAR",       "scalar" : { "value" : 32 },       "role" : "*",     },     {       "name" : "mem",       "type" : "SCALAR",       "scalar" : { "value" : 65536 },       "role" : "*",     }   ] } The framework can decide to reserve 8 CPUs and 4096 MB memory by sending the Operation::Reserve message with resources field with the desired resources state: [   {     "type" : Offer::Operation::RESERVE,     "resources" : [       {         "name" : "cpus",         "type" : "SCALAR",         "scalar" : { "value" : 8 },         "role" : <framework_role>,         "reservation" : {           "framework_id" : <framework_id>,           "principal" : <framework_principal>         }       }       {         "name" : "mem",         "type" : "SCALAR",         "scalar" : { "value" : 4096 },         "role" : <framework_role>,         "reservation" : {           "framework_id" : <framework_id>,           "principal" : <framework_principal>         }       }     ]   } ] After a successful execution, the framework will receive resource offers with reservation. The next offer from the slave might look as follows: {   "id" : <offer_id>,   "framework_id" : <framework_id>,   "slave_id" : <slave_id>,   "hostname" : <hostname>,   "resources" : [     {       "name" : "cpus",       "type" : "SCALAR",       "scalar" : { "value" : 8 },       "role" : <framework_role>,       "reservation" : {         "framework_id" : <framework_id>,         "principal" : <framework_principal>       }     },     {       "name" : "mem",       "type" : "SCALAR",       "scalar" : { "value" : 4096 },       "role" : <framework_role>,       "reservation" : {         "framework_id" : <framework_id>,         "principal" : <framework_principal>       }     },     {       "name" : "cpus",       "type" : "SCALAR",       "scalar" : { "value" : 24 },       "role" : "*",     },     {       "name" : "mem",       "type" : "SCALAR",       "scalar" : { "value" : 61440 },       "role" : "*",     }   ] } As shown, the framework has 8 CPUs and 4096 MB memory reserved resources and 24 CPUs and 61440 MB memory underserved in the resource offer. The unreserve operation is similar. The framework on receiving the resource offer can send the unreserve operation message, and subsequent offers will not have reserved resources. The operators can use/reserve and/unreserve HTTP endpoints of the operator API to manage the reservation. The operator API allows operators to change the reservation specified when the slave starts. For example, the following command will reserve 4 CPUs and 4096 MB memory on slave1 for role1 with the operator authentication principal ops: ubuntu@master:~ $ curl -d slaveId=slave1 -d resources="{          {            "name" : "cpus",            "type" : "SCALAR",            "scalar" : { "value" : 4 },            "role" : "role1",            "reservation" : {              "principal" : "ops"            }          },          {            "name" : "mem",            "type" : "SCALAR",            "scalar" : { "value" : 4096 },            "role" : "role1",            "reservation" : {              "principal" : "ops"            }          },        }"        -X POST http://master:5050/master/reserve Before we end this discussion on resource allocation, it would be important to note that the Mesos community continues to innovate on the resource allocation front by incorporating interesting ideas, such as oversubscription (https://issues.apache.org/jira/browse/MESOS-354), from academic literature and other systems. Summary In this article, we looked at the Mesos architecture in detail and learned how Mesos deals with resource allocation, resource isolation, and fault tolerance. We also saw the various ways in which we can extend Mesos. Resources for Article: Further resources on this subject: Recommender systems dissected Tuning Solr JVM and Container [article] Transformation [article] Getting Started [article]
Read more
  • 0
  • 0
  • 5733

article-image-integrating-google-play-services
Packt
08 Jul 2015
41 min read
Save for later

Integrating Google Play Services

Packt
08 Jul 2015
41 min read
In this article Integrating Google Play Services by Raul Portales, author of the book Mastering Android Game Development, we will cover the tools that Google Play Services offers for game developers. We'll see the integration of achievements and leaderboards in detail, take an overview of events and quests, save games, and use turn-based and real-time multiplaying. Google provides Google Play Services as a way to use special features in apps. Being the game services subset the one that interests us the most. Note that Google Play Services are updated as an app that is independent from the operating system. This allows us to assume that most of the players will have the latest version of Google Play Services installed. (For more resources related to this topic, see here.) More and more features are being moved from the Android SDK to the Play Services because of this. Play Services offer much more than just services for games, but there is a whole section dedicated exclusively to games, Google Play Game Services (GPGS). These features include achievements, leaderboards, quests, save games, gifts, and even multiplayer support. GPGS also comes with a standalone app called "Play Games" that shows the user the games he or she has been playing, the latest achievements, and the games his or her friends play. It is a very interesting way to get exposure for your game. Even as a standalone feature, achievements and leaderboards are two concepts that most games use nowadays, so why make your own custom ones when you can rely on the ones made by Google? GPGS can be used on many platforms: Android, iOS and web among others. It is more used on Android, since it is included as a part of Google apps. There is extensive step-by-step documentation online, but the details are scattered over different places. We will put them together here and link you to the official documentation for more detailed information. For this article, you are supposed to have a developer account and have access to the Google Play Developer Console. It is also advisable for you to know the process of signing and releasing an app. If you are not familiar with it, there is very detailed official documentation at http://developer.android.com/distribute/googleplay/start.html. There are two sides of GPGS: the developer console and the code. We will alternate from one to the other while talking about the different features. Setting up the developer console Now that we are approaching the release state, we have to start working with the developer console. The first thing we need to do is to get into the Game services section of the console to create and configure a new game. In the left menu, we have an option labeled Game services. This is where you have to click. Once in the Game services section, click on Add new game: This bring us to the set up dialog. If you are using other Google services like Google Maps or Google Cloud Messaging (GCM) in your game, you should select the second option and move forward. Otherwise, you can just fill in the fields for I don't use any Google APIs on my game yet and continue. If you don't know whether you are already using them, you probably aren't. Now, it is time to link a game to it. I recommend you publish your game beforehand as an alpha release. This will let you select it from the list when you start typing the package name. Publishing the game to the alpha channel before adding it to Game services makes it much easier to configure. If you are not familiar with signing and releasing your app, check out the official documentation at http://developer.android.com/tools/publishing/app-signing.html. Finally, there are only two steps that we have to take when we link the first app. We need to authorize it and provide branding information. The authorization will generate an OAuth key—that we don't need to use since it is required for other platforms—and also a game ID. This ID is unique to all the linked apps and we will need it to log in. But there is no need to write it down now, it can be found easily in the console at anytime. Authorizing the app will generate the game ID, which is unique to all linked apps. Note that the app we have added is configured with the release key. If you continue and try the login integration, you will get an error telling you that the app was signed with the wrong certificate: You have two ways to work with this limitation: Always make a release build to test GPGS integration Add your debug-signed game as a linked app I recommend that you add the debug signed app as a linked app. To do this, we just need to link another app and configure it with the SHA1 fingerprint of the debug key. To obtain it, we have to open a terminal and run the keytool utility: keytool -exportcert -alias androiddebugkey -keystore <path-to-debug-keystore> -list -v Note that in Windows, the debug keystore can be found at C:Users<USERNAME>.androiddebug.keystore. On Mac and Linux, the debug keystore is typically located at ~/.android/debug.keystore. Dialog to link the debug application on the Game Services console Now, we have the game configured. We could continue creating achievements and leaderboards in the console, but we will put it aside and make sure that we can sign in and connect with GPGS. The only users who can sign in to GPGS while a game is not published are the testers. You can make the alpha and/or beta testers of a linked app become testers of the game services, and you can also add e-mail addresses by hand for this. You can modify this in the Testing tab. Only test accounts can access a game that is not published. The e-mail of the owner of the developer console is prefilled as a tester. Just in case you have problems logging in, double-check the list of testers. A game service that is not published will not appear in the feed of the Play Services app, but it will be possible to test and modify it. This is why it is a good idea to keep it in draft mode until the game itself is ready and publish both the game and the game services at the same time. Setting up the code The first thing we need to do is to add the Google Play Services library to our project. This should already have been done by the wizard when we created the project, but I recommend you to double-check it now. The library needs to be added to the build.gradle file of the main module. Note that Android Studio projects contain a top-level build.gradle and a module-level build.gradle for each module. We will modify the one that is under the mobile module. Make sure that the play services' library is listed under dependencies: apply plugin: 'com.android.application'     dependencies { compile 'com.android.support:appcompat-v7:22.1.1' compile 'com.google.android.gms:play-services:7.3.0' } At the point of writing, the latest version is 7.3.0. The basic features have not changed much and they are unlikely to change. You could force Gradle to use a specific version of the library, but in general I recommend you use the latest version. Once you have it, save the changes and click on Sync Project with Gradle Files. To be able to connect with GPGS, we need to let the game know what the game ID is. This is done through the <meta-data> tag on AndroidManifest.xml. You could hardcode the value here, but it is highly recommended that you set it as a resource in your Android project. We are going to create a new file for this under res/values, which we will name play_services.xml. In this file we will put the game ID, but later we will also have the achievements and leaderboard IDs in it. Using a separate file for these values is recommended because they are constants that do not need to be translated: <application> <meta-data android_name="com.google.android.gms.games.APP_ID" android_value="@string/app_id" /> <meta-data android_name="com.google.android.gms.version" android_value="@integer/google_play_services_version"/> [...] </application> Adding this metadata is extremely important. If you forget to update the AndroidManifest.xml, the app will crash when you try to sign in to Google Play services. Note that the integer for the gms version is defined in the library and we do not need to add it to our file. If you forget to add the game ID to the strings the app will crash. Now, it is time to proceed to sign in. The process is quite tedious and requires many checks, so Google has released an open source project named BaseGameUtils, which makes it easier. Unfortunately this project is not a part of the play services' library and it is not even available as a library. So, we have to get it from GitHub (either check it out or download the source as a ZIP file). BaseGameUtils abstracts us from the complexity of handling the connection with Play Services. Even more cumbersome, BaseGameUtils is not available as a standalone download and has to be downloaded together with another project. The fact that this significant piece of code is not a part of the official library makes it quite tedious to set up. Why it has been done like this is something that I do not comprehend myself. The project that contains BaseGameUtils is called android-basic-samples and it can be downloaded from https://github.com/playgameservices/android-basic-samples. Adding BaseGameUtils is not as straightforward as we would like it to be. Once android-basic-samples is downloaded, open your game project in Android Studio. Click on File > Import Module and navigate to the directory where you downloaded android-basic-samples. Select the BaseGameUtils module in the BasicSamples/libraries directory and click on OK. Finally, update the dependencies in the build.gradle file for the mobile module and sync gradle again: dependencies { compile project(':BaseGameUtils') [...] } After all these steps to set up the project, we are finally ready to begin the sign in. We will make our main Activity extend from BaseGamesActivity, which takes care of all the handling of the connections, and sign in with Google Play Services. One more detail: until now, we were using Activity and not FragmentActivity as the base class for YassActivity (BaseGameActivity extends from FragmentActivity) and this change will mess with the behavior of our dialogs while calling navigateBack. We can change the base class of BaseGameActivity or modify navigateBack to perform a pop-on fragment navigation hierarchy. I recommend the second approach: public void navigateBack() { // Do a pop on the navigation history getFragmentManager().popBackStack(); } This util class has been designed to work with single-activity games. It can be used in multiple activities, but it is not straightforward. This is another good reason to keep the game in a single activity. The BaseGameUtils is designed to be used in single-activity games. The default behavior of BaseGameActivity is to try to log in each time the Activity is started. If the user agrees to sign in, the sign in will happen automatically. But if the user rejects doing so, he or she will be asked again several times. I personally find this intrusive and annoying, and I recommend you to only prompt to log in to Google Play services once (and again, if the user logs out). We can always provide a login entry point in the app. This is very easy to change. The default number of attempts is set to 3 and it is a part of the code of GameHelper: // Should we start the flow to sign the user in automatically on   startup? If // so, up to // how many times in the life of the application? static final int DEFAULT_MAX_SIGN_IN_ATTEMPTS = 3; int mMaxAutoSignInAttempts = DEFAULT_MAX_SIGN_IN_ATTEMPTS; So, we just have to configure it for our activity, adding one line of code during onCreate to change the default behavior with the one we want: just try it once: getGameHelper().setMaxAutoSignInAttempts(1); Finally, there are two methods that we can override to act when the user successfully logs in and when there is a problem: onSignInSucceeded and onSignInFailed. We will use them when we update the main menu at the end of the article. Further use of GPGS is to be made via the GameHelper and/or the GoogleApiClient, which is a part of the GameHelper. We can obtain a reference to the GameHelper using the getGameHelper method of BaseGameActivity. Now that the user can sign into Google Play services we can continue with achievements and leaderboards. Let's go back to the developer console. Achievements We will first define a few achievements in the developer console and then see how to unlock them in the game. Note that to publish any game with GPGS, you need to define at least five achievements. No other feature is mandatory, but achievements are. We need to define at least five achievements to publish a game with Google Play Game services. If you want to use GPGS with a game that has no achievements, I recommend you to add five dummy secret achievements and let them be. To add an achievement, we just need to navigate to the Achievements tab on the left and click on Add achievement: The menu to add a new achievement has a few fields that are mostly self-explanatory. They are as follows: Name: the name that will be shown (can be localized to different languages). Description: the description of the achievement to be shown (can also be localized to different languages). Icon: the icon of the achievement as a 512x512 px PNG image. This will be used to show the achievement in the list and also to generate the locked image and the in-game popup when it is unlocked. Incremental achievements: if the achievement requires a set of steps to be completed, it is called an incremental achievement and can be shown with a progress bar. We will have an incremental achievement to illustrate this. Initial state: Revealed/Hidden depending on whether we want the achievement to be shown or not. When an achievement is shown, the name and description are visible, players know what they have to do to unlock it. A hidden achievement, on the other hand, is a secret and can be a funny surprise when unlocked. We will have two secret achievements. Points: GPGS allows each game to have 1,000 points to give for unlocking achievements. This gets converted to XP in the player profile on Google Play games. This can be used to highlight that some achievements are harder than others, and therefore grant a bigger reward. You cannot change these once they are published, so if you plan to have more achievements in the future, plan ahead with the points. List order: The order of the achievements is shown. It is not followed all the time, since on the Play Games app the unlocked ones are shown before the locked ones. It is still handy to rearrange them. Dialog to add an achievement on the developer console As we already decided, we will have five achievements in our game and they will be as follows: Big Score: score over 100,000 points in one game. This is to be granted while playing. Asteroid killer: destroy 100 asteroids. This will count them across different games and is an incremental achievement. Survivor: survive for 60 seconds. Target acquired: a hidden achievement. Hit 20 asteroids in a row without missing a hit. This is meant to reward players that only shoot when they should. Target lost: this is supposed to be a funny achievement, granted when you miss with 10 bullets in a row. It is also hidden, because otherwise it would be too easy to unlock. So, we created some images for them and added them to the console. The developer console with all the configured achievements Each achievement has a string ID. We will need these ids to unlock the achievements in our game, but Google has made it easy for us. We have a link at the bottom named Get resources that pops up a dialog with the string resources we need. We can just copy them from there and paste them in our project in the play_services.xml file we have already created. Architecture For our game, given that we only have five achievements, we are going to add the code for achievements directly into the ScoreObject. This will make it less code for you to read so we can focus on how it is done. However, for a real production code I recommend you define a dedicated architecture for achievements. The recommended architecture is to have an AchievementsManager class that loads all the achievements when the game starts and stores them in three lists: All achievements Locked achievements Unlocked achievements Then, we have an Achievement base class with an abstract check method that we implement for each one of them: public boolean check (GameEngine gameEngine, GameEvent gameEvent) { } This base class takes care of loading the achievement state from local storage (I recommend using SharedPreferences for this) and modify it as per the result of check. The achievements check is done at AchievementManager level using a checkLockedAchievements method that iterates over the list of achievements that can be unlocked. This method should be called as a part of onEventReceived of GameEngine. This architecture allows you to check only the achievements that are yet to be unlocked and also all the achievements included in the game in a specific dedicated place. In our case, since we are keeping the score inside the ScoreGameObject, we are going to add all achievements code there. Note that making the GameEngine take care of the score and having it as a variable that other objects can read are also recommended design patterns, but it was simpler to do this as a part of ScoreGameObject. Unlocking achievements To handle achievements, we need to have access to an object of the class GoogleApiClient. We can get a reference to it in the constructor of ScoreGameObject: private final GoogleApiClient mApiClient;   public ScoreGameObject(YassBaseFragment parent, View view, int viewResId) { […] mApiClient =  parent.getYassActivity().getGameHelper().getApiClient(); } The parent Fragment has a reference to the Activity, which has a reference to the GameHelper, which has a reference to the GoogleApiClient. Unlocking an achievement requires just a single line of code, but we also need to check whether the user is connected to Google Play services or not before trying to unlock an achievement. This is necessary because if the user has not signed it, an exception is thrown and the game crashes. Unlocking an achievement requires just a single line of code. But this check is not enough. In the edge case, when the user logs out manually from Google Play services (which can be done in the achievements screen), the connection will not be closed and there is no way to know whether he or she has logged out. We are going to create a utility method to unlock the achievements that does all the checks and also wraps the unlock method into a try/catch block and make the API client disconnect if an exception is raised: private void unlockSafe(int resId) { if (mApiClient.isConnecting() || mApiClient.isConnected()) {    try {      Games.Achievements.unlock(mApiClient, getString(resId));    } catch (Exception e) {      mApiClient.disconnect();    } } } Even with all the checks, the code is still very simple. Let's work on the particular achievements we have defined for the game. Even though they are very specific, the methodology to track game events and variables and then check for achievements to unlock is in itself generic, and serves as a real-life example of how to deal with achievements. The achievements we have designed require us to count some game events and also the running time. For the last two achievements, we need to make a new GameEvent for the case when a bullet misses, which we have not created until now. The code in the Bullet object to trigger this new GameEvent is as follows: @Override public void onUpdate(long elapsedMillis, GameEngine gameEngine) { mY += mSpeedFactor * elapsedMillis; if (mY < -mHeight) {    removeFromGameEngine(gameEngine);    gameEngine.onGameEvent(GameEvent.BulletMissed); } } Now, let's work inside ScoreGameObject. We are going to have a method that checks achievements each time an asteroid is hit. There are three achievements that can be unlocked when that event happens: Big score, because hitting an asteroid gives us points Target acquired, because it requires consecutive asteroid hits Asteroid killer, because it counts the total number of asteroids that have been destroyed The code is like this: private void checkAsteroidHitRelatedAchievements() { if (mPoints > 100000) {    // Unlock achievement    unlockSafe(R.string.achievement_big_score); } if (mConsecutiveHits >= 20) {    unlockSafe(R.string.achievement_target_acquired); } // Increment achievement of asteroids hit if (mApiClient.isConnecting() || mApiClient.isConnected()) {    try {      Games.Achievements.increment(mApiClient, getString(R.string.achievement_asteroid_killer), 1);    } catch (Exception e) {      mApiClient.disconnect();    } } } We check the total points and the number of consecutive hits to unlock the corresponding achievements. The "Asteroid killer" achievement is a bit of a different case, because it is an incremental achievement. These type of achievements do not have an unlock method, but rather an increment method. Each time we increment the value, progress on the achievement is updated. Once the progress is 100 percent, it is unlocked automatically. Incremental achievements are automatically unlocked, we just have to increment their value. This makes incremental achievements much easier to use than tracking the progress locally. But we still need to do all the checks as we did for unlockSafe. We are using a variable named mConsecutiveHits, which we have not initialized yet. This is done inside onGameEvent, which is the place where the other hidden achievement target lost is checked. Some initialization for the "Survivor" achievement is also done here: public void onGameEvent(GameEvent gameEvent) { if (gameEvent == GameEvent.AsteroidHit) {    mPoints += POINTS_GAINED_PER_ASTEROID_HIT;    mPointsHaveChanged = true;    mConsecutiveMisses = 0;    mConsecutiveHits++;    checkAsteroidHitRelatedAchievements(); } else if (gameEvent == GameEvent.BulletMissed) {    mConsecutiveMisses++;    mConsecutiveHits = 0;    if (mConsecutiveMisses >= 20) {      unlockSafe(R.string.achievement_target_lost);    } } else if (gameEvent == GameEvent.SpaceshipHit) {    mTimeWithoutDie = 0; } […] } Each time we hit an asteroid, we increment the number of consecutive asteroid hits and reset the number of consecutive misses. Similarly, each time we miss a bullet, we increment the number of consecutive misses and reset the number of consecutive hits. As a side note, each time the spaceship is destroyed we reset the time without dying, which is used for "Survivor", but this is not the only time when the time without dying should be updated. We have to reset it when the game starts, and modify it inside onUpdate by just adding the elapsed milliseconds that have passed: @Override public void startGame(GameEngine gameEngine) { mTimeWithoutDie = 0; […] }   @Override public void onUpdate(long elapsedMillis, GameEngine gameEngine) { mTimeWithoutDie += elapsedMillis; if (mTimeWithoutDie > 60000) {    unlockSafe(R.string.achievement_survivor); } } So, once the game has been running for 60,000 milliseconds since it started or since a spaceship was destroyed, we unlock the "Survivor" achievement. With this, we have all the code we need to unlock the achievements we have created for the game. Let's finish this section with some comments on the system and the developer console: As a rule of thumb, you can edit most of the details of an achievement until you publish it to production. Once your achievement has been published, it cannot be deleted. You can only delete an achievement in its prepublished state. There is a button labeled Delete at the bottom of the achievement screen for this. You can also reset the progress for achievements while they are in draft. This reset happens for all players at once. There is a button labeled Reset achievement progress at the bottom of the achievement screen for this. Also note that GameBaseActivity does a lot of logging. So, if your device is connected to your computer and you run a debug build, you may see that it lags sometimes. This does not happen in a release build for which the log is removed. Leaderboards Since YASS has only one game mode and one score in the game, it makes sense to have only one leaderboard on Google Play Game Services. Leaderboards are managed from their own tab inside the Game services area of the developer console. Unlike achievements, it is not mandatory to have any leaderboard to be able to publish your game. If your game has different levels of difficulty, you can have a leaderboard for each of them. This also applies if the game has several values that measure player progress, you can have a leaderboard for each of them. Managing leaderboards on Play Games console Leaderboards can be created and managed in the Leaderboards tag. When we click on Add leaderboard, we are presented with a form that has several fields to be filled. They are as follows: Name: the display name of the leaderboard, which can be localized. We will simply call it High Scores. Score formatting: this can be Numeric, Currency, or Time. We will use Numeric for YASS. Icon: a 512x512 px icon to identify the leaderboard. Ordering: Larger is better / Smaller is better. We are going to use Larger is better, but other score types may be Smaller is better as in a racing game. Enable tamper protection: this automatically filters out suspicious scores. You should keep this on. Limits: if you want to limit the score range that is shown on the leaderboard, you can do it here. We are not going to use this List order: the order of the leaderboards. Since we only have one, it is not really important for us. Setting up a leaderboard on the Play Games console Now that we have defined the leaderboard, it is time to use it in the game. As happens with achievements, we have a link where we can get all the resources for the game in XML. So, we proceed to get the ID of the leaderboard and add it to the strings defined in the play_services.xml file. We have to submit the scores at the end of the game (that is, a GameOver event), but also when the user exits a game via the pause button. To unify this, we will create a new GameEvent called GameFinished that is triggered after a GameOver event and after the user exits the game. We will update the stopGame method of GameEngine, which is called in both cases to trigger the event: public void stopGame() { if (mUpdateThread != null) {    synchronized (mLayers) {      onGameEvent(GameEvent.GameFinished);    }    mUpdateThread.stopGame();  mUpdateThread = null; } […] } We have to set the updateThread to null after sending the event, to prevent this code being run twice. Otherwise, we could send each score more than once. Similarly, as happens for achievements, submitting a score is very simple, just a single line of code. But we also need to check that the GoogleApiClient is connected and we still have the same edge case when an Exception is thrown. So, we need to wrap it in a try/catch block. To keep everything in the same place, we will put this code inside ScoreGameObject: @Override public void onGameEvent(GameEvent gameEvent) { […] else if (gameEvent == GameEvent.GameFinished) {    // Submit the score    if (mApiClient.isConnecting() || mApiClient.isConnected()) {      try {        Games.Leaderboards.submitScore(mApiClient,          getLeaderboardId(), mPoints);      }      catch (Exception e){        mApiClient.disconnect();      }    } } }   private String getLeaderboardId() { return mParent.getString(R.string.leaderboard_high_scores); } This is really straightforward. GPGS is now receiving our scores and it takes care of the timestamp of the score to create daily, weekly, and all time leaderboards. It also uses your Google+ circles to show the social score of your friends. All this is done automatically for you. The final missing piece is to let the player open the leaderboards and achievements UI from the main menu as well as trigger a sign in if they are signed out. Opening the Play Games UI To complete the integration of achievements and leaderboards, we are going to add buttons to open the native UI provided by GPGS to our main menu. For this, we are going to place two buttons in the bottom–left corner of the screen, opposite the music and sound buttons. We will also check whether we are connected or not; if not, we will show a single sign-in button. For these buttons we will use the official images of GPGS, which are available for developers to use. Note that you must follow the brand guidelines while using the icons and they must be displayed as they are and not modified. This also provides a consistent look and feel across all the games that support Play Games. Since we have seen a lot of layouts already, we are not going to include another one that is almost the same as something we already have. The main menu with the buttons to view achievements and leaderboards. To handle these new buttons we will, as usual, set the MainMenuFragment as OnClickListener for the views. We do this in the same place as the other buttons, that is, inside onViewCreated: @Override public void onViewCreated(View view, Bundle savedInstanceState) { super.onViewCreated(view, savedInstanceState); [...] view.findViewById(    R.id.btn_achievements).setOnClickListener(this); view.findViewById(    R.id.btn_leaderboards).setOnClickListener(this); view.findViewById(R.id.btn_sign_in).setOnClickListener(this); } As happened with achievements and leaderboards, the work is done using static methods that receive a GoogleApiClient object. We can get this object from the GameHelper that is a part of the BaseGameActivity, like this: GoogleApiClient apiClient = getYassActivity().getGameHelper().getApiClient(); To open the native UI, we have to obtain an Intent and then start an Activity with it. It is important that you use startActivityForResult, since some data is passed back and forth. To open the achievements UI, the code is like this: Intent achievementsIntent = Games.Achievements.getAchievementsIntent(apiClient); startActivityForResult(achievementsIntent, REQUEST_ACHIEVEMENTS); This works out of the box. It automatically grays out the icons for the unlocked achievements, adds a counter and progress bar to the one that is in progress, and a padlock to the hidden ones. Similarly, to open the leaderboards UI we obtain an intent from the Games.Leaderboards class instead: Intent leaderboardsIntent = Games.Leaderboards.getLeaderboardIntent( apiClient, getString(R.string.leaderboard_high_scores)); startActivityForResult(leaderboardsIntent, REQUEST_LEADERBOARDS); In this case, we are asking for a specific leaderboard, since we only have one. We could use getLeaderboardsIntent instead, which will open the Play Games UI for the list of all the leaderboards. We can have an intent to open the list of leaderboards or a specific one. What remains to be done is to replace the buttons for the login one when the user is not connected. For this, we will create a method that reads the state and shows and hides the views accordingly: private void updatePlayButtons() { GameHelper gameHelper = getYassActivity().getGameHelper(); if (gameHelper.isConnecting() || gameHelper.isSignedIn()) {    getView().findViewById(      R.id.btn_achievements).setVisibility(View.VISIBLE);    getView().findViewById(      R.id.btn_leaderboards).setVisibility(View.VISIBLE);    getView().findViewById(      R.id.btn_sign_in).setVisibility(View.GONE); } else {    getView().findViewById(      R.id.btn_achievements).setVisibility(View.GONE);    getView().findViewById(      R.id.btn_leaderboards).setVisibility(View.GONE);    getView().findViewById(      R.id.btn_sign_in).setVisibility(View.VISIBLE); } } This method decides whether to remove or make visible the views based on the state. We will call it inside the important state-changing methods: onLayoutCompleted: the first time we open the game to initialize the UI. onSignInSucceeded: when the user successfully signs in to GPGS. onSignInFailed: this can be triggered when we auto sign in and there is no connection. It is important to handle it. onActivityResult: when we come back from the Play Games UI, in case the user has logged out. But nothing is as easy as it looks. In fact, when the user signs out and does not exit the game, GoogleApiClient keeps the connection open. Therefore the value of isSignedIn from GameHelper still returns true. This is the edge case we have been talking about all through the article. As a result of this edge case, there is an inconsistency in the UI that shows the achievements and leaderboards buttons when it should show the login one. When the user logs out from Play Games, GoogleApiClient keeps the connection open. This can lead to confusion. Unfortunately, this has been marked as work as expected by Google. The reason is that the connection is still active and it is our responsibility to parse the result in the onActivityResult method to determine the new state. But this is not very convenient. Since it is a rare case we will just go for the easiest solution, which is to wrap it in a try/catch block and make the user sign in if he or she taps on leaderboards or achievements while not logged in. This is the code we have to handle the click on the achievements button, but the one for leaderboards is equivalent: else if (v.getId() == R.id.btn_achievements) { try {    GoogleApiClient apiClient =      getYassActivity().getGameHelper().getApiClient();    Intent achievementsIntent =      Games.Achievements.getAchievementsIntent(apiClient);    startActivityForResult(achievementsIntent,      REQUEST_ACHIEVEMENTS); } catch (Exception e) {    GameHelper gameHelper = getYassActivity().getGameHelper();    gameHelper.disconnect();    gameHelper.beginUserInitiatedSignIn(); } } Basically, we have the old code to open the achievements activity, but we wrap it in a try/catch block. If an exception is raised, we disconnect the game helper and begin a new login using the beginUserInitiatedSignIn method. It is very important to disconnect the gameHelper before we try to log in again. Otherwise, the login will not work. We must disconnect from GPGS before we can log in using the method from the GameHelper. Finally, there is the case when the user clicks on the login button, which just triggers the login using the beginUserInitiatedSignIn method from the GameHelper: if (v.getId() == R.id.btn_sign_in) { getYassActivity().getGameHelper().beginUserInitiatedSignIn(); } Once you have published your game and the game services, achievements and leaderboards will not appear in the game description on Google Play straight away. It is required that "a fair amount of users" have used them. You have done nothing wrong, you just have to wait. Other features of Google Play services Google Play Game Services provides more features for game developers than achievements and leaderboards. None of them really fit the game we are building, but it is useful to know they exist just in case your game needs them. You can save yourself lots of time and effort by using them and not reinventing the wheel. The other features of Google Play Games Services are: Events and quests: these allow you to monitor game usage and progression. Also, they add the possibility of creating time-limited events with rewards for the players. Gifts: as simple as it sounds, you can send a gift to other players or request one to be sent to you. Yes, this is seen in the very mechanical Facebook games popularized a while ago. Saved games: the standard concept of a saved game. If your game has progression or can unlock content based on user actions, you may want to use this feature. Since it is saved in the cloud, saved games can be accessed across multiple devices. Turn-based and real-time multiplayer: Google Play Game Services provides an API to implement turn-based and real-time multiplayer features without you needing to write any server code. If your game is multiplayer and has an online economy, it may be worth making your own server and granting virtual currency only on the server to prevent cheating. Otherwise, it is fairly easy to crack the gifts/reward system and a single person can ruin the complete game economy. However, if there is no online game economy, the benefits of gifts and quests may be more important than the fact that someone can hack them. Let's take a look at each of these features. Events The event's APIs provides us with a way to define and collect gameplay metrics and upload them to Google Play Game Services. This is very similar to the GameEvents we are already using in our game. Events should be a subset of the game events of our game. Many of the game events we have are used internally as a signal between objects or as a synchronization mechanism. These events are not really relevant outside the engine, but others could be. Those are the events we should send to GPGS. To be able to send an event from the game to GPGS, we have to create it in the developer console first. To create an event, we have to go to the Events tab in the developer console, click on Add new event, and fill in the following fields: Name: a short name of the event. The name can be up to 100 characters. This value can be localized. Description: a longer description of the event. The description can be up to 500 characters. This value can also be localized. Icon: the icon for the event of the standard 512x512 px size. Visibility: as for achievements, this can be revealed or hidden. Format: as for leaderboards, this can be Numeric, Currency, or Time. Event type: this is used to mark events that create or spend premium currency. This can be Premium currency sink, Premium currency source, or None. While in the game, events work pretty much as incremental achievements. You can increment the event counter using the following line of code: Games.Events.increment(mGoogleApiClient, myEventId, 1); You can delete events that are in the draft state or that have been published as long as the event is not in use by a quest. You can also reset the player progress data for the testers of your events as you can do for achievements. While the events can be used as an analytics system, their real usefulness appears when they are combined with quests. Quests A quest is a challenge that asks players to complete an event a number of times during a specific time frame to receive a reward. Because a quest is linked to an event, to use quests you need to have created at least one event. You can create a quest from the quests tab in the developer console. A quest has the following fields to be filled: Name: the short name of the quest. This can be up to 100 characters and can be localized. Description: a longer description of the quest. Your quest description should let players know what they need to do to complete the quest. The description can be up to 500 characters. The first 150 characters will be visible to players on cards such as those shown in the Google Play Games app. Icon: a square icon that will be associated with the quest. Banner: a rectangular image that will be used to promote the quest. Completion Criteria: this is the configuration of the quest itself. It consists of an event and the number of times the event must occur. Schedule: the start and end date and time for the quest. GPGS uses your local time zone, but stores the values as UTC. Players will see these values appear in their local time zone. You can mark a checkbox to notify users when the quest is about to end. Reward Data: this is specific to each game. It can be a JSON object, specifying the reward. This is sent to the client when the quest is completed. Once configured in the developer console, you can do two things with the quests: Display the list of quests Process a quest completion To get the list of quests, we start an activity with an intent that is provided to us via a static method as usual: Intent questsIntent = Games.Quests.getQuestsIntent(mGoogleApiClient,    Quests.SELECT_ALL_QUESTS); startActivityForResult(questsIntent, QUESTS_INTENT); To be notified when a quest is completed, all we have to do is register a listener: Games.Quests.registerQuestUpdateListener(mGoogleApiClient, this); Once we have set the listener, the onQuestCompleted method will be called once the quest is completed. After completing the processing of the reward, the game should call claim to inform Play Game services that the player has claimed the reward. The following code snippet shows how you might override the onQuestCompleted callback: @Override public void onQuestCompleted(Quest quest) { // Claim the quest reward. Games.Quests.claim(mGoogleApiClient, quest.getQuestId(),    quest.getCurrentMilestone().getMilestoneId()); // Process the RewardData to provision a specific reward. String reward = new    String(quest.getCurrentMilestone().getCompletionRewardData(),    Charset.forName("UTF-8")); } The rewards themselves are defined by the client. As we mentioned before, this will make the game quite easy to crack and get rewards. But usually, avoiding the hassle of writing your own server is worth it. Gifts The gifts feature of GPGS allows us to send gifts to other players and to request them to send us one as well. This is intended to make the gameplay more collaborative and to improve the social aspect of the game. As for other GPGS features, we have a built-in UI provided by the library that can be used. In this case, to send and request gifts for in-game items and resources to and from friends in their Google+ circles. The request system can make use of notifications. There are two types of requests that players can send using the game gifts feature in Google Play Game Services: A wish request to ask for in-game items or some other form of assistance from their friends A gift request to send in-game items or some other form of assistance to their friends A player can specify one or more target request recipients from the default request-sending UI. A gift or wish can be consumed (accepted) or dismissed by a recipient. To see the gifts API in detail, you can visit https://developers.google.com/games/services/android/giftRequests. Again, as for quest rewards, this is done entirely by the client, which makes the game susceptible to piracy. Saved games The saved games service offers cloud game saving slots. Your game can retrieve the saved game data to allow returning players to continue a game at their last save point from any device. This service makes it possible to synchronize a player's game data across multiple devices. For example, if you have a game that runs on Android, you can use the saved games service to allow a player to start a game on their Android phone and then continue playing the game on a tablet without losing any of their progress. This service can also be used to ensure that a player's game play continues from where it was left off even if their device is lost, destroyed, or traded in for a newer model or if the game was reinstalled The saved games service does not know about the game internals, so it provides a field that is an unstructured binary blob where you can read and write the game data. A game can write an arbitrary number of saved games for a single player subjected to user quota, so there is no hard requirement to restrict players to a single save file. Saved games are done in an unstructured binary blob. The API for saved games also receives some metadata that is used by Google Play Games to populate the UI and to present useful information in the Google Play Game app (for example, last updated timestamp). Saved games has several entry points and actions, including how to deal with conflicts in the saved games. To know more about these check out the official documentation at https://developers.google.com/games/services/android/savedgames. Multiplayer games If you are going to implement multiplayer, GPGS can save you a lot of work. You may or may not use it for the final product, but it will remove the need to think about the server-side until the game concept is validated. You can use GPGS for turn-based and real-time multiplayer games. Although each one is completely different and uses a different API, there is always an initial step where the game is set up and the opponents are selected or invited. In a turn-based multiplayer game, a single shared state is passed among the players and only the player that owns the turn has permission to modify it. Players take turns asynchronously according to an order of play determined by the game. A turn is finished explicitly by the player using an API call. Then the game state is passed to the other players, together with the turn. There are many cases: selecting opponents, creating a match, leaving a match, canceling, and so on. The official documentation at https://developers.google.com/games/services/android/turnbasedMultiplayer is quite exhaustive and you should read through it if you plan to use this feature. In a real-time multiplayer there is no concept of turn. Instead, the server uses the concept of room: a virtual construct that enables network communication between multiple players in the same game session and lets players send data directly to one another, a common concept for game servers. Real-time multiplayer service is based on the concept of Room. The API of real-time multiplayer allows us to easily: Manage network connections to create and maintain a real-time multiplayer room Provide a player-selection user interface to invite players to join a room, look for random players for auto-matching, or a combination of both Store participant and room-state information on the Play Game services' servers while the game is running Send room invitations and updates to players To check the complete documentation for real-time games, please visit the official web at https://developers.google.com/games/services/android/realtimeMultiplayer. Summary We have added Google Play services to YASS, including setting up the game in the developer console and adding the required libraries to the project. Then, we defined a set of achievements and added the code to unlock them. We have used normal, incremental, and hidden achievement types to showcase the different options available. We have also configured a leaderboard and submitted the scores, both when the game is finished and when it is exited via the pause dialog. Finally, we have added links to the native UI for leaderboards and achievements to the main menu. We have also introduced the concepts of events, quests, and gifts and the features of saved games and multiplayer that Google Play Game services offers. The game is ready to publish now. Resources for Article: Further resources on this subject: SceneKit [article] Creating Games with Cocos2d-x is Easy and 100 percent Free [article] SpriteKit Framework and Physics Simulation [article]
Read more
  • 0
  • 0
  • 3837
article-image-developing-javafx-application-ios
Packt
08 Jul 2015
10 min read
Save for later

Developing a JavaFX Application for iOS

Packt
08 Jul 2015
10 min read
In this article by Mohamed Taman, authors of the book JavaFX Essentials, we will learn how to develop a JavaFX, Apple has a great market share in the mobile and PC/Laptop world, with many different devices, from mobile phones such as the iPhone to musical devices such as the iPod and tablets such as the iPad. (For more resources related to this topic, see here.) It has a rapidly growing application market, called the Apple Store, serving its community, where the number of available apps increases daily. Mobile application developers should be ready for such a market. Mobile application developers targeting both iOS and Android face many challenges. By just comparing the native development environments of these two platforms, you will find that they differ substantially. iOS development, according to Apple, is based on the Xcode IDE (https://developer.apple.com/xcode/) and its programming languages. Traditionally, it was Objetive-C and, in June 2014, Apple introduced Swift (https://developer.apple.com/swift/); on the other hand, Android development, as defined by Google, is based on the Intellij IDEA IDE and the Java programming language. Not many developers are proficient in both environments. In addition, these differences rule out any code reuse between the platforms. JavaFX 8 is filling the gap for reusable code between the platforms, as we will see in this article, by sharing the same application in both platforms. Here are some skills that you will have gained by the end of this article: Installing and configuring iOS environment tools and software Creating iOS JavaFX 8 applications Simulating and debugging JavaFX mobile applications Packaging and deploying applications on iOS mobile devices Using RoboVM to run JavaFX on iOS RoboVM is the bridge from Java to Objetive-C. Using this, it becomes easy to develop JavaFX 8 applications that are to be run on iOS-based devices, as the ultimate goal of the RoboVM project is to solve this problem without compromising on developer experience or app user experience. As we saw in the article about Android, using JavaFXPorts to generate APKs was a relatively easy task due to the fact that Android is based on Java and the Dalvik VM. On the contrary, iOS doesn't have a VM for Java, and it doesn't allow dynamic loading of native libraries. Another approach is required. The RoboVM open source project tries to close the gap for Java developers by creating a bridge between Java and Objective-C using an ahead-of-time compiler that translates Java bytecode into native ARM or x86 machine code. Features Let's go through the RoboVM features: Brings Java and other JVM languages, such as Scala, Clojure, and Groovy, to iOS-based devices Translates Java bytecode into machine code ahead of time for fast execution directly on the CPU without any overhead The main target is iOS and the ARM processor (32- and 64-bit), but there is also support for Mac OS X and Linux running on x86 CPUs (both 32- and 64-bit) Does not impose any restrictions on the Java platform features accessible to the developer, such as reflection or file I/O Supports standard JAR files that let the developer reuse the vast ecosystem of third-party Java libraries Provides access to the full native iOS APIs through a Java-to-Objective-C bridge, enabling the development of apps with truly native UIs and with full hardware access Integrates with the most popular tools such as NetBeans, Eclipse, Intellij IDEA, Maven, and Gradle App Store ready, with hundreds of apps already in the store Limitations Mainly due to the restrictions of the iOS platform, there are a few limitations when using RoboVM: Loading custom bytecode at runtime is not supported. All class files comprising the app have to be available at compile time on the developer machine. The Java Native Interface technology as used on the desktop or on servers usually loads native code from dynamic libraries, but Apple does not permit custom dynamic libraries to be shipped with an iOS app. RoboVM supports a variant of JNI based on static libraries. Another big limitation is that RoboVM is an alpha-state project under development and not yet recommended for production usage. RoboVM has full support for reflection. How it works Since February 2015 there has been an agreement between the companies behind RoboVM and JavaFXPorts, and now a single plugin called jfxmobile-plugin allows us to build applications for three platforms—desktop, Android, and iOS—from the same codebase. The JavaFXMobile plugin adds a number of tasks to your Java application that allow you to create .ipa packages that can be submitted to the Apple Store. Android mostly uses Java as the main development language, so it is easy to merge your JavaFX 8 code with it. On iOS, the situation is internally totally different—but with similar Gradle commands. The plugin will download and install the RoboVM compiler, and it will use RoboVM compiler commands to create an iOS application in build/javafxports/ios. Getting started In this section, you will learn how to install the RoboVM compiler using the JavaFXMobile plugin, and make sure the tool chain works correctly by reusing the same application, Phone Dial version 1.0. Prerequisites In order to use the RoboVM compiler to build iOS apps, the following tools are required: Gradle 2.4 or higher is required to build applications with the jfxmobile plugin. A Mac running Mac OS X 10.9 or later. Xcode 6.x from the Mac App Store (https://itunes.apple.com/us/app/xcode/id497799835?mt=12). The first time you install Xcode, and every time you update to a new version, you have to open it once to agree to the Xcode terms. Preparing a project for iOS We will reuse the project we developed before, for the Android platform, since there is no difference in code, project structure, or Gradle build script when targeting iOS. They share the same properties and features, but with different Gradle commands that serve iOS development, and a minor change in the Gradle build script for the RoboVM compiler. Therefore, we will see the power of WORA Write Once, Run Everywhere with the same application. Project structure Based on the same project structure from the Android, the project structure for our iOS app should be as shown in the following figure: The application We are going to reuse the same application from the Phone DialPad version 2.0 JavaFX 8 application: As you can see, reusing the same codebase is a very powerful and useful feature, especially when you are developing to target many mobile platforms such as iOS and Android at the same time. Interoperability with low-level iOS APIs To have the same functionality of natively calling the default iOS phone dialer from our application as we did with Android, we have to provide the native solution for iOS as the following IosPlatform implementation: import org.robovm.apple.foundation.NSURL; import org.robovm.apple.uikit.UIApplication; import packt.taman.jfx8.ch4.Platform;   public class IosPlatform implements Platform {   @Override public void callNumber(String number) {    if (!number.equals("")) {      NSURL nsURL = new NSURL("telprompt://" + number);      UIApplication.getSharedApplication().openURL(nsURL);    } } } Gradle build files We will use the Gradle build script file, but with a minor change by adding the following lines to the end of the script: jfxmobile { ios {    forceLinkClasses = [ 'packt.taman.jfx8.ch4.**.*' ] } android {    manifest = 'lib/android/AndroidManifest.xml' } } All the work involved in installing and using robovm compilers is done by the jfxmobile plugin. The purpose of those lines is to give the RoboVM compiler the location of the main application class that has to be loaded at runtime is, as it is not visible by default to the compiler. The forceLinkClasses property ensures that those classes are linked in during RoboVM compilation. Building the application After we have added the necessary configuration set to build the script for iOS, its time to build the application in order to deploy it to different iOS target devices. To do so, we have to run the following command: $ gradle build We should have the following output: BUILD SUCCESSFUL   Total time: 44.74 secs We have built our application successfully; next, we need to generate the .ipa and, in the case of production, you have to test it by deploying it to as many iOS versions as you can. Generating the iOS .ipa package file In order to generate the final .ipa iOS package for our JavaFX 8 application, which is necessary for the final distribution to any device or the AppStore, you have to run the following gradle command: gradle ios This will generate the .ipa file in the directory build/javafxports/ios. Deploying the application During development, we need to check our application GUI and final application prototype on iOS simulators and measure the application performance and functionality on different devices. These procedures are very useful, especially for testers. Let's see how it is a very easy task to run our application on either simulators or on real devices. Deploying to a simulator On a simulator, you can simply run the following command to check if your application is running: $ gradle launchIPhoneSimulator This command will package and launch the application in an iPhone simulator as shown in the following screenshot: DialPad2 JavaFX 8 application running on the iOS 8.3/iPhone 4s simulator This command will launch the application in an iPad simulator: $ gradle launchIPadSimulator Deploying to an Apple device In order to package a JavaFX 8 application and deploy it to an Apple device, simply run the following command: $ gradle launchIOSDevice This command will launch the JavaFX 8 application in the device that is connected to your desktop/laptop. Then, once the application is launched on your device, type in any number and then tap Call. The iPhone will ask for permission to dial using the default mobile dialer; tap on Ok. The default mobile dialer will be launched and will the number as shown in the following figure: To be able to test and deploy your apps on your devices, you will need an active subscription with the Apple Developer Program. Visit the Apple Developer Portal, https://developer.apple.com/register/index.action, to sign up. You will also need to provision your device for development. You can find information on device provisioning in the Apple Developer Portal, or follow this guide: http://www.bignerdranch.com/we-teach/how-to-prepare/ios-device-provisioning/. Summary This article gave us a very good understanding of how JavaFX-based applications can be developed and customized using RoboVM for iOS to make it possible to run your applications on Apple platforms. You learned about RoboVM features and limitations, and how it works; you also gained skills that you can use for developing. You then learned how to install the required software and tools for iOS development and how to enable Xcode along with the RoboVM compiler, to package and install the Phone Dial JavaFX-8-based application on OS simulators. Finally, we provided tips on how to run and deploy your application on real devices. Resources for Article: Further resources on this subject: Function passing [article] Creating Java EE Applications [article] Contexts and Dependency Injection in NetBeans [article]
Read more
  • 0
  • 0
  • 10071

article-image-deployment-preparations
Packt
08 Jul 2015
23 min read
Save for later

Deployment Preparations

Packt
08 Jul 2015
23 min read
In this article by Jurie-Jan Botha, author of the book Grunt Cookbook, has covered the following recipes: Minifying HTML Minifying CSS Optimizing images Linting JavaScript code Uglifying JavaScript code Setting up RequireJS (For more resources related to this topic, see here.) Once our web application is built and its stability ensured, we can start preparing it for deployment to its intended market. This will mainly involve the optimization of the assets that make up the application. Optimization in this context mostly refers to compression of one kind or another, some of which might lead to performance increases too. The focus on compression is primarily due to the fact that the smaller the asset, the faster it can be transferred from where it is hosted to a user's web browser. This leads to a much better user experience, and can sometimes be essential to the functioning of an application. Minifying HTML In this recipe, we make use of the contrib-htmlmin (0.3.0) plugin to decrease the size of some HTML documents by minifying them. Getting ready In this example, we'll work with the a basic project structure. How to do it... The following steps take us through creating a sample HTML document and configuring a task that minifies it: We'll start by installing the package that contains the contrib-htmlmin plugin. Next, we'll create a simple HTML document called index.html in the src directory, which we'd like to minify, and add the following content in it: <html> <head>    <title>Test Page</title> </head> <body>    <!-- This is a comment! -->    <h1>This is a test page.</h1> </body> </html> Now, we'll add the following htmlmin task to our configuration, which indicates that we'd like to have the white space and comments removed from the src/index.html file, and that we'd like the result to be saved in the dist/index.html file: htmlmin: { dist: {    src: 'src/index.html',    dest: 'dist/index.html',    options: {      removeComments: true,      collapseWhitespace: true    } } } The removeComments and collapseWhitespace options are used as examples here, as using the default htmlmin task will have no effect. Other minification options can be found at the following URL: https://github.com/kangax/html-minifier#options-quick-reference We can now run the task using the grunt htmlmin command, which should produce output similar to the following: Running "htmlmin:dist" (htmlmin) task Minified dist/index.html 147 B ? 92 B If we now take a look at the dist/index.html file, we will see that all white space and comments have been removed: <html> <head>    <title>Test Page</title> </head> <body>    <h1>This is a test page.</h1> </body> </html> Minifying CSS In this recipe, we'll make use of the contrib-cssmin (0.10.0) plugin to decrease the size of some CSS documents by minifying them. Getting ready In this example, we'll work with a basic project structure. How to do it... The following steps take us through creating a sample CSS document and configuring a task that minifies it. We'll start by installing the package that contains the contrib-cssmin plugin. Then, we'll create a simple CSS document called style.css in the src directory, which we'd like to minify, and provide it with the following contents: body { /* Average body style */ background-color: #ffffff; color: #000000; /*! Black (Special) */ } Now, we'll add the following cssmin task to our configuration, which indicates that we'd like to have the src/style.css file compressed, and have the result saved to the dist/style.min.css file: cssmin: { dist: {    src: 'src/style.css',    dest: 'dist/style.min.css' } } We can now run the task using the grunt cssmin command, which should produce the following output: Running "cssmin:dist" (cssmin) taskFile dist/style.css created: 55 B ? 38 B If we take a look at the dist/style.min.css file that was produced, we will see that it has the compressed contents of the original src/style.css file: body{background-color:#fff;color:#000;/*! Black (Special) */} There's more... The cssmin task provides us with several useful options that can be used in conjunction with its basic compression feature. We'll look at prefixing a banner, removing special comments, and reporting gzipped results. Prefixing a banner In the case that we'd like to automatically include some information about the compressed result in the resulting CSS file, we can do so in a banner. A banner can be prepended to the result by supplying the desired banner content to the banner option, as shown in the following example: cssmin: { dist: {    src: 'src/style.css',    dest: 'dist/style.min.css',    options: {      banner: '/* Minified version of style.css */'    } } } Removing special comments Comments that should not be removed by the minification process are called special comments and can be indicated using the "/*! comment */" markers. By default, the cssmin task will leave all special comments untouched, but we can alter this behavior by making use of the keepSpecialComments option. The keepSpecialComments option can be set to either the *, 1, or 0 value. The * value is the default and indicates that all special comments should be kept, 1 indicates that only the first comment that is found should be kept, and 0 indicates that none of them should be kept. The following configuration will ensure that all comments are removed from our minified result: cssmin: { dist: {    src: 'src/style.css',    dest: 'dist/style.min.css',    options: {      keepSpecialComments: 0    } } } Reporting on gzipped results Reporting is useful to see exactly how well the cssmin task has compressed our CSS files. By default, the size of the targeted file and minified result will be displayed, but if we'd also like to see the gzipped size of the result, we can set the report option to gzip, as shown in the following example: cssmin: { dist: {    src: 'src/main.css',    dest: 'dist/main.css',    options: {      report: 'gzip'    } } } Optimizing images In this recipe, we'll make use of the contrib-imagemin (0.9.4) plugin to decrease the size of images by compressing them as much as possible without compromising on their quality. This plugin also provides a plugin framework of its own, which is discussed at the end of this recipe. Getting ready In this example, we'll work with the basic project structure. How to do it... The following steps take us through configuring a task that will compress an image for our project. We'll start by installing the package that contains the contrib-imagemin plugin. Next, we can ensure that we have an image called image.jpg in the src directory on which we'd like to perform optimizations. Now, we'll add the following imagemin task to our configuration and indicate that we'd like to have the src/image.jpg file optimized, and have the result saved to the dist/image.jpg file: imagemin: { dist: {    src: 'src/image.jpg',    dest: 'dist/image.jpg' } } We can then run the task using the grunt imagemin command, which should produce the following output: Running "imagemin:dist" (imagemin) task Minified 1 image (saved 13.36 kB) If we now take a look at the dist/image.jpg file, we will see that its size has decreased without any impact on the quality. There's more... The imagemin task provides us with several options that allow us to tweak its optimization features. We'll look at how to adjust the PNG compression level, disable the progressive JPEG generation, disable the interlaced GIF generation, specify SVGO plugins to be used, and use the imagemin plugin framework. Adjusting the PNG compression level The compression of a PNG image can be increased by running the compression algorithm on it multiple times. By default, the compression algorithm is run 16 times. This number can be changed by providing a number from 0 to 7 to the optimizationLevel option. The 0 value means that the compression is effectively disabled and 7 indicates that the algorithm should run 240 times. In the following configuration we set the compression level to its maximum: imagemin: { dist: {    src: 'src/image.png',    dest: 'dist/image.png',    options: {      optimizationLevel: 7    } } } Disabling the progressive JPEG generation Progressive JPEGs are compressed in multiple passes, which allows a low-quality version of them to quickly become visible and increase in quality as the rest of the image is received. This is especially helpful when displaying images over a slower connection. By default, the imagemin plugin will generate JPEG images in the progressive format, but this behavior can be disabled by setting the progressive option to false, as shown in the following example: imagemin: { dist: {    src: 'src/image.jpg',    dest: 'dist/image.jpg',    options: {      progressive: false    } } } Disabling the interlaced GIF generation An interlaced GIF is the equivalent of a progressive JPEG in that it allows the contained image to be displayed at a lower resolution before it has been fully downloaded, and increases in quality as the rest of the image is received. By default, the imagemin plugin will generate GIF images in the interlaced format, but this behavior can be disabled by setting the interlaced option to false, as shown in the following example: imagemin: { dist: {    src: 'src/image.gif',    dest: 'dist/image.gif',    options: {      interlaced: false    } } } Specifying SVGO plugins to be used When optimizing SVG images, the SVGO library is used by default. This allows us to specify the use of various plugins provided by the SVGO library that each performs a specific function on the targeted files. Refer to the following URL for more detailed instructions on how to use the svgo plugins options and the SVGO library: https://github.com/sindresorhus/grunt-svgmin#available-optionsplugins Most of the plugins in the library are enabled by default, but if we'd like to specifically indicate which of these should be used, we can do so using the svgoPlugins option. Here, we can provide an array of objects, where each contain a property with the name of the plugin to be affected, followed by a true or false value to indicate whether it should be activated. The following configuration disables three of the default plugins: imagemin: { dist: {    src: 'src/image.svg',    dest: 'dist/image.svg',    options: {      svgoPlugins: [        {removeViewBox:false},        {removeUselessStrokeAndFill:false},        {removeEmptyAttrs:false}      ]    } } } Using the 'imagemin' plugin framework In order to provide support for the various image optimization projects, the imagemin plugin has a plugin framework of its own that allows developers to easily create an extension that makes use of the tool they require. You can get a list of the available plugin modules for the imagemin plugin's framework at the following URL: https://www.npmjs.com/browse/keyword/imageminplugin The following steps will take us through installing and making use of the mozjpeg plugin to compress an image in our project. These steps start where the main recipe takes off. We'll start by installing the imagemin-mozjpeg package using the npm install imagemin-mozjpeg command, which should produce the following output: imagemin-mozjpeg@4.0.0 node_modules/imagemin-mozjpeg With the package installed, we need to import it into our configuration file, so that we can make use of it in our task configuration. We do this by adding the following line at the top of our Gruntfile.js file: var mozjpeg = require('imagemin-mozjpeg'); With the plugin installed and imported, we can now change the configuration of our imagemin task by adding the use option and providing it with the initialized plugin: imagemin: { dist: {    src: 'src/image.jpg',    dest: 'dist/image.jpg',    options: {      use: [mozjpeg()]    } } } Finally, we can test our setup by running the task using the grunt imagemin command. This should produce an output similar to the following: Running "imagemin:dist" (imagemin) task Minified 1 image (saved 9.88 kB) Linting JavaScript code In this recipe, we'll make use of the contrib-jshint (0.11.1) plugin to detect errors and potential problems in our JavaScript code. It is also commonly used to enforce code conventions within a team or project. As can be derived from its name, it's basically a Grunt adaptation for the JSHint tool. Getting ready In this example, we'll work with the basic project structure. How to do it... The following steps take us through creating a sample JavaScript file and configuring a task that will scan and analyze it using the JSHint tool. We'll start by installing the package that contains the contrib-jshint plugin. Next, we'll create a sample JavaScript file called main.js in the src directory, and add the following content in it: sample = 'abc'; console.log(sample); With our sample file ready, we can now add the following jshint task to our configuration. We'll configure this task to target the sample file and also add a basic option that we require for this example: jshint: { main: {    options: {      undef: true    },    src: ['src/main.js'] } } The undef option is a standard JSHint option used specifically for this example and is not required for this plugin to function. Specifying this option indicates that we'd like to have errors raised for variables that are used without being explicitly defined. We can now run the task using the grunt jshint command, which should produce output informing us of the problems found in our sample file: Running "jshint:main" (jshint) task      src/main.js      1 |sample = 'abc';          ^ 'sample' is not defined.      2 |console.log(sample);          ^ 'console' is not defined.      2 |console.log(sample);                      ^ 'sample' is not defined.   >> 3 errors in 1 file There's more... The jshint task provides us with several options that allow us to change its general behavior, in addition to how it analyzes the targeted code. We'll look at how to specify standard JSHint options, specify globally defined variables, send reported output to a file, and prevent task failure on JSHint errors. Specifying standard JSHint options The contrib-jshint plugin provides a simple way to pass all the standard JSHint options from the task's options object to the underlying JSHint tool. A list of all the options provided by the JSHint tool can be found at the following URL: http://jshint.com/docs/options/ The following example adds the curly option to the task we created in our main recipe to enforce the use of curly braces wherever they are appropriate: jshint: { main: {    options: {      undef: true,      curly: true    },    src: ['src/main.js'] } } Specifying globally defined variables Making use of globally defined variables is quite common when working with JavaScript, which is where the globals option comes in handy. Using this option, we can define a set of global values that we'll use in the targeted code, so that errors aren't raised when JSHint encounters them. In the following example, we indicate that the console variable should be treated as a global, and not raise errors when encountered: jshint: { main: {    options: {      undef: true,      globals: {        console: true      }    },    src: ['src/main.js'] } } Sending reported output to a file If we'd like to store the resulting output from our JSHint analysis, we can do so by specifying a path to a file that should receive it using the reporterOutput option, as shown in the following example: jshint: { main: {    options: {      undef: true,      reporterOutput: 'report.dat'    },    src: ['src/main.js'] } } Preventing task failure on JSHint errors The default behavior for the jshint task is to exit the running Grunt process once a JSHint error is encountered in any of the targeted files. This behavior becomes especially undesirable if you'd like to keep watching files for changes, even when an error has been raised. In the following example, we indicate that we'd like to keep the process running when errors are encountered by giving the force option a true value: jshint: { main: {    options: {      undef: true,      force: true    },    src: ['src/main.js'] } } Uglifying JavaScript Code In this recipe, we'll make use of the contrib-uglify (0.8.0) plugin to compress and mangle some files containing JavaScript code. For the most part, the process of uglifying just removes all the unnecessary characters and shortens variable names in a source code file. This has the potential to dramatically reduce the size of the file, slightly increase performance, and make the inner workings of your publicly available code a little more obscure. Getting ready In this example, we'll work with the basic project structure. How to do it... The following steps take us through creating a sample JavaScript file and configuring a task that will uglify it. We'll start by installing the package that contains the contrib-uglify plugin. Then, we can create a sample JavaScript file called main.js in the src directory, which we'd like to uglify, and provide it with the following contents: var main = function () { var one = 'Hello' + ' '; var two = 'World';   var result = one + two;   console.log(result); }; With our sample file ready, we can now add the following uglify task to our configuration, indicating the sample file as the target and providing a destination output file: uglify: { main: {    src: 'src/main.js',    dest: 'dist/main.js' } } We can now run the task using the grunt uglify command, which should produce output similar to the following: Running "uglify:main" (uglify) task >> 1 file created. If we now take a look at the resulting dist/main.js file, we should see that it contains the uglified contents of the original src/main.js file. There's more... The uglify task provides us with several options that allow us to change its general behavior and see how it uglifies the targeted code. We'll look at specifying standard UglifyJS options, generating source maps, and wrapping generated code in an enclosure. Specifying standard UglifyJS options The underlying UglifyJS tool can provide a set of options for each of its separate functional parts. These parts are the mangler, compressor, and beautifier. The contrib-plugin allows passing options to each of these parts using the mangle, compress, and beautify options. The available options for each of the mangler, compressor, and beautifier parts can be found at each of following URLs (listed in the order mentioned): https://github.com/mishoo/UglifyJS2#mangler-options https://github.com/mishoo/UglifyJS2#compressor-options https://github.com/mishoo/UglifyJS2#beautifier-options The following example alters the configuration of the main recipe to provide a single option to each of these parts: uglify: { main: {    src: 'src/main.js',    dest: 'dist/main.js',    options: {      mangle: {        toplevel: true      },      compress: {        evaluate: false      },      beautify: {        semicolons: false      }    } } } Generating source maps As code gets mangled and compressed, it becomes effectively unreadable to humans, and therefore, nearly impossible to debug. For this reason, we are provided with the option of generating a source map when uglifying our code. The following example makes use of the sourceMap option to indicate that we'd like to have a source map generated along with our uglified code: uglify: { main: {    src: 'src/main.js',    dest: 'dist/main.js',    options: {      sourceMap: true    } } } Running the altered task will now, in addition to the dist/main.js file with our uglified source, generate a source map file called main.js.map in the same directory as the uglified file. Wrapping generated code in an enclosure When building your own JavaScript code modules, it's usually a good idea to have them wrapped in a wrapper function to ensure that you don't pollute the global scope with variables that you won't be using outside of the module itself. For this purpose, we can use the wrap option to indicate that we'd like to have the resulting uglified code wrapped in a wrapper function, as shown in the following example: uglify: { main: {    src: 'src/main.js',    dest: 'dist/main.js',    options: {      wrap: true    } } } If we now take a look at the result dist/main.js file, we should see that all the uglified contents of the original file are now contained within a wrapper function. Setting up RequireJS In this recipe, we'll make use of the contrib-requirejs (0.4.4) plugin to package the modularized source code of our web application into a single file. For the most part, this plugin just provides a wrapper for the RequireJS tool. RequireJS provides a framework to modularize JavaScript source code and consume those modules in an orderly fashion. It also allows packaging an entire application into one file and importing only the modules that are required while keeping the module structure intact. Getting ready In this example, we'll work with the basic project structure. How to do it... The following steps take us through creating some files for a sample application and setting up a task that bundles them into one file. We'll start by installing the package that contains the contrib-requirejs plugin. First, we'll need a file that will contain our RequireJS configuration. Let's create a file called config.js in the src directory and add the following content in it: require.config({ baseUrl: 'app' }); Secondly, we'll create a sample module that we'd like to use in our application. Let's create a file called sample.js in the src/app directory and add the following content in it: define(function (require) { return function () {    console.log('Sample Module'); } }); Lastly, we'll need a file that will contain the main entry point for our application, and also makes use of our sample module. Let's create a file called main.js in the src/app directory and add the following content in it: require(['sample'], function (sample) { sample(); }); Now that we've got all the necessary files required for our sample application, we can setup a requirejs task that will bundle it all into one file: requirejs: { app: {    options: {      mainConfigFile: 'src/config.js',      name: 'main',      out: 'www/js/app.js'    } } } The mainConfigFile option points out the configuration file that will determine the behavior of RequireJS. The name option indicates the name of the module that contains the application entry point. In the case of this example, our application entry point is contained in the app/main.js file, and app is the base directory of our application in the src/config.js file. This translates the app/main.js filename into the main module name. The out option is used to indicate the file that should receive the result of the bundled application. We can now run the task using the grunt requirejs command, which should produce output similar to the following: Running "requirejs:app" (requirejs) task We should now have a file named app.js in the www/js directory that contains our entire sample application. There's more... The requirejs task provides us with all the underlying options provided by the RequireJS tool. We'll look at how to use these exposed options and generate a source map. Using RequireJS optimizer options The RequireJS optimizer is quite an intricate tool, and therefore, provides a large number of options to tweak its behavior. The contrib-requirejs plugin allows us to easily set any of these options by just specifying them as options of the plugin itself. A list of all the available configuration options for the RequireJS build system can be found in the example configuration file at the following URL: https://github.com/jrburke/r.js/blob/master/build/example.build.js The following example indicates that the UglifyJS2 optimizer should be used instead of the default UglifyJS optimizer by using the optimize option: requirejs: { app: {    options: {      mainConfigFile: 'src/config.js',      name: 'main',      out: 'www/js/app.js',      optimize: 'uglify2'    } } } Generating a source map When the source code is bundled into one file, it becomes somewhat harder to debug, as you now have to trawl through miles of code to get to the point you're actually interested in. A source map can help us with this issue by relating the resulting bundled file to the modularized structure it is derived from. Simply put, with a source map, our debugger will display the separate files we had before, even though we're actually using the bundled file. The following example makes use of the generateSourceMap option to indicate that we'd like to generate a source map along with the resulting file: requirejs: { app: {    options: {      mainConfigFile: 'src/config.js',      name: 'main',      out: 'www/js/app.js',      optimize: 'uglify2',      preserveLicenseComments: false,      generateSourceMaps: true    } } } In order to use the generateSourceMap option, we have to indicate that UglifyJS2 is to be used for optimization, by setting the optimize option to uglify2, and that license comments should not be preserved, by setting the preserveLicenseComments option to false. Summary This article covers the optimization of images, minifying of CSS, ensuring the quality of our JavaScript code, compressing it, and packaging it all together into one source file. Resources for Article: Further resources on this subject: Grunt in Action [article] So, what is Node.js? [article] Exploring streams [article]
Read more
  • 0
  • 0
  • 1543
