Overview

In this chapter, you will learn how to differentiate between traditional data warehousing and modern AI-focused systems. You'll be able to describe the typical layers in an architecture that is suited for building AI systems, such as a data lake, and list the requirements for creating the storage layers for an AI system. Later, you will learn how to define the specific requirements per storage layer for a use case and identify the infrastructure as well as the software systems based on the requirements. By the end of this chapter, you'll be able to identify the requirements for data storage solutions for AI systems based on the data layers.

In the previous chapter, we covered the fundamentals of data storage. In this chapter, we'll dive a little deeper into the architecture of Artificial Intelligence (AI) solutions, starting with the requirements that define them. This chapter will be a mixture of theoretical content and hands-on exercises, with real-life examples where AI is actively used.

Let's say you are a solution architect involved in the design of a new data lake. There are a lot of technology choices to be made that would have an impact on the people involved and on the long-term operations of the organization. It is great to have a set of requirements at the start of the project that each decision could be based on. Storing data essentially means writing data to disk or memory so that it is safe, secure, findable, and retrievable. There are many ways to store data: on-premise, in the cloud, on disk, in a database, in memory, and so on. Each way fulfills a set of requirements to a greater...

It's crucial to keep track of the requirements of your solution in all phases of the project. Since most projects follow the agile methodology, it's not an option to just define the requirements at the start of the project and then "get to work."

The agile methodology requires team members to continuously reflect on the initial plan and requirements provided in the Deming cycle, as shown in the following figure:

Figure 2.1: The Deming cycle

A list of requirements can be divided into functional and non-functional requirements. The functional requirements contain the user stories that explain how to interact with the system; these are not in the scope of this book since they are less technical and more concerned with UX design and customer journeys. The non-functional (or technical) requirements contain descriptions of the required workings of the system. The non-functional architecture requirements for an AI storage...

An AI system consists of multiple data storage layers that are connected with Extract, Transform, and Load (ETL) or Extract, Load, and Transform (ELT) pipelines. Each separate storage solution has its own requirements, depending on the type of data that is stored and the usage pattern. The following figure shows this concept:

Figure 2.3: Conceptual overview of the data layers in a typical AI solution

From a high-level viewpoint, the backend (and thus, the storage systems) of an AI solution is split up into three parts or layers:

• Raw data layer: Contains copies of files from source systems. Also known as the staging area.
• Historical data layer: The core of a data-driven system, containing an overview of data from multiple source systems that have been gathered over time. By stacking the data rather than replacing or updating old values, history is preserved and time travel (being able to make queries over a data state in the past) is...

The raw data layer contains the one-to-one copies of files from the source systems. The copies are stored to make sure that any data that arrives is preserved in its original form. After storing the raw data, some checks can be done to make sure that the data can be processed by the rest of the ETL pipeline, such as a checksum.

Security

We'll look at data security first. All modern software and data systems must be secure. By security requirements, we mean all aspects related to ensuring that the data in a system cannot be viewed or deleted by unauthorized people or systems. It entails identity and access management, role-based access, and data encryption.

Basic Protection

In any data project, security is a key requirement. The basic level of data protection is to require a username-password combination for anyone who can access the data: customers, developers, analysts, and so on. In all cases, the passwords should be evaluated against a strong password policy...

The historical data layer contains data stores that hold all data from a certain point in the past (for example, the start of the company) up until now. In most cases, this data is considered to be important to run a business, and in some cases, even vital for its existence. For example, the historical data layer of a newspaper agency contains sources, reference material, interviews, media footage, and so on, all of which were used to publish news articles. Data is stored in blobs, file shares, and relational tables, often with primary and foreign keys (enforced by the infrastructure or in software). The data can be modeled to a standard such as a data vault to preserve historical information. This data layer is responsible for keeping the truth, which means it is highly regulated and governed. Any data that is inserted into one of the tables in this layer has gone through several checks, and metadata is stored next to the actual data to keep track of the history and...

The requirements for a streaming data layer are different from a batch-oriented data lake. Firstly, the time dimension plays a crucial role. Any event data that enters the message bus as a stream must be timestamped. Secondly, performance and latency are more important since it must be certain that data can be processed in due time. Thirdly, the way that analytics and machine learning are applied differs; while the data is being streamed in, the system must analyze it in near-real-time. In general, streaming data software relies more on computing power than storage space; processing speed, low latency, and high throughput are key. Nevertheless, the storage requirements that are in place for a streaming data system are worth considering and are a bit different from "static" batch-driven applications.

Security

A typical streaming datastore is separated into topics. A topic is named as such in the popular streaming data store Kafka. These can be considered...

The responsibility of the analytics layer of an AI system is to make data fast and available for machine learning models, queries, and so on. This can be achieved by caching data efficiently or by virtualizing views and queries where needed to materialize these views.

Performance

The data needs to be quickly available for ad hoc queries, reports, machine learning models, and so on. Therefore, the data schema that is chosen should reflect a "schema-on-read" pattern rather than a "schema-on-write" one. When caching data, it can be very efficient to store the data in a columnar NoSQL database for fast access. This would mean the duplication of data in many cases, but that's all right since the analytics layer is not responsible for maintaining "one version of the truth." We call these caches data marts. They are usually specific for one goal, for example, retrieving the sales data of the last month.

In modern data lakes, the entire...

Data that is used for developing and training machine learning models is temporarily stored in a model development environment. The data store itself can be physical (a file share or database) or in memory. The data is a copy of one or more sources in the other data layers. Once the data has been used, it should be removed to free up space and to prevent security breaches. When developing reinforcement learning systems, it's necessary to merge this environment with the production environment; for example, by training the models directly on the data in the historical data layer.

In our example of PacktBank, the model development environment of the new data lake is used by data scientists to build and train new risk models. Whereas the old way of forecasting whether clients could afford a loan was purely based on rules, the new management wants to become more data-driven and rely on algorithms that have been trained on historical data. The historical...

In this chapter, we discussed the non-functional requirements for data storage solutions. It has become clear that a data lake, which is an evolution of a data warehouse, consists of multiple layers that have their own requirements and thus technology. We have discussed the key requirements for a raw data store where primarily flat files need to be stored in a robust way, for a historical database where temporal information is saved, and for analytics data stores where fast querying is necessary. Furthermore, we have explained the requirements for a streaming data engine and for a model development environment. In all cases, requirements management is an ongoing process in an AI project. Rather than setting all the requirements in stone at the start of the project, architects and developers should be agile, revisiting and revising the requirements after every iteration.

In the next chapter, we will connect the layers of the architecture we have explored in this chapter by...
